Norcold N1095 Series User manual

WARNING: Improper installation, adjustment, alteration, service or maintenance
can cause personal injury or property damage. Refer to this manual.
For assistance or additional information, contact a qualified installer,
service agency, or the gas supplier.
FOR YOUR SAFETY
Do not store or use gasoline or other flammable vapors and liquid in
the vicinity of this or any other appliance.
FOR YOUR SAFETY
If you smell gas:
1. Open windows
2. Don’t touch electrical switches.
3. Extinguish any open flame.
4. Immediately call your gas supplier.
For N109X and N109XXX models: 10 cu.ft., 2-way R.V. refrigerators.
For N109XIM and N109XIMXX models: 10 cu.ft., 2-way R.V. refrigerators with ice maker.
The letter “X”, in the model numbers above, stands for a letter or a numeral which means a
refrigerator option.
NORCOLD, Inc.
P.O. Box 4248
Sidney, OH 45365-4248
Part No. 628934A (2-06)
English
French
Owner’s Manual
Norcold Cutomer Service Dept.
Telephone: [phone]
Fax: [phone]
Web Site: www.norcold.com

Owner’s Manual 2
Table of Contents
Gas Absorption 3 Year Limited Warranty Policy......................... 2
Gas Absorption Warranty Information ........................................ 3
Gas Absorption Warranty Questions.......................................... 3
Safety Awareness ....................................................................... 4
Safety Instructions ...................................................................... 4
About Your Refrigerator .............................................................. 4
Storage volume ................................................................... 4
Leveling ............................................................................... 4
Operation during travel........................................................ 4
Food compartment.............................................................. 4
Freezer compartment.......................................................... 5
Crisper(s) ............................................................................ 5
Door bins............................................................................. 5
Door bin slide...................................................................... 5
Adjustable shelves.............................................................. 5
Door handles ...................................................................... 5
Interior light.......................................................................... 6
Door alarm .......................................................................... 6
Moisture reduction heater ................................................... 6
Temperature control system
Backup operating system ................................................... 6
Operating the Refrigerator Controls .......................................... 7
Control panel....................................................................... 7
Automatic mode operation.................................................. 7
Removing air from the propane gas supply lines .............. 7
Set the controls to automatic mode operation ................... 8
Set the controls to manual mode operation ....................... 8
Cooling unit sensing........................................................... 8
Effects of HIgh Altitude on Propane Gas Operation................... 9
Ice Maker (N109XIM and N109XIMXX models) .......................... 9
Ice maker operation ............................................................ 9
Refrigerator Care Checklist ....................................................... 9
Defrosting ................................................................................. 10
Cleaning ................................................................................... 10
Interior ............................................................................... 10
Drip tray ............................................................................. 10
Metal doors........................................................................ 10
Glass shelf .........................................................................11
Door Sealing .............................................................................11
Refrigerator Maintenance Checklist .........................................11
Refrigerator Storage ..................................................................11
Ice Maker Storage (N109XIM and N109XIMXX models) ...........11
Refrigerator Maintenance......................................................... 12
Gas flame appearance ..................................................... 12
Remove and clean the burner orifice ............................... 12
Remove the Refrigerator .......................................................... 13
Reinstall the Refrigerator ......................................................... 13
Replacement Parts .................................................................. 14
Wiring Diagram and Pictorial ................................................... 14
Ice Maker Wiring Pictorial and Diagram (N109XIM and ...............
N109XIMXX models) ......................................................... 14
Fault Codes .............................................................................. 15
Norcold • P.O. Box 4248 • Sidney, OH • USA • 45365-4248
Provided it is properly installed, properly maintained and placed
under normal service and use, Norcold, Inc. warrants its
refrigeration equipment to be free from defects in material and
workmanship for three years with respect to the equipment’s
component parts, and for two years with respect to the labor to
repair or replace such parts, commencing from the original date
of purchase.
Limitations of warranty
1. This Warranty applies only to Norcold gas absorption
refrigerator operating equipment. This Warranty does not
extend to glassware, electric light bulbs, and replaceable
fuses.
2. This warranty does not apply to parts and assemblies that
have been subjected to misuse, improper installation,
improper or abnormal service, transit damage, recharging of
the cooling system, accident, fire, improper repair, tampering
or abuse.
3. Irrespective of the nature of the warranty protection offered or
claimed, the period of warranty shall in no case extend
beyond three years for component parts and two years for the
labor to repair or replace such parts, commencing from the
original date of purchase of the new equipment.
4. In order to obtain the remedy of repair and replacement, the
refrigerator must be brought to any Norcold Service Center for
warranty service. The end consumer is responsible for all
expenses resulting from any remote service call if the
refrigerator cannot be brought into the Norcold service center.
5. It is the responsibility of the end consumer to have mainte-
nance performed upon the warranted equipment one time
during the second year or before the beginning of the third
year after original purchase. Such maintenance is required to
maintain this warranty in effect and failure to perform such
maintenance will void the remainder of the warranty. Re-
quired maintenance during the second year or before the
third year after purchase is cleaning and checking of the
following: Burner, Flue, Spiral Baffle, Roof Cap Screen, and
Control Board Sequence.
LIMITATION OFREMEDY
1. THERESPONSIBILITYOFNORCOLD UNDER THISORANY
WARRANTYIS LIMITED TOTHEREPAIR OR REPLACEMENT
(ATNORCOLD’SOPTION)OF THEDEFECTIVE PARTOR
ASSEMBLY.
NORCOLD - GasAbsorption 3 Year Limited
Warranty Policy

Owner’s Manual 3
GasAbsorption Warranty Information
2. INNOEVENTAND UNDERNOCIRCUMSTANCES SHALL
NORCOLDBERESPONSIBLEUNDERTHISLIMITED WAR-
RANTYFORANYOTHERCHARGEWHATSOEVER,INCLUDING
BUTNOTLIMITEDTOCHARGES ORCLAIMSFORLABOR,
LOSTBUSINESS, LOSTTIME,LOST PROFITS, LOSSOFUSE,
ORANYKINDOFINCIDENTALORCONSEQUENTIALDAM-
AGES,HOWEVERDENOMINATEDORDESCRIBED. THE
REMEDYUNDERTHISWARRANTYISLIMITEDTOREPLACE-
MENTORREPAIR.
3. SOMESTATESDO NOTALLOW THE EXCLUSIONOR
LIMITATIONOFINCIDENTALORCONSEQUENTIALDAMAGES,
SOTHEABOVE EXCLUSIONMAYNOTAPPLYTOYOU.
DISCLAIMEROFOTHERWARRANTIES
THISWARRANTYIS EXPRESSLYINLIEUOFALLOTHER
WARRANTIESEITHER EXPRESSEDORIMPLIED. ALLOTHER
WARRANTIES,EXPRESSEDORIMPLIED,INCLUDINGANY
WARRANTYOFMERCHANTABILITYORFITNESSFORAPAR-
TICULARPURPOSE,AREHEREBYDISCLAIMEDANDEX-
CLUDED.
Legal rights
This warranty gives you specific legal rights, and you may have
other legal rights, which vary from state to state.
Your refrigerator is made to provide the ultimate in cooling
satisfaction and will serve you reliably in the years to come.
Norcold refrigerators are the only RV refrigerators made in the
United States and offer a standard limited three-year warranty.
Norcold also offers an additional warranty coverage plan which
extends the standard limited three-year warranty. To activate
your three-year limited warranty and to receive an invitation to
participate in the extended warranty plan, complete and mail the
warranty registration supplied.
Help us to help you.
Write the model number and serial number below for future
reference. These numbers are on the serial plate in the
refrigerator. The serial plate is located in the fresh food
compartment on the top right hand side. Use these numbers
when receiving service or in any correspondence concerning
your refrigerator.
Model number ___________ Serial number ___________
If a problem occurs with your refrigerator, contact any of the
service centers throughout the United States and Canada. To
find an authorized Norcold Service Center near you, please
telephone the Norcold Customer Support Dept. at 800-543-
1219 (option-1) or visit our web site at www.norcold.com.
Norcold is committed to providing products that are in harmony
with the environment. Your Norcold refrigerator meets all
environmental safety standards.
About your warranty
Thiswarranty coveragebegins onthe originaldate ofpurchase bythe
consumerpurchaser and isthe onlywarranty forthe Norcold refrigera-
tor. In no case will the Limited Warranty extend beyond two (2) years
for labor and three (3) years for parts and freight. Norcold reserves
theright tochange design orspecifications ofa refrigeratorwithout
obligationto modifypreviouslyproduced refrigerators. Thereare no
otherwarranties, eitherexpressedor implied.
What is coverd by this warranty?
- Defectsin materialandworkmanship.
- Parts and labor for two (2) years
- Partsonly forthe thirdyear if therequired maintenanceis
performed.
- Freight(ground service only) for shipmentof areplacement part
and for return of the defective part.
What is not covered by this warranty?
- Shippingmethods otherthanground service.
- Defectsin glassware,electric lightbulbs, andreplacement fuses.
- Adjustmentof theburner electrode.
- Cleaningof theburner.
- Feesfor mobilerepair service.
- Mileageor travelexpenses toobtain warranty service.
- Expensesfor requiredmaintenance asspecified intheLimited
Warrantyand inthe Owner’sManual.
- Incidentalorconsequential lossordamageincluding butnotlimited
tocharges orclaims forlabor (includinglabor whenno partsare
usedfor arepair), lostbusiness, losttime, lostprofits, lostfood,
andlost use.
- Replacementparts thatarenot manufacturedorsupplied by
Norcold.
- Defect a of a part or assembly when the defect originates from
misuse,improperinstallation, improperorabnormalservice,transit
damage,recharging ofthecooling system,accident,fire, improper
repair,tampering,or abuse.
What will Norcold do?
Fora refrigeratorthatis properlyinstalled,maintained, andusedas
specifiedin theInstallation/Owner’sManuals, Norcoldresponsibilities
are:
- Limitedto therepairand replacementofparts.
- To provide no charge parts and labor for two (2) years.
- To provide no charge parts only for year 3 if the required
maintenanceisperformed.
- To provide freight (ground service only) for shipment of a
replacement part and for return of a defective part for three (3)
years.
What will the refrigerator owner do?
To obtainwarranty service,the refrigeratorowner responsibilitiesare:
- To use,service, andmaintainthe refrigeratoras specifiedin the
Installation/Owner’sManuals.
- To deliverthe warrantedproduct toan authorizedNorcold Service
Center for warranty repair.
- To show proof that the refrigerator is within warranty coverage.
- To havethe required maintenanceperformed byanauthorized
NorcoldService Centeronetime duringyear 2ofthe Limited
Warranty.
- To paytohave the requiredmaintenance performed.
- To mailpaidreceipt toNorcoldshowing requiredperformed before
expirationof year2 of the LimitedWarranty.
- To showproof ofthe requiredmaintenance beforerequesting
warranty service in year 3 of the Limited Warranty.
What rights do you have?
The warranty gives you specific legal rights. You may also have other
rights which vary from state to state.
GasAbsorption Warranty Questions

Owner’s Manual 4
- Do not spray liquids near electrical outlets, connec-
tions, or the refrigerator components. Many liquids are
electrically conductive and can cause a shock hazard,
electrical shorts, and in some cases fire.
- The refrigerator cooling system is under pressure. Do
not try to repair or to recharge a defective cooling
system. The cooling system contains sodium chro-
mate. The breathing of certain chromium compounds
can cause cancer. The cooling system contents can
cause severe skin and eye burns, and can ignite and
burn with an intense flame. Do not bend, drop, weld,
move, drill, puncture, or hit the cooling system.
- At regular intervals, make sure that the refrigerator flue
the burner, the vent areas, and the ventilation air
pathway between the vents are completely free from
any flammable material or blockage. After a period of
storage, it is especially important to check these areas
for any flammable material or blockage caused by
animals.
CAUTION:
- The rear of the refrigerator has sharp edges and
corners. To prevent cuts or abrasions when working
on the refrigerator, be careful and wear cut resistant
gloves.
About Your Refrigerator
Storage Volume:
This refrigerator is made for storage of foods and frozen food
and for making ice.
Total capacity 9.5 cubic feet
Leveling:
CAUTION: The refrigerator is made to operate within 3°
off level side-to-side and 6° off level front-to-back (as
looking at the front of the refrigerator). Operating it at
more than these limits can cause damage to the cooling
system and create a risk of personal injury or property
damage. Make sure the vehicle is level before you
operate the refrigerator.
Operation during travel:
While the refrigerator should be level when the vehicle is
stopped, performance during travel is not usually effected.
Food compartment:
Start up the refrigerator and let it cool for eight hours before
loading with food. If the refrigerator does not start to cool down
after eight hours, contact your dealer or a Norcold authorized
service center.
Safety Instructions
Safety Awareness
Read this manual carefully and understand the contents before
you use the refrigerator.
Be aware of possible safety hazards when you see the safety
alert symbol on the refrigerator and in this manual. A signal
word follows the safety alert symbol and identifies the danger of
the hazard. Carefully read the descriptions of these signal
words to fully know their meanings. They are for your safety.
WARNING: This signal word means a hazard, which if
ignored, can cause dangerous personal injury, death, or
much property damage.
CAUTION: This signal word means a hazard, which if
ignored, can cause small personal injury or much
property damage.
WARNING:
- The storage of flammable materials behind or around
the refrigerator creates a fire hazard. Do not use the
area behind the refrigerator to store anything, espe-
cially flammable materials (gasoline, cleaning
supplies, etc.)
- Do not remove the round ground prong from any of the
AC power cords. Do not use a two prong adapter or an
extension cord with any of the AC power cords.
- A circuit overload can result in an electrical fire if the
wires and/or fuses are not the correct size. Use only
the wire and fuse sizes as writtten in the “Installation
Manual”.
- Incorrect installation, adjustment, change to, or
maintenance of this refrigerator can cause personal
injury, property damage, or both. Have service and
maintenance work done by your dealer or by an
Norcold authorized service center.
- Disconnect both the AC and DC power sources before
doing any maintenance work on the refrigerator. All
service work on this refrigerator must be done by a
qualified service technician.
- Do not bypass or change the refrigerator’s electrical
components or features.
- When you discard an appliance, remove all doors to
prevent accidental entrapment and suffocation.

Owner’s Manual 5
For the best cooling performance:
- Let air move freely inside the entire food compartment.
- Do not cover the shelves with plastic, paper, etc.
To decrease the amount of ice that collects on the cooling fins:
- Cover all liquids and moist foods.
- Let all hot foods cool before putting them in the refrigerator.
- Do not open the door any longer than necessary.
Freezer compartment:
The freezer compartment is made to keep pre-frozen food
frozen and not to quick freeze food. Keep pre-frozen foods in the
freezer compartment.
NOTE: Do not put other items on the ice tray while the water is
freezing. The water freezes more rapidly if the thermo-
stat is at the COLDEST position.
Crisper(s):
The crisper(s) are located at the bottom of the fresh food
compartment and supply a storage area to preserve fruit and
vegetable freshness. Make sure that you always push the
crispers fully in.
NOTE: Do not wash the crispers in a dishwasher. The crispers
are not dishwasher safe.
Doorbins:
You may put the door bins [1] of the freezer and fresh food
compartment in a location that best meets your needs (See
Art00989). To remove the bins, lift them over the locator and pull
them forward. To install the bins, push them onto the locator.
NOTE: Do not wash the door bins and bin slides in a
dishwasher. The door bins and bin slides are not
dishwasher safe.
Door bin slide:
Each door bin includes an adjustable door bin slide [2] to
prevent the bin contents from moving or overturning during
transit (See Art00989).
Push each door bin slide against the bin contents. To remove
each door bin slide, rotate it out of the bin. Rotate each bin
slide into the bin to install.
Adjustableshelves:
The shelves in the freezer and the fresh food compartment are
made so you can remove them or move them.
To move or remove the wire shelf of the freezer:
- Locate the plastic clip that is around the wire shelf.
- Remove and save the screw that attaches the plastic clip to
the inside of the refrigerator cabinet.
- Lift the left side of the shelf upward to remove the shelf.
- Push the wire shelf fully into the slot that you wish.
- Put the plastic clip back in the original position on the wire
shelf.
- Attach the plastic clip with the screw.
To remove or move the large shelves of the fresh food compart-
ment:
- Locate the plastic clip [1] that is around each wire shelf [2]
(See Art01692).
- Remove and save the screw [3] that attaches the plastic clip
to the inside of the refrigerator cabinet.
- Pull the shelf slightly forward to disengage the left side of
the shelf from the slot [4] of the refrigerator cabinet and lift
the left side of the shelf to remove the shelf.
- Put each wire shelf into the slot that you wish.
- Put the plastic clip back in the original position on each wire
shelf.
- Attach the plastic clip with the screw.
To remove the small top shelf of the fresh food compartment:
- Locate the plastic clip [1] that is around the wire shelf [2]
(See Art01692).
- Remove and save the screw [3] that attaches the plastic clip
to the inside of the refrigerator cabinet.
- Pull the shelf forward out of the slot.
- Put the wire shelf into the slot.
- Put the plastic clip back in the original position on the wire
shelf.
- Attach the plastic clip with the screw.
Door handles:
During travel, the door latch prevents the door from opening.
When closing each door, push the door toward the refrigerator
until you hear a “click sound.
To open each door, pull the handle away from the refrigerator
(See Art00990).

Owner’s Manual 6
During storage, the storage latch prevents the door from
completely closing. Use it to prevent odors when the refrigera-
tor is stored for an extended period of time.
To operate the storage latch (see Art00991), open each door
about 1/2 inch, hold the door handle in the open position, and
push the storage latch [1] into the cutout [2] of the strike plate.
Do not use the storage latch as a travel latch because the doors
will not be fully closed.
Interior light:
The interior light is at the top of the fresh food compartment. It
comes on when the refrigerator is ON and the door is open. To
replace the bulb:
1. Remove the DC power supply wires from the power board at
the rear of the refrigerator.
2. To remove the cover [1] , push it toward the rear of the
refrigerator (See Art00988).
3. Remove the light bulb [2] from the holder [3].
NOTE: Use a GE#214-2 bulb or equivalent as the replacement
bulb. This bulb is available at most retail automotive
parts centers.
4. Install the replacement bulb.
5. Install the cover.
6. Connect the DC power supply wires to the power board at
the rear of the refrigerator.
Door alarm:
The refrigerator has an alarm to alert you if the fresh food
compartment door is not closed. The refrigerator continues to
operate, but if the fresh food compartment door is open and the
interior light remains on for two minutes:
- An audible alarm starts.
- “dr” appears in the center display.
- The interior light automatically turns off.
Close the door to silence the alarm.
Moisture reduction heater:
The refrigerator has a heater that prevents moisture from
forming on the center divider between the doors of the freezer
and the fresh food compartment. The heater operates only
when the refrigerator is ON and the DC power is sufficient.
Temperature control system:
Although the refrigerator is not frost -free, it is made to limit frost
on the cooling fins. At regular intervals, the temperature control
system automatically melts most of the frost from the cooling
fins. The water from the cooling fins drains into a collection cup
that is attached to the back of the refrigerator. The heat of the
cooling system evaporates the water from the collection cup.
Backup operating system:
This refrigerator has a backup operating system. The backup
operating system allows the refigerator to continue to cool if the
temperature sensor of the refrigerator should fail.
If this failure occurs:
- The refrigerator automatically changes to the backup
operating system.
- When you push the TEMP SET button, the temperature
setting flashes in the center display for ten seconds.
- The backup operating system can overfreeze or thaw the
contents of the freezer and the fresh food compartment.
- Make sure the temperatures of the freezer and the fresh
food compartment are satisfactory.
NOTE: If you open the door(s) too often, the tempera-
tures inside the freezer and fresh food compart-
ment do not become stable. Allow the refrigera-
tor to operate for about one hour after each
adjustment change before you examine the
contents. The number “9” is the coldest
temperature setting.
- If the temperature is too warm, push and hold the
TEMP SET button to raise the temperature setting
by one number.
- If the temperature is too cold, push and hold the
TEMP SET button to lower the temperature setting
by one number.
- Have the refrigerator serviced by your dealer or a Norcold
authorized Service Center as soon as possible.

Owner’s Manual 7
Operating the Refrigerator Controls
Control panel:
The refrigerator control panel (See Art01018) is between the
freezer compartment and the fresh food compartment. A 12 volt
DC power supply is necessary for the control functions of the
refrigerator to operate. The refrigerator receives DC power from
the 12 volt system of the vehicle; either an auxiliary battery, a
converter, or the vehicle engine battery.
The ON / OFF button [1] starts and shuts down the refrigerator:
- To turn on the refrigerator, push and release the ON / OFF
button.
- To turn off the refrigerator, push the ON / OFF button for one
second and then release.
The TEMP SET button [3] controls the temperature adjustment
of the freezer and the fresh food compartment. The temperature
adjustment that you select does not change if the operation
mode of the refrigerator changes.
- Push the TEMP SET button and the temperature setting (the
numbers “1-9”) show in the center display [4].
- The number “9” is the coldest temperature setting.
- Push and hold the TEMP SET button and the temperature
setting changes.
- Release the TEMP SET button when the temperature
setting that you wish appears.
- After ten seconds, the temperature setting will go out and
only a green power ON light remains.
The MODE button [2] controls the operation mode of the
refrigerator:
- Push and hold the MODE button and each of the operating
modes of the refrigerator show one at a time in the center
display.
- There is one automatic mode of operation and two
manual modes of operation.
When the mode of operation that you wish shows in the
center display, release the MODE button.
NOTE: If you should forget in what mode your
regfrigerator is operating, push and release
the MODE button to show the current mode of
operation in the center display for 10 seconds.
Automatic mode operation:
When the refrigerator is in AUTO mode, it automatically uses the
most efficient energy source that is available for operation.
During operation, if a more efficient energy source becomes
available, the refrigerator controls change from the current
energy source to the more efficient energy source as follows:
- The first choice is AC operation if 120 volts AC is available to
the refrigerator.
- The second choice is propane gas operation if 120 volts AC
is not available to the refrigerator.
Removing air from the propane gas supply lines:
For safety reasons, the burner is made to ignite on propane gas
within a specified amount of time. When starting the refrigerator
for the first time, after storage, or after replacing propane gas
tank, the propane gas supply lines can have air in them. Due to
the air in the gas supply lines, the burner may not ignite on
propane gas within the specified amount of time.
To remove the air from the propane gas supply lines:
- Make sure that valve of the propane gas tanks(s) is open.
- Push the ON / OFF button to turn the refrigerator on.
- Push and hold the MODE button until the letters “LP” show
in the center display.
- This means that the refrigerator is operating on
propane gas.
- If the air in the propane gas supply lines prevents the
burner from ignition on propane gas, the fault codes
“no” and then “FL” will appear in the center display and
you will hear an alarm sound.
- Push and hold the ON / OFF button for one second and
then release to silence the alarm.
- Push the ON / OFF button to turn the refrigerator on.
- The refrigerator will start a 30 second trial for ignition.
- During the 30 second trial for ignition, the refrigerator
controls open the gas safety valve and the igniter
makes sparks.

Owner’s Manual 8
- When no fault code shows and only the power indicator
remains, this means that the refrigerator is operating on
propane gas in the manual mode.
- At this time, all of the air is removed from the propane
gas supply lines and you may select AUTO mode of
operation if you wish.
- Depending on how much air may be in the propane gas
supply lines, you may need to repeat the 30 second trial for
ignition two or three times.
- If the burner does not ignite on propane gas after two or
three attempts, stop and consult your local dealer or an
authorized Norcold Service Center.
Set the controls to automatic mode operation:
- Push the ON / OFF button to turn the refrigerator on.
- Push and hold the MODE button until the letters “AU” show
in the center display and then release.
- If 120 volts AC is available to the refrigerator:
- The letters “AU” and then “AC” show in the center
display.
- After ten seconds, the “AU” and then “AC” go off and
only a green power ON light remains.
- This means that the refrigerator is operating on AC
electric.
- If 120 volts AC is not available to the refrigerator:
- The letters “AU” and then “AC” show in the center
display.
- After five seconds, the “AU” and then “LP” show in the
center display.
- After ten seconds, the “AU” and the “LP” go off and only
a green power ON light remains.
- This means that the refrigerator is operating on
propane gas.
- If neither 120 volts AC nor propane gas is available to the
refrigerator:
- The fault codes “no” “AC” and then “no” “FL” show in
the center display and an audible alarm sounds.
If an energy source is available to the refrigerator, but is not
operating correctly:
- A fault code shows in the center display.
- The refrigerator controls try to change to a less efficient
energy source.
- If a less efficient energy source is not available:
- An audible alarm starts.
- A fault code shows in the center display.
- Refer to the “Fault Codes” section of this manual.
Set the controls to manual mode operation:
- Push the ON / OFF button to turn the refrigerator on.
- Push and hold the MODE button until the letters “ AC” show
in the center display and then release.
- After ten seconds, the “AC” goes off and only a green
power ON light remains.
- Push and hold the MODE button until the letters “LP” show
in the center display and then release.
- After ten seconds, the “LP” goes off and only a green
power ON light remains.
If the energy source is interrupted:
- A fault code shows in the center display.
- Refer to the “Fault Codes” section of this manual.
Cooling unit sensing:
The controls have the ability to sense the operation of the
cooling unit. If the controls sense that the cooling unit has
stopped cooling:
- The heat sources to the cooling unit are turned off and are
locked out by the controls.
- An audible alarm starts.
- A fault code “no” “co” shows in the Center display.
You can reset the controls and remove this fault code one time.
To reset the controls, shut off and then start the refrigerator.
- To turn off the refrigerator, push the ON / OFF button for one
second and then release.
- To turn on the refrigerator, push and release the ON / OFF
button.
If you reset the controls and the fault occurs again before the
refrigerator completes a full cooling cycle:
- The heat sources to the cooling unit are turned off and are
locked out.
- An audible alarm starts.

Owner’s Manual 9
Ice Maker
(N109XIM, and N109XIMXX models)
Effects of High Altitude on Propane Gas
Operation
When you operate the refrigerator on propane gas at altitudes
higher than 5500 feet above sea level:
- You may experience reduced cooling performance of the
refrigerator.
- You may experience burner outages.
To avoid these possible problems, Norcold recommends that
you operate the refrigerator on AC when at altitudes higher than
5500 feet above sea level.
The ice maker is assembled to the refrigerators at the factory as
optional equipment. If the refrigerator does not have a factory
installed ice maker, one can not be added to the refrigerator at a
later time.
The ice maker is fully automatic and will operate in ambient
temperatures as low as 0° F. To allow operation at tempera-
tures between 0° F. and 32° F., the ice maker has a heater on
the solenoid water valve and on the water line between the
solenoid water valve and the ice maker.
CAUTION: The water line heater does not protect the
water supply line from the vehicle shut off valve to the
solenoid water valve on the back of the refrigerator.
When the freezer temperature of the refrigerator is low enough,
the ice maker opens the water solenoid valve and fills the mold.
The ice maker ejects the frozen ice into a storage bin. As the
storage bin fills, the ice raises the shut-off arm until it turns off
the ice maker. As you use the ice and lower the ice level in the
storage bin, the shut-off arm also lowers. This turns the ice
maker on and begins the process of making ice.
The ice maker operates on:
- Cold potable water at a pressure of 15 psi - 125 psi.
- 120 VoltsAC (108 VAC min. - 132 VAC max.).
- A fault code “no” “co” shows in the Center display.
- This time you can not reset the fault. Have the refrigerator
serviced by your dealer or a Norcold authorized Service
Center as soon as possible.
Ice maker operation:
1. Make sure the separate (white) AC power cord which
supplies AC to the ice maker is secure.
2. Open the water shut off valve of the vehicle.
NOTE: Make sure that the ice maker arm can move freely and
does not touch the frozen foods in the freezer.
3. Push the ice maker arm down to the ON position [1] (See
Art01015).
CAUTION: If you operate the refrigerator without
connecting the water supply line and/or opening the
water shut off valve of the vehicle, make sure the ice
maker arm is up in the OFF position.
4. Allow the freezer to cool enough and ice production will begin
to fill the storage bin [2].
NOTE: New plumbing connections and/or impurities in the
water supply line after winterizing can cause the first
ice to be discolored or have an odd flavor.
5. To stop the ice maker, push the ice maker arm up to the OFF
position [3].
Refrigerator Care Checklist
Your refrigerator will give you years of trouble free service if you
do these simple checks every three to six months:
- Keep the food compartment and the freezer clean. See
“Cleaning”.
- Defrost the refrigerator as necessary. See “Defrosting”.
- Make sure the door seals correctly. See “Door Sealing“.
- Be aware of any cooling changes that are not because of
weather, loading, or gas control changes. If changes occur,
contact your dealer or service center.
- Make sure the gas supply is propane gas only and not
butane or a butane mixture.
- When in propane gas operation, examine the appearance
of the flame. See “Gas Flame Appearance”.
- Make sure the air flow in the lower intake vent, through the
refrigerator coils and condenser, and out the upper exhaust
vent is not blocked or decreased.
- Make sure the area behind the refrigerator is clear. Do not
use the area behind the refrigerator for storage of anything,
especially gasoline and other flammable vapors and
liquids.

Owner’s Manual 10
Defrosting
Interior:
A good time to clean the refrigerator is just after you defrost it.
Clean the inside of the refrigerator as often as necessary to
avoid food odors:
- Remove all food from the refrigerator.
NOTE: Do not use abrasive cleaners, chemicals, or
scouring pads because they can damage the
interior of the refrigerator.
- Wash the interior with a mild cleaner or a solution of liquid
dish detergent and warm water.
- Rinse with a solution of baking soda and clean water.
- Dry with clean cloth.
- Put all food in the refrigerator.
Drip tray:
To remove and clean the drip tray:
NOTE: Do not wash the drip tray in a dishwasher. The drip tray
is not dishwasher safe.
- Pull the drip tray out of the drain hose.
- Pull the drip tray forward to remove from the slots in the
refrigerator cabinet.
- Clean the drip tray.
- Push the drip tray back into the slots in the refrigerator
cabinet.
- Push the drip tray back into the drain hose.
Metal doors:
To clean the metal doors:
- Wash the doors with a mild cleaner or a solution of liquid
dish detergent and warm water.
- Rinse with clean water.
- Dry with a clean cloth.
NOTE: Do not use abrasive cleaners, chemicals, or
scouring pads because they can damage the
metal doors.
Cleaning
The cooling fins of the refrigerator operate at below freezing
temperature and will naturally form frost from humidity, which is
always present in the air. The humidity inside the refrigerator
increases:
- with higher outside temperature and humidity.
- with the storage of non-sealed fresh foods or warm foods.
- with the amount of time that the door(s) are open.
- with any air leakage into the refrigerator.
Although the refrigerator is not frost -free, it is made to limit frost
on the cooling fins. At regular intervals, the temperature control
system automatically melts most of the frost from the cooling
fins. The water from the cooling fins drains into a collection cup
that is attached to the back of the refrigerator. The heat of the
cooling system evaporates the water from the collection cup.
It is normal for frost to collect inside the freezer. Excess frost
decreases the cooling performance of the refrigerator. Defrost
the refrigerator and freezer as necessary:
- Remove all food from the refrigerator.
- Turn the refrigerator OFF.
NOTE: Defrosting the refrigerator makes excess water inside
the refrigerator.
- Remove the drain hose from the drip cup at the rear of the
refrigerator.
- Put the drain hose into a half-gallon or larger container to
capture water.
- Put dry towels (etc.) inside the refrigerator and freezer to
absorb melted frost.
CAUTION: High temperatures can cause the inside
surfaces of the refrigerator to warp or melt. Do not use
pans of HOT water, a hair dryer, or any other high
temperature devices to defrost the refrigerator. Do not
use any hard or sharp objects to remove frost. Damage
to the interior of the refrigerator can occur.
- To increase the speed of defrosting, put pans of WARM
water in the refrigerator and freezer.
- Remove the wet towels (etc.) and dry the interior.
- Remove the drain hose from the large container and put the
drain hose back into the drip cup.
- Remove the large container from the enclosure.
- Start up the refrigerator.
- Allow the refrigerator to cool down.
- Return all food to the refrigerator.

Owner’s Manual 11
Door Sealing
Glassshelf:
To clean the glass shelf:
- Remove the screw and grommet that is in front of the glass
shelf.
- Pull the glass shelf forward out of the slot
- After cleaning, push the glass shelf fully into the slot.
- Put the screw and grommet back in the orignial position.
Refrigerator Maintenance Checklist
Read and understand the following maintenance sections of
this manual.
NOTE: Norcold is not responsible for installation, adjust-
ment, alteration, service, or maintenance per-
formed by anyone other than a qualified RV dealer
or a Norcold authorized service center.
Have a qualified RV dealer or a Norcold authorized service
center do these annual safety and maintenance checks:
- Examine the gas supply lines for leaks.
- Replace or repair if needed.
Check the seal of the doors.
If either door does not seal correctly, excess frost will collect
inside the refrigerator. Make sure the doors seal correctly (See
Art00980):
- Close each door on a piece of paper that is about the size
and thickness of a dollar bill.
- Gently pull the paper.
- You should feel a slight drag between the gasket and
the cabinet.
- Do this on all four sides of the door.
- If you do not feel a slight drag on the
paper, the door does not seal correctly.
- Have your dealer or an authorized Norcold Service
Center correct the seal of the door.
- Make sure the propane gas pressure is 11 inches of water
column.
- Adjust if needed.
- Make sure the combustion seal is complete and intact.
- Replace or repair it if needed.
- Make sure the burner and the burner orifice are clean.
- Clean if needed.
- Make sure the electrode spark gap is 1/8 - 3/16 inch.
- Adjust if needed.
- Make sure the AC voltage is 108 - 132 volts and the DC
voltage is 10.5 - 15.4 volts.
- Make sure the thermocouple tip is clean and secure.
- Make sure the area at the rear of the refrigerator is free of
any combustible materials, gasoline, and other flammable
vapors and liquids.
Refrigerator Storage
Before the refrigerator is stored for an extended (seasonal)
period of time:
- Defrost and clean the interior of the refrigerator.
- Close the doors with the storage latch.
If the refrigerator is stored for an extended period of time, before
start up:
- Make sure there are no obstructions in the vents, the
ventilation air pathway, the burner, the orifice, or the flue
area.
Ice Maker Storage
(N109XIM, and N109XIMXX models)
To prepare the ice maker for seasonal storage:
1. Close the vehicle water supply valve to the ice maker.
2. Push the ice maker arm up until it locks into the OFF
position.
3. Remove the garden hose adapter from the water solenoid
valve.

Owner’s Manual 12
Refrigerator Maintenance
Gas flame appearance:
While in GAS operation, examine the appearance of the gas
flame:
- Push and hold the TEMP SET button until the “9” tempera-
ture setting shows in the center dispaly.
- Open the lower intake vent.
CAUTION: The burner box cover can be hot. Wear
gloves to avoid burns.
- Remove the drip cup by removing the screw.
- Remove the burner box cover by removing the screw.
4. Remove the ice maker water line from the water solenoid
valve
- Do not unwrap the water line heater wires from around the
water solenoid valve.
5. Drain all of the water from both the water supply line and the
ice maker water line.
6. Put the end of the water supply line, the end of the ice maker
water line, and the water solenoid valve each into a clean
plastic bag.
7. Use tape to close each plastic bag around the water lines
and the water solenoid valve.
To use the ice maker after seasonal storage:
CAUTION: Do not operate the ice maker when the
ambient air temperature is 0° F. or lower. Damage to the
water solenoid valve and the water supply line can occur.
1. Remove the tape and plastic bags from the end of the water
supply line, the end of the ice maker water line, and the water
solenoid valve.
2. Connect the ice maker water line to the water solenoid valve.
3. Connect the garden hose adapter to the water solenoid
valve.
4. Push the ice maker arm down into the ON position.
5. Open the vehicle water supply valve to the ice maker.
NOTE: You should discard and not use the first two batches of
ice cubes. It will take about three cycles for the ice
maker to make fully formed and clean ice cubes.
- Look at the gas flame [1] (See Art01605).
- The flame should be:
- a darker blue color on the inside of the flame and
a lighter blue color on the outside of the flame.
- a constant shape without flickering.
- Contact your dealer or Norcold authorized service
center if the flame is:
- yellow
- flickering or changing shape.
- Make sure the flame does not touch the inside of the
flue tube [2].
- If the flame touches the inside of the flue tube, contact
your dealer or Norcold authorized service center.
- Close the burner box door.
Remove and clean the burner orifice:
Your dealer or Norcold authorized service center must do this
procedure.
Remove and clean the burner orifice (See Art00956):
- Close the valve at the propane gas tank(s).
- Push the ON / OFF button to shut down the refrigerator.
CAUTION: The burner box cover can be hot. Wear
gloves to avoid burns.
- Open the lower intake vent.
- Remove the drip cup by removing the screw.
- Remove the burner box cover by removing the screw.
WARNING: To avoid possible propane gas leaks,
always use two wrenches to loosen and tighten the
gas supply line connections.
- Remove the flare nut from the orifice assembly [1] (See
Art00956).
- Remove the orifice assembly from the burner [2].
WARNING: Do not try to remove the orifice [3] from the
orifice adapter [4] when cleaning. Removal will
damage the orifice and seal of the orifice and can
cause a propane gas leak. Leaking propane gas can
ignite or explode which can result in dangerous
personal injury or death. Do not clean the orifice with a
pin or other objects.

Owner’s Manual 13
Remove the Refrigerator
Your dealer or Norcold authorized service center must do this
procedure.
CAUTION: The rear of the refrigerator has sharp edges
and corners. To prevent cuts or abrasions when working
on the refrigerator, be careful and wear cut resistant
gloves.
1. Close the valve at the propane gas tank(s).
WARNING: To avoid possible propane gas leaks,
always use two wrenches to loosen and tighten the gas
supply line connections.
2. Remove the black AC power cord and the white ice maker
AC power cord (N109XIM and N109XIMXX models only) from
the receptacle.
3. Remove the DC wiring from the refrigerator:
- Put a mark on the DC wires so you can put them back in the
correct location.
- Remove the DC fuse or remove the DC wiring from the
battery or the converter.
- Remove the DC wires from the refrigerator.
4. Open the lower intake vent and remove the gas supply line
from the combination gas valve of the refrigerator.
5. Remove the garden hose adapter from the water solenoid
valve (N109XIM and N109XIMXX models only).
6. Remove the screws from the mounting flange at the rear of
the refrigerator.
7. Remove the upper and lower trim pieces from the mounting
flanges of the refrigerator.
Reinstall the Refrigerator
Your dealer or Norcold authorized service center must do this
procedure.
WARNING: Make sure the combustion seal is not
broken, is completely around the refrigerator mounting
flanges, and is between the mounting flanges and the
wall of the enclosure. If the combustion seal is not
complete, exhaust fumes can be present in the living
area of the vehicle. The breathing of exhaust fumes can
cause dizziness, nausea, and in extreme cases, death.
1. Push the refrigerator completely into the enclosure.
2. Install the screws in the upper and then the lower mounting
flanges on the front of the refrigerator.
3. Install the upper and lower trim pieces to the mounting
flanges of the refrigerator.
4. Install the screws in the mounting flange at the rear of the
refrigerator.
WARNING: To avoid possible propane gas leaks,
always use two wrenches to loosen and tighten the gas
supply line connections.
5. Attach the garden hose adapter to the water solenoid valve
(N109XIM and N109XIMXX models only).
6. Attach the gas supply line to the combination gas valve of the
refrigerator.
7. Open the valve at the propane gas tank(s).
WARNING: Do not allow the leak checking solution to
touch the electrical components. Many liquids are
electrically conductive and can cause electrical shorts
and in some cases, fire.
8. Examine the gas supply line for leaks.
9. Connect the DC wiring to the refrigerator:
- Connect the DC wires to the refrigerator.
- Install the DC fuse or connect the DC wiring to the battery or
the converter.
10. Connect the black AC power cord and the white ice maker
AC power cord (N109XIM and N109XIMXX models only) to the
receptacle.
- Clean the orifice assembly with air pressure and alcohol
only.
- Using a wrench, assemble the orifice assembly to the
burner.
- Assemble the flare nut to the orifice assembly.
- Examine all of the connections for gas leaks.
- Clean the burner box.
- Assemble the burner box cover.
- Assemble the drip cup.
8. Remove the screws from the upper and lower mounting
flanges on the front of the refrigerator.
9. Remove the refrigerator from the opening.

Owner’s Manual 14
Ice Maker Wiring Pictorial and Diagram
(N109XIM and N109XIMXX models)
The parts of the ice maker wiring pictorial and diagram are (See
Art01016):
120VAC Hot................................................................................ 1
PC Board .................................................................................... 2
Ground screw ............................................................................. 3
Hot / smooth ............................................................................... 4
Neutral / Ribbed ......................................................................... 5
Solenoid Water Valve.................................................................. 6
Thermal Fuse ............................................................................. 7
Ice maker .................................................................................... 8
Mold Heater ................................................................................ 9
Thermostat ............................................................................... 10
Shut Off Switch ..........................................................................11
Fill Switch.................................................................................. 12
Holding Switch ......................................................................... 13
Motor ......................................................................................... 14
120VAC Neutral ....................................................................... 15
Replacement Parts
You may purchase replacement parts through your local RV
dealer or authorized Norcold Service Center.
Wiring Diagram and Pictorial
The parts in the wiring pictorial are (See Art01771):
The parts in the wiring diagram are (See Art01772):
A.................................................................................... AC heater
B............................................................................................ Light
C ..................................................................................Thermister
D ....................................................................................Gas valve
E.......................................................................................... Igniter
F ..............................................................................Divider heater
G ...................................................Temperature switch (optional)
H ...................................................Temperature switch (optional)
I ...............................................................................Fan (optional)
J ........................................Ice maker water line heater (optional)
K................................................................... DC heater (optional)
L ..........................................................................Chassis ground
M ................................................................... DC board (optional)
N ................................................................................ Door switch
1 ........................................................................ Switched 12 VDC
2 ......................................................... Fused continuous 12 VDC
3 ........................................................................ Communications
4 ............................................................................Display ground
5 ...........................................................................Auxiliary ground
6 ........................................................................Auxiliary+12VDC
7 ..........................................................................Divider +12 VDC
8 ..................................................................... Gas valve +12 VDC
F1 .......................................................................... 5 Amp fuse DC
F2 ........................................................................... 8 Amp fuse AC
F3 ........................................................................30 Amp fuse DC

Owner’s Manual 15
Fault Codes
sedoCtluaFgninaeMedoCtluaFsnoitcAevitcerroC
oN .yalpsid
siegatlovCD ehtotelbaliavanu lortnocrotaregirfer ehtrolenap .FFOsirotaregirfer
:kcehC .NOsirotaregirferehttahT- .lanoitareposielcihevehtfotnempiuqegnigrahcyrettabehttahT- .)elbacilppafi(lanoitareposiretrevnocCD/CAehttahT- .retnececivresdezirohtuadlocroNarorelaedruoyeeS-
"rd" .oslamralaelbiduA rofneposawroodehT .setunim2nahterom .roodehtesolC
"LF""on"
.oslamralaelbiduA tondidrenrubehT .etingi-erroetingi
:kcehC .neposi)s(knatsagenaporpehtfoevlavehttahT- .erusserptcerrocehttasisagenaporpehttahT- .neposirotaregirferehtfoevlavffotuhslaunamehttahT- riagnivomeR"eeS.enilylppussagenaporpehtniriaonsierehttahT- .launamsihtfonoitces"senilylppussagenaporpehtmorf .retneCecivreSdlocroNdezirohtuarorelaedruoyeeS-
"CA""on"
.oslamralaelbiduA
siegatlovCA ehtotelbaliavanu .lortnocrotaregirfer
:kcehC .teltuoelbaecivresaotnideggulprotaregirferehttahT- .tcatnisielcihevehtforekaerbtiucricroesufehttahT- .)elbacilppafi(lanoitareposirotarenegelcihevehttahT- .retneCecivreSdlocroNdezirohtuarorelaedruoyeeS-
"OL""cd" ehtotegatlovCD lortnocrotaregirfer .wolootsilenap
:kcehC .lanoitareposielcihevehtfotnempiuqegnigrahcyrettabehttahT- .)elbacilppafi(lanoitareposiretrevnocCD/CAehttahT- .retneCecivreSdlocroNdezirohtuarorelaedruoyeeS-
"oc""on"
.oslamralaelbiduA gniloocrotaregirferehT .gniloocdeppotssahtinu
tesererofeB-emitts1 :kcehC .dekcolbtonerastnevehttahT- .)s(roodesolC.nepotonsi)s(roodatahT- .levelsielcihevehttahT-
teserretfA-emitdn2 ecivreSdlocroNdezirohtuarorelaedruoyeeS.elbaecivresrenwotonsisihT .retneC
rebmunerutarepmeT PMETnehwsehsalf .dehsupsinottubTES sirotaregirferehT kcaB"ehtnognitarepo ."metsySgnitarepOpU ecivreSdlocroNdezirohtuarorelaedruoyeeS.elbaecivresrenwotonsisihT .retneC
"Er""CA" .oslamralaelbiduA ehtnihtiwtluafasisihT .slortnocrotaregirfer ecivreSdlocroNdezirohtuarorelaedruoyeeS.elbaecivresrenwotonsisihT .retneC
"Er""cd" .oslamralaelbiduA ehtnihtiwtluafasisihT .slortnocrotaregirfer ecivreSdlocroNdezirohtuarorelaedruoyeeS.elbaecivresrenwotonsisihT .retneC
"EH""CA" .oslamralaelbiduA ehtnihtiwtluafasisihT .slortnocrotaregirfer ecivreSdlocroNdezirohtuarorelaedruoyeeS.elbaecivresrenwotonsisihT .retneC
"EH""cd" .oslamralaelbiduA ehtnihtiwtluafasisihT .slortnocrotaregirfer ecivreSdlocroNdezirohtuarorelaedruoyeeS.elbaecivresrenwotonsisihT .retneC
"rS" .oslamralaelbiduA ehtnihtiwtluafasisihT .slortnocrotaregirfer ecivreSdlocroNdezirohtuarorelaedruoyeeS.elbaecivresrenwotonsisihT .retneC 18710trA

Owner’s Manual 16
