PARTS LIST
PARTNO.623421
NORCOLD04/16/2008
N61/N81 SERIES
N61 SERIES
N610
N611
N611F
N81 SERIES
N810
N811
N811F
N811F
N814F2

N61/N81 SERIES PARTS LIST - PAGE 2
UPPER DOOR (FREEZER) - N61/N81 SERIES
NO. PART # PART DESCRIPTION N610 N611 N810 N811*
1 619558 PANEL RETAINER-UPPER DOOR/BLACK/WDL (2 PER DOOR) WDL WDL
622906 PANEL RETAINER-UPPER DOOR/BROWN/WDL (2 PER DOOR) WDL WDL
623943 PANEL RETAINER-UPPER DOOR/PANEL/BLACK/SDL (2 PER DOOR) SDL SDL
624797 PANEL RETAINER-UPPER DOOR/PANEL/BROWN/SDL (2 PER DOOR) SDL SDL
2 618511 HINGE-DOORSIDE/TOP RH/BTM LH/BLACK/WDL WDL WDL
622924 HINGE-DOOR SIDE/TOP RH/BTM LH/BROWN/WDL WDL WDL
3 619671 HINGEBUSHING-DOOR/WARM GRAY/WDL WDL WDL WDL WDL
4 619627 DOOR LINER ASSY-UPPER/PANEL/BLACK FRAME/WDL WDL WDL
622897 DOOR LINER ASSY-UPPER/PANEL/BROWN FRAME/WDL WDL WDL
623945 DOOR LINER ASSY-UPPER/PANEL/BLACK FRAME/SDL SDL SDL
624813 DOOR LINER ASSY-UPPER/PANEL/BROWN FRAME/SDL SDL SDL
5 618160 CAP-HINGEPLUG/BLACK ALL ALL
622989 CAP-HINGEPLUG/BROWN ALL ALL
6 621465 DOOR HANDLE ASSY-UPPER DOOR/RH SWING/PLASTIC/BLACK ALL ALL
622916 DOOR HANDLE ASSY-UPPER DOOR/RH SWING/PLASTIC/BROWN ALL ALL
7 622313 LATCH-STORAGE/DOOR/PLASTIC HANDLE/WARM GRAY ALL ALL ALL ALL
8 618510 HINGE-DOORSIDE/TOP LH/BTM RH/BLACK/WDL WDL WDL
622923 HINGE-DOOR SIDE/TOP LH/BTM RH/BROWN/WDL WDL WDL
9 618618 RAIL-UPPER DOOR/WDL (1 PER DOOR) WDL WDL WDL WDL
10 624863 BIN-DOORSHELF/WHITE/SDL (1 PER DOOR) SDL SDL SDL SDL
NS 619569 BOLT-CAP SHOULDER/TORX HEAD ALL ALL ALL ALL
NS = NOT SHOWN
* NOTE: N811 SERIES INCLUDES N814F2 MODELS
SERIESWDL - WAFFLEDOORLINER SDL = SMOOTHDOORLINER
1
9
3
4
1
7
8
3
5
2
6
ART01078C
10

N61/N81 SERIES PARTS LIST - PAGE 3
LOWER DOOR (FRESH FOOD) - N61/N81 SERIES
NO. PART # PART DESCRIPTION N610 N611 N810 N811*
1 619559 PANEL RETAINER-LOWERDOOR/6'/BLACK/WDL WDL WDL
622907 PANEL RETAINER-LOWER DOOR/6'/BROWN/WDL WDL WDL
623948 PANEL RETAINER-LOWER DOOR/6'/BLACK/SDL SDL SDL
624799 PANEL RETAINER-LOWER DOOR/6'/BROWN/SDL SDL SDL
619560 PANEL RETAINER-LOWERDOOR/8'/BLACK/WDL WDL WDL
622908 PANEL RETAINER-LOWER DOOR/8'/BROWN/WDL WDL WDL
623760 PANEL RETAINER-LOWER DOOR/8'/BLACK/SDL SDL SDL
624798 PANEL RETAINER-LOWER DOOR/8'/BROWN/SDL SDL SDL
2 618511 HINGE-DOORSIDE/TOP RH/BTM LH/BLACK/WDL WDL WDL
622924 HINGE-DOOR SIDE/TOP RH/BTM LH/BROWN/WDL WDL WDL
3 619671 HINGEBUSHING-DOOR/WARM GRAY/WDL WDL WDL WDL WDL
4 619629 DOORLINER ASSY-LOWER/6'/PANEL/BLACKFRAME/WDL WDL WDL
622898 DOOR LINER ASSY-LOWER/6'/PANEL/BROWN FRAME/WDL WDL WDL
623955 DOORLINER ASSY-LOWER/6'/PANEL/BLACKFRAME/SDL SDL SDL
624812 DOOR LINER ASSY-LOWER/6'/PANEL/BROWN FRAME/SDL SDL SDL
619631 DOORLINER ASSY-LOWER/8'/PANEL/BLACKFRAME/WDL WDL WDL
624208 DOOR LINER ASSY-LOWER/8'/PANEL/BROWN FRAME/WDL WDL WDL
623942 DOORLINER ASSY-LOWER/8'/PANEL/BLACKFRAME/SDL SDL SDL
624814 DOOR LINER ASSY-LOWER/8'/PANEL/BROWN FRAME/SDL SDL SDL
5 621469 DOORHANDLEASSY-LOWERDOOR/RH SWING/PLASTIC/BLACK ALL ALL
622915 DOOR HANDLE ASSY-LOWER DOOR/RH SWING/PLASTIC/BROWN ALL ALL
6 622313 LATCH-STORAGE/GRAY ALL ALL ALL ALL
7 618578 RAIL-LOWER DOOR/WDL WDL WDL WDL WDL
624866 WIRE-BIN/SDL SDL SDL SDL SDL
8 618510 HINGE-DOORSIDE/TOP LH/BTM RH/BLACK/WDL WDL WDL
622923 HINGE-DOOR SIDE/TOP LH/BTM RH/BROWN/WDL WDL WDL
9 618619 BIN-DOOR SHELF/SMALL/WHITE/WDL (2 FOR N611/3 FOR N811) WDL WDL WDL WDL
624863 BIN-DOOR SHELF/WHITE/SDL (3 FOR N611/4 FOR N811) SDL SDL SDL SDL
NS 619569 BOLT-CAP SHOULDER/TORX HEAD ALL ALL ALL ALL
WDL - WAFFLEDOORLINER SDL = SMOOTH DOORLINER SERIES
NS = NOT SHOWN * = N811 SERIES INLUDES THEN814F2 MODEL
Art01079C
1
1
2
7
8
3
9
5
3
6
4

N61/N81 SERIES PARTS LIST - PAGE 4
CABINET AREA (FRONT VIEW) - N61/N81 SERIES
1
2
3
4
5
7
6
8
11
12
13
14
15
17
16
18
19
20
Art00933C
9
10

N61/N81 SERIES PARTS LIST - PAGE 5
CABINET AREA (FRONT VIEW) - N61/N81 SERIES
NO. PART # PART DESCRIPTION N610 N611 N810 N811*
1 622319 TRIM PIECEASSY-TOP/WITH INSERTS/BLACK X X
622931 TRIM PIECE ASSY-TOP/WITH INSERTS/BROWN (USE622926) X X X
2 618170 HOLE PLUG-FOR TOP TRIM PIECE/BLACK (2 PER CABINET) X X
622930 HOLE PLUG-FOR TOP TRIM PIECE/BROWN (2 PER CABINET) X X X
3 619335 HINGE-CABINET/3 POINT/TOP RH/BTM LH/BLACK/WDL (2 PERCABINET) WDL WDL
622885 HINGE-CABINET/3 POINT/TOP RH/BTM LH//BROWN/WDL (2 PER CABINET) WDL WDL
623771 HINGE-CABINET/3 POINT/TOP RH/BTM LH/PANEL/BLACK/SDL SDL SDL
624787 HINGE-CABINET/3 POINT/TOP RH/BTM LH/BROWN/SDL SDL SDL
4 622295 TRIM PIECEFOAM TAPEASSY-SIDE/6'/BLACK(2 PERCABINET) X X
623516 TRIM PIECEFOAM TAPEASSY-SIDE/6'/BROWN (2 PERCABINET) X X
622296 TRIM PIECEFOAM TAPEASSY-SIDE/8'/BLACK (2 PERCABNET) X X
TBA TRIM PIECEFOAM TAPEASSY-SIDE/8'/BROWN(2 PER CABNET) X X
5 620250 SHELF-WIRE/FREEZER X X X X
6 621988 CONTROL ASSY-OPTICAL/BLACK(SERIAL # 9056491 & BELOW) X X
624207 CONTROL ASSY-OPTICAL/BROWN(SERIAL # 9056491 & BELOW) X X
628979 CONTROL ASSY-OPTICAL/BLACK (SERIAL # 9056492 & ABOVE) X X
629079 CONTROL ASSY-OPTICAL/BROWN(SERIAL # 9056492 & ABOVE) X X
7 622002 FRONT BOX-BLACK X X
623428 FRONT BOX-BROWN X X
8 623250 DRIP TRAY-INSIDE (ONE PIECE DRIP TRAY & LOUVER) X X X X
9 620272 SHELF-WIRE/CUT OUT X X X X
10 620273 SHELF-WIRE/FULL (2 FORTHEN611)( 3 FOR THEN811) X X X X
11 618158 CRISPER COVER-GLASS SHELF X X X X
12 618571 CRISPER-WHITE/FULL X X X X
13 618145 HINGE PIN-UPPER HINGE/BLACK WDL WDL
622925 HINGE PIN-UPPER HINGE/BROWN WDL WDL
623899 HINGE PIN-UPPER/BLACK/SDL SDL SDL
61114600 HINGEPIN-TOP/WDL SDL SDL
61550722 HINGE PIN-BOTTOM/SDL SDL SDL SDL SDL
14 619671 HINGE BUSHING-DOOR/WARM GRAY (4 PER REFRIGERATOR) WDL WDL WDL WDL
15 619336 HINGE-CABINET/3 POINT/TOP LH/BTM RH/BLACK/WDL (2 PERCABINET) WDL WDL
622886 HINGE-CABINET/3 POINT/TOP LH/BTM RH/BROWN/WDL (2 PER CABINET) WDL WDL
623772 HINGE-CABINET/3 POINT/TOP LH/BTM RH/BLACK/SDL ,
624789 HINGE-CABINET/3 POINT/TOP LH/BTM RH/PANEL/BLK/SDL , X
16 619301 COVER-HINGEHOLE/WHITE/3 POINT (2 PERCABINET) X X X X
17 622323 TRIM PIECEFOAM TAPEASSY-BOTTOM/BLACK X X
622927 TRIM PIECEFOAM TAPEASSY-BOTTOM/BROWN(USE622926) X X
18 61536522 CLAMP-NYLON1/2" (SHELF CLIP) (2 FORTHEN61)( 3 FOR THEN811) X X X X
19 620282 HOLEPLUG-DIVIDER/WHITE(2 PERCABINET) X X X X
20 618167 STRIKEPLATE-BLACK X X
619673 STRIKEPLATE-WARM GRAY X X
NS 622325 KIT-INSTALLATION/BLACK (TRIM PIECES/SCREWS/PLUGS) N611 N611F N811 N811F
NS 622926 KIT-INSTALLATION/BROWN (TRIM PIECES/SCREWS/PLUGS) N610 N610F N810 N810F
WDL - WAFFLEDOORLINER SDL = SMOOTH DOORLINER SERIES
NS = NOT SHOWN * = N811 SERIES INLUDES THE N814F2 MODEL

N61/N81 SERIES PARTS LIST - PAGE 6
CABINET AREA (REAR VIEW) - N61/N81 SERIES
1
2
3
4
5
6
7Art00908C
8
NO. PART # PART DESCRIPTION N610 N611 N810 N811 N814F2
1 632307 NSC SYSTEM PACK-COOLING UNIT (BACKER HEATER) X X
632314 NSC SYSTEM PACK-COOLING UNIT (BACKER HEATER) X X
NS 2M0802 THERMAL SWITCH/BRACKET ASSY (SEENOTE) X X X X
NS 618111 BAFFLE DIFFUSER/WIRE ASSY-COOLING UNIT (NOT SHOWN) X X X X
2 61686823 FINS XXXX
3 61695022 CAP-HEAT DEFLECTOR X X X X
4 621702 HEATER-AC (COOLING UNIT SERIAL# 11231023 & BELOW) X X
HEATER-AC (COOLING UNIT SERIAL# 11232007 & BELOW) X X
630811 HEATER-AC/BACKER (COOLING UNIT SERIAL# 11231024 & ABOVE) X X
HEATER-AC/BACKER(COOLING UNIT SERIAL# 11232008 & ABOVE) X X
5 61695322 BASE-BURNER BOX X X X X
6 61712637 COVER ASSY-BURNER BOX X X X X
7 622546 DRIP CUP-REAR/PLASTIC X X X X
8 622390 DRAIN HOSE ASSY-N6 SERIES X X
622391 DRAIN HOSE ASSY-N8 SERIES X X
NOTE: FOR COOLING UNITS WITH A THERMAL SWITCH.

N61/N81 SERIES PARTS LIST - PAGE 7
CONTROLS (REAR VIEW) - N61/N81 SERIES
54
3
2
1
7
10 11
12
8
9
Art01318C
6
11
NO. PART # PART DESCRIPTION N610 N611 N810 N811*
1 618186 BASE-POWER BOARD(SERIAL # 9056491 & BELOW) X X X X
628674 BASE-POWER BOARD(SERIAL # 9056492 & ABOVE) X X X X
2 621991001 KIT-POWERBOARD(SERIAL # 9056491 & BELOW) X X X X
628661 POWER BOARD(SERIAL # 9056492 & ABOVE) X X X X
3 618185 COVER-POWER SUPPLY (SERIAL # 9056491 & BELOW) X X X X
628677 COVER-POWER BOARD (SERIAL # 9056492 & ABOVE) X X X X
4 621448 WIRE-WHITE/9"/GAS VALVE X X X X
5 624681 BRACKET-GAS VALVE(9185698 & BELOW) X X X X
628993 BRACKET-GAS VALVE(9185699 & ABOVE) X X X X
6 621334 KIT-GAS VALVE/BRACKET/WIRES (9185698 & BELOW) X X X X
628741 GAS VALVE(9185699 & ABOVE) X X X X
7 624682 BURNER TUBE X X X X
8 621957 KIT-BURNER/ORIFICE ADAPTER ASSY X X X X
9 61554422 CORD-AC POWER/BLACK X X X X
10 61712637 COVER ASSY-BURNER BOX X X X X
11 61695322 BASE-BURNER BOX X X X X
12 61692222 ELECTRODE-SPARK/SENSE/SINGLEELECTRODE/0.25" X X X X
SERIES
* = N811 SERIES INLUDES THE N814F2 MODEL

N61/N81 SERIES PARTS LIST - PAGE 8
INTERIOR LIGHT AND THERMISTER ASSY - N61/N81 SERIES
1
3
2
5
4
Art00930C
NO. PART # PART DESCRIPTION N610 N611 N810 N811*
1 61629722 LAMP BRACKET ASSY X X X X
2 61628922 LAMP-GE#214-2/DC LIGHT BULB X X X X
3 621827 COVER-LAMP BRACKET X X X X
4 61689122 CLIP-THERMISTERMOUNTING/FIN X X X X
5 618548 LAMP THERMISTER WIREASSY X X X X
SERIES
* = N811 SERIES INLUDES THEN814F2 MODEL

N61/N81 SERIES PARTS LIST - PAGE 9
FAN ASSEMBLY PARTS - N61/N81 SERIES
PART # DESCRIPTION N611F N811F N811V
618857 BRACKET-DC FAN 1 1
619016 BRACKET-FAN SUPPORT 1 1
61417922 CABLETIE-NYLON 3 3
618856 FAN-EXTERNAL DC 1
623442 FAN-EXTERNAL DC/HIGH VELOCITY 1
618093 THERMOSTAT-DC FAN/THERMO DISC 1 1
618950 WIRE MOUNT-ADHESIVE 2 2
621943 WIRE-60" (FAN MODELS) 1 1
621431 WIRE-AUXILLARY/BLACK/POSITIVE(+) 1 1
621430 WIRE-AUXILLARY/RED/NEGATIVE(-) 1 1
618700 WIRE-BLACK/24"/18 GA 1 1
618701 WIRE-RED/36"/18 GA 1 1
PART # DESCRIPTION N611F N811F N811V N814F2
618857 BRACKET-DC FAN 1 1 2
619016 BRACKET-FAN SUPPORT 1 1 2
61417922 CABLETIE-NYLON 3 3 3
618856 FAN-EXTERNAL DC 1 2
623442 FAN-EXTERNAL DC/HIGH VELOCITY 1
618093 THERMOSTAT-DC FAN/THERMO DISC 1 1 1
618950 WIRE MOUNT-ADHESIVE 2 2 2
621943 WIRE-60" (FAN MODELS) 1 1 1
628758 WIRE-AUXILLARY/OUTPUT/BLACK 1 1 1
628759 WIRE-AUXILLARY/OUTPUT/RED 1 1 1
628999 WIRE-NEGATIVE/AUXILLARY TO Y CONNECTION 1 1 1
618701 WIRE-RED/36"/18 GA 1 1 1
618978 WIRE-FAN/RED/6"/18 GA/12V 1
619017 WIRE-BLACK/6"/18 GA 1
PART # DESCRIPTION N611F N811F N811V N814F2
628747 BRACKET-DC FAN 1 1 2
61417922 CABLETIE-NYLON 3 3 3
628685 FAN-EXTERNAL DC 1 2
623442 FAN-EXTERNAL DC/HIGH VELOCITY 1
618093 THERMOSTAT-DC FAN/THERMO DISC 1 1 1
618950 WIRE MOUNT-ADHESIVE 2 2 2
621943 WIRE-60" (FAN MODELS) 1 1 1
628758 WIRE-AUXILLARY/OUTPUT/BLACK 1 1 1
NOTE: LOWERFANPOSITION- MODELS WITHSERIAL # 9056492 TO 10086691
NOTE: UPPERFANPOSITION- MODELS WITHSERIAL# ABOVE10086691
NOTE: LOWERFANPOSITION- MODELS WITHSERIAL # BELOW 9056492
628759 WIRE-AUXILLARY/OUTPUT/RED 1 1 1
629883 WIREASSY 111
629882 WIREASSY 111
628690 WIRE-FAN/BLACK 1
629025 WIRE-INPUT/NEGATIVE /NEGATIVE AUXILLARY TO THERM OSTAT 1
618978 WIRE-FAN/RED/6"/18 GA/12V 1
