Nordic ID 811-4A User manual

QUICK GUIDE

1.
2.
13.3.
4.
5.
7.
8.
12.
11.
6.
10.
9.
15.
14.
16.
20.
17.
18.
19.
2
1. EARPHONE
2. DISPLAY
• Colour display with touch
screen
• Select, open or drag-and-
drop GUI objects
• Use as a virtual keyboard to
input text
3. GREEN KEY
• By default OK or Enter
4. SCAN KEY
5. TAB / ALT KEY
6. TELEPHONE KEYPAD /
FUNCTION KEYS
7. BACKSPACE
8. MICROPHONE
9. CHARGING INDICATOR
10. POWER KEY
• If needed, press and hold
for 5 seconds to perform
hardware reset
11. MODE / FUNCTION selection key
Press the Mode/Function key
repeatedly to select one of the
following keypad modes:
• Function: Numeric keys act as
• Function keys F1 to F10
• abc: Numeric keys act as
lower case letters
• ABC: Numeric keys act as
UPPER CASE letters
NORDIC ID MORPHIC
KEY PARTS
Nordic ID Morphic Quick Guide
• 123: Numeric keys act as
numbers
12. ARROW KEYS
• Move cursor within an input
field or to navigate menus.
13. RED key
• By default Cancel or Esc
14. DOCKING CRADLE
15. CHARGER CONNECTOR
16. OPTICAL READER
• 1D laser scanner or 2D image
17. LOUDSPEAKER
• Audible alarms and signals
18. HANDSTRAP
19. BATTERY COVER
20. RFID ANTENNA (OPTIONAL)

1
1
1
2
2
2
3
INSTALLING BATTERY
BATTERY
ATTACHING THE BATTERY
ATTACHING THE BATTERY COVER
Nordic ID Morphic Quick Guide

1
1
1
2
2
2
4
INSTALLING SIM AND MICRO SD CARDS
INSTALLING A SIM CARD
INSTALLING A MICRO SD CARD
The SIM card holder is inside the battery compartment. First remove the battery to access the SIM card holder.
The microSD card holder is inside the battery compartment. First remove the battery to access the microSD card

The AC adapter is shipped with three
exchangeable adapter plugs for EU,
UK, US and China .
Suitable adapter plug has to be
attached onto the AC adapter before
first use:
1. Place the exchangeable adapter
plug to the open end of its
attachment slot on the power
switching unit.
2. Slide the adapter plug along the
grooves of the slot.
3. Press the adapter plug until it is
firmly locked to its place by the
locking clip.
5
RECHARGING BATTERY
HANDSTRAP
ATTACHING THE HANDSTRAP
AC ADAPTER SCANNING DIRECTION
Nordic ID Morphic Quick Guide

1
NOTE
Do not touch the antenna with your 󰘰ngers. Touching the antenna reduces the reading distance!
6
READING RFID TAGS
NORDIC ID MORPHIC UHF RFID
NORDIC ID MORPHIC UHF RFID CROSS DIPOLE
The optimal reading direction with Nordic ID Morphic UHF RFID is forward along the device axis from the top of
the device. The antenna is horizontally linear polarized and provides best performance when the tag polarization is
aligned with the device.
Before using Nordic ID Morphic Cross UHF RFID Dipole for reading TAGs: (1) Turn the foldable antenna as in the
picture below. The optimal reading direction with Nordic ID Morphic UHF RFID Cross Dipole antenna is directly
forward from the antenna along the device axis. The antenna polarization can be software controlled between vertical,
horizontal or cross polarization (default). The chosen polarization, as well as other settings, effect the practical reading
distance.

1
1
2
2
CHARGING THE NORDIC ID
MORPHIC DIRECT WITH THE
POWER SUPPLY
ORANGE: Battery is more than 80 %
charged but still being charged at low
current
RED: Battery is being charged
GREEN: Battery is fully charged
CHARGING
CHARGING THE SPARE
BATTERY AND DOCKED
NORDIC ID MORPHIC
DOCKING THE NORDIC ID
MORPHIC
PLACING THE BATTERY IN
THE CHARGING SLOT
CONNECTING THE POWER
SUPPLY TO THE CRADLE
RED: Spare battery is being charged
GREEN: Spare battery is fully charged
7

Your Nordic ID Morphic contains delicate
electronic parts. Therefore it is vulnerable to
environmental factors such as dirt, extreme
temperatures, humidity and mechanical
stress. Treat your Nordic ID Morphic
with care. The following hints help you to
preserve your device’s functionality and
longevity.
CLEANING
The device can be wiped clean with a damp,
non-abrasive, clean, lint-free cloth.
Do not use harsh chemicals, strong
detergents, or abrasive cleaners to clean
the device.
HANDLING
• Avoid dropping the Nordic ID Morphic,
or bumping it against other objects. Hard
impacts can damage the device. Note that
damages caused by careless handling
are not covered by the warranty.
• The touch sensitive colour display, i.e. the
touch screen, is vulnerable to mechanical
stress. Do not use sharp objects or
excess force on the touch screen.
• Avoid storing the Nordic ID Morphic in
dusty and dirty or extremely humid, cold
or hot conditions. Harsh environmental
factors can shorten the life of electronic
components, damage batteries and warp
or fracture plastics or other mechanical
parts.
• When the Nordic ID Morphic is moved
from a cold environment to a warm
environment, condensation may lead
to a short circuit inside the device.
It is advisable to allow the device to
acclimatise for several hours, after being
brought in from the cold, before powering
up.
• Try to keep your Nordic ID Morphic dry.
Wipe spilled liquids immediately with a
dry, non-abrasive, clean, lint-free cloth.
If moisture gets inside your Nordic ID
Morphic because of condensation or
spillage, open the battery cover and
remove the battery. You may power up
the device again once it has dried. Do not
open the device case. Opening the case
voids the warranty.
• Before using the device, the batteries
must be fully charged. Charging takes
approx. 8 hours.
• The surface of the touch screen is
vulnerable to damage. Do not use a sharp
object or press hard on the surface with
the stylus
CRADLE
The Nordic ID Morphic docking cradle
includes electronics for charging battery,
and for emitting and picking up USB and
Ethernet signals. Therefore the cradle
is vulnerable especially to high and low
temperatures, splashed liquids, and
rough treatment. The following hints help
preserving the docking cradle’s health and
longevity.
Do not use the power supply for any other
purposes than for charging the rechargeable
batteries on the Nordic ID Morphic device or
on the battery charger slot of the cradle.
CARE AND
MAINTENANCE
1.
2.
3.
LAN AND USB
CONNECTIVITY
1. Mini-B (Mini USB)
2. RJ-45 (LAN)
3. Power supply
USB INTERFACE
• Full-speed (12Mbit/s)
• Low-speed (1.5Mbit/s)
• USB socket for Mini-B (Mini USB)
plug
The cradle can be connected e.g. to
PC by means of the USB cable with the
Mini-B connector at the other end.
LAN INTERFACE
• Ethernet 10/100BASE-TX
• LAN socket for RJ-45 plug
The LAN and USB connections can be
used simultaneously. Both connections
are plug-and-play. Your Nordic ID
Morphic LAN interface is set on factory
default settings, and the LAN into
which you have plugged the cradle
provides DHCP service.
8

9
LASER BATTTERY AC ADAPTER
MEDICAL DEVICES
POTENTIALLY EXPLOSIVE
ENVIRONMENTS
SAFETY PRECAUTIONS
Nordic ID Morphic mobile computers,
equipped with 1D laser scanner, are
classi󰘰ed as Class 2 Laser products having
1mW power and 650nm wavelength. The
laser scanner uses a low power, visible
laser diode. As with any very bright light
source, such as the sun, the user should
avoid staring directly into the light beam.
Momentary exposure to a Class 2 laser is
not known to be harmful.
The NORDIC ID Morphic ful󰘰ls the
regulatory requirements as follows:
Complies with 21CFR1040.10 and 1040.11
except for deviations pursuant to Laser
Notice No. 50, dated June 24, 2007.
IEC/EN 60825-1:2007
用错误型号电池更换, 会有爆炸的危险, 务必
按照说明处置用完的电池
Use only the following Varta EasyPack
Recahargeable Li-Polymer 3,7V battery
models being intended for your Nordic ID
Morphic:
• EZPack XL (2260 mAh / 8,4Wh)
• EZPack L (1130 mAh / 4,2 Wh)
Note! Using some other battery type or
model for powering your Nordic ID Morphic
than those mentioned above may cause a
battery explosion.
Do not disassemble the battery.
Do not short circuit the battery’s electrical
contacts.
Do not expose the battery to direct sunlight
or other heat sources.
Dispose the battery in ecologically sound
manner and according to local laws and
regulations.
• Use only AC adapters approved by
Nordic ID. This device is intended for use
with Nordic Power S024EM0520300 AC
adapter.
• Do not use the AC adapter for any other
purposes than for charging the Nordic ID
Morphic rechargeable batteries.
• Check the mains voltage against those
speci󰘰ed in the AC adapter before
plugging to mains socket.
• Use the AC adapter indoors at normal
room temperatures.
To avoid potential interference from Nordic
ID Morphic it shall be operated (, and kept) a
minimum of 20 centimetres (8 inches) from
a medical device such as a pacemaker,
hearing aid, or cardioverter-de󰘰brillator, in
every situation.
Switch o󰘯 your device when in area with
potentially explosive atmosphere. Sparks in such
areas could cause 󰘰re or an explosion. Potentially
explosive environment include areas where the
air contains chemicals or particles such as dust
or other powders. Potentially explosive areas are
often, but not necessarily always, clearly marked.
Obey all signs and instructions.
DANSK LASERLYF! SE IKKE IND I STRÅLEN! KLASSE 2 LASER!
DEUTSCH LASERSTRAHLEN! NICHT DIRECT IN DEN LASERSTRAHL SCHAUEN!
LASER PRODUKT DER KLASSE 2!
ENGLISH LASER LIGHT! DO NOT STARE INTO BEAM! CLASS 2 LASER!
ESPAÑOL LUZ LASER! NO MIRE FIJAMENTE EL HAZ! PRODUCTO LASER DE
LA CLASE 2!
FRANCAIS LUMIERE LASER! NE PAS REGARDER LE RAYON FIXEMENT!
PRODUIT LASER DE CLASSE 2!
ITALIANO LUCE LASER! NON FISSARE IL RAGGIO PRODOTTO!
NEDERLANDS LASERLICHT! NIET IN STRAAL STAREN! KLASSE-2 LASER!
NORSK LASERLYS! IKKE STIRRINN I LYSSTRÅLEN! LASER, KLASSE 2!
PORTUGUÊS LUZ DE LASER! NÃO FIXAR O RAIO LUMINOSO! PRODUTO LASER
DA CLASSE 2!
SUOMI VARO LASERSÄDETTÄ! ÄLÄ SUUNTAA SÄDETTÄ SILMIIN! LASER,
LUOKKA 2!
SVENSKA VARNING LASERSTÅLNING! STIRRA EJ IN I STRÅLEN! KLASS 2
LASER!

10
Les ordinateurs mobiles Nordic ID Morphic,
équipés avec un scanner laser 1D, sont
classi󰘰és comme produit de classe 2 Laser
ayant 1mW de puissance et 650nm de
longueur d´ondes. Le scanner laser utilise
une faible puissance, une diode laser
visible. Comme toute source lumineuse,
comme le soleil, l´utilisateur doit éviter de
regarder directement le rayon laser. Une
exposition momentanée à un produit laser
de Classe 2 n´est pas reconnue comme
dangereuse.
Le NORDIC ID Morphic répond aux
exigences réglementaires suivantes :
Est conforme avec 21CFR1040.10 et
1040.11 excepté pour les déviations
conformément à la notice Laser No 50,
datant du 24 Juin 2007,
IEC/EN 60825-1 :2007
PRECAUTIONS D´UTILISATION
LASER
BATTERIE
Veuillez utiliser la batterie Varta EasyPack
rechargeable Li-Polymer 3,7V, étant le
modèle destiné pour votre Morphic.
EZPack XL (2260 mAh / 8,4Wh).
EZPack L (1130 mAh / 4,2 Wh).
Note: Utiliser d´autres type/modèle de
batteries pour la mise sous tension du
Morphic que ceux mentionnés ci-dessus
peut provoquer l´explosion de la batterie.
Ne pas démonter la batterie.
Ne pas court-circuiter les connecteurs
électriques de la batterie.
Ne pas exposer la batterie directement
au soleil, ou à toutes autres sources de
chaleur.
Veuillez jeter la batterie selon les normes
écologiques en accord avec les autorités
locales et les lois et régulations en vigueur.
ADAPTATEUR AC
• Veuillez utiliser l´adaptateur AC approuvé
par Nordic ID. Cet appareil est destiné
pour l´utilisation avec le Nordic ID Power
S024EM0520300 adaptateur AC.
• Ne pas utiliser l´adaptateur AC pour
tout autre usage que pour rechargé les
batteries rechargeable du Nordic ID
Morphic.
• Véri󰘰er toujours le voltage avec celui
spéci󰘰é sur l´adaptateur AC avant de
brancher ce dernier.
• Veuillez utiliser l´adaptateur AC en
intérieur à température ambiante.
ENVIRONEMENTS POTEN-
TIELLEMENT EXPLOSIFS
Eteignez votre appareil lorsque vous vous
trouvez dans une zone potentiellement
sujette à des explosions. Des étincelles
dans de telles zones peuvent provoquer
un incendie ou une explosion. Les zones
considérées comme potentiellement
explosive inclus les zones ou l´air
contient des produits chimiques ou des
particules, poussières ou tout autres types
de poudres. Les zones potentiellement
sujettes à explosion sont souvent, mais
pas nécessairement toujours, clairement
indiquées. Veuillez obéir strictement aux
signes et instructions.
Pour éviter toutes interférences du Nordic
ID Morphic, celui-ci doit être utilisé (et
conservé) à un minimum de 20 centimètres
(8 pouces) d´un appareil médical tel qu´un
pacemaker, un appareil d´aide auditif
ou d´un dé󰘰brillateur à synchronisation
automatique en toutes situations.
APAREIL MEDICAU

11
COMPLIANCE STATEMENTS
Depending on the markings in the device
label the product is compliant for the
following statements.
CE COMPLIANCE
STATEMENT
Hereby, Nordic ID Oy declares that this
Nordic ID Morphic product is in compliance
with the essential requirements and other
relevant provisions of Directive 1999/5/EC
Dansk Undertegnede Nordic ID Oy erklærer
herved, at følgende udstyr Nordic ID
Morphic overholder de væsentlige krav og
øvrige relevante krav i direktiv 1999/5/EF.
Deutsch Hiermit erklärt Nordic ID Oy,
dass sich das Gerät Nordic ID Morphic in
Übereinstimmung mit den grundlegenden
Anforderungen und den übrigen
einschlägigen Bestimmungen der Richtlinie
1999/5/EG be󰘰ndet.
Español Por medio de la presente Nordic ID
Oy declara que el Nordic ID Morphic cumple
con los requisitos esenciales y cualesquiera
otras disposiciones aplicables o exigibles de
la Directiva 1999/5/CE.
Ελληνική ΜΕ ΤΗΝ ΠΑΡΟΥΣΑ Nordic
ID Oy ΔΗΛΩΝΕΙ ΟΤΙ Nordic ID Morphic
ΣΥΜΜΟΡΦΩΝΕΤΑΙ ΠΡΟΣ ΤΙΣ ΟΥΣΙΩΔΕΙΣ
ΑΠΑΙΤΗΣΕΙΣ ΚΑΙ ΤΙΣ ΛΟΙΠΕΣ ΣΧΕΤΙΚΕΣ
ΔΙΑΤΑΞΕΙΣ ΤΗΣ ΟΔΗΓΙΑΣ 1999/5/ΕΚ.
Français Par la présente Nordic ID Oy
déclare que l’appareil Nordic ID Morphic
est conforme aux exigences essentielles
et aux autres dispositions pertinentes de la
directive 1999/5/CE.
Italiano Con la presente Nordic ID Oy
dichiara che questo Nordic ID Morphic è
conforme ai requisiti essenziali ed alle altre
disposizioni pertinenti stabilite dalla direttiva
1999/5/CE.
Nederlands Hierbij verklaart Nordic ID
Oy dat het toestel Nordic ID Morphic in
overeenstemming is met de essentiële
eisen en de andere relevante bepalingen
van richtlijn 1999/5/EG.
Norsk Nordic ID Morphic er i samsvar med
de grunnleggende krav og andre relevante
bestemmelser i EU-direktiv 1999/5/EF.
Português Nordic ID Oy declara que este
Nordic ID Morphic está conforme com os
requisitos essenciais e outras disposições
da Directiva 1999/5/CE.
Suomi Nordic ID Oy vakuuttaa täten että
Nordic ID Morphic tyypin laite on direktiivin
1999/5/EY oleellisten vaatimusten ja
sitä koskevien direktiivin muiden ehtojen
mukainen.
Svenska Härmed intygar Nordic ID
Oy att denna Nordic ID Morphic står I
överensstämmelse med de väsentliga
egenskapskrav och övriga relevanta
bestämmelser som framgår av direktiv
1999/5/EG.
NATIONAL RESTRICTIONS IN
THE EUROPEAN UNION
When the Nordic ID Morphic device
incorporates an optional 2.4 GHz wideband
transmission system (transceiver), it
imposes some restrictions on the use of its
2.4 GHz WLAN connectivity in France, Italy,
and Latvia where restrictive use applies to
2.4 GHz band.
In Italy the end-user should apply for a
license at the national spectrum authorities
in order to obtain authorization to use the
outdoor WLAN set-ups and/or for supplying
public WLAN access to telecommunications
and/or network services.
The outdoor WLAN set-ups may not be
used in France and in some areas the RF
output power may be limited to 10 mW EIRP
in the frequency range of 2454 – 2483.5
MHz. For detailed information the end-
user should contact the national spectrum
authority in France.
In Latvia the outdoor usage of the 2.4 GHz
band requires an authorization from the
Electronic Communications O󰘲ce.
France Pour la bande 2,4 GHz, la puissance
est limitée à 10 mW en p.i.r.e. pour les
équipements utilisés en extérieur dans
la bande 2454 - 2483,5 MHz. Il n’y a pas
de restrictions pour des utilisations dans
d’autres parties de la bande 2,4 GHz.
Consultez http://www.arcep.fr/ pour de plus
amples détails.
Italy Questo prodotto è conforme alla
speci󰘰che di Interfaccia Radio Nazionali
e rispetta il Piano Nazionale di ripartizione
delle frequenze in Italia. Se non viene
installato all ‘interno del proprio fondo,
l’utilizzo di prodotti Wireless LAN richiede
una “Autorizzazione Generale”. Consultare
http://www.comunicazioni.it/it/ per maggiori
dettagli.
Latvia 2,4 GHz frekveču joslas izmantošanai
ārpus telpām nepieciešama atļauja no
Elektronisko sakaru direkcijas. Vairāk
informācijas:
http://www.esd.lv.

12
FCC COMPLIANCE
STATEMENT
This hand-held device complies with part 15
of the FCC Rules. Operation is subject to
the following two conditions: (1) This device
may not cause harmful interference, and (2)
this device must accept any interference
received, including interference that may
cause undesired operation.
Changes or modi󰘰cations not expressly
approved by the party responsible for
compliance could void the user’s authority
to operate the hand-held equipment.
FCC COMPLIANCE NOTICE
NOTE: This equipment has been tested and
found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide
reasonable protection against harmful
interference in a residential installation.
This equipment generates, uses, and can
radiate radio frequency energy and, if not
installed and used in accordance with the
instructions, may cause harmful interference
to radio communications. However, there
is no guarantee that interference will not
occur in a particular installation. If this
equipment does cause harmful interference
to radio or television reception, which can
be determined by turning the equipment
o󰘯 and on, the user is encouraged to try to
correct the interference by one or more of
the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the
equipment and receiver.
Connect the equipment into an outlet on
a circuit di󰘯erent from that to which the
receiver is connected.
Consult the dealer or an experienced radio/
TV technician for help.
IC COMPLIANCE STATEMENT
This hand-held device complies with
Canadian radio regulation.
Operation is subject to the following two
conditions: (1) This device may not cause
harmful interference, and (2) this device
must accept any interference received,
including interference that may cause
undesired operation.
Changes or modi󰘰cations not expressly
approved by the party responsible for
compliance could void the user’s authority
to operate the hand-held equipment.
To prevent radio interference to the licensed
service, this device is intended to be
operated indoors and away from windows
to provide maximum shielding. Equipment
that is used outdoors is subject to licensing.
RF EXPOSURE STATEMENT
This equipment complies with EU, FCC and
IC’s RF radiation exposure limits set forth
for an uncontrolled environment under the
following conditions:
1. This equipment should be installed and
operated such that a minimum separation
distance of 20cm is maintained between the
antenna and user’s/nearby person’s body at
all times.
2. This equipment must not be co-located
or operating in conjunction with any other
antenna or transmitter.
THE PICTURE SHOWS THE SAFE WAY
TO HANDLE THE DEVICE.
ETL LISTED
CONFORMS TO UL STD 60950-1
CERTIFIED TO CAN/CSA STD C22.2 NO.
60950-1
В PОССЙИ
ГОСТ Р
СЕРТИФИКАТ СООТВЕТСТВИЯ В
СИСТЕМЕ ГОСТ Р
Устройство обработки информации:
компьютер портативный Nordic ID Morphic
удостоверен сертификатом соответствия
ГОСТ Р № POCC FI.AГ23.B04078, срок
действия с 27.12.2011 до 26.12.2012,
выдан органом по сертификации
продукции «ТЕСТМАКС» (ООО «Бизнес
аспект»), РОСС RU.0001.11AГ23.
4004039
ETL LISTED

13
IMPORTANT – READ CAREFULLY
THIS END USER LICENSE
AGREEMENT (“Licence Terms”)
BEFORE INSTALLING OR USING
THE SOFTWARE.
By using the Device on which Software
is installed, You agree to be bound
by the terms of the Licence Terms,
including the warranty disclaimers and
limitations of liability provisions below.
If You do not agree to the Licence
Terms, You may not use the Device or
install the Software. Instead, promptly
contact the reseller You purchased the
Device from for instructions on return
of unused Device(s) for a refund. ANY
INSTALLATION OR USE OF THE
SOFTWARE OR THE DEVICE ON
WHICH SOFTWARE IS INSTALLED
INDICATES YOUR AGREEMENT TO
BE BOUND BY THE CONDICTIONS
OF THE LICENCE TERMS (OR
RATIFICATION OF ANY PREVIOUS
CONSENT).
DEFINITIONS
“Device” means the Nordic ID
equipment You acquired from Nordic
ID or one of its resellers and on which
the Software was pre-installed or onto
which it is to be installed.
“Software” means the computer
program(s) licensed and installed
on the Device and/or any Revisions
thereto. Software may include
computer programs made by Nordic
ID as well as operating systems and
application programs by third party
licensors or other software suppliers.
The Software includes any disks or
media on which it is recorded and any
Documentation.
“Documentation” means the materials
accompanying the Software which
describe its functions and how to install
and use the Software.
“Revision” means any correction,
modi󰘰cation, update, enhancement,
or new version of the Software or
Documentation whether printed or in
electronic format (including but not
limited to on-line documentation).
“You” or “Your” refers to the end user
licensed to use the Software under this
EULA.
“Nordic ID” means Nordic ID Oy, a
company incorporated in Salo, Finland
PROPRIETARY RIGHTS AND
LICENSE
You agree that the Software constitute
trade secrets and/or copyrighted
material of Nordic ID, its licensors, or
other software suppliers. All rights,
title and interest in and to the Software
(including, without limitation, any
images, photographs, animations,
video, audio, music, text, and applets
incorporated into the Software, the
accompanying media and printed
materials), and any copies of the
Software are owned by Nordic ID, its
licensors or other software suppliers.
You acknowledge and agree that
nothing in this EULA gives You any
right, title or interest in and to the
END USER LICENSE AGREEMENT
Software except the limited rights
expressly granted herein. You agree
to maintain and reproduce all copyright
and other proprietary notices of
Software.
Nordic ID hereby grants You a license
to use the Software subject to the
following terms and conditions:
Unless expressly provided in the
Documentation, You may use the
Software only as embedded in, for
execution on, or (where the applicable
Documentation permits installation
on non-Nordic ID equipment) for
communication with Device. You have
no right to use Revisions unless You,
at the time of acquiring such Revision
hold a valid license to the original
Software and have paid the applicable
license fees (if any)
The Software is licensed, not sold.
Nordic ID hereby grants You a non-
exclusive, terminable, limited license to
use the Software on the Device(s) for
Your own internal business purposes
subject to payment of applicable
license fees (if required). No other right
or license is granted or implied. You
agree not to modify copy, distribute
or otherwise disclose the Software
without the prior written consent of
Nordic ID. You further agree not to
reverse engineer, disassemble, or
de-compile the Software, except and
only to the extent that such activity is
expressly permitted by applicable law
notwithstanding this limitation. This
license shall terminate when You no
longer own or You cease to use the

14
Device(s) on which You are licensed
to use the Software. Your rights to the
Software do not include any license,
right, power or authority to subject the
Software in whole or in part to any of
the terms of an Excluded License.
“Excluded License” means any license
that requires as a condition of use,
modi󰘰cation and/or distribution of
Software subject to Excluded License,
that such Software of other software
combined or distributed with such
software be a) disclosed or distributed
in source code form; b) licensed for the
purpose of making derivative works; or
c) redistributable at no charge
You may not sell, lease, rent, assign,
sublicense or transfer the Software
except that You may transfer all of
Your rights under this EULA as part of
a sale or transfer of the Device(s). Such
a sale or transfer may only be made if
You retain no copies of the Software,
You transfer all of the Software
(including any media, archival copies,
Revisions and Documentation) and the
recipient agrees to abide by the terms
of this EULA. A Revision may not be
transferred unless You transfer all prior
versions of the Software. In the event
of any such transfer, You shall remain
liable and responsible to Nordic ID for
the performance of all of Your duties
and obligations under this EULA.
You agree to grant Nordic ID and its
independent accountants the right to
examine Your books, accounts and
records to verify compliance with this
EULA. In the event such an audit
reveals non-compliance, You shall
promptly sustain compliance and pay
Nordic ID the applicable license fees
(if any)
DISCLAIMER OF WARRANTY
AND LIMITATION OF LI-
ABILITY
The software is not fault tolerant and
is not designed, manufactured or
intended for any use requiring fail-safe
performance in which the failure of
Software could lead to death, serious
personal injury, severe physical or
environmental damage (“High Risk
Activities”). This includes the operation
of aircraft, aircraft navigation or
communication systems, direct life
support machines or weapons systems
or nuclear facilities. Use of Device in
High Risk Activities is not licensed.
The Software is not warranted to be
compatible with all applications or
environments. Contact the reseller You
purchased the Device for information
about hardware and/or software
compatibility.
NO WARRANTIES FOR THE
SOFTWARE. THE SOFTWARE IS
PROVIDED AS IS AND WITH ALL
FAULTS. NORDIC ID, ITS LICENSORS
AND OTHER SOFTWARE
SUPPLIERS DISCLAIM ANY AND ALL
PROMISES, REPRESENTATIONS,
AND WARRANTIES WITH RESPECT
TO THE SOFTWARE, INCLUDING
ITS CONDITION, ITS CONFORMITY
TO ANY REPRESENTATION OR
DESCRIPTION, THE EXISTENCE
OF ANY LATENT OR PATENT
DEFECTS, ANY NEGLIGENCE
AND ITS MERCHANTABILITY OR
FITNESS FOR A PARTICULAR USE
OR NON-INFRINGEMENT. THE
ENTIRE RISK WITH RESPECT TO
THE SOFTWARE IS WITH YOU.
IF YOU HAVE RECEIVED ANY
WARRANTIES REGARDING THE
SOFTWARE, THOSE WARRANTIES
DO NOT ORIGINATE FROM, AND
ARE NOT BINDING ON, NORDIC ID,
ITS LICENSORS OR ITS SOFTWARE
SUPPLIERS.
EXCEPT AS PROHIBITED BY LAW,
NEITHER NORDIC ID NOR ANY
OF ITS SOFTWARE SUPPLIERS
SHALL HAVE ANY LIABILITY FOR
ANY DIRECT, INDIRECT, SPECIAL
CONSEQUENTIAL OR INCIDENTAL
DAMAGES ARISING FROM OR
IN CONNECTION WITH THE USE
OR PERFORMANCE OF THE
SOFTWARE. THIS LIMITATION
SHALL APPLY EVEN IF ANY REMEDY
FAILS OF ITS ESSENTIAL PURPOSE.
IN NO EVENT SHALL NORDIC
ID OR NORDIC ID’S SOFTWARE
SUPPLIERS BE LIABLE FOR ANY
AMOUNT IN EXCESS OF THE INITIAL
LICENSE FEE NORDIC ID RECEIVED
FROM YOU FOR THE NORDIC ID
DEVICE IN THE CASE OF NORDIC ID
OR U.S. TWO HUNDRED AND FIFTY
DOLLARS (U.S. $250.00) IN THE
CASE OF NORDIC ID’S LICENSORS
OR SOFTWARE SUPPLIERS.

15
TERMINATION
Nordic ID, its licensors and its software
suppliers reserve the right to terminate
this EULA if You violate any term or
condition of this EULA. If You assert
any claims against Nordic ID, its
licensors or software suppliers over
patents that You think might apply to
Software (including a cross-claim or
counterclaim in a lawsuit) Your license
to the Software ends automatically.
In the event of termination, You must
stop using the Software and You shall
immediately return to Nordic ID, all
Software and any copies thereof and
related Documentation and certify
to Nordic ID that You have done so.
The provisions of this paragraph of
this EULA and any other material
provisions of this EULA shall survive
any termination of this EULA.
GENERAL PROVISIONS
You agree that You will not export or
import any portion of the Software to
any country that is not party to either:
(i) The Berne Convention of 1989, (ii)
The Universal Copyright Convention,
(iii) The Buenos Aires Convention,
or (iv) a treaty with the United States
of America (U.S.A.) which allows for
the recognition of the property rights
claimed by Nordic ID or its licensors
and other software suppliers in the
Software. Further the Devices are
subject to United States and European
Union export laws and regulations.
You agree to comply with all domestic
and international export laws and
regulations that apply to the Devices.
These laws include restrictions on
destinations, end users and end
use. U.S. Government Restricted
Rights. If the Device or the Software
is acquired under the terms of a U.S.
Government contract, use, duplication,
and disclosure are subject to the terms
of this license and the restrictions
contained in the Rights in Technical
Data and Computer Software clause
at 252.227-7013 (DOD contracts); and
subdivisions (a) through (d) of 52.227-
19 as applicable.
This EULA shall be governed by and
construed under the laws of Finland.
Any dispute arising out of this EULA
shall be 󰘰nally settled in arbitration by
a sole arbitrator in accordance with
the Arbitration Rules of the Central
Chamber of Commerce, in Turku,
Finland and in English language.
However Nordic ID shall be entitled to
seek injunctive relief in a competent
court. Nordic ID may assign this EULA
without the consent of You. If any
portion hereof is found to be void or
enforceable, the remaining portions
of this Agreement shall remain in full
force and e󰘯ect. Except as expressly
provided herein, this Agreement
constitutes the entire agreement with
respect to the license of Software and
supersedes any con󰘱icting or additional
terms.
© Nordic ID Oy, 4/2012

www.nordicid.com
EU DIRECTIVE
2002/96/EC ON WASTE
ELECTRICAL AND
ELECTRONIC
EQUIPMENT (WEEE)
LASER RADIATION
DO NOT STARE INTO BEAM
CLASS 2 LASER
S&E
NORDIC ID
Myllyojankatu 2 A
24100 SALO, FINLAND
tel. [phone]
fax [phone]
www.nordicid.com
SUPPORT
https://support.nordicid.com/extranet/
HEADQUARTERS
[email protected]
phone: [phone]
UK & NORTHERN IRELAND
[email protected]
phone: [phone]
GERMAN SPEAKING COUNTRIES
[email protected]
phone: [phone]
REPAIR
This device has a two year limited warranty.
Nordic ID provides repair services for its products during
and after their warranty period. Nordic ID serves customers
together with its full support and primary support partners
throughout Europe. The full support centers handle both
warranty and non-warranty repair services on behalf of
Nordic ID in the countries they are located in. In addition
Nordic ID has a growing network of primary support
partners, who offer the first line of support to their local
customers.
Contact details of all repair centers can be found at www.
nordicid.com
For any enquiries about Nordic ID repair services please
contact:
[email protected] or [phone]
V1001
