Nordmende BravoFIT BF100HR User manual
EN
SMARTBAND
USER GUIDE
BF100HR
Chapter 1 GENERAL INFORMATION.................................4
Introductions and note .............................................5
What is a smartband( FITNESS bracelets) ..............6
Pedometer,Mileage and heart rate .......................... 7
Chapter 2 How to wear ..................................................10
Chapter 3 Battery charging ............................................ 12
Chapter 4 APP download ...............................................13
Chapter 5 Power ON/OFF & Display ................................ 14
Chapter 6 APP manage with smartphone ......................15
startup ...........................................................................16
personal informations ...............................................18
Pedometer and mileage ............................................ 22
Sleep ..............................................................................24
Heart rate ......................................................................26
Contents
USER MANUAL page 2
Chapter 7 SAFETY...........................................................28
Safety precautions .........................................29
Use warnings..................................................30
Chapter 8 TECHNICAL SPECIFICATIONS .......................... 33
Chapter 9 WARNINGS ..................................................... 34
Chapter 10 WARRANTY .....................................................36
Legal warranty ...............................................36
Company warranty......................................... 37
Declaration of conformity ..............................39
USER MANUAL page 3
Initial setup
USER MANUAL page 4
CAPITOLO 5
Chapter 1
USER MANUAL page 5
INTRODUCTION
Thank you for choosing the BravoFIT BF100HR
Please read this manual carefully so you can use the device in
the best way, and keep it for future use.
IMPORTANT: Some features may not be available on all
models on the market
Package Contents:
- Fitness bracelet
- USB Charging Cable (charging adapter NOT in the box, you can
use what you have with your smartphone)
- Quick setup manual
- Safety and warranty guides
NOTE: Lithium polymer battery already included in the
bracelet; Non-removable and non-replaceable battery if not at
an authorized repair center
Http://www.nordmende-phones.it/ supporto
Any attempt to remove the battery will invalidate the
warranty.
This device is not a medical device and can not be applied
to any medical function; This device is designed and in-
tended solely for fitness intended as amateur practice
What is a FITNESS bracelet?
Basically, a smartband, also known as the FITNESS bracelet, is
nothing more than a bracelet designed to track your daily physi-
cal activity.
In fact, once worn on the wrist, it records all your movements and
saves them and then displays them on the smartphone display
with the help of a dedicated APP that you can download for free
via your device’s store,
ANDROID and / or IOS.
In order to make the most of a FITNESS bracelet, commonly
known as smartband, it is used to connect to a mobile device
(SMARTPHONE), which has a large display and a more useful
memory to keep track of your movements and all the other
measurements.
Bluetooth technology is used as a means of communicating
information from the FITNESS bracelet to the smartphone and
vice versa
The connection to and from the smartphone takes place through
a dedicated APP, available on ANDROID and APPLE
NOTE:
( Apple and Apple logo are a trademark of Apple Inc, registered in
the U.S. and other countries.
App Store is a trademark of service of Apple Inc..
Google Play and the Google Play logo are trademarks of Google
Inc.)
USER MANUAL page 6
CAPITOLO 5
Chapter 1
There are certainly various types of smartband, from the simplest
to just counting the steps, the most complex ones, who also
take into account burned calories, sleep cycles, read heart rate,
and receive notifications (calls, SMS and more) from your smart-
phone, below a few examples(Some features listed may not be
available on all commercial models):
• Date and time
• Count calories
• Pedometer
• Distance
• Sleep monitoring
• Heart rate
• Blood pressure (not on BF100HR)
• Blood oxygenation (not on BF100HR)
How it works
steps counter (Pedometer)
The operating principle of the pedometer is as follows:
The bracelet has incorporated a “gyroscope” inside, when the end
user wears the bracelet and starts to move, for example, the gyro
vibrates (unknowingly) and generates a waveguide.
Several movements will produce dierent waveforms.
An algorithm identifies a specific number by identifying and
recognizing the action that generates a fixed waveform;
USER MANUAL page 7
USER MANUAL page 8
Chapter 1
Plus the sw is skilled in recognizing the dierence between a
real step and for example liing the arm or arm movement while
driving, and the more the result will be accurate
(NOTE: These devices are not used for professional sports
activities but must be considered useful for purely amateur
purposes)
Measurement Km routes:
The operating principle of Km reading is as follows:
The distance traveled is based on the number of steps.
The average pitch multiplied by number of steps = distance.
The user fill his or her personal data into the smartphone ap-
plication such as sex, age, height, weight, and more
The more data entered are accurate, the more the algorithm
will be accurate and will give a better result.
This is because the average pitch is very dierent from person to
person, and the above data are identifying the dierence.
The application’s sw performs a calculation and monitors the KM
paths on the bracelet screen if provided on the application itself.
CAPITOLO 5
CAPITOLO 3
Heart Rate Measurement
Calculation of heart rate is taking into account the volume of arte-
rial blood, taking advantage of the fact that an increase in heart
rate is associated with an increase in blood volume.
The technology used by optical sensors used in heart rate FITNESS
bracelets is photopletismography (PPG) that records changes in
the volume of blood through the skin’s light absorption variations.
In other words, light diuses in tissues dierently based on chang-
es in hemodynamic fluxes.
The optical sensor consists of 2 LEDs that send light waves to the
body.
The FITNESS bracelet processor captures the portrayed light and
translates it into the heart rate of the person.
These values are then sent to the bracelet display (if available )
and to the application installed on the smartphone, where real-
time and / or statistical measurements will be highlighted during
the day
Algorithms can also give more information about consumed calo-
ries, blood pressure, and blood oxygenation.
NOTE: This device is not a medical device and can not be ap-
plied for any medical function, the read values are considered
for purely amateur purposes
USER MANUAL page 9
Chapter 2
How to wear
USER MANUAL page 10
Strap Device
Open the package and pull out the device and the strap
Insert, as per image, the device in the strap
USER MANUAL page 11
ulnar styloid
Wear the FITNESS bracelet near the ulnar styloid (wrist) as
shown above
Hook the FITNESS bracelet with care not to tighten too
much, ensuring air passage, like a normal watch
USER MANUAL page 12
CAPITOLO 5
Chapter 3
Battery charging
In order to recharge the battery of the FITNESS bracelet:
• Remove the cu from the wrist
• Use the cable with the clamp in the package and place it on the
copper contacts on the rear side (fig1)
• The cable must then be connected to a USB charging adapter
(NOT in BOX)
• you can use the battery charger that you normally use with your
smartphone
• On the bracelet display, the battery icon starts blinking until the
recharge is completed
Fig.1
Lithium polymer battery already included in the bracelet; Non-
removable and non-replaceable battery if not at an authorized repair
center (go to http://www.nordmende-phones.com/ support
Any attempt to remove the battery will invalidate the warranty.
Copper contacts
USER MANUAL page 13
CAPITOLO 5
Chapter 4
APP download
In order to manage data from the FITNESS bracelet, you must install
the Bracelet APP on your Smartphone
“BravoFIT”
• Smartphone connection:
1. Ensure that the bracelet is on (Power on button is on the le side)
and verify battery is charged
2. Download and run APP on your phone (make sure that Bluetooth on
your phone is switched on)
3. Go to settings (top le button)> Device Search> Scroll down to the
“Scan” entry
4.Select relevant Bracelet , a dialog box informs you that the associa-
tion is in progress: repeat the procedure if there is a problem (Tip:
move to an area where no other BT devices are available, the name of
the bracelet May not match the commercial name)
5.Use the upper le arrow to return to the main menu
When connected to the
display, you see the cor-
rect date and time (based
on the smartphone) ,
see figure
CAPITOLO 5
Chapter 5
USER MANUAL page 14
Power on/o & display
• Power on FITNESS bracelet:
1. Make sure the battery is charged
2. Press and hold the power button on the side (the cu vibrates)
for about 3 seconds, see figure below
on/o Key
Date&time Pedometer
Mileage( KM)
Heart rate
NOTE :
Once bracelet is on , by quick press of same button, the screens
below will be displayed sequentially
CAPITOLO 5
CAPITOLO 6
USER MANUAL page 15
Chapter 6
APP management with smartphone
Using smartphone APP with the FITNESS bracelet:
1. Download and launch APP on your smartphone, see Chapter 4
2.The following screen displays the various screens and functions
available on the APP called “BravoFIT”
Note: NOT all bracelets have the same functions, some indicated
on the following pages may not be available on your bracelet
USER MANUAL page 16
CAPITOLO 5
CAPITOLO 6
Chapter 6
APP management with smartphone
The following two pages have four initial synthesis screens,
suggesting various actions that will follow (you do not need to
enter now):
Fig. 1) recording of moving data
Fig. 2) Recording of sleep data
Fig. 1
Fig. 2
USER MANUAL page 17
Fig. 3) Entering personal data (birth year, height, weight, sex, name,
photo)
Fig. 4) Various tips
Fig. 4
Fig. 3
USER MANUAL page 18
CAPITOLO 5
CAPITOLO 6
Chapter 6
APP management with smartphone
To access the Settings> Personal Information menu, press the button
on the top le, which you can see in Figure 10 of pag22.
Enter your personal information (birth year, sex, height, weight, name,
photo, step goal and metering system
Tip: Enter your data in a very accurate way to ensure that read-
ings are as accurate as possible
Tap here to enter
personal image
Tap here to enter
name
Tap here to en-
ter metric system
(Km, kilograms) Or
English(Pounds,
etc.)
Tap here to enter
weight
Tap here to enter
the height
Tap here to enter
age
Tap here to enter
your sex, male,
female
Tap here to enter your goal
daily steps, normally 10000
steps
Fig. 5
USER MANUAL page 19
Tap here to view application
firmware data and more,
including factory data reset
Tap here to take a
picture with your
smartphone by wrist
movement
Tap here to enable or
disable bracelet notifica-
tions, such as Incoming
Call, SMS, Facebook, and
add few more personal,
example WhatsApp
(Fig 9 )
Tap here for alarms,
warnings and more on
your bracelet(Fig 8)
Tap here to bind
FITNESS bracelet (Fig7)
Tap here to enter
personal informations
( Fig.5)
Fig. 6
Tap here to exit
from APP
USER MANUAL page 20
CAPITOLO 5
CAPITOLO 6
Chapter 6
APP management with smartphone
Fig. 8
This screen show how you can as-
sociate a FITNESS bracelet with the
APP “BravoFIT”.
NOTE: The name of the bracelet
model to associate may not match
the commercial name, and it is
recommended that you search the
site in an isolated location and still
disable other Bluetooth devices in
the area
This screen show you can turn on
or o some alarms (such as loss
notice, or excessive seating alert);
You can also run a bracelet research
test as a connection check (find
bracelet)
Table of contents
Other Nordmende Watch manuals
