Norlake NSPF241WWW User manual

Nor-Lake ScieNtific
Premier freezerS
Standard Product Features:
■ Digital LED microprocessor with audible and visual Hi/Lo
alarm
■ Adjustable control range from -10°C to -25°C factory preset
to -25°C
■ Exterior front, sides, back and doors are white baked on
enamel
■ Exterior top and bottom are galvanized steel
■ Interior liner and interior door panel are painted
white
■ The complete cabinet is foamed-in-place with
high density polyurethane foam insulation
■ Heavy duty, pivot hinges and pull handles
■ Magnetic door gaskets
■ Key door lock(s)
■ Four casters on one and two door models (2 locking) and
six casters (3 locking) on three door model
■ 3 epoxy coated shelves per door section
■ Complete perimeter anti-condensate door
opening heater wires
■ Interior light, switch activated
■ Thermostatic expansion valve system
■ Forced air ow refrigeration optimizes air
ow and temperature uniformity
■ Air-cooled condensing unit
■ Automatic defrost
■ Warranties: 18 months parts and labor
5 year compressor (US and Canada)
18 months parts (International)
■ UL and C-UL LISTED, Energy Star, CEC
California Energy Commission
Optional Features:
■ Temperature chart
recorder
■ Chart Paper
■ Extra shelves
■ Legs in lieu of casters
■ Stainless steel exterior
■ Stainless steel interior
■ Reverse door hinge
Nor-Lake, Inc.
Registered to ISO 9001:2000
File No. A3204
NOR-LAKE SCIENTIFIC
A Division of
NOR-LAKE, INCORPORATED
727 Second Street
P.O. Box 248
Hudson, Wisconsin 54016
800-477-5253
715-386-2323
800-388-5253 PARTS
715-386-4290 FAX
www.norlake.com
Designed to meet the demanding requirements
of scientic and laboratory applications.
Special cabinet incorporates industrial quality
with a heavy duty refrigeration system to
maintain your valuable products.
NSPF331WWW/
NSPF241WWW/ NSPF331WWW/ NSPF522WWW/ NSPF803WWW/
■ Stainless steel drawers
up to 8 per door section
■ 4-20 ma output with
remote alarm contacts
SCIENTIFIC

SPECIFICATIONS
Models NSPF241WWW/0 NSPF331WWW/0 NSPF522WWW/0 NSPF803WWW/8
Models NSPF241WWW/5 NSPF331WWW/5 NSPF522WWW/5 NSPF803WWW/5
Crated Height 83-3/4” (212.7 cm) 91-3/4” (233.0 cm) 83-3/4” (212.7 cm) 83-3/4” (212.7 cm)
Crated Width 38” (96.5 cm) 35-1/4” (89.5 cm) 59” (149.9 cm) 86” (218.4 cm)
Crated Depth 40” (101.6 cm) 39” (99.1 cm) 40” (101.6 cm) 38” (96.5 cm)
Crated Weight (lbs) (kg) 375 (170.1 kg) 439 (199.5 kg) 590 (268.2 kg) 805 (365.1 kg)
Interior Height 59” (149.9 cm) 67” (170.2 cm) 59” (149.9 cm) 59” (149.9 cm)
Interior Width 23-1/2” (59.7 cm) 27-3/4” (70.5 cm) 51” (129.5 cm) 78-1/2” (199.4 cm)
Interior Depth 30” (76.2 cm) 31” (78.7 cm) 30” (76.2 cm) 30” (76.2 cm)
Overall Height 80-3/8” (204.2 cm) 88-3/8” (224.5 cm) 80-3/8” (204.2 cm) 80-3/4” (204.2 cm)
Overall Width 27-1/2” (69.9 cm) 31-3/4” (80.6) 55” (139.7 cm) 82-1/2” (209.6 cm)
Overall Depth 34-7/8” (88.6 cm) 35-7/8” (91.1 cm) 34-7/8” (88.6 cm) 34-7/8” (88.6 cm)
Gross Cubage (ft.3) (m3) 24.0 (0.68) 33.1 (0.94) 52.0 (1.47) 80.0 (2.26)
Shelf Area (sq. ft.) (m2) 12.83 (1.19) 15.85 (1.47) 28.6 (2.66) 42.84 (3.98)
Number of Shelves 3 3 6 9
Number of Casters 4 4 4 6
Condensing Unit Size 1/2 1/2 3/4 1
Refrigerant R-404A R-404A R-404A R-404A
Maximum Fuse Size 15 20 20 15
Total Amp Draw /0 & /8 9.7 12.3* 12.4* 7.8
Total Amp Draw /5 5.2 5.9 8.96 6.49
Specications subject to change without notice.
NSPF241WWW/
NSPF241WWW/
NSPF803WWW/
NSPF522WWW/
FRONT SIDE
NSPF331WWW/
NSPF522WWW/ NSPF803WWW/
NSPF331WWW/
Voltage Model
Sufx Code
Voltage
Description
NEMA
Plug
NEMA
Receptacle
/0 115V, 1PH, 60HZ 5-15P 5-15R
/0* 115V, 1PH, 60HZ 5-20P 5-20R
/5 230V, 1PH, 50HZ Power Inlet
(IEC 60320) Module
Cord Supplied
Locally
/8 115/208-230V/1PH60HZ L14-20P L-14-20R
TOP
Revision Date: 12/06
© 2006 NOR-LAKE, INC.
Printed in the U.S.A.
Part Number: 073276
SCIENTIFIC
