Normande AFL012US User manual

End Table Floor Lamp
148mmL x 210mmD
Instructions
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY BEFORE FIRST USE.
AAIN005013
This lamp must be assembled before use.
Please take a moment to read these
instructions before attempting assembly.
Assembly Instructions
1. Lay out all parts on smooth surface
as shown in illustration.
2. Screw post (B) onto the base (A)
and tighten.
3. Slide main cable through post (C) and
attach post (C) onto post (B).
Fix in place using the Allen key and 2 grub
screws provided.
4. Attach the connector cable from post (D)
to post (C)
Screw post (D) onto post (C) and tighten.
5. Screw in max 25 Watt bulb into socket.
6. Screw shade (E) on to the lamp holder,
fixing in place by rotating in a counter
clockwise direction.
7. Plug into outlet and turn on via the 3-way
dimmable touch switch and enjoy.
Suitable Bulbs
Each socket accepts dimmable bulbs of
E26 base to a maximum rating of 25W.
Recommend 25W A15 E26 dimmable
incandescent or 8W A15 E26 dimmable LED
or smaller bulbs.
AFL012US
4a
AAIN005013
A
B
C
E
D
Bulb
Touch
Switch Wireless Charger

LIMITED ONE YEAR WARRANTY
This limited warranty gives you specific legal rights, and you may have other legal rights that vary from state to state.
Arlec America LLC (Arlec America) warrants this lamp to be free of defects in workmanship and materials for one year from date of purchase (the
“Warranty Period”). ALL IMPLIED WARRANTIES, INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE,
ARE HEREBY LIMITED TO THE DURATION OF THE WARRANTY PERIOD. Some states do not allow limitations on how long an implied warranty lasts, so
the above limitation may not apply to you.
This warranty does not cover damage to this lamp resulting from misuse, accident, abuse, transportation, storage, failure to follow our instructions,
modifications, unauthorized repair, normal wear and tear, or any actions or events beyond our reasonable control.
If this lamp does not conform to this limited warranty and, prior to the expiration of the Warranty Period, you may return this lamp to us as provided below,
Arlec America will replace this lamp. To receive such replacement, simply mail this lamp to us at the address set forth below, postage paid, and indicate
the reason for the lamp’s return and the address to which the replacement lamp should be shipped. We will pay the cost to ship the replacement lamp
back to you at any location within the lower 48 states of the U.S.A. If the location to which you request that we ship the replacement lamp is outside of
the lower 48 states, we will ship the replacement lamp only after we have invoiced you, and you have paid, for the cost of shipping.
Please include sales receipt with your correspondence. Mail to: Arlec America LLC. 18437 Cascade Ave. South Tukwila, WA.98188, U.S.A.
Be sure to wrap your unit securely before mailing!
Note: Arlec America makes no warranty whatsoever for any incandescent light bulbs, high intensity bulbs or fluorescent tubes supplied with or used
with the lamp. These bulbs and tubes are not manufactured by Arlec America. The warranty extends only to the consumer who originally purchased
this lamp (“you”). It does not extend to any subsequent owner or other transferee of this lamp, nor does it extend to any replacement lamp. Because
small electrical appliances do not lend themselves to normal repair procedures, the consumer should not attempt such repairs.
THE REMEDIES DESCRIBED ABOVE ARE YOUR SOLE AND EXCLUSIVE REMEDIES AND OUR ENTIRE LIABILITY FOR ANY BREACH OF THIS LIMITED
WARRANTY. OUR LIABILITY SHALL UNDER NO CIRCUMSTANCES EXCEED THE ACTUAL AMOUNT PAID BY YOU FOR THE DEFECTIVE PRODUCT, NOR
SHALL WE BE LIABLE FOR ANY CONSEQUENTIAL, INCIDENTAL, SPECIAL, OR PUNITIVE DAMAGES OR LOSSES, WHETHER DIRECT OR INDIRECT.
SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION OR
EXCLUSION MAY NOT APPLY TO YOU.
Warranty
Instructions
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY BEFORE FIRST USE.
AAIN005013
To Fit / Change the Bulb
• To fit bulb, screw bulb into socket.
Do not force.
• Before changing a bulb, switch off; disconnect
the plug and let it cool for at least 10 minutes.
Unscrew from the socket.
• Replace it with a bulb of any of the types
recommended.
USB Charger
Lamp comes with USB output for charging mobile
devices. Maximum output 10.5W 5Vdc 2.1A.
Wireless Charger
Lamp comes with wireless charger for charging
compatible devices. maximum output 5Vdc 1amp.
To charge device place it on top of the wireless
charging symbol engraved on the table top.
Instructions For Use and Care
1. Place the lamp on a stable surface in
a dry location.
2. Use the lamp indoors only.
3. Keep out of the reach of young children and pets.
4. To control the lamp, operate the 3-way dimmable
touch switch on the table top.
5. WARNING!
The lamp will get hot in use, avoid contact with the
hot lamp, especially direct contact with the bulb.
6. Use only E26 bulbs of type and rating as
recommended above.
7. To clean the lamp use a clean dry cloth.Wait 10
minutes after disconnecting to allow time to cool.
8. The electrical parts can only be serviced by
a qualified tradesman, in compliance with
standards/specifications.
9. If the supply cord is damaged it should be replaced
by the manufacturer or his service agent or a
similar qualified person in order to avoid a hazard.

FCC STATEMENT
1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause undesired operation.
2. Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to
operate the equipment.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
—Consult the dealer or an experienced radio/ TV technician for help.
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. In order to avoid the
possibility of exceeding the FCC radio frequency exposure limits。
Human proximity to the antenna shall not be less than 20cm (8 inches) during normal operation
The equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
During the operation of device a distance of 15 cm surrounding the device and 20 cm above the top
surface of the device must be respected.
