Novatech CHEM-TECH XPV Instruction manual

REV. E PN J63091 - 1 -
XPV Peristaltic Pump Installation, Operation
and Maintenance Manual
Tested and Certified by WQA
against NSF/ANSI 61-Section 8.
and CSA B483.1
[e-mail]
www.novatech-usa.com
Tel: [phone] Fax: [phone]
Tel: [phone] Fax: [phone]

REV. E PN J63091 - 2 -
TABLE OF CONTENTS
1. Introduction....................................................................................................3
2. Safety Instructions.........................................................................................4
3. Technical Specifications ................................................................................6
4. Installation......................................................................................................7
5. Operation.......................................................................................................8
5.1. General.................................................................................................10
6. Maintenance................................................................................................11
6.1. Tubing Removal ...................................................................................11
6.2. Tubing Assembly Installation and Lubrication.......................................12
6.3. Pools and Spas ....................................................................................14
7. Policies and Procedures..............................................................................14
7.1. Manufacturers Product Warranty..........................................................14
7.2. Returns.................................................................................................15
7.3. Credits..................................................................................................15
Appendix.........................................................................................................16
I. Pump Assembly.......................................................................................16
II. Pump Head and Tube Assemblies...........................................................17
III. Notes:...................................................................................................18
IV. Installation (Use gridlines to map out pump installation).......................18
8. Parts
[phone] • [phone] • [email protected] • www.novatech-usa.com

REV. E PN J63091 - 3 -
1. Introduction
Thank you for your purchase of the Chem-Tech Series XP peristaltic pump from
Pulsafeeder. We appreciate your decision to purchase a Pulsafeeder product. Please
take this time to become familiar with your pump and the number of accessories that
shipped with your product.
The shipping box contains the following items:
1) Peristaltic pump comprising of: (a) pump head and tube assembly, (b) clear
polycarbonate splash guard with locking thumb screw, and (c) snap-on rear
splash guard. This can be found in the sealed bag that shipped with the product.
2) Instruction Manual.
3) Factory replacement tube
4) Suction and discharge tubing set (15-feet of ¼-inch OD polyethylene tubing).
5) Injector valve
6) Strainer w/ceramic weight.
[phone] • [phone] • [email protected] • www.novatech-usa.com

REV. E PN J63091 - 4 -
2. Safety Instructions
READ AND UNDERSTAND ALL INSTRUCTIONS PRIOR TO USE. Failure to follow or
understand instructions can/may lead to serious injury or death.
LISEZ ET COMPRENEZ TOUTES LES INSTRUCTIONS AVANT L'UTILISATION.
L'échec de suivre ou comprendre les instructions causer la blessure sérieuse ou la mort.
WARNING: Secure chemicals & metering pumps, making them inaccessible to children &
pets.
AVERTISSEMENT: les produits chimiques sûrs et les pompes mesurantes, en les faisant
inaccessible aux enfants et aux animaux de compagnie.
WARNING: DO NOT PUMP FLAMMABLE LIQUIDS.
AVERTISSEMENT: NE POMPEZ PAS DE LIQUIDES INFLAMMABLES.
WARNING: To reduce the risk of electrical shock-before maintenance, repair, or moving
always disconnect the power to the pump by unplugging from wall outlet.
AVERTISSEMENT: Pour réduire le risque de choc électrique - avant la maintenance, la
réparation, ou déplaçant débranche toujours le pouvoir de la pompe en se non connectant de
l'issue murale.
WARNING: Do not tamper with, cut the plug, or ground lug off the electrical cord. Consult a
licensed electrician for proper installation.
AVERTISSEMENT: ne tripotez pas, coupez la prise de courant ou la terre traînent de la
corde électrique. Consultez un électricien agréé pour l'installation nécessaire.
WARNING: Always wear protective clothing, including gloves and safety eye protection,
when working on or near chemical metering pumps, consult chemical manufacture for
protective equipment recommendations.
AVERTISSEMENT: portez Toujours des vêtements protecteurs, en incluant des gants et une
protection d'oeil de sécurité, en travaillant ou près des pompes mesurantes chimiques,
consultez la fabrication chimique pour les recommandations d'équipement protectrices.
WARNING: Always make sure the voltage on the pump data plate matches the installation
voltage before plugging the pump into a wall outlet or hooking up to an electrical supply. If
you are unsure have a licensed electrician inspect and install your pump.
AVERTISSEMENT: assurez-vous Toujours que le voltage sur la plaque de données de
pompe correspond au voltage d'installation avant le fait de brancher la pompe dans une issue
murale ou le fait d'agrafer aux réserves électriques. Si vous êtes peu sûrs font inspecter un
électricien agréé et installent votre pompe.
WARNING: Always depressurize system and drain the chemical prior to installation or
maintenance.
AVERTISSEMENT: dépressurisez Toujours le système et égouttez le produit chimique avant
l'installation ou de la maintenance.
WARNING: Read and fully understand the section on tube replacement. Failure to do so may
lead to serious injury.
AVERTISSEMENT: Lisez et comprenez complètement la section sur le remplacement de
tube. L'échec de faire ainsi peut causer la blessure sérieuse.
WARNING: DO NOT MODIFY PUMP, as this poses a potentially dangerous situation and
voids the warranty.
AVERTISSEMENT: NE MODIFIEZ PAS DE POMPE, comme cela pose une situation
potentiellement dangereuse et des vides la garantie.
WARNING: If the injection point is lower than the chemical tank and pump, install an anti-
siphon valve.
AVERTISSEMENT: si le point d'injection est plus bas que le réservoir chimique et la pompe,
installez une valve d'antisiphon.
WARNING: All pumps are factory tested with water. Remove tubing and thoroughly dry if the
chemical being pumped will react with water (for example: sulfuric acid).
AVERTISSEMENT: Toutes les pompes sont l'usine évaluée avec l'eau. Enlevez la tuyauterie
et tout à fait sec si le produit chimique étant pompé réagira avec l'eau (par exemple : acide
sulfurique).
[phone] • [phone] • [email protected] • www.novatech-usa.com

REV. E PN J63091 - 5 -
WARNING: Only finger tighten plastic connections (Do not use a wrench).
AVERTISSEMENT: Seulement le doigt se serre les connexions de plastique (n'utilisez pas
de tourne-à-gauche).
WARNING: Consult licensed plumber and electrician before installation to be sure to conform
to local codes.
AVERTISSEMENT: Consultez le plombier autorisé et l'électricien avant l'installation pour être
sûr de vous conformer aux codes locaux.
WARNING: Risk of electric shock –This pump is supplied with a grounding conductor and
grounding-type attachment plug. To reduce the risk of electric shock, be certain that it is
connected only to a properly grounded, grounding-type receptacle.
AVERTISSEMENT: le Risque de décharge électrique –Cette pompe est fourni un
conducteur de bases et une prise de courant d'attachement de type de bases. Pour réduire le
risque de décharge électrique, soyez certains qu'il est raccordé seulement à correctement
fondé, le réceptacle de type de bases.
WARNING: To reduce risk of electric shock, connect only to properly grounded, grounding-
type receptacle.
WARNING: Acceptable for indoor use only.
WARNING: Non-submersible pump.
CAUTION: Inspect tubing regularly for cracking or deterioration and replace as necessary.
(Always wear protective clothing and safety eye protection when inspecting tubing.)
PRUDENCE: Inspectez la tuyauterie régulièrement pour le fait de faire craquer ou la
détérioration et remplacez comme nécessaire. (Portez toujours des vêtements protecteurs et
une protection d'oeil de sécurité en inspectant la tuyauterie.)
CAUTION: KEEP FINGERS AWAY FROM ROTATING PARTS.
PRUDENCE: TENEZ DES DOIGTS À DISTANCE DE FAIRE TOURNER DES PARTIES.
CAUTION: If the pump is exposed to direct sunlight, use a U.V. resistant tubing.
PRUDENCE: si la pompe est exposée pour diriger la lumière du soleil, utilisez une tuyauterie
résistante U.V..
CAUTION: Follow directions and warnings provided with the chemical from the chemical
manufacturer. The user is responsible for determining the chemical compatibility with the
chemical feed pump.
PRUDENCE: Suivez des directions et des avertissements fournis avec le produit chimique du
fabricant chimique. L'utilisateur est responsable de déterminer la compatibilité chimique avec
la pompe de nourriture chimique.
CAUTION: Consult with local health officials and qualified water conditioning specialists when
treating potable water
PRUDENCE: Entretenez-vous avec les fonctionnaires de santé locaux et l'eau autorisée
conditionnant des spécialistes en traitant de l'eau potable
CAUTION: For accurate volume output, the pump must be calibrated under all operating
conditions.
PRUDENCE: Pour la production de volume exacte, la pompe doit être calibrée sous toutes
les conditions d'utilisation.
[phone] • [phone] • [email protected] • www.novatech-usa.com

REV. E PN J63091 - 6 -
3. Technical Specifications
Refer to the data plate located on the back of the peristaltic pump. Note that the data
plate will be located behind the back splash cover if installed. Please make note of the
Electrical Rating, Feed Rate and Maximum Pressure of the pump.
Table 1: Technical Specifications (XPV)
Electrical Rating
115V/230V 1.8/0.9A 50/60Hz
Feed Rate (GPD)
Feed Rate (LPH)
08 17 33
1.3 2.7 5.2
55
8.7
100
15.8
Maximum Pressure (PSI)
Maximum Pressure (Bar)
100
6.8
80
5.4
25
1.7
Maximum Ambient Temperature
104OF (40OC)
Pump Safety Rating
ETL,CETL, ETLSAN, NSF 50*
Enclosure Rating
NEMA 3R (IP32)
Pump Head
PVC
Pump Head Tubing
Norprene
Injection Fitting
PVC
Strainer
Polypropylene
Suction/Discharge Tubing
Polyethylene
Pump Housing
ABS or Polycabonate/PBT/15%GF
Figure 1: Pump Dimensions
[phone] • [phone] • [email protected] • www.novatech-usa.com

REV. E PN J63091 - 7 -
Figure 2: Injector Placement
Vertical
Mount
Horizontal
4. Installation
NOTE: For pumps operating in swimming pool installations
the pump is to be supplied by an isolating transformer or
through a residual current device (RCD).
1) The pump can be installed either vertically or horizontally
(See Figure 2). Make sure to secure the pump on a flat level
surface that will support 50-lbs (22kg) and secure with four
.25-in (6mm) screws in the holes provided. The guard snaps
into the back of the pump via three tangs - see Figure 1.
The pump should be mounted with no less than 1.75-in
(44mm) of clearance around the venting on both the front
and the rear of the pump. Locate the pump so there is direct
access to the power cord plug.
The pump is rated for indoor use only. For applications that
are subject to splashing make sure the pump is mounted
horizontally level with splash guard in place. Vertical
mountings require the purchase of optional hood (J63004).
2) Verify the electrical requirements for the pump as listed
on the name plate and connect to an appropriate electrical source in
compliance with local codes for the specific application.
3) Relieve the system pressure and drain the piping
run where the injection fitting is to be installed. See
Figure 2 for reference. The injection fitting must not be installed in a dead end pipe
or a deeply recessed tee. It should be installed so as to place the tip at the center
of the fluid stream as indicated in Figure 2. The injection fitting is supplied with .25-in
NPT threads. If necessary drill a .44-in (11mm) diameter hole and using care not to tap
to deeply, tap for .25-in NPT.
4) Apply Pipe tape to the injection fitting threads and install into piping system. Do not
remove the plastic sleeve on the tip of the fitting; it is a functional part –see Figure
4.
CAUTION: Inspect the piping system and eliminate piping cross-connections to prevent
feeding chemical to areas not needing treatment.
PRUDENCE: Inspectez le système piping et éliminez des trans-connexions piping pour
prévenir le produit chimique mangeant aux régions pas ayant besoin du traitement.
To install tubing remove the compression fitting’s coupling nut and sleeve and slide onto
tubing with the sleeve located .38-in (9,5mm) from the tubing end –see Figure 4. Place
tubing into fitting and hand tighten the coupling nut. NOTE: Immerse tubing in hot water
to soften prior to pushing on to fitting. Hand-tighten only, do not use wrenches. For
in line check valve location, do not insert the tube more than .38in into the valve
body.
[phone] • [phone] • [email protected] • www.novatech-usa.com

REV. E PN J63091 - 8 -
Figure 4: Injector valve
5) Referring to Figure 5 slide ceramic strainer weight on suction
tubing first then remove the coupling nut from the strainer and slide
onto tubing next. Push the end of the tubing onto the strainer and
hand tighten the coupling nut. Hand-tighten only, do not use
wrenches. Note: Immerse tubing in hot water to soften prior to
pushing on fitting.
6) Install the strainer so it is off the bottom of the chemical
container (1 to 2-inches (25-50mm)) and measure suction tubing
length required. Cut tubing ends square and install on suction
fitting of the pump. Hand-tighten only, do not use wrenches.
5. Operation
WARNING: Always make sure the voltage on the pump data plate
matches the installation voltage before plugging the pump into a
wall outlet or hooking up to an electrical supply. If you are unsure, have a licensed
electrician inspect and install your pump.
AVERTISSEMENT: assurez-vous Toujours que le voltage sur la plaque de données de
pompe correspond au voltage d'installation avant le fait de brancher la pompe dans une
issue murale ou le fait d'agrafer aux réserves électriques. Si vous êtes peu sûrs, faites
inspecter un électricien agréé et installez votre pompe.
If your application requires a Cycle Timer or Daily Timer pump operation you must set
the time and day of week in the Configuration->Settings->Set Time menu. Because this
pump uses a small battery to keep the time and day information it is recommended that
the pump stay powered up initially for at least 24 hours to charge the battery once
installed.
The front panel includes an LCD display, six menu driven pushbuttons, and three
indicator lights. Below are the menu options that are available to the user to set the
different pumping modes as well as system settings.
Use the UP, DOWN, ENTER, and ESCAPE buttons to navigate the different menu
options.
Figure 5: Ceramic-
Weighted Strainer
[phone] • [phone] • [email protected] • www.novatech-usa.com

REV. E PN J63091 - 9 -
Indicator Lights:
Run: Illuminated when the pump is running or idle
Stop: Illuminated when the pump is stopped by the external stop signal
Fault: Illuminated when a fault condition occurs
Button functions:
Escape: Use this button to go back to the previous screen
Up/Down Arrow: Use these buttons to scroll through the menus
Prime: Push and hold this button to prime at fixed speed (default 100%)
Enter: Use this button to choose/accept menu lines
Stop: Use this button to stop the pump from running
Pump Modes:
Fixed Speed: Pump operates at a constant speed based on percentage of full
speed
Cycle Timer: Pump operates at set intervals and fixed speed based on
percentage of full speed
Daily Timer: Pump operates at set intervals, on set days at set times of the day
and fixed speed based on percentage of full speed
Pulse: Pump operates based on closed contact input pulse from the external
connector pins
4-20mA: Pump operates based on 4-20mA input signal from the external
connector pins
Configuration:
Pump Settings:
Prime Speed: Sets the priming speed of the pump based on percentage
of full speed
Auto Resume: Commands the pump to resume pumping when power is
restored if power was lost while the pump was operating
Set Time: Set the system day and time
Contrast: Adjusts the display contrast
Factory Reset: Resets the pump to the default settings
Run
Stop
Fault
Prime
Stop
Escape
Enter
Down Arrow
Up Arrow
[phone] • [phone] • [email protected] • www.novatech-usa.com

REV. E PN J63091 - 10 -
Software Ver: Indicates software version
Troubleshoot: Shows various system inputs to aid startup issues
W-Meter Input:
W-Meter: Selects the type of water meter being used (dry contact or Hall
Effect)
Volume/Kfact: Sets the water meter volume per pulse or K-factor
Flow Units: Sets the units for flow display (gallons or liters)
Relay Output:
Stop Input: Relay activates when the stop input is active
Low 4-20 Alrm: Relay activates when 4-20mA input drops below the low
4-20mA alarm point
Hi 4-20 Alrm: Relay activates when 4-20mA input is above the high 4-
20mA alarm point
Circuit Failure: Relay activates when a circuit failure is detected
Pump Running: Relay activates when the motor is running
Wiring connections for the External I/O
WIRE FUNCTION
RED 4-20mA(+) /
W-METER(+)
BLACK 4-20mA(-) /
W-METER(-)
YELLOW STOP
VIOLET STOP
BROWN RELAY OUT(-)
BLUE RELAY OUT(+)
ORANGE +12VDC
WHITE HALL/Flow(SIG)
GREEN GND.
Dry contact water meter Hall-Effect water meter
Stop Input Connection Relay Connection 4-20mA Connection
5.1. General
DANGER: DO NOT ATTEMPT TO FEED CHEMICALS WITHOUT FIRST
CONSULTING YOUR CHEMICAL FEEDER DEALER OR CHEMICAL SUPPLIER. To
avoid running out of chemical, follow a regular schedule of monitoring chemical supply.
[phone] • [phone] • [email protected] • www.novatech-usa.com

REV. E PN J63091 - 11 -
AVERTISSEMENT: N'ESSAYEZ PAS DE NOURRIR DES PRODUITS CHIMIQUES
SANS PREMIÈRE CONSULTATION DE VOTRE COMMERÇANT DE MANGEUR
CHIMIQUE OU FOURNISSEUR CHIMIQUE. Pour éviter de manquer du produit
chimique, suivez un programme régulier de contrôler des réserves chimiques.
CAUTION: Inspect peristaltic tubing frequently and replace when deterioration becomes
apparent. Peristaltic tubing will eventually wear and break if neglected. This occurrence
will cause chemical spillage and a potential for personal injury or damage to equipment.
Always refer to chemical manufacturers recommendations with regards to safety and
handling of hazardous or corrosive chemicals. Always wear protective clothing and
safety glasses when working near chemical feed systems.
PRUDENCE: Inspectez la tuyauterie peristaltic souvent et remplacez quand la
détérioration devient évidente. La tuyauterie de Peristaltic s'usera finalement et se
cassera si négligé. Cette occurrence provoquera le renversement chimique et un
potentiel pour la blessure personnelle ou nuira à l'équipement. Faites toujours allusion
aux recommandations de fabricants chimiques en ce qui concerne la sécurité et la
manipulation de produits chimiques les hasardeux ou corrosifs. Portez toujours des
vêtements protecteurs et des verres de sécurité en travaillant près des systèmes de
nourriture chimiques.
WARNING: Do not expose the pump or tubing to pressure exceeding the pressure
rating on the pump nameplate.
AVERTISSEMENT: n'exposez pas la pompe ou la tuyauterie à la pression excédant
l'estimation de pression sur la plaque de pompe.
6. Maintenance
NOTE: To get actual feed rates for specific settings, the output must be verified by
measuring the volume output. To get the actual feed rate for specific settings, each
pump must be calibrated for its flow. As with any peristaltic pump output varies with
pressure and tubing condition. It is recommended that feed rates be verified at every
tubing change and after every 250-hour. More critical applications require more frequent
verification.
NOTE: NO USER SERVICEABLE COMPONENTS ARE INSIDE THE ENCLOSURE. IF
THE POWER SUPPLY CORD BECOMES DAMAGED, IT MUST BE REPLACED BY
PULSAFEEDER, ITS REPRESENTATIVE, OR A SIMILARLY QUALIFIED TECHNICIAN
IN ORDER TO AVOID A HAZARD.
6.1. Tubing Removal
Always wear protective clothing and safety glasses when working on the chemical pump
and refer to the chemical manufacturers’ safety precautions.
1) Remove the power to the pump.
2) Relieve the system pressure and the drain discharge and suction tubing.
3) Loosen coupling nuts and remove the tubing from suction and discharge ports - see
Figure 7a.
[phone] • [phone] • [email protected] • www.novatech-usa.com

REV. E PN J63091 - 12 -
Figure 7a: Pump Head Assembly with Front Cover Attached
Figure 7b: Pump Head Assembly with Front Cover Removed
4) Remove the two thumb screws holding on the pump head cover and remove - See
figure 7b above.
5) Remove pump head tube assembly by removing both connector fittings and pulling
tubing straight out of the pump head. Tubing may retain a small amount of chemical.
6) Remove rotor assembly by pulling straight out of pump head.
6.2. Tubing Assembly Installation and Lubrication
Figure 8: Pump Head w/ Rotor Assembly Removed
NOTE: Lubrication of rotor assembly should be performed at least once a year
(residential service). Clean front and rear rotor bearings and surfaces with a clean shop
cloth (item. No. 8, in assembly drawing on pg. 17). Lubricate with a PTFE thickened,
medium viscosity, synthetic grease intended for plastic parts. Ref. Grease Kit (P/N
J30257) –see Figure 8.
Lube all roller ends (3)
and bearing surfaces
(2)
[phone] • [phone] • [email protected] • www.novatech-usa.com

REV. E PN J63091 - 13 -
1) Reinstall the rotor assembly by aligning the cross in the rotor to the drive shaft cross
and fully insert into pump head.
2) Use the Prime button and align the rotor assembly as shown in Figure 9a.
Figure 9a: Rotor Alignment at Start of Tube Installation
3) Insert one connector end of the tubing assembly into the bottom retaining slot in the
pump head. Insert the tube through the guide slot in the rotor. Using caution,
intermittently depress the Prime button and feed the tube around the pump head as the
guide slot rotates. Be very careful not to get any objects (fingers, ties, hair, etc.)
close to the rotors and pump head as severe pinch points exist, see Figure 9b.
Keep hands and fingers away from the rotor assembly while feeding the new tube.
Figure 9b: Feeding the new tube
When the rotor is positioned as in Figure 9c, release the Prime button. Insert the other
connector into its retaining slot.
4) Align the pump head cover bearing bore with the rotor shaft and press into place.
5) Loosely reinstall the two thumb screws.
Note position of tube and
rotor’s cut-away guide
slot.
WARNING: Note severe pinch points between rollers and pump housing
AVERTISSEMENT: Notez des points de pincement sévères entre l'habitation de
pompe et les rouleaux
[phone] • [phone] • [email protected] • www.novatech-usa.com

REV. E PN J63091 - 14 -
Figure 9c: Finishing the New Tube Installation
6) Using the Prime button, run the pump for several revolutions and then fully tighten
the thumb screws hand tight.
7) Return the pump to service by following the procedures in the installation section.
6.3. Pools and Spas
Pumps carrying the “ETL Sanitation” (tested to NSF Standard-50) marks are listed for
swimming pools, spas and hot tubs, and when proper materials are selected, are
capable of handling but not limited to the following chemical solutions:
12.0% ALUMINUM SULPHATE, 5.0% SODIUM CARBONATE,
2.0% CALCIUM HYPOCHLORITE, 10.0% SODIUM HYDROXIDE,
12.5% SODIUM HYPOCHLORITE, 10.0% HYDROCHLORIC ACID.
To meet the requirements of the “ETL Sanitation Mark” qualification, (1) Replace the
peristaltic tubing (as described above), (2) Grease the rotor bearing and (3) Oil the three
rotor rollers at intervals of 500-hours operation time (actual running time).
7. Policies and Procedures
7.1. Manufacturers Product Warranty
PULSAFEEDER warrants equipment of its manufacture to be free of defects in material
or workmanship. Liability under this policy extends for 24-months from the date of
shipment. The manufacturer’s liability is limited to repair or replacement of any failed
equipment or part which is proven defective in material or workmanship upon
manufacturers’ examination. This warranty does not include removal or installation
costs and in no event shall the manufacturers liabilities exceed the selling price of such
equipment or part.
The manufacturer disclaims all liability for damage to its products through improper use,
installation, maintenance, or attempts to operate such products beyond their functional
capacity, intentionally or otherwise, or any unauthorized repair. Replaceable elastomeric
parts, including peristaltic tubing, are covered for 12 months. The manufacturer is not
responsible for consequential or other damages, injuries, or expense incurred through
the use of its products.
The above warranty is in lieu of any other warranty, either expressed or implied. The
manufacturer makes no warranty of fitness or merchantability. No agent of ours is
authorized to provide any warranty other than the above.
[phone] • [phone] • [email protected] • www.novatech-usa.com

REV. E PN J63091 - 15 -
For warranty and service matters within the European Union, contact the seller or:
PULSAFEEDER, INC.
STEIGAR 24
NL 1351 AB ALMERE
NETHERLANDS
7.2. Returns
The Customer Service Department will issue a Return Authorization (RA) number for all
returns.
The following information will be required:
1. Billing and a ship-to address.
2. Model and serial number.
3. Contact name and phone number.
4. Reason for return.
5. Purchase order (where applicable).
6. RA number on outside of the carton.
7. Type of chemical that was pumped.
All material must be returned freight prepaid. All merchandise must be properly
packaged and free of any corrosive, toxic, or otherwise hazardous chemical. All items
returned must reference Return Authorization number.
7.3. Credits
No equipment will be accepted beyond six months after date of shipment from the
factory. Only unused and undamaged equipment will be accepted for return to stock.
All credits are based on acceptance of materials as new and unused by our inspection
personnel. A restocking fee will apply. All equipment returned for credit must have an
RA number and be returned freight prepaid.
[phone] • [phone] • [email protected] • www.novatech-usa.com

REV. E PN J63091 - 16 - Appendix
I. Pump Assembly

REV. E PN J63091 - 17 -
II. Pump Head and Tube Assemblies
NC400003-PRC
NC400004-PRC

REV. E PN J63091 - 18 -
Date
Maintenance Performed
III. Notes:
IV. Installation (Use gridlines to map out pump installation)

REV. E - 19 -
8. Parts
Chem-Tech XP Series Spare Parts
U8800712 ¼” OD Tubing Injection valve assembly
U8800705 3/8” OD Tubing injection valve assembly Strainer assembly
J60609 (1/4” Tubing)
J60664 (3/8” Tubing
03-174-02 Injection valve ½” MNPT adapter
NC110002 PVC Suction and discharge Coupling Nut, .25 NPT
NC110016-000 Suction and discharge tubing Sleeve, .25 OD Tube
J63004 Rain Shield
U0818286 ¼” OD Suction and discharge tubing 15 feet (4.5m) PE white/translucent
U0818994 ¼” OD Suction and discharge tubing 15 feet (4.5 m) optional, Black/UV resistant
U0810294 3/8” OD Suction and discharge tubing 15 feet (4.5m) PE white/translucent
U0818502 3/8” OD Suction and discharge tubing 15 feet (4.5 m) optional, Black/UV resistant
J63135 3/8” OD tubing adapter from ¼” FNPT
Keep On Pumping Kits
When you need a part, you’ve got it! A KOPkit can
help you cut downtime and put you back in
business fast. Use KOPkits also for preventive
maintenance, to ensure continuous high
performance from your Pulsafeeder metering
pump.
Save money too, buying parts in KOPkits instead
of ordering individual parts.
KOPkits include the pump head, the rotor, new
hardware and a replacement tube
The KOPkit part number is
located behind the rain shield
on the pumps data label.
J63049 Optional
Weather shield.
[phone] • [phone] • [email protected] • www.novatech-usa.com
[e-mail]
www.novatech-usa.com
Tel: [phone] Fax: [phone]
Tel: [phone] Fax: [phone]
PN J63091
