NPort Networks N1-9802W User manual

1
User's Manual
Version 1.0
N1-9802W
Gigabit Ethernet Level 2+ Managed Switch
8-Port Gigabit Fiber and 2-Port Gigabit slots
10 Port Managed

2
Revision History
Version
Date
Author
Changes from Previous Version
1.0
April 28, 2015
Mori/Jes
Released

3
Safety Warning
Purpose
This manual gives specific information on how to operate and use the management
functions of this switch.
Audience
This m a nual is i n t ended fo r u s e by netw o rk a dministrato rs w ho ar e
r e s p o n s i b l e f o r o p e r a t i n g a n d m a i n t a in i n g n e t wo r k e q u i p m e n t s ；
consequently, it assumes a basic network network knowledge of general switch functions,
the Internet Protocol (IP), IEEE 802.3at/af Power over Ethernet Standard and Simple
Network Management Protocol(SNMP).
FCC Warning
This device has been tested and found to comply with limits for a Class A digital device,
pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates and radiates radio frequency
energy and, if not installed and used in accordance with the user’s manual, it may
cause interference in which case users will be required to correct interference at their
own expenses.
CE Warning
This is a CE certificated product. In a domestic environment, this product may cause
radio interference in which case the user may be required to take adequate measures.

4
Revision History ...................................................................................................................................... 2
Safety Warning........................................................................................................................................ 3
Chapter 1 INTRODUCTION ....................................................................................................... 12
Product Overvier........................................................................................................................... 12
Features......................................................................................................................................... 12
Specifications ................................................................................................................................ 14
Performances ................................................................................................................................ 14
Package Contents.......................................................................................................................... 15
Chapter 2 HARDWARE DESCRIPTION .................................................................................. 16
Physical Dimension And Weight ................................................................................................... 16
Front Panel .................................................................................................................................... 16
Led Indicators................................................................................................................................ 16
Rear Panel ..................................................................................................................................... 17
ARDWARE INSTALLATION ...................................................................................................................... 17
Installing Equipment ............................................................................................................. 17
Connecting Networking ........................................................................................................ 17
Chapter 3 WEB MANAGEMENT ........................................................................................... 19
Initial Switch Configuration........................................................................................................... 19
WEB Interface ............................................................................................................................... 20
Front Panel .................................................................................................................................... 21
Menu Tree..................................................................................................................................... 21
Chapter 4 WEB CONFIGURATION ........................................................................................ 35
System/Information ...................................................................................................................... 36

5
System/IP ...................................................................................................................................... 37
System/NTP................................................................................................................................... 39
System/Time ................................................................................................................................. 40
System/Log.................................................................................................................................... 41
Green Ethernet/LED...................................................................................................................... 42
Green Ethernet/Port Power Savings ............................................................................................. 44
Ports .............................................................................................................................................. 45
DHCP/Server/Mode ...................................................................................................................... 48
DHCP/Server/Excluded IP.............................................................................................................. 49
DHCP/Server/Pool......................................................................................................................... 50
DHCP/Snooping............................................................................................................................. 51
DHCP/Relay ................................................................................................................................... 52
Security/Switch/Users................................................................................................................... 53
Security/Switch/Privilege Levels ................................................................................................... 54
Security/Switch/Auth Method ...................................................................................................... 56
Security/Switch/SSH...................................................................................................................... 57
Security/Switch/HTTPS ................................................................................................................. 58
Security/Switch/Access Management .......................................................................................... 59
Security/Switch/SNMP/System..................................................................................................... 60
Security/Switch/SNMP/Trap ......................................................................................................... 62
Security/Switch/SNMP/Communities........................................................................................... 65
Security/Switch/SNMP/Users ....................................................................................................... 66
Security/Switch/SNMP/Groups..................................................................................................... 68
Security/Switch/SNMP/Views....................................................................................................... 69
Security/Switch/SNMP/Access...................................................................................................... 70

6
Security/Switch/RMON/Statistics ................................................................................................. 71
Security/Switch/RMON/History.................................................................................................... 72
Security/Switch/RMON/Alarm...................................................................................................... 73
Security/Switch/RMON/Event ...................................................................................................... 75
Security/Network/Limit Control ................................................................................................... 77
Security/Network/NAS.................................................................................................................. 80
Security/Network/ACL/Ports ........................................................................................................ 89
Security/Network/ACL/Rate Limiters............................................................................................ 92
Security/Network/ACL/Access Control List................................................................................... 93
Security/Network/IP Source Guard/Configuration....................................................................... 96
Security/Network/IP Source Guard/Static Table .......................................................................... 97
Security/Network/ARP Inspection/Port Configuration................................................................. 98
Security/Network/ARP Inspection/VLAN Configuration............................................................. 100
Security/Network/ARP Inspection/Static Table .......................................................................... 101
Security/AAA/RADIUS ................................................................................................................. 102
Security/AAA/TACACS+ ............................................................................................................... 104
Aggregation/Static ...................................................................................................................... 105
Aggregation/LACP ....................................................................................................................... 107
Loop Protection........................................................................................................................... 109
Spanning Tree/Bridge Settings.................................................................................................... 111
Spanning Tree/MSTI Mapping..................................................................................................... 113
Spanning Tree/MSTI Priorities .................................................................................................... 114
Spanning Tree/CIST Ports............................................................................................................ 115
Spanning Tree/MSTI Ports........................................................................................................... 118
IPMC Profile/Profile Table........................................................................................................... 120

7
IPMC Profile/Address Entry......................................................................................................... 122
MVR............................................................................................................................................. 123
IPMC/IGMP Snooping/Basic Configuration ................................................................................ 126
IPMC/IGMP Snooping/VLAN Configuration................................................................................ 129
IPMC/IGMP Snooping/Port Filtering Profile ............................................................................... 131
IPMC/MLD Snooping/Basic Configuration.................................................................................. 132
IPMC/MLD Snooping/VLAN Configuration ................................................................................. 134
IPMC/MLD Snooping/Port Filtering Profile................................................................................. 136
LLDP/LLDP ................................................................................................................................... 137
LLDP/LLDP-MED .......................................................................................................................... 141
MAC Table ................................................................................................................................... 150
VLANs .......................................................................................................................................... 152
Private VLANs/Membership........................................................................................................ 154
Private VLANs/Port Isolation....................................................................................................... 156
VCL/MAC-based VLAN ................................................................................................................ 157
VCL/Protocol-based VLAN/Protocol to Group ............................................................................ 158
VCL/Protocol-based VLAN/Group to VLAN................................................................................. 160
VCL/IP Subnet-based VLAN......................................................................................................... 162
Voice VLAN/Configuration .......................................................................................................... 163
Voice VLAN/OUI .......................................................................................................................... 166
QoS/Port Classification ............................................................................................................... 167
QoS/Port Policing ........................................................................................................................ 169
QoS/Port Scheduler .................................................................................................................... 171
QoS/Port Shaping........................................................................................................................ 172
QoS/Port Tag Remarking............................................................................................................. 174

8
QoS/Port DSCP ............................................................................................................................ 175
QoS/DSCP-Based QoS ................................................................................................................. 177
QoS/DSCP Translation ................................................................................................................. 179
QoS/DSCP Classification.............................................................................................................. 180
QoS/QoS Control List .................................................................................................................. 181
QoS/Strorm Control .................................................................................................................... 184
Mirroring ..................................................................................................................................... 185
UPnP............................................................................................................................................ 186
GVRP/Global Config .................................................................................................................... 188
GVRP/Port Config ........................................................................................................................ 189
sFlow ........................................................................................................................................... 190
Chapter 5 WEB MONITOR...................................................................................................... 194
System/Information .................................................................................................................... 194
System/CPU Load........................................................................................................................ 195
System/IP Status ......................................................................................................................... 196
System/Log.................................................................................................................................. 197
System/Detailed Log ................................................................................................................... 199
Green Ethernet/Port Power Savings ........................................................................................... 200
Ports/State .................................................................................................................................. 202
Ports/Traffic Overview ................................................................................................................ 203
Ports/QoS Statistics..................................................................................................................... 204
Ports/QCL Status ......................................................................................................................... 206
Ports/Detailed Statistics.............................................................................................................. 208
DHCP/Server/Statistics................................................................................................................ 210
DHCP/Server/Binding.................................................................................................................. 212

9
DHCP/Server/Declined IP............................................................................................................ 213
DHCP/Relay Statistics .................................................................................................................. 216
DHCP/Detailed Statistics ............................................................................................................. 218
Security/Access Management Statistics ..................................................................................... 220
Security/Network/Port Security/Switch ..................................................................................... 221
Security/Network/Port Security/Port ......................................................................................... 223
Security/Network/NAS/Switch ................................................................................................... 225
Security/Network/NAS/Port ....................................................................................................... 227
Security/Network/ACL Status ..................................................................................................... 231
Security/Network/ARP Inspection .............................................................................................. 233
Security/Network/IP Soruce Guard ............................................................................................ 234
Security/AAA/RADIUS Overview................................................................................................. 235
Security/AAA/RADIUS Details ..................................................................................................... 237
Security/Switch/RMON/Statistics ............................................................................................... 238
Security/Switch/RMON/History.................................................................................................. 240
Security/Switch/RMON/Alarm.................................................................................................... 242
Security/Switch/RMON/Event .................................................................................................... 244
LACP/System Status..................................................................................................................... 245
LACP/Port Status ......................................................................................................................... 246
LACP/Port Statistics..................................................................................................................... 247
Loop Protection........................................................................................................................... 249
Spanning Tree/Bridge Status....................................................................................................... 250
Spanning Tree/Port Status .......................................................................................................... 252
Spanning Tree/Port Statistics ...................................................................................................... 253
MVR/Statistics............................................................................................................................. 255

10
MVR/MVR Channel Groups ........................................................................................................ 256
MVR/MVR SFM Information ....................................................................................................... 257
IPMC/IGMP Snooping/Status...................................................................................................... 258
IPMC/IGMP Snooping/Groups Information................................................................................ 260
IPMC/IGMP Snooping/IPv4 SFM Information ............................................................................ 261
IPMC/MLD Snooping/Status ....................................................................................................... 262
IPMC/MLD Snooping/Groups Information ................................................................................. 264
IPMC/MLD Snooping/IPv6 SFM Information .............................................................................. 265
LLDP/Neighbours......................................................................................................................... 266
LLDP/LLDP-MED Neighbours....................................................................................................... 267
LLDP/EEE ..................................................................................................................................... 273
LLDP/Port Statistics ..................................................................................................................... 275
MAC Table ................................................................................................................................... 277
VLANs/Membership.................................................................................................................... 278
VLANs/Ports ................................................................................................................................ 280
sFlow ........................................................................................................................................... 282
Chapter 6 WEB DIAGNOSTICS............................................................................................ 285
Diagnostics/Ping.......................................................................................................................... 285
Diagnostics/Ping6........................................................................................................................ 286
Chapter 7 WEB MAINTENANCE ........................................................................................... 288
Maintenance/Restart Device ...................................................................................................... 288
Maintenance/Factory Defaults ................................................................................................... 289
Maintenance/Software/Upload.................................................................................................. 290
Maintenance/Software/Image Select......................................................................................... 291
Maintenance/Configuration/Save startup-config....................................................................... 292

11
Maintenance/Configuration/Download ..................................................................................... 293
Maintenance/Configuration/Upload .......................................................................................... 294
Maintenance/Configuration/Activate......................................................................................... 295
Maintenance/Configuration/Delete ........................................................................................... 296

12
Chapter 1 INTRODUCTION
This chapter provides an overview of this Web Smart switch,
and introduces the key features and supported
specifications of this Web Smart switches.
Product Overvier
This switch is a Web Smart switch equiped with
8-Port Gigabit Fiber and 2-Port Gigabit open slots. It
provides a broad range of features for Layer2 switching
It was designed for easy installation and high performance
in an environment where the traffic is on the network and
the number of users increases continuously. The smart and
efficient power design can improve the power saving.
Features
Table 1. Features
Features
Descriptions
Dual Images
Prevent any kind of upgrading process
failure
IPv4
IPv6
Supports IPv4 addressing, management
and QoS
Supports IPv6 addressing, management
and MLD snooping
Log
Support local and remote syslog server
with 3 levels(Info, Warning, Error)
Power Saving
LED Power management
802.3az EEE
Security
Private VLAN(Static)
ACLs for filtering, policing, and port copy,
including ACL wizards

13
Table 1. Features
(continued)
Authentication
Telnet, Web - username/password
Telnet - SSH
SNMP v1/v2c –Community strings
SNMP version 3 –MD5 or SHA
password
Port-based 802.1X
Port Limiting
Input rate limiting per port(manual
setting or ACL)
Port Configuration
Speed, Duplex mode, Flow control,
MTU, Power saving mode
Port Mirroring
1 sessions, up to 10 source port to one
analysis port per session
Port Aggregation
IEEE 802.3ad Link Aggregation, static
and LACP
Spanning Tree
Algorithm
Supports standard STP, Rapid Spanning
Tree Protocol (RSTP), (Multiple
Spanning Tree Protocol (MSTP)
IEEE 802.1D
Bridge
Supports dynamic data switching and
addresses learning
Quality of Service
Traffic classes(1,2, or 4/8 active
priorities)
Storm control for UC, MC and BC
DHCP
Client
Configuration
Save and Restore configuration
Firmware
Upgrade & firmware image switch using
Web & console port
CLI command
Support Cli command with console port
(Baudrate:115200, DataBit:8, Parity:
N,StopBit 1)

14
Specifications
Table 2, Specifications
Standard
IEEE 802.3ad Link Aggregation
IEEE 802.3x Flow Control
IEEE 802.1x Port-based Network Access Control
IEEE 802.1Q VLAN Tagging
IEEE 802.1d Spanning Tree Protocol
IEEE 802.1w Rapid Spanning Tree Protocol
24 integrated IEEE 802.3ab-compliant 10/100/1000BASE-T
Ethernet
MIBs
RFC 1213 MIB II
RFC 3411 SNMP Management Frameworks
RFC 3621 LLEP-MED Power
RFC 3635 Ethernet-like MIB
RFC 4188 Bridge MIB
IEEE 802.1AB LLDP MIB
RFC 3621 Power Ethernet
Performances
Table 3, Performance
Information
MAC Address : 8K , 4K VLAN support
Packet Memory : 4 Megabits of Integrated shared memory
Jambo Frame : 9.6K
Transmission Method : Store and Forward

15
Package Contents
Before you start to install this switch, please verify your package that contains the
following items:
One 8+2-port Gigabit Ethernet Switch
One Power Cord
One User’s Manual (CD disk)

16
Chapter 2 HARDWARE DESCRIPTION
This chapter primarily presents hardware of the switch,
physical dimenstions and functional overview would be
described.
Physical Dimension And Weight
263 x 160 x 44 mm (L x W x H) / 1.1kg
Front Panel
The Front Panel of the Web Smart Switch consists of
8-Port Gigabit Fiber and 2-Port Gigabit open slot.
The LED indicators are also located on the Front Panel.
Led Indicators
The LED Indicators present real-time information of
systematic operation status. The following table provides the
description of LED status and meanings.
Table 4, LED INDICATORS
LED
Status
Description
Power
On(Orange)
System on
OFF
System off
Link/ACT
Flashing(Green)
Link and Data Activating
OFF
Port is disable or disconnected

17
Rear Panel
The 3-pronged power plug is placed at the rear panel of the
Web Smart Switch right side show as below:
ARDWARE INSTALLATION
Installing Equipment
You can mount the this device into a standard 19-inch equipment rack.
You can center- or front-mount the device in a rack. Optional
rack-mounting brackets are supplied with the device.
Connecting Networking

18
Connecting Power
The AC power cord shipped with the device connects the device to
earth ground when plugged into an AC grounding-type power outlet.
The device must be connected to earth ground during normal operation.
To connect power to the device, plug one end of the AC power cord into
the AC power appliance inlet on the back panel of the device. Plug the
other end into an AC power source.
Power ON/OFF Device
To power on this device, press the AC power switch on the rear panel to
the on position. The POWER LED lights during startup and remains on
steadily when the device is operating normally. To power off this device,
press the power switch to the OFF position.

19
Chapter 3 WEB MANAGEMENT
This chapter provides the entire Web Smart switch
features, along with a detailed description of how to
configure each feature via web interface.
Initial Switch Configuration
This part guides you to configure and manage this switch
through the web interface. With this facility, you can easily
configure and monitor through any one port of this
switch.
Start up by the following steps:
1. Place the switch close to your PC/NB that you intend to
use for configuration. It will help you to check the status
of the switch by LED in front panel while working on
your PC/NB.
2. Connect the Ethernet port of your PC/NB to any port on
the front panel of the switch. Turn the switch on and
make sure the connectivity by checking LED in the front
panel of the switch.
3. Configure your PC’s IP address the same subnet with the
switch’s.
The following table describes the default necessary
login Information:
Table. Login Information
IP Address
192.168.2.1
IP Mask
255.255.255.0
IP Router
0.0.0.0
Username
admin
Password
4. Open the web browser, and go to 192.168.2.1Site then
the login windows will pop out. Key in the username
“admin”and leave password blank then clicks OK.

20
Figure 3-1.
5. After you login successfully, you will see the home page
is displayed as shown below. The home page display the
Menu Bar on the left side of the screen and show the
front panel port states on the right side.
Figure 3-2
Before you start to configure, we strongly recommended
you to change the password. To change the password, click
Security and then Switch. Fill old and new password in
Password tab.
WEB Interface
Configuration Option Configurable parameters have
seveal forms : text field, drop-down list, radio button and
checkbox. Once you change the parameters, please make
sure to click Save button to apply
