SPECIFICATION SHEET
Broan-NuTone Storage Solutions, 501 S. Wilhite Street, Cleburne, TX 76031 (1-800-325-8351)
REFERENCE QTY. REMARKS Project
Location
Architect
Engineer
Contractor
Submitted by Date
SURFACE
MOUNT
RECESSED
A
B
CD
E
F
MODEL OVERALL SIZE WALL OPENING
NO. A B C D E F SHELVES
401ADJ 16 20 33/414 18 21/22 (adj)
407ADJ 16 22 33/414 18 21/22 (adj)
624 16 26 41/2137/8237/8 27/83 (fixed)
RECESSED CABINETS
STYLELINE SERIES
MOLDED BATH
CABINETS
Standard builder models - for recessed and
surface mount installation
FEATURES
•Easy to clean, one-piece, injection-molded
polystyrene construction
• Glass Mirror
• Stainless steel frame
• Butt hinge
• Polystyrene shelves (fixed or adjustable)
• Reversible - for left-hand or right-hand
door opening
• Includes mounting hardware
80D A99044182 B
SURFACE MOUNT CABINET
TYPICAL SPECIFICATION
Bath cabinet shall be NuTone Styleline Series Model
401ADJ, (407ADJ), (614) and (624).
Bath cabinet shall be of one-piece, injection-molded
polystyrene construction.
Glass mirror shall have full surround of stainless steel
frame with spring clip closure (401ADJ & 407ADJ) or
screw closure (614 & 624). Door back shall be fitted
tight within the frame and finished in white.
Cabinet shall have butt hinges.
Cabinet shall be reversible for left-hand or right-hand
installation.
MODEL BODY SIZE OVERALL SIZE
NO. A B C D E F SHELVES
614 155/8195/83
5/8161/4221/441/42 (fixed)
E
D
B
C
F
A
