IMPORTANT SAFETY INSTRUCTIONS.
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE.
• Thisproductcanbeusedbychildren
agedfrom8yearsandaboveandper-
sonswithreducedphysical,sensoryor
mentalcapabilitiesorlackofexperience
andknowledgeiftheyhavebeengiven
supervisionorinstructionconcerning
useoftheproductinasafewayandun-
derstandthehazardsinvolved.
• Childrenshallnotplaywiththeproduct.
• Cleaningandusermaintenanceshall
notbemadebychildrenunlesstheyare
supervised.
• Adamagedpowercordmayonlybe
replacedbytheauthorisedservice
agentinordertoavoidhazards.
OFZ501_A5_130405.indb 3 5/4/13 3:53 PM

4
Size - A5
• Readthismanualbeforerstusethoroughly.Itcontainsimportantinformationfor
yoursafetyaswellasfortheuseandmaintenanceoftheequipment.
• Keepthismanualforfuturereferenceandpassitonwiththeproduct.
• Payparticularattentiontothewarningsontheproductandinthismanual.
• Usetheproductonlyforitsintendedpurpose.Improperusemayleadtohazards.
• Intheeventofimproperuseorwrongoperation,wedonotacceptanyliabilityfor
resultingdamages.
• Theuseofaccessoriesandcomponentsnotexpresslyrecommendedbythe
manufacturermayresultininjuriesordamagesandvoidsthewarranty.
• Neverimmerseelectricalpartsoftheproductinwaterduringcleaningoroperation.
Neverholdtheproductunderrunningwater.
• Donotunderanycircumstancesattempttorepairtheproductyourself.For
servicingandrepairs,pleaseconsultanauthorisedserviceagent.
• Themainsvoltagemustmatchtheinformationontheratinglabeloftheproduct.
• Thepowerplugisusedasthedisconnectdevice.Pleasebesurethatthepowerplug
isinoperablecondition.
• Onlyunplugfromthepowersocketcanseparatetheproductcompletelyfromthe
mains.
• Avoiddamagestothepowercordthatmaybecausedbykinksorcontactwith
sharpcorners.
• Keepthisproductincludingpowercordandpowerplugawayfromallheatsources
likeforexample,ovens,hotplatesandotherheat-producingproducts/objects.
• Onlyunplugfromthepowersocketbytheplugitself.Donotpullonthecord.
• Unplugtheproduct...
-whentheproductisnotbeingused,
-incaseofmalfunctions,
-beforeattaching/detachingaccessoriesand
-beforecleaningtheproduct.
• Ifthepowercordorthecasingoftheproductisdamagedoriftheproductis
dropped,theproductmaynotbeusedbeforeitisexaminedbyanauthorised
serviceagent.
OFZ501_A5_130405.indb 4 5/4/13 3:53 PM

5
Size - A5
• Usethisproductindryindoorareasonlyandneveroutdoors.
• Placetheproductonaat,sturdyandslip-resistantsurface.
• Protectthisproductfromextremeheatandcoldaswellasfromdirectsunlightand
dust.
• Inordertoreducetheriskofreandelectricshock,donotexposetheproduct
tore(replace,grill,candles,cigarettesandsoon)orwater(waterdrops,water
splashes,vases,tubs,pondsandsoon).
• Warning!Donotusethisproductnearwaterorheavymoisture;e.g.inadamp
basementorbesideaswimmingpoolorbathtub.
• Usethisproductintemperatelatitudesonly.Avoidtropicalandespeciallyhumid
climaticregions.
• Protectthisproductfromallmoistureincludingspraywaterandhumidity.
• Thisproductisnotintendedforcommercialuse.
• Itisdesignedforhouseholduseandsimilarapplicationsonly,suchasforexample:
-inemployeecafeterias,instores,ocesandotherworkingenvironments;
-bycustomersinhotels,motelsandotherresidentialfacilities;
-inBedandBreakfastestablishments;
-infarmhouses.
• Warning! Keepventilationopenings,intheapplianceenclosureorinthebuilt-in
structure,clearofobstruction.
• Warning! Donotusemechanicaldevicesorothermeanstoacceleratethe
defrostingprocess,otherthanthoserecommendedbythemanufacturer.
• Warning!Donotdamagetherefrigerantcircuit.
• Warning! Donotuseelectricalproductsinsidethefoodstoragecompartmentsof
theproductunlesstheyareofthetyperecommendedbythemanufacturer.
• Donotstoreexplosivesubstancessuchasaerosolcanswithaammablepropellant
inthisproduct.
• Warning! Thisproductisusingammableinsulationblowinggases.Contact
authorisedserviceagentbeforedisposal.
• FollowtheinstructionsinthechapterCleaningandcare.
OFZ501_A5_130405.indb 5 5/4/13 3:53 PM

6
Size - A5
CONGRATULATIONS
Thanksforyourpurchaseofok.product.Pleasereadthismanualcarefullyandkeepit
forfuturereference.
INTENDED USE
Theproductissuitableforfreezingfoodonly.Anyotherusemayresultindamageto
productorinjuries.
COMPONENTS
DRAINDRAIN
1
2
3
8
7
5
4
6
1. Doorwithhandles
2. Drainageholeswithcover(inside)
3. Drainageholeswithcover(outside)
4. Indicator(Power,Run,Alarm)
5. Temperatureregulator
6. Compressor(notshown)
7. Powercordwithplug(notshown)
8. Shelvebasket
BEFORE FIRST TIME USE
Inspectthedeliverycontentsforcompletenessanddamages.Shouldthedelivery
contentsbeincompleteordamaged,contactyoursalesoutletimmediately.
Afterunpacking,pleaserefertochapterCleaning and care.
OFZ501_A5_130405.indb 6 5/4/13 3:53 PM

7
Size - A5
INSTALLING THE PRODUCT
DRAIN
1
DRAIN
20 cm
20 cm
20 cm
70 cm
2
Placetheproductona
stableandlevelsurface.
Thedistancebetweenthe
backoftheproductand
thewallmustbeatleast
20cm.
NOTE
• Thebestambienttemperatureforthefreezer’soperationisbetween16°Cand32°C.
• Donotplacetheproductclosetoradiators,heatingductsorchimneys,andprotect
itfromdirectsunlight.
• Theairheatedbytheproductmustbeallowedtocirculatefreely.Donotobstruct
theaircirculationatthebackoftheproduct!
30 min
CAUTION
Eachtimetheproductismoved,itmustbeallowedto
standunpluggedforatleast30minutesbeforebeing
operatedagaintopermitthecoolingsystemtoregain
fullcapacity,becausetheoilcontainedinthecompressor
maybecomedisplacedduringtransport.
OFZ501_A5_130405.indb 7 5/4/13 3:53 PM

8
Size - A5
USING THE FREEZER
1
2
3
4
5
0
FF
Power AlarmRun
6
1
1
2
3
4
5
0
FF
Power AlarmRun
6
2
2-3h
3
Connectthepowerplug
toasuitablepoweroutlet
andthepowerindicator
lightsup.
Turnthetemperature
regulatortodesired
settingandtherun
indicatorlightsup.
Allowtheproductto
precoolforabout2-3hours
beforeputtinginthefood.
NOTE
Alarmindicatorlightsupwhentheinsidetemperatureistoohigh.
1
2
3
4
5
0
FF
Power AlarmRun
6
Temperature regulator
Thelevel1-6doesnotmeanaspecictemperature.The
lowerthesettingis,thehigherthetemperatureinside.
NOTE
• Todeterminethetemperatureoftheproduct,obtainacommerciallyavailable
thermometer,andplaceitinsidetheproduct.
• Thetemperatureoftheproductdependsontheambienttemperature,onthe
settingofthetemperatureregulator.
• Pleasemakesurethedoorisclosedproperlyandisnotobstructedbyfoods.
OFZ501_A5_130405.indb 8 5/4/13 3:53 PM

9
Size - A5
DEFROSTING
Defrostthefreezerwhenthelayeroffrostonthesurfacereaches3to4mm.Remove
allfoodsfromthefreezer.Unplugthefreezer.
1
Openthedoorandunscrewthedrainageholecover
(inside).
DRAIN
2
Unscrewthedrainageholecover(outside)andplacea
suitablecontainertocollectthewater.
Afterthefrostmelted,discardthewaterandcleanupthe
interior.
CAUTION
Makesurethedrainopeningisnotplugged,toallowmeltwatertodrainfreelyfromthe
refrigerator.
CLEANING AND CARE
• Warning! Unplugtheproductandletitcooldowncompletelybeforecleaning.
• Takethefoodsandbeveragesoutoftheproduct.
• Warning! Whencleaning,neverusesolventsorabrasivematerials,hardbrushes,
metallicorsharpobjects.Solventsareharmfultohumanhealthandcanattack
plasticparts,whileabrasivecleaningmechanismsandtoolsmayscratchthe
surface(s).
• Cleantheproduct’sexteriorsurfaceswithaslightlydampclothandthendrythem
thoroughly.
• Makesurethatnowaterenterstheproductinterior(forexample,throughthe
switch).
• Wipethedoorsealwithcleanwateronly,anddryitthoroughlyafterwards.
• Warning! Neveruseoilorgreaseonthedoorseal.Thiswillmakeitporousovertime.
• Atleastonceayear,removeanydustfromthebackoftheproduct.
• Allvariablepartsoftheproductcanbetakenoutforcleaning.
• Warning! Donotusesteamcleaningequipment.Thesteammaycomeincontact
withelectricalpartsoftheproduct,causingashortcircuit.
OFZ501_A5_130405.indb 9 5/4/13 3:53 PM

10
Size - A5
SPECIFICATION
Voltage 220-240V
Frequency 50Hz
RatedInputPower 90W
EnergyConsumption
kWh/24h
kWh/year
0.61
223
Ambienttemperature 16°C-38°C
Netcapacityoffreezer 198L
Measurement(HxWxD) 850x945x523mm
Depthwithdooropen 1333mm
DISPOSAL
Donotdisposeofthisapplianceasunsortedmunicipalwaste.Returnittoa
designatedcollectionpointfortherecyclingofWEEE.Bydoingso,youwill
helptoconserveresourcesandprotecttheenvironment.Contactyourretailer
orlocalauthoritiesformoreinformation.
