ODES ODES1000ATV-L User manual

OWNER’S MANUAL
This ATV should not be ridden by anyone under 16years of
age.READ THIS MANUAL CAREFULLY BEFORE RIDING It
contains important safety information.
ODES1000ATV-L, ODES800ATV-L, ODES650ATV-L
ODES1000ATV-S, ODES800ATV-S, ODES650ATV-S
This manual is general version, the pictures in manual book are little-
difference compare with real part, so please check real part accordin-
gly.

WARNING
● Operation of this ATV by anyone under the age of 16 may increase
the risk of severe injury or death!!! This vehicle can roll if not driven
properly!!!
● Adult supervision is always required.
● Anyone under the age of 16 may NOT operate this ATV.
● Overloading the ATV may adversely affect the handling of this
vehicle.
● Operator use only, excess passengers prohibited.
● All Riders MUST wear helmet and other protective equipment.
● Do NOT operate this vehicle during/after consuming Alcohol or
Drugs.
● Don’t do drugs. It’s not healthy for you.
● When refueling, you must shut off the engine to avoid spark or fire
risk.
● Read owner's manual carefully before operating this vehicle.
WARNING
Indicates a hazardous situation which, if not avoided, could result in
death or serious injury.
CAUTION: Indicates a hazardous situation, which, if not avoided,
could result in minor or moderate injury. It may also be used without
the safety alert symbol as an alternative to “NOTICE.”
NOTICE: “NOTICE”is the preferred signal word to address
practices not related to personal injury. The safety alert symbol shall
not be used with this signal word. As an alternative to “NOTICE,”the
word “CAUTION”without the safety alert symbol may be used to
indicate a message not related to personal injury.
Warning for ATV transportation
1.Special ATV trailer is recommended for ATV long distance trans
portation;
2.Container truck is recommended for ATV long distance transport
ation;
3.Notice: Before transportation, please check ATV if there is tire d
amage or overwearing, steering working conditions and battery
power level;

Dear Valued Customer：
Congratulations and thank you for choosing to become a part of our
family with the purchase of your new ATV. We have designed this
vehicle with you, the customer, in mind, providing you with great power
stability, and functionality with your ATV.
This Operator ’s Manual is here to familiarize any operators of all
proper operating procedures. It also includes important and required
information about the general care and maintenance of your ATV.
Read the following pages regarding safety warnings, active riding skills,
and
precautions for your own safety and the safety of others around you.
Children and
adults have different skill levels, physical abilities, and use of judgment.
Anyone
under the age of 16 is NOT permitted to drive this vehicle.
All information in this manual is based on the latest product data and
specifications available at the time of printing. The Manufacture of this
ATV, reserve the right to make product changes and improvements,
which may effect the illustrations, layout, or explanations without
NOTE.
If you have any other questions regarding our ATV operation or
maintenance
please contact any authorized dealer.
Product and specifications are subject to change without NOTE.

TABLE OF CONTENTS
OPERATION WARNINGS ............................................................... 1
RIDING THE VEHICLE ................................................................19
Pre-Ride Inspection .................................................................... 20
Riding Gear .................................................................................. 22
Carrying Loads ............................................................................ 23
Loading the Cargo Rack ........................................................ 23
Hauling a Load (if Equipped with Hitch ....................................24
Pulling a Trailer (if Equipped with Hitch) ................................. 24
Working with your Vehicle ........................................................ 25
Environment ............................................................................... 26
Off-Road Operation ................................................................26
General Operating and Safety Precautions ..........................27
Riding Techniques ....................................................................... 27
IMPORTANT ON-PRODUCT LABELS .......................................36
Engine and Vehicle Identification Number Location .......... 36
Vehicle Safety Labels ................................................................37
DESCRIPTION AND VEHICLE IDENTIFICATION .................. 41
(1) Brake pedal ....................................................................... 43
(2)WD/4WD Selector ................................................................43
(3)Mechanical parking brake ..................................................... 44
(4) Throttle Lever ....................................................................... 45
(5) Foot pegs ............................................................................... 45
(6) Multi Function Switch ............................................................46
(7) Multifunction gauge ...............................................................47
(8) rearview mirror .......................................................................49
(9)Rear Storage Compartment ................................................ 49

(10) license plate lamp ............................................................... 49
(11) Tail/brake lights ................................................................... 49
(12) Turn signal/Hazard warning ligh....................................... 49
(13) Front seat ............................................................................. 49
(14) Shift Lever ............................................................................ 50
(15)Headlight (low beam)/turn lights ........................................ 51
(16) Headlight (high beam) ........................................................ 51
(17) Winch .................................................................................... 51
(18)LH Brake Lever .....................................................................52
(19) Rear seat ............................................................................... 53
(20)Ignition Switch ....................................................................... 53
(21) Auxiliary DC jack ................................................................53
(22) USB port ............................................................................... 54
FUEL ................................................................................................. 55
Fuel Requirements ..................................................................... 55
Fueling Procedure ....................................................................... 55
TIRES .............................................................................................. 56
BREAK-IN PERIOD ....................................................................... 58
Operation During Break-In .........................................................58
BASIC PROCEDURES ................................................................58
Starting the Engine ..................................................................... 58
Changing Gear Selection ...........................................................59
Stopping the Engine ................................................................... 59
Engine Overheat ....................................................................... 59
Post-Operation Care ................................................................60
Storage .......................................................................................60
SPECIAL PROCEDURES ........................................................ 60
What to Do if Water is in the CVT .........................................60
What to Do if Water is in the Air Filter Housing ...................... 61
What to Do if Vehicle is Turned Over .......................................61
What to Do if Vehicle is Immersed in Water ..........................62

MAINTENANCE PROCEDURE ................................................... 63
Air Filter .........................................................................................63
Maintenance of CVT intake pipe .............................................. 65
Greasing points ........................................................................... 66
lifting jack position operation manual introduction ..................... 66
Engine Oil .....................................................................................67
Oil Change and Oil Filter ............................................................68
Engine Coolant ............................................................................ 69
Suspension Adjustment ............................................................. 70
Muffler Spark Arrester Cleaning and Inspection .................... 71
Declaration of Driver’s exposure to noise level ...................... 73
Declaration of Vibration declaration ...................................... 75
MAINTENANCE CHART ............................................................77
TROUBLESHOOTING ............................................................... 80
FAULT CODES ............................................................................81
SPECIFICATIONS .......................................................................... 85

1
OPERATION WAENINGS
NOTE: The following illustration is a general description. Your model may be
different.
POTENTIAL HAZARD
Operating the ATV without proper guidance will increase the risk of
accidents.
WHAT CAN HAPPEN
If the operator does not know how to operate the vehicle correctly in different
situations and under different circumstances, the risk of accidents will
increase greatly.
HOW TO AVOID DANGER
Beginners and inexperienced operators should complete training courses.
Then, they should practice the skills learned in the course according to the
operation techniques described in this operation guide.
For more information about training courses, please contact an authorized
dealer.

2
POTENTIAL HAZARD
Failure to follow the age recommendations for this vehicle.
WHAT CAN HAPPEM
A lack of respect for this age recommendation can lead to severe injury or
death of the child.
Even though a child may be within the age group for which this vehicle is
recommendation, he may not have may be involved in a serious accident.
HOW TO AVOID THE HAZARD
No one under the age of 16 is allowed to drive this vehicle.

3
POTENTIAL HAZARD
Did not follow the vehicle operating advice.
WHAT CAN HAPPEM
Always refuel with the engine stopped, and outdoors or in a well-ventilated
place.
Do not smoke or open flames or sparks in or near the refueling place or store
gasoline.
If gasoline spills on your skin or clothes, immediately wash them with soap
and water and change clothes.
HOW TO AVOID THE HAZARD
Children are not allowed to operate vehicles with fuel.

4
POTENTIAL HAZARD
Use vehicles in enclosed environments.
WHAT CAN HAPPEM
It is possible to have poisoning, which can be dangerous to your safety.
HOW TO AVOID THE HAZARD
Always use for cycling in open areas.

5
POTENTIAL HAZARD
Transporting flammable or dangerous material can leas to explosions.
WHAT CAN HAPPEM
This can serious injury or death.
HOW TO AVOID THE HAZARD
Never transport flammable or dangerous material.

6
POTENTIAL HAZARD
Using this vehicle with drugs or alcohol.
WHAT CAN HAPPEM
Could seriously affect your judgment.
Could cause you to react more slowly.
Could affect your to balance and perception.
Could result in an accident or death.
HOW TO AVOID THE HAZARD
Never use this vehicle with drugs or alcohol.

7
POTENTIAL HAZARD
Operating this vehicle at excessive speeds.
WHAT CAN HAPPEM
Increases your chances of losing control of the vehicle, which
can result in an accident.
HOW TO AVOID THE HAZARD
Always travel at a speed which is appropriate for the terrain visibility
and operating conditions, and your experience.

8
POTENTIAL HAZARD
Operating this vehicle on paved surfaces.
WHATCANHAPPEN
The tires are designed for off-road use only, not for use on pavement.
Paved surfaces may seriously affect handing and control of this vehicle.
and may cause the vehicle to go out of control.
HOWTO AVOID THEHAZARD
Never operate this vehicle on any paved surfaces.
Including sidewalks. driveways, parking lots and streets.

9
POTENTIALHAZARD
Operating this vehicle on public streets, roads or highways.
WHAT CAN HAPPEN
You can collide with another vehicle.
HOWTO AVOID THEHAZARD
Never operate this vehicle on any public street, road or highway even a
dirt or gravel one. In many states or provinces it is illegal
to operate this vehicle on public streets, roads or highways.

10
POTENTIALHAZARD
Riding this vehicle without wearing an approved helmet, eye protection and
protective clothing.
WHATCAN HAPPEN
The following items concern all ATV's operator:
- Riding without an approved helmet increases the chances of a severe head
injury or death in the event of an accident. Riding without eye protection can
result in an accident and increases the chances of a severe injury in the event
of an accident.
-Riding without protective clothing increases the chances of severe injury in the
event of an accident.
HOWTO AVOID THEHAZARD
Always wear an approved helmet that fits properly. You should also wear:
-Eye protection(goggles or face shield)
-Gloves and boots
-Long sleeved shirt or jacket -Long pants.

11
POTENTIALHAZARD
Attempting wheelies, jumps and other stunts.
WHAT CAN HAPPEN
Increases the chance of an accident, including an overturn.
HOWTO AVOID THE HAZARD
Never attempt stunts, such as wheelies or jumps. Do not try to show off.
POTENTIALHAZARD
Failure to inspect the vehicle before operating.
Failure to properly maintain the vehicle.
WHATCANHAPPEN
Increases the possibility of an accident or equipment damage.
HOWTO AVOID THE HAZARD
Always inspect your vehicle prior to every time you use it to make sure
the vehicle is in safe operating condition.
Always follow the inspection and maintenance procedures and schedules
described further in this Operator's Guide.

12
POTENTIALHAZARD
Failure to use extra care when operating this vehicle on unfamiliar terrain.
WHATCAN HAPPEN
You can come upon hidden rocks, bumps, or holes, without enough time to
react.
Could result in the vehicle overturning or loss of control.
HOWTO AVOID THE HAZARD
Go slowly and be extra careful when operating on unfamiliar terrain.
Always be alert to changing terrain conditions when operating the vehicle.

13
POTENTIALHAZARD
Operating on excessively steep hills.
WHATCAN HAPPEN
The vehicle can overturn more easily on extremely steep hills than
on level surfaces or small hills.
HOWTO AVOID THEHAZARD
Never operate this vehicle on hills too steep for the vehicle or for
your abilities.
Practice on smaller hills before attempting larger hills.

14
POTENTIALHAZARD
Climbing hills improperly.
WHATCAN HAPPEN
Could cause loss of control or cause vehicle to overturn.
HOWTO AVOID THEHAZARD
Always follow proper procedures for climbing hills as described further in
this Operator's Guide.
Always check the terrain carefully before you start up any hill. Never climb
hills with excessively slippery or loose surfaces. Shift your weight forward.
Never open the throttle suddenly or make sudden gear changes.
The vehicle could flip over backwards.
Never go over the top of any hill at high speed. An obstacle, a sharp drop
or another vehicle or person could be on the other side of the hill.
