OEM 24875 Service manual

UNPACKING
After unpacking unit, inspect carefully for
any damage that may have occurred during
transit. Check for loose, missing, or damaged
parts. If any damage is observed, a shipping
damage claim must be filed with carrier.
Do not use the OEMTOOLS Fan if broken,
bent, cracked or damaged parts (including
labels) are noted. Any Fan that appears
damaged in any way, operates abnormally
or is missing parts should be removed from
service immediately. If you suspect that the
Fan was subjected to shock load (a load that
was dropped suddenly, unexpectedly, etc.)
immediately discontinue use until it has
been checked by a factory authorized
service center.
Please read and save these instructions. Read through this owner’s manual carefully before using product. Protect
yourself and others by observing all safety information, warnings, and cautions. Failure to comply with instructions
could result in personal injury and/or damage to product or property. Please retain instructions for future reference.
Operating Instructions and Parts Manual 24875
12/14
2014 ©OEMTOOLS
The following safety information is provided as a guideline to help you operate your Fan under the safest possible
conditions. Any tool or piece of equipment can be potentially dangerous to use when safety or safe handling
instructions are not known or not followed. The following safety instructions are to provide the user with the
information necessary for safe use and operation. Please read and retain these instructions for the continued safe use
of your service system. Failure to followinstructions listed belowmay result in serious injury. In addition, make certain
that anyone that uses the equipment understands and follows these safety instructions as well.
Explanation of Safety Signal Words
CAUTION
Notes
CAUTION
WARNING
WARNING
: Indicates a potentially hazardous situation which, if not avoided, could result in death or
serious injury.
: Indicates a potentially hazardous situation which, if not avoided, may result in minor or
moderate injury.
: Used without the safety alert symbol indicates a potentially hazardous situation which, if
not avoided, may result in property damage.
: Provide clarity and helpful information.
WARNING Pursuant to California Proposition 65, this product contains chemicals known to the state of
California to cause cancer and birth defects or other reproductive harm. Wash hands after handling.
36” DRUM FAN

2
Operating Instructions and Parts Manual 24875
36” DRUM FAN
Thank you very much for choosing an OEMTOOLS
Product!
For future reference, please complete the owner’s
record below:
Model: _______________ Purchase Date: _______________
Save the receipt, warranty and these instructions. It is
important that you read the entire manual to become
familiar with this product before you begin using it.
This machine is designed for certain applications only.
OEMTOOLS cannot be responsible for issues
arising from modification. We strongly recommend
this machine is not modified and/or used for any
application other than that for which it was
designed. If you have any questions relative to a
particular application, DO NOT use the machine until
you have first contacted OEMTOOLS to determine if
it can or should be performed on the product.
IMPORTANT INSTRUCTIONS
AND SAFETY RULES
1. Know your fan. Read this manual carefully. Learn
the fan’s applications and limitations, as well as,
potential hazards specific to it.
2. Keep work area clean and well lit. Cluttered or dark
work areas invite accidents.
3. Keep children away. All children should be kept
away from the work area. Never let a child handle
a fan without strict adult supervision.
4. DO NOT operate this fan if under the influence
of alcohol or drugs. Read warning labels on
prescriptions to determine if your judgment or
reflexes are impaired while taking drugs. If there is
any doubt, do not attempt to operate.
5. Use safety equipment. Eye protection should be
worn at all times when operating this fan. Use ANSI
approved safety glasses. Everyday eyeglasses are
NOT safety glasses. Dust mask, non-skid safety
shoes, hard hat or hearing protection should be used
in appropriate conditions.
6. Wear proper apparel. Loose clothing, gloves, neck-
ties, rings, bracelets or other jewelry may present a
potential hazard when operating this fan. Keep all
apparel clear of the fan.
7. Don’t overreach. Keep proper footing and balance
at all times when operating this fan.
8. Check for damage. Check your fan regularly. If
part of the fan is damaged it should be carefully
inspected to make sure that it can perform its
intended function correctly. If in doubt, the part
should be repaired. Refer all servicing to a qualified
technician. Consult your dealer for advice.
9. Keep away from flammables. Do not attempt
to operate this fan near flammable materials
or combustibles. Failure to comply may cause
serious injury or death.
10. Store idle fans out of the reach of children and
untrained persons. Fans may be dangerous in the
hands of untrained users.
• Maintain fan with care.
• Keep fan dry and clean.
•DO NOT use a damaged fan. Tag damaged fan “DO
NOT use” until repaired.
• Use only accessories that are recommended by the
manufacturer for your model. Accessories that may
be suitable for one tool may become hazardous
when used on another fan.
•Fan service must be performed only by qualified repair
personnel. Service or maintenance performed by
unqualified personnel could result in a risk of injury.
• When servicing a fan, use only identical replacement
parts. Use of unauthorized parts or failure to follow
maintenance instructions may create a risk of injury.
• Maintain a safe working environment. Keep the
work area well lit. Make sure there is adequate
surrounding workspace. Keep the work area free of
obstructions, grease, oil, trash, and other debris.
DO NOT use this product in a damp or wet location.
• Maintain labels and nameplates on this product.
These carry important information. If unreadable or
missing, contact OEMTOOLS for a replacement.
IMPORTANT SAFETY INSTRUCTIONS
The warnings, precautions, and instructions discussed
in this manual cannot cover all possible conditions
and situations that may occur. The operator must
understand that common sense and caution are
factors which cannot be built into this product, but
must be supplied by the operator.
DISPOSAL
At the end of the useful life of the OEMTOOLS Fan
dispose of the components according to all state,
federal, and local regulations
12/14
2014 ©OEMTOOLS

3
Operating Instructions and Parts Manual 24875
36” DRUM FAN
PURPOSE
The OEMTOOLS Fan 24875 is a 36” Drum Fan that not
only helps circulate the air and keep it in motion while
maintaining a fresh breeze but also helps to prevent the
inhalation of dangerous gasses and fumes by adding
ventilation
SAFETY INFORMATION
SAVE THESE INSTRUCTIONS
READ AND SAVE THESE INSTRUCTIONS
1. Unplug the fan before moving it or performing
maintenance. Do not touch the fan when your
hands are wet.
2. Those who are not qualified electricians should not
disassemble, repair or rebuild the fan.
3. Unplug the fan when it is not in use.
4. DO NOT unplug the fan by holding the cable cord.
Unplug by holding the plug.
5. DO NOT use the fan when there is damage to the
cable cord or plug.
6. Avoid the use of extension cords when possible.
Ensure that they are UL listed if they must be used.
DO NOT use a single extension cord to operate
more than one fan. DO NOT plug the fan into any
other cord-connected device (power strip, surge
protector, multiple outlet adapters ect.).
7. DO NOT use the fan close to any fire or heat
source.
8. DO NOT insert your hand or other objects into the
guard or the movable parts.
9. To reduce the risk of fire or electric shock, do not
use this fan with any solid-state speed control
device.
10. DO NOT use this fan outdoors.
11. Please don’t operate any fan with a damaged cord
or plug. Discard fan or return to an authorized
service facility for examination and/or repair.
12. Please don’t run cord under carpeting. Do not
cover cord with throw rugs, runners, or similar
coverings. Do not route cord under furniture or
appliances. Arrange cord away from traffic area
and where it will not be tripped over.
13. DO NOT use if electrical cord is frayed or bent.
14. DO NOT immerse the fan.
15. Fit the guard onto fan before starting up the fan.
16. This fan is not intended for use by people
(including children) with reduced physical, sensory
or mental capabilities or lack of experience
and knowledge unless they have been given
supervision or instructions concerning use of
the fan by a person responsible for their safety.
Supervise children to ensure they do not play with
the fan.
17. Always place the fan on a stable, flat, level surface
when operating, to avoid the chance of the fan
overturning.
18. DO NOT immerse fan in water.
OPERTATING INSTRUCTIONS
1. The fan comes with two different speeds.
2. Switch the fan on by turning the switch knob to
speed 1 or 2.
3. To switch the fan off, turn the switch knob to 0.
4. Assemble the wheel as the instruction of wheel
assembly drawing before operating.
DO NOT depend upon the on-off switch as the sole
means of disconnecting power when installing or
servicing the fan. Always unplug the power cord.
12/14
2014 ©OEMTOOLS
Size 36”
Weight 62 Lbs.
Voltage 120 V/60 Hz
Current 4.4 A
PRODUCT SPECIFICATIONS
WARNING
CAUTION
WARNING

123456
10
9
78
Front Guard
Blades
Drum Body
Rear Guard
Motor
Switch Box
Switch Knob
Power Cord and Plug
Wheel
Bracket
