Ohmtec OHM Series User manual

OHMTECHPRO.COM
User Guide V1.0
HIGHEND PROFESSIONAL
AUDIO POWER AMPLIFIER
DIGITAL AMPLIFIER
OHM SERIES
OHM D SERIES
This manual does not include all of the details of design, production, or variations of the equipment.
Nor does it cover every possible situation which may arise during installation, operation or maintenance.
READ THESE INSTRUCTIONS BEFORE UNPACK

BEFORE INSTALLING OR OPERATING THE EQUIPMENT, READ ALL SAFETY INSTRUCTIONS,
WARNINGS AND OPERATING INSTRUCTIONS. HEED ALL WARNINGS. FOLLOW ALL
INSTRUCTIONS. KEEP ALL SAFETY, INSTALLATION AND OPERATING INSTRUCTIONS FOR
FUTURE REFERENCE
WARNING!
OHMTECHPRO.COM
▪IF THE POWER CORD IS DAMAGED, PLEASE GET A REPLACEMENT FROM THE DISTRIB-
UTOR. OTHERWISE, CONTINUED USE OF THE EQUIPMENT MAY LEAD TO FIRE OR ELEC-
TRIC SHOCK.
▪IF THE DEVICE FALLS FROM A HEIGHT OR THE SHELL IS DAMAGED, PLEASE IMMEDI-
ATELY TURN OFF THE POWER SWITCH AND UNPLUG THE POWER PLUG. AND CONTACT
THE AGENT DEALER TO SOLVE THE PROBLEM.
▪WHEN ANY ABNORMALITY OCCURS, SUCH AS SMOKE, ODOR, ETC.
▪PLEASE TURN OFF THE POWER SWITCH IMMEDIATELY AND UNPLUG THE POWER
PLUG TO CHECK THE PROBLEM. AT THE SAME TIME, PLEASE CONTACT THE DISTRIBU-
TOR TO CHECK THE REASON FOR THE ABNORMALITY.
▪TO PREVENT ELECTRIC SHOCK DO NOT REMOVE TOP OR BOTTOM COVERS.
▪THE EQUIPMENT IS ONLY TESTED AND EVALUATED AT THE HIGHEST
▪ALTITUDE OF 2,000 METERS.
All information provided in this manual is accurate at the time of delivery. Due to version
change or design change, it cannot be timely notified.The latest information can be obtained
of contacting the distributor.
DESIGN CHANGES
WE RESERVE THE RIGHT TO CHANGE THE DESIGN OF ANY PRODUCT FROM TIME TO TIME
WITHOUT NOTICE AND WITH NO OBLIGATION TO MAKE CORRESPONDING CHANGES IN
PRODUCTS PREVIOUSLY MANUFACTURED.
The exclamation point triangle symbol prompts the user for important operation
and maintenance instructions.
Lightning, or the lightning triangle symbol, warns the user of the risk of electric
shocks.
Notice these symbols:
Electrical and electronic equipment may contain hazardous substances for humans and their environment.
The “crossed out wheelie bin” symbol present on the device and represented above is there to remind one
of the obligation of selective collection of waste. This label is applied to various products to indicate that the
product is not to be thrown away as unsorted municipal waste. At the end of life, dispose of this product by
returning it to the point of sale or to your local municipal collection point for recycling of electric and elec-
tronic devices. Customer participation is important to minimize the potential affects on the environment
and human health that can result from hazardous substances that may be contained in this product. Please,
dispose of this product and its packaging in accordance with local and national disposal regulations includ-
ing those governing the recovery and recycling of waste electrical and electronic equipment. Contact your
local waste administration, waste collection company or dealer.
Environmental precaution
2 | OHM Series

OHMTECHPRO.COM
Do not use this apparatus near water. Do not expose
this apparatus to drips or splashes. Do not place
any objects filled with liquids, such as vases, on the
apparatus.
Do not install near any heat sources such as radia-
tors, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat. No naked
flames, such as lighted candles, should be placed
on the apparatus. Do not install the apparatus in a
confined space such as a book case or similar unit.
Do not block any ventilation openings.
Ensure that foreign objects and liquids cannot get
into the equipment.
Install in accordance with the manufacturer’s
instructions. Only use attachments/accessories
specified by the manufacturer. Use only with the
cart, stand, tripod, bracket or table specified by the
manufacturer, or sold with the apparatus. When a
cart is used, use caution when moving the cart/
apparatus combination to avoid injury from
tip-over.
The apparatus should be located close enough to
the AC outlet so that you can easily grasp the power
cordplug at anytime.
The mains plug, the appliance coupler or the mains
switch is used as the disconnect device. Either
device
shall remain readily operable when the apparatus is
installed or used.
Unplug the apparatus from the wall outlet before
cleaning. Do not use liquid cleaners or aerosol
cleaners. Use a damp cloth for cleaning. Do not
attempt to service this product yourself, as opening
or removing covers may expose you to dangerous
voltage or other hazards. Refer all servicing to quali-
fied service personal. Servicing is required when
the apparatus has been damaged in any way, such
as power-supply cord or plug damaged, liquid has
been spilled or objects have fallen into the appara-
tus, the apparatus has been exposed to rain or
moisture, does not operate normally or has been
dropped.
The equipment may only be used for the purpose
described in the operation instructions. Never carry
out any work on the equipment other than as speci-
fied in the operating manual. Never push objects of
any kind into this product through openings, as they
may touch dangerous voltage points or short-cut
parts, which could result in a fire or electric shock.
Children should never use the apparatus without
close adult supervision.
WARNING: excessive sound pressure levels can
cause hearing loss.
This product should be operated only from the
power source indicated on the apparatus or in the
operating instructions. If you are not sure of the
type of power supply to the premises where the
equipment is to be used, consult your product
dealer or local power company.
Do not defeat the safety purpose of the polarised or
grounding-type plug. A polarised plug has two
blades with one wider than the other. A grounding
type plug has two blades and a third grounding
prong. The wide blade or the third prong is provided
for your safety. If the provided plug does not fit into
your outlet, consult an electrician for replacement
of the obsolete outlet.
Connect Class I construction apparatus to an AC
outlet with a protective grounding connection.
Do not overload wall outlets, extension cords or
integral convenience receptacles, as this can result
in a risk of fire or electric shock.
Protect the power cord from being walked on or
pinched, particularly at plugs, convenience recep-
tacles and the point where they exit from the appa-
ratus. Unplug this apparatus during lightning
storms or when unused for long periods of time.
POWER SUPPLY AND POWER CORD REQUIRE-
MENTS:
Power supply class I grounding requirements:
For protection from fault currents, the equipment
shall be connected to a grounding terminal. Plug
the system power cord into an AC outlet that
provides a ground connection. Substitute cords
may not provide adequate fault protection. Only use
the power cord supplied with this product or an
authorized/equivalent replacement
Installing and operation location
Cleaning, maintenance and
servicing
Intended use
Power source and grounding
3 | OHM Series

OHMTECHPRO.COM
Front panel Features
Dual Signal LED
LED Screen
Gain Control
Sets output level of each channel Air Vent
Allows Bow-through ventilation from front to back
LED Screen
Display device status
Power Switch
Press "1"-on; Press "O"-off
Note: For the convenience of introducing the front panel, this schematic diagram is a simplified sche-
matic diagram after removing the exterior decorative panel. Due to the change of version, it may be
inconsistent with the real thing, please refer to the product. The vent area and layout of this product have
been strictly tested of experiments to meet the cooling needs.
Please make sure not to block the vent during use.
The red LED turns on: This channel turn on protective state, stop working.
Please wait for around a minute, if the device still stops working, please restart the device.
The yellow LED flashes: This channel signal is audibly distorting. It may damage the tweeter.
The yellow LED turns on:
1. The temperature of the equipment ≥70°C;
2. The signal over load.
1. Display per channel operation mode: Mono mode, Bridge mode and Stereo mode;
2.Display the temperature of the equipment:
Green : the normal status, and the temperature of the equipment <69°C;
Orange: the warning of overheat, and the temperature of the equipment between 69°C and 75°C;
Red: the device turns on protective state, and the temperature of the equipment >75°C;
the output signal of SPEAKON ≥-3dB;
the output signal of SPEAKON ≥-5dB;
the output signal of SPEAKON ≥-10dB;
the output signal of SPEAKON ≥-20dB;
the input signal of XLR ≥-40dB;
Green Signal LED
4 | OHM Series

OHMTECHPRO.COM
Front panel Features
Front panel Features
Tunnel through cooling system
PFC Power
AC~100V-240V
wide voltage SPEAKON
One SPEAKON per channel connect to loudspeakers
Input Connectors
One balanced XLR per channel
Fans
NOTE:
The size is 437mm inside of the device(without
the cover plate and front panel).
The size is around 472mm of the complete
device, but a little bit different size in the different
front panel.
Some series with different size that had not
shown, please learn it in the parameter.
Cold air comes in from the front panel of the equipment, forms a duct through the radiator to take the
heat away and out from the rear panel of the equipment.
5 | OHM Series

OHMTECHPRO.COM
Front panel Features with DSP
Network Link
Note: For the convenience of introducing the front panel, this schematic diagram is a simplified sche-
matic diagram after removing the exterior decorative panel. Due to the change of version, it may be
inconsistent with the real thing, please refer to the product. The vent area and layout of this product have
been strictly tested of experiments to meet the cooling needs.
Please make sure not to block the vent during use.
DSP chip and software designed by ALLDSP in Germany.
https://alldsp-oem.com.
Professional audio applications for over 23 years.
Air Vent
Allows flow-through ventilation
from front to back
LED
Display device status
LED Screen
Display device status Power Switch
Press "'"-on; Press "O" -off
DSP Control Button
Network Link
6 | OHM Series

OHMTECHPRO.COM
Rear panel Features with DSP
To create a Loudspeaker Library file
To create a Loudspeaker Library file
Please do the following:
• Enter Developer mode
• Use the output channels starting at output one (1, 2, 3, .. and not 4, 5, 6)
• Mute all outputs that are not part of the system (for a one way use out 1 and mute the rest)
• You can define one-way, multi-way systems, setup a one loudspeaker of a stereo set
• Set-up the DSP to your liking for one system.
• Turn off "Show full graphics" for administrator mode. (The administrator needs it see the right skin)
• Name each output appropriately with clear labels that enable an easy check by the administrators
• Store the setting with a name starting with # in the highest position on the device (i.e. 100, 99, 98, 97,
• Enter Administrator mode
• Click on the appropriate loudspeaker icon for the output channel that you want to load the loudspeaker
to. This does not have to start at channel 1. (e.g. it is possible to define a two way loudspeaker, which must
be done on output 1 and 2, and to load that to output 5 and 6 later)
• Select the appropriate loudspeaker file from the pull down list
• Check for each output if the correct signal is applied to that channel
• Unmute the channels and slowly turn up the signal and check to make sure that each driver gets the
right signal
For more information about dsp features,
please visit the official website (https://alldsp-oem.com) or contact your supplier.
PFC Power
AC~100V-240V
wide voltage SPEAKON
One SPEAKON per channel connect to loudspeakers
Input Connectors
One balanced XLR per channel
Fans
7 | OHM Series

OHMTECHPRO.COM
Application introduction
2 channel Series
STEREO MODE
BRIDGE MODE
MONO MODE
8 | OHM Series

OHMTECHPRO.COM
4 channel Series
STEREO MODE
BRIDGE MODE
MONO MODE
9 | OHM Series

OHMTECHPRO.COM
Performance parameter
Power
Rated power demand
Operation voltage
Power correction factor cos (q)
Standby
Gain, Sensitivity Maximum Output
Voltage/Current Power Comsumption
PFC Power
100-240 V ‡10%, 50/60 Hz
90V-270V
>0.95 @ >500 W
47W and 0.8A
32dB, 35dB, 38dB, 41dB
185V/85A 370V in the BRIDGE MODE
Frequency Response
Signal-to-Noise Ratio
Crosstalk
Input Impedance
Total Harmonic Distortion (THD)
Intermodulation Distortion(IMD)
Damping Factor (8 ohms)
Slew Rate
Signal in-connection
Signal out-connection
Power cord
Multiple-Functions Switch
Dimensions
Net weight
Packing size
Shipping weight
20 Hz - 20 kHz (1 W @ 8 N, ‡0.5 dB)
>110 dBA (20 Hz - 20 kHz, A weighted)
> 66 dB @ 1 kHz
10 kΩ balanced
<0.5% from 1 W to full power (Typical value <0.05%)
<0.5% from 1 W to full power (Typical value <0.05%)
>5000 @ 20-200 Hz
50 V/us @ 8 Ω
One PCS Green LED: the input signal of XLR ≥-40dB;
Four pieces Green LED:
display the output signal (-20dB,-10dB,-5dB,-3dB) of SPEAKON
1 piece dual LED (Yellow and Red):
Protective state/Clip state/Over heat/Over load
1.Display per channel operation mode:
Mono mode, Bridge mode and Stereo mode;
Display the temperature of the equipment:
the device turns on protective state, and the temperature of the equip-
ment >75°C;
Press" I" -on; Press" O" -off.
Two pieces dust-proof cotton,
it can take off to clearn from the bottom of front pannel
4 Channel: One balanced XLR(with lock) female per channel;
2 Channel: One balanced XLR(with lock) female and one balanced XLR
male per channel.
One SPEAKON per channel connect to loudspeakers.
Fixed to the device, and the CSA( cross sectional area of the cord is 3 x
2.5mm and the cord is 1.5 meters long.
Two Sensitivity Switches, one Mode Switch and one Clip Switch.
482x44x380mm / 482x44x470mm
10Kg/12Kg
580x580x119mm / 615x615x119mm
12Kg/14Kg
Indicator LED/per channel
LED Screen
Power Switch
Dust-proof
Environment temperature
Cooling system
0°- 45C / 32°-113°F
Tunnel through cooling system
Alternating Current Power Supply
Temperature
Performance
Front Panel
Application
Structure(The size and weight depond on different series and shipping demand)
10 | OHM Series

OHMTECHPRO.COM
Power parameter - 2 CHANNEL
OHM-2250 (2*2500W) 2 Channel Mode Bridge Mode
EIAJ Test Standard, 1 kHz, 1% THD 8Ω 4Ω 8Ω 4Ω
8500W 11900W
2Ω
2*2500W 2*4800W
1271W, 7 A
2232W, 14 A
1271W, 13,7 A
2232W, 28,5 A
2*6800W
1/8 Maximum Power Output in 4Ω
1/4 Maximum Power Output in 4Ω
2 Channel Mode Bridge Mode
EIAJ Test Standard, 1 kHz, 1% THD 8Ω 4Ω 8Ω 4Ω
10200W 14280W
2Ω
2*3000W 2*5100W
1457W, 8 A
2564W, 16 A
1457W, 15,6 A
2564W, 31,8 A
2*7140W
1/8 Maximum Power Output in 4Ω
1/4 Maximum Power Output in 4Ω
2 Channel Mode Bridge Mode
EIAJ Test Standard, 1 kHz, 1% THD 8Ω 4Ω 8Ω 4Ω
13000W 15000W
2Ω
2*3500W 2*6500W
1857W, 10 A
3268W, 20 A
1857W, 19,2 A
3268W, 38,9 A
2*7500W
1/8 Maximum Power Output in 4Ω
1/4 Maximum Power Output in 4Ω
2 Channel Mode Bridge Mode
EIAJ Test Standard, 1 kHz, 1% THD 8Ω 4Ω 8Ω 4Ω
15600W 17000W
2Ω
2*4200W 2*7800W
2228W, 12 A
3920W, 23 A
2228W, 24,6 A
3920W, 47,1 A
2*8500W
1/8 Maximum Power Output in 4Ω
1/4 Maximum Power Output in 4Ω
OHM-2300 (2*3000W)
OHM-2350 (2*3500W)
OHM-2420 (2*4200W)
11 | OHM Series

OHMTECHPRO.COM
Power parameter - 4 CHANNEL
4 Channel Mode Bridge Mode
EIAJ Test Standard, 1 kHz, 1% THD 8Ω 4Ω 8Ω 4Ω
2*3400W 2*5780W
2Ω
4*1000W 4*1700W
1020W, 6 A
1800W, 9,36 A
1020W, 10,8 A
1800W, 24,96 A
4*2890W
1/8 Maximum Power Output in 4Ω
1/4 Maximum Power Output in 4Ω
4 Channel Mode Bridge Mode
EIAJ Test Standard, 1 kHz, 1% THD 8Ω 4Ω 8Ω 4Ω
2*4300W 2*6390W
2Ω
4*1300W 4*2150W
1360W, 7,5 A
2400W, 12,48 A
1360W, 14,4 A
2400W, 25,08 A
4*3195W
1/8 Maximum Power Output in 4Ω
1/4 Maximum Power Output in 4Ω
4 Channel Mode Bridge Mode
EIAJ Test Standard, 1 kHz, 1% THD 8Ω 4Ω 8Ω 4Ω
2*5200W 2*7000W
2Ω
4*1600W 4*2600W
1700W, 9,1 A
3000W, 15,6 A
1700W, 18 A
3000W, 31,2 A
4*3500W
1/8 Maximum Power Output in 4Ω
1/4 Maximum Power Output in 4Ω
4 Channel Mode Bridge Mode
EIAJ Test Standard, 1 kHz, 1% THD 8Ω 4Ω 8Ω 4Ω
2*6800W 2*9520W
2Ω
4*2000W 4*3400W
2125W, 11,375 A
3750W, 19,5 A
2125W, 22,5 A
3750W, 39 A
4*4760W
1/8 Maximum Power Output in 4Ω
1/4 Maximum Power Output in 4Ω
4 Channel Mode Bridge Mode
EIAJ Test Standard, 1 kHz, 1% THD 8Ω 4Ω 8Ω 4Ω
2*10000W 2*13000W
2Ω
4*3000W 2*5000W
2857W, 14 A
5000W, 23,8 A
2857W, 28,2 A
5000W, 45,8 A
2*6500W
1/8 Maximum Power Output in 4Ω
1/4 Maximum Power Output in 4Ω
OHM-4100 (4*1000W)
OHM-4130 (4*1300W)
OHM-4160 (4*1600W)
OHM-4160 (4*2000W)
OHM-4300 (4*3000W)
12 | OHM Series

OHMTECHPRO.COM
Important Safety Instructions
Safety Warnings
+30 C
0 °C
OPERATING TEMPERATURE RANGE: 0°C TO +35°C - DERATING ABOVE 35°C.
10%
85%
%STORAGE RELATIVE HUMIDITY RANGE: 10% TO 85% HUMIDITY (NON CONDENSING).
DO NOT USE THE UNIT AT ALTITUDES ABOVE 2000 M.
DO NOT USE THE UNIT IN TROPICAL ENVIRONMENT.
CLASS3
WIRING
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT ATTEMPT TO OPEN ANY PART OF THE UNIT. NO
USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
CLASS3
WIRING
CONNECTION TO THE MAINS SHALL BE DONE ONLY BY A ELECTROTECHNICAL SKILLED PERSON
ACCORDING THE NATIONAL REQUIREMENTS OF THE COUNTRIES WHERE THE UNIT IS SOLD.
CLASS3
WIRING
DO NOT USE THIS AMPLIFIER IF THE ELECTRICAL POWER CORD IS FRAYED OR BROKEN.
CLASS3
WIRING
TO AVOID ELECTRICAL SHOCK, DO NOT TOUCH ANY EXPOSED SPEAKER WIRING WHILE THE
AMPLIFIER IS OPERATING.
CLASS3
WIRING
DO NOT SPILL WATEROR OTHERLIQUIDS INTO ORON THE AMPLIFIER.
CLASS3
WIRING
THIS DEVICE MUST BE POWERED EXCLUSIVELY BY EARTH CONNECTED MAINS SOCKETS IN
ELECTRICAL NETWORKS COMPLIANT TO THE IEC 364 OR SIMILAR RULES
CLASS3
WIRING
DISCONNECT THE AC MAINS SOURCE BEFORE ATTEMPTING TO CLEAN ANY PART OF THE AMPLIFIER
CLASS3
WIRING
PROPERLY FIT THE AC MAINS PLUG TO THE AMPLIFIER INLET.
BEFORE POWERING THIS AMPLIFIER, VERIFY THAT THE CORRECT VOLTAGE RATING IS BEING USED.
CLASS3
WIRING
TAKE CARE TO LOCK THE OUTPUT TERMINAL BEFORE SWITCHING THE DEVICE ON.
CLASS3
WIRING
VERIFY THAT YOUR MAINS CONNECTION IS CAPABLE OF SATISFYING THE POWER RATINGS OF THE
DEVICE.
CLASS3
WIRING
NO NAKED FLAME SOURCES SUCH AS LIGHTED CANDLES SHOULD BE PLACED ON THE AMPLIFIER.
CLASS3
WIRING
IT IS HIGHLY RECOMMENDED TO UNPLUG THE OUTPUT CONNECTORS BEFORE PROCEEDING WITH
THE SELF CHECK PROCEDURE
CLASS3
WIRING
THE TESTING SIGNALS MIGHT CAUSE LOUDSPEAKER IMPAIRMENTS.
CLASS3
WIRING
TO PREVENT INJURY, THIS APPARATUS MUST BE SECURELY RACK MOUNTED IN ACCORDANCE WITH
THE INSTALLATION INSTRUCTIONS.
CLASS3
WIRING
THE MANUFACTURER CANNOT BE HELD RESPONSIBLE FOR DAMAGES CAUSED TO PERSONS,
THINGS OR DATA DUE TO AN IMPROPER OR MISSING GROUND CONNECTION.
CLASS3
WIRING
IT IS ABSOLUTELY NECESSARY TO VERIFY THESE FUNDAMENTAL REQUIREMENTS OF SAFETY AND, IN
CASE OF DOUBT, REQUIRE AN ACCURATE CHECK BY QUALIFIED PERSONNEL.
Common symbols and meanings
CLASS3
WIRING
THE TRIANGLE WITH THE LIGHTNING BOLT IS USED TO ALERT THE USER TO THE RISK OF ELECTRIC
SHOCK.
CLASS3
WIRING
THE TRIANGLE WITH THE EXCLAMATION POINT IS USED TO ALERT THE USER TO IMPORTANT
OPERATING OR MAINTENANCE INSTRUCTIONS.
THE CE-MARK INDICATES THE COMPLIANCE OF THE PRODUCT TO ALL THE APPLICABLE EUROPEAN
DIRECTIVES
SYMBOL FOR EARTH/GROUND CONNECTION.
SYMBOL INDICATING THAT THE EQUIPMENT IS FOR INDOOR USE ONLY.
SYMBOL FOR CONFORMITY WITH DIRECTIVE 2012/19/EC OF THE EUROPEAN PARLIAMENT ON WASTE
ELECTRICAL AND ELECTRONIC EQUIPMENT (WEEE).
Technical Service
Warranty
Please read and keep all safety and use instructions.
This product is intended for installation by professional installers only! This
document is intended to provide professional installers with basic installa-
tion and
safety guidelines for this product in typical fixed-installation systems.
Please read this
document and all safety warnings before attempting installation.
1. Read these instructions before unpack
• Keep these instructions.
• Heed all warnings.
• Follow all instructions.
• Please keep the accessories (such as feet, instructions, desiccant and
plastic bags) away from children.
• The packaging of the equipment is guaranteed of the drop test, ensuring
that the original packaging is used in the transportation.
2. The installation operation
• Do not use this apparatus near water.
• Do not block any ventilation openings.
• Do not install near any heat sources.
• Do not damage the safety function of the device with the polarity plug or
grounding plug.
• Protect the power cord from being walked on or pinched, particularly at
plugs, convenience receptacles, and the point where they exit from the
apparatus.
Unplug this apparatus during lighting storms or when unused for long
periods of time.
• Do not expose this equipment to dripping or splashing and ensure that no
object filled with liquids.
3. Use equipment
• Please make sure to turn the volume control knob to the minimum before
turning on the power of the device. Otherwise, sudden bursts of sound may
damage your hearing.
• Please avoid using the equipment on unstable surfaces or bevels.
• Please avoid using the equipment in the environment with high air
humidity or dust accumulation.
• Please avoid using the equipment in an overheated environment.
• When connecting to the device, turn off all audio devices and speakers.
SUMMARY OF WARRANTY
The warranty period provided by our company is one year (The warranty
period is calculated from the purchase date of the original purchaser).
During the warranty period, you can obtain the free maintenance if the
product material and process caused by the problem.
WHAT THE WARRANTOR WILL DO
We will remedy any defect, regardless of the reason for failure (except as
excluded), by repair, replacement. Warranty work can only be performed at
our authorized service centers or at the factory.
WHAT SITUATION INVALID BY THE WARRANTY SERVICE
• Exceeds warranty period posterior product.
• The warranty does not cover any product which has been damaged
because of any intentional misuse, accident, negligence, or loss which is
covered under any of your insurance contracts.
• This Warranty also does not extend to the new product if the serial num
ber has been defaced, altered, or removed.
• The equipment has been repaired or modified by people who does not
belong to our company.
• The equipment broken in case of force majeure such as earthquake and
fire, etc.
• Damage in transit caused by not using the original packaging, such as
scratches, deformation or falls.
SUMMARY OF NON-WARRANTY SERVICE
The company provides paid maintenance services for products that have
passed the warranty period. We'll show you the test report. And we will not
start the repair until we get your approval and receive the cost for replace-
ment parts. If you do not agree to repair, please take back the equipment.
THE COMPANY HAS NO OBLIGATION TO KEEP YOUR EQUIPMENT.
IF THE EQUIPMENT IS NOT TAKEN BACK WITHIN 30 DAYS WITHOUT SPECIAL
REASONS, THE COMPANY SHALL HAVE THE RIGHT TO DISPOSE OF IT AT ITS
OWN DISCRETION.
Warnings
CLASS3
WIRING
CLASS3
WIRING
DO NOT OPEN
RISK OF ELECTRICAL SHOCK
This product is covered by a limited warranty
This Ohmtech product contains no user-serviceable parts. All warranty repairs must be carried by a certified
technician operating in a Ohmtech Authorized Service Centre
Contact The Authorized Service Center For Ordinary And Extraordinary Maintenance
To learn more about warranty terms and conditions, visit ohmtechpro.com
13 | OHM Series

OHMTECHPRO.COM
