Omega OM30GX User manual

omega
MODEL:OM30GX
Read these instructions carefully before using your
microwave oven, and keep it carefully.
If you follow the instructions, your oven will provide you with
many years of good service.
SAVE THESE INSTRUCTIONS CAREFULLY

2
PRECAUTIONS T O AVOID POSSIBLE EXPOSURE
T O EXCESSIVE MICROWAVE ENERGY
(a) Do not attempt to operate this oven with the door open since this can
result in harmful exposure to microwave energy. It is important not to
break or tamper with the safety interlocks.
(b) Do not place any object between the oven front face and the door or allow
soil or cleaner residue to accumulate on sealing surfaces.
(c) WARNING: If the door or door seals are damaged, the oven must not
be operated until it has been repaired by a competent person.
ADDENDUM
If the apparatus is not maintained in a good state of cleanliness, its surface could
be degraded and affect the lifespan of the apparatus and lead to a dangerous
situation.
Specifications
Model:
OM30GX
Rated Voltage:
240V~50Hz
Rated Input Power(Microwave): 1450W
Rated Output Power(Microwave):
900W
Rated Input Power(Grill):
100W1
Oven Capacity:
30L
Turntable Diameter:
315 mm
External Dimensions: 520x43 x3 mm5 25
Net Weight:
Approx. 15kg

3
IMPORTANT SAFETY INSTRUCTIONS
WARNING
To reduce the risk of fire, electric shock, injury to persons or exposure to excessive
microwave oven energy when using your appliance, follow basic precautions, including
the following:
1. Warning: Liquids and other foods must
not be heated in sealed containers since
they are liable to explode.
2. Warning:It is hazardousfor anyone other
than a competent person to carry out any
service or repair operation that involves
the removal of a cover which gives
protection against exposure to microwave
energy.
3. The appliance is not intended for use by
persons (including children) with
reduced physical, sensory or mental
capabilities, or lack of experience and
knowledge, unless they have been given
supervised or instruction concerning use
of the appliance by a responsible person
for their safety.
4. Keep the appliance and its cord out of
reach of children.
5. Only use utensils suitable for use in
microwave ovens.
6. The oven should be cleaned regularlyand
any food deposits should be removed.
7. Read and follow the specific: "PRECAU-
TIONS TO AVOID POSSIBLE EXPOSURE
TO
EXCESSIVE MICROWAVE ENERGY".
8. When heating food in plastic or paper
containers, keep an eye on the oven due
to the possibility of ignition.
9. If smoke is emitted, switch off or unplug
the appliance and keep the door closed
in order to stifle any flames.
10. Do not overcook food.
11. Do not use the oven cavity for storage
purposes. Do not store items, such as
bread, cookies, etc. inside the oven.
12. Remove wire twist-ties and metal handles
from paper or plastic containers/bags
before placing them in the oven.
13. Install or locate this oven only in
accordance with the installation
instructions provided .
14. Eggs in the shell and whole
hard-boiled
eggs should not be heated in microwave
ovens since they may explode, even
after microwave heating has ended.
15.This appliance is intended to be used in
household and similar applications such
as:
-staff kitchen areas in shops, offices and
other working environments;
-by clients in hotels, motels and other
residential type environments;
-farm houses;
-bed and breakfast type environments.
16. If the supply cord is damaged, it must
be replaced by the manufacturer, its
service agent or similarly qualified
persons in order to avoid a hazard.
17. Do not store or use this
appliance
outdoors.
18. Do not use this oven near water, in
a
wet basement or near a swimming
pool.
19. The temperature of accessible surfaces
may be high when the appliance is
operating. The surfaces are liable to get
hot during use . Keep cord away from
heated surface, and do not cover any
vents on the oven.
20. Do not let cord hang over edge of table
or counter.
21. Failure to maintain the oven in a
clean
condition could lead to deterioration
of the surface that could
adversely
affect the life of the appliance and
possibly result in a hazardous situation.
22. The contents of feeding bottles
and
baby food jars shall be stirred or shaken
and the temperature checked before
consumption,
in order to avoid burns.

4
23. Microwave heating of beverages can result in delayed eruptive boiling,
therefore
care must be taken when handling the container.
unless they have been given supervision or instruction concerning use of the appliance
by a person responsible for their safety.
24. Young children should be supervised to ensure that they do not play with the appliance.
25. The appliances are not intended to be operated by means of an external timer
or
separate remote-control system.
26. Accessible parts may become hot during use. Young children should be kept away.
27. Steam cleaner is not to be used.
28. During use the appliance becomes hot. Care should be taken to avoid touching heating
elements inside the oven.
29. Only use the temperature probe recommended for this oven.(for ovens provided with a
facility to use a temperature-sensing probe.)
30. WARNING: The appliance and its accessible parts become hot during use.Care should
be taken to avoid touching heating elements. Children shall be kept away unless
continuously supervised.
31. The microwave oven must be operated with the decorative door open.(for ovens with a
decorative door.)
32. The rear surface of appliance shall be placed against a wall
.
33. The microwave oven shall not be placed in a cabinet unless it has been tested in
a cabinet.
34. WARNING: Only allow children to use the oven without supervision when adequate
instructions have been given so that the child is able to use the oven in a safe way and
understands the hazards of improper use.
READ CAREFULLY AND KEEP FOR FUTURE
REFERENCE

5
To Reduce the Risk of Injury to Persons
DANGER
ElectricShockHazard
Touchingsome of the internal
components cancauseseriouspersonal
injuryordeath. Donotdisassemblethis
appliance.
WARNING
1. A short power-supply cord is provided
to reduce the risks resulting from
becoming entangled in or tripping over a
longer cord.
2. If a long cord set or extension cord is
used:
1) The marked electrical rating of the cord
set or extension cord should be at least as
great as the electrical rating of the
appliance.
3) The long cord should be arranged so
that it will not drape over the counter
top or tabletop where it can be pulled
on by children or tripped over
unintentionally.
CLEANING
Besuretounplugtheappliancefromthe
powersupply.
1. Cleanthecavityoftheovenafterusing
withaslightlydampcloth.
2. Cleantheaccessoriesintheusualway
insoapywater.
3. Thedoorframeandsealand
neighbouringpartsmustbecleaned
carefullywithadampcloth whenthey
aredirty.
4. Do not use harsh abrasive cleaners
or sharp metal scrapers to clean the
oven door glass since they can
scratch the surface, which may
result in shattering of the glass.
5. Cleaning Tip---For easier cleaning of the
cavity walls that the food cooked can
touch:
Place half a lemon in a bowl, add 300ml
(1/2 pint) water and heat on 100%
microwave power for 10 minutes.
Wipe the oven clean using a soft, dry cloth.

6
UTENSILS See the instructions on "Materials you can use in
microwave oven or to be avoided in microwave oven."
There may be certain non-metallic utensils that are not
CAUTION
Personal Injury Hazard
It is hazardous for anyone
other than a compentent person to
carry out any service or repair
operation that involves the removal
of a cover which gives protection
against exposure to microwave
energy.
safe to use for microwaving. If in doubt, you can test the
utensil in question following the procedure below.
Utensil Test:
1. Fill a microwave-safe container with 1 cup of cold
water (250ml) along with the utensil in question.
2. Cook on maximum power for 1 minute.
3. Carefully feel the utensil. If the empty utensil is
warm, do not use it for microwave cooking.
4. Do not exceed 1 minute cooking time.
Materials you can use in microwave oven
Utensils Remarks
Aluminum foil Shielding only. Small smooth pieces can be used to cover thin parts of
meat or poultry to prevent overcooking. Arcing can occur if foil is too
close to oven walls. The foil should be at least 1 inch (2.5cm) away from
oven walls.
Browning dish
Dinnerware
Glass jars
Glassware
Oven cooking
bags
Paper plates
and cups
Paper towels
Parchment
paper
Plastic
Plastic wrap
Follow manufacturer’s instructions. The bottom of browning dish must be
at least 3/16 inch (5mm) above the turntable. Incorrect usage may cause
the turntable to break.
Microwave-safe only. Follow manufacturer's instructions. Do not use
cracked or chipped dishes.
Always remove lid. Use only to heat food until just warm. Most glass jars
are not heat resistant and may break.
Heat-resistant oven glassware only. Make sure there is no metallic trim.
Do not use cracked or chipped dishes.
Follow manufacturer’s instructions. Do not close with metal tie. Make
slits to allow steam to escape.
Use for short–term cooking/warming only. Do not leave oven unattended
while cooking.
Use to cover food for reheating and absorbing fat. Use with supervision
for a short-term cooking only.
Use as a cover to prevent splattering or a wrap for steaming.
Microwave-safe only. Follow the manufacturer’s instructions. Should be
labeled "Microwave Safe". Some plastic containers soften, as the food
inside gets hot. "Boiling bags" and tightly closed plastic bags should be
slit, pierced or vented as directed by package.
Microwave-safe only. Use to cover food during cooking to retain
moisture. Do not allow plastic wrap to touch food.
Thermometers Microwave-safe only (meat and candy thermometers).
Wax paper Use as a cover to prevent splattering and retain moisture.

7
Materials to be avoided in microwave oven
Utensils Remarks
Aluminum tray
Food carton with May cause arcing. Transfer food into microwave-safe dish.
May cause arcing. Transfer food into microwave-safe dish.
metal handle
Metal or metal-
trimmed utensils
Metal twist ties
Paper bags
Plastic foam
Wood
Metal shields the food from microwave energy. Metal trim may
cause arcing.
May cause arcing and could cause a fire in the oven.
May cause a fire in the oven.
Plastic foam may melt or contaminate the liquid inside when exposed
to high temperature.
Wood will dry out when used in the microwave oven and may split
or crack.
SETTING UP YOUR OVEN
Names of Oven Parts and Accessories
Remove the oven and all materials from the carton and oven cavity.
Your oven comes with the following accessories:
Glass tray 1
A
Turntable ring assembly 1
Instruction Manual 1
F
E
D
G
Grill Rack( Only be used in grill function
and be placed on the glass tray )
C
B
A) Control panel
B)
Turntable shaft
C)
Turntable ring assembly
D) Glass tray
E)
Observation window
F) Door assembly
G) Safety interlock system

8
Turntable Installation
Hub (underside)
Glass tray
Turntable shaft
a. Never place the glasstray upside down. The glass
tray should never be restricted.
b. Both glass trayand turntable ring
assembly must
always be used during cooking.
c. All food and containers of food are always placed
on the glasstray for cooking.
d. Ifglasstrayor
turntable ring assembly cracks or
breaks, contact your nearest authorized service
center.
Turntable ring assembly
Countertop Installation
Remove all packing material and accessories.
Examine the oven for any damage such as
dents or broken door. Do not install if oven is
damaged.
Installation
1. Select a level surface that provide
enough open space for the intake
and/or outlet vents.
30cm
Cabinet: Remove any protective film found
on the microwave oven cabinet surface.
Do not remove the light brown Mica cover
that is attached to the oven cavity to
protect the magnetron.
(4) Blocking the intake and/or outlet openings
can damage the oven.
(5) Place the oven as far away from
radios and TV as possible.
0cm
20cm
min85cm
20cm Operation of microwave oven may
cause interference to your radio or TV
reception.
2. Plug your oven into a standard household
outlet. Be sure the voltage and the
frequency is the same as the voltage
and the frequency on the rating label.
(1) The minimum installation height is
85cm.
(2) The rear surface of appliance shall
be placed against a wall.
Leave a minimum clearance of
30cm above the oven, a minimum
clearance of 20cm is required
between the oven and any adjacent
walls.
(3) Do not remove the legs from the
bottom of the oven.
WARNING: Do not install oven over a
range cooktop or other heat-producing
appliance. If installed near or over a heat
source, the oven could be damaged and
the warranty would be void.
The accessible surface
may be hot during
operation.

9
OPERATION INSTRUCTION
This microwave oven uses modern electronic controls to meet your cooking needs.
1.Clock Setting
When the microwave oven is Power On, the oven will display "0:00", buzzer will
ring once.
1) Press " CLOCK/KITCHEN TIMER " once. "00:00" displays.
2) Turn " " to adjust the hour figures, the input time should be within 0--23(24-hour).
3) Press " CLOCK/KITCHEN TIMER ", the minute figures will flash.
4) Turn " " to adjust the minute figures, the input time should be within 0--59.
5) Press " CLOCK/KITCHEN TIMER" to finish clock setting. ":" will flash.
Note: 1) If the clock is not set, it would not function when powered.
2) During the process of clock setting, if you press " STOP/CLEAR ", the oven
will go back to the previous status automatically.
2. Kitchen Timer
(1) Press " CLOCK/KITCHEN TIMER " twice, LED will display 00:00.
(2) Turn " " to enter the correct timer.(The maximum cooking time is 95 minutes.)
(3) Press " START/+30SEC./CONFIRM " to confirm setting.
(4) When the kitchen time is reached, the buzzer will ring 5 times.
If the clock be set(24-hour system), LED will display the current time.
Note: The kitchen Time is differ from 24-hour system,Kitchen Timer is a timer.
3. Microwave Cooking
Press " Microwave " the LED will display "P100".Press " Microwave " for times
or turn " "to choose the power you want, and "P100", "P80" "P50", "P30" or
"P10" will display for each added press. Then press "START/+30SEC./CONFIRM " to
confirm, and turn " " to set cooking time from 0:05 to 95:00. Press
" START/+30SEC./CONFIRM " again to start cooking.

10
Example: If you want to use 80% microwave power to cook for 20 minutes, you can
operate the oven as the following steps.
1) Press " Microwave " once, the screen display "P100".
2) Press "Microwave " once again or turn" " to choose 80% microwave power.
3) Press "Start/+30Sec./Confirm " to confirm, and the screen displays "P 80".
4) Turn " " to adjust the cooking time until the oven displays "20:00".
5) Press " Start/+30Sec./Confirm" to start cooking .
NOTE: the step quantities for the adjustment time of the coding switch are as follow:
0---1 min : 5 seconds
1---5 min : 10 seconds
5---10 min : 30 seconds
10---30 min : 1 minute
30---95 min : 5 minutes
Microwave Power Chart
Press Once Twice Thrice 4 times 5 times
Microwave Power
100%
80%
50%
30%
10%
4. Grill or Combi. Cooking
Press " Grill/Combi. " the LED will display "G",and press "Grill/Combi. "for times
or turn the " " to choose the power you want, and "G","C-1"or"C-2" will display
for each added press. Then press "Start/+30Sec./Confirm " to confirm, and turn " "
to set cooking time from 0:05 to 95:00. Press
"Start/+30Sec./Confirm" again to start cooking.
Example: If you want to use grill power to cook for 10 minutes, you can operate the
oven as the following steps.
1) Press " Grill/Combi. " once, the screen display "G".
2) Press " Start/+30Sec./Confirm " to confirm.
3) Turn " " to adjust the cooking time until the oven displays "10:00".
4) Press " Start/+30Sec./Confirm " to start cooking .
Note:If half the grill time passes, the oven sounds twice, and this is normal.
In order to have a better effect of grilling food, you should turn the food over,
close the door, and then if no operation the oven will continue cooking.

11
"Grill/Combi." Pad instructions
Order
Display
1 G
2 C-1
3 C-2
Microwave
Power
0%
55%
36%
Grill
Power
100%
45%
64%
5.Multi-Stage Cooking
Two stages can be maximally set. If one stage is defrosting, it should be put in the first
stage. The buzzer will ring once after each stage and the next stage will begin.
Note: Auto menu and preheating cannot be set as one of the multi-stage.
Example: if you want to defrost the food for 5 minutes, then to cook with 80%
microwave power for 7 minutes. The steps are as following:
1) Press "Time Defrost", the screen will display "dEF2";
2) Turn " " to adjust the defrost time of 5 minutes;
3) Press"MICROWAVE" once;
4) Turn " " to choose 80% microwave power till "P80" display;
5) Press "START/+30SEC./CONFIRM" to confirm;
6) Turn " " to adjust the cooking time of 7 minutes;
7) Press "START/+30SEC./CONFIRM" to start cooking.
6. Speedy Cooking
1) In waiting state, press "START/+30SEC./CONFIRM" key to cook with 100% power
level for 30 seconds. Each press on the same key can increase 30 seconds. The
maximum cooking time is 95 minutes.
2) During microwave,grill and combination states, press
"START/+30SEC./CONFIRM" key to cook with 100% power level for 30 seconds.
Each press on the same key can increase 30 seconds.
Note: this function cannot work under defrost and auto menu cooking.
7. Speedy Microwave Cooking
In waiting state, turn " " left to choose cooking time directly then press
"START/+30SEC./CONFIRM" key to cook with 100% microwave power.
This program can be set as one of multi-stage.

12
Auto menu Chart
Menu
Weight(g)
Display
Power
A-1
PIZZA
200
200
100%
400
400
A-2
Meat
250
250
100% 350
350
450
450
A-3
Vegetable
200
200
100%
300
300
400
400
A-4
Pasta
50g(with 450g cold
water)
50
80%
100g(with 800g cold water)
100
A-5
Potato
200
200
100%
400
400
600
600
A-6
Fish
250
250
80%
350
350
450
450
A-7
Beverage
1 cup
about(120ml)
1
100%
2 cup about(240ml)
2
3 cup about(240ml)
3
A-8
Popcorn
50
50
100%
85
85
100
100
8. Auto Menu
1) In waiting state, turn " " right to choose the function wanted,
and "A-1","A-2","A-3"...."A-8" will be displayed.
2) Press "START/ +30 SEC./CONFIRM" to confirm the menu you need.
3) Turn " " to choose the weight of menu,and "g" indicator will light.
4) Press "START/ +30 SEC./CONFIRM" to start cooking.

13
9. Weight Defrost
1) Press "Weight Defrost " ,the oven will display "dEF1",.
2) Turn " " to select the weight of food.At the same time, "g" will lights,
The weight should be 100-2000g.
3) Press "START/+30SEC./CONFIRM" key to start defrosting.
10. Time Defrost
1) Press " Time Defrost ", the oven will display "dEF2"
2) Turn " " to select the cooking time. The maximum setting time is 95 minutes.
3) Press " START/+30SEC./CONFIRM" key to start defrosting.
11. Inquiring Function
(1) During cooking state, press "CLOCK/KITCHEN TIMER" to check the current time. It will be
displayed for 2-3 seconds.
(2) In cooking state, press "MICROWAVE"or"GRILL/ COMBI." , the current power will be
displayed for 2-3 seconds.
12. Lock-out Function for Children
Lock: In waiting state, press "STOP/CLEAR" for 3 seconds, there will be a long beep
denoting entering the children-lock state and the locked indicator will display if the
time has been set, otherwise, the LED will display " ".
Lock quitting: In locked state, press "STOP/CLEAR " for 3 seconds, there will be a long
"beep" denoting that the lock is released.
13. Specification
(1) The buzzer will sound once when turning the knob at the beginning;
(2) "START/+30 SEC./CONFIRM" must be pressed to continue cooking if the door is opened
during cooking;
(3) Once the cooking programmer has been set , "START/+30 SEC./CONFIRM" is not
pressed in 1minute. The current time will be displayed. The setting will be cancelled.
(4) The buzzer sounds once by efficient press, inefficient press will be no response.
(5) The buzzer will sound five times to remind you when cooking is finished.

14
Trouble shooting
It is forbidden to run the unit without any food inside.
It is very dangerous.
The Oven should be separately collected and treated. If at any
time in future you need to dispose of this product please do
NOT dispose of this product with household waste.
