OMNI-IP KNC-p3DR28V12IR User guide

1
KNC-p3DR28V12IR
IP66 Varifocal IR Dome Camera
Network Dome Camera
Quick Operation Guide

KNC-p3DR28V12IR Varifocal Dome Camera Quick Operation Guide
1
1
Thank you for selecting this KT&C Omni IP Series product. For
additional information please refer to the complete User Guide for
this cameras series. End users should contact their KT&C Certified
Dealer for service. Certified Dealers can obtain support directly from
KT&C.
About This Guide
While KT&C makes every effort to insure the completeness and
accuracy of the information contained in this Guide, we are not
responsible for typographical errors or misprints. At the same time,
KT&C reserves the right to make changes to improve the performance
of our products at any time without notice, and so the specifications
and content of this document are subject to change without notice.
Every effort will be made to include updates in new versions of this
manual and/or online.
DISCLAIMER STATEMENT
“Underwriters Laboratories Inc. (“UL”) has not tested the
performance or reliability of the security or signaling aspects of this
product. UL has only tested for fire, shock or casualty hazards as
outlined in UL’s Standard(s) for Safety, UL60950-1. UL Certification
does not cover the performance or reliability of the security or
signaling aspects of this product. UL MAKES NO REPRESENTATIONS,
WARRANTIES OR CERTIFICATIONS WHATSOEVER REGARDING THE
PERFORMANCE OR RELIABILITY OF ANY SECURITY OR SIGNALING
RELATED FUNCTIONS OF THIS PRODUCT.

KNC-p3DR28V12IR Varifocal Dome Camera Quick Operation Guide
2
2
Regulatory Information
FCC Information
FCC compliance: This equipment has been tested and found to
comply with the limits for a digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in
a residential area is likely to cause harmful interference in which case
the user will be required to correct the interference at his own
expense.
FCC Conditions
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received, including
interference that may cause undesired operation.
EU Conformity Statement
This product and - if applicable - the supplied
accessories too are marked with "CE" and comply
therefore with the applicable harmonized European
standards listed under the Low Voltage Directive 2006/95/EC, the
EMC Directive 2004/108/EC, the RoHS Directive 2011/65/EU.

KNC-p3DR28V12IR Varifocal Dome Camera Quick Operation Guide
3
3
2012/19/EU (WEEE directive): Products marked with
this symbol cannot be disposed of as unsorted
municipal waste in the European Union. For proper
recycling, return this product to your local supplier
upon the purchase of equivalent new equipment, or
dispose of it at designated collection points. For more information
see: www.recyclethis.info.
2006/66/EC (battery directive): This product
contains a battery that cannot be disposed of as
unsorted municipal waste in the European Union.
See the product documentation for specific battery
information. The battery is marked with this symbol,
which may include lettering to indicate cadmium (Cd), lead (Pb), or
mercury (Hg). For proper recycling, return the battery to your supplier
or to a designated collection point. For more information see:
www.recyclethis.info

KNC-p3BR_IR IP Mini Bullet Camera·Quick Operation Guide
4
4
Safety Instructions
These instructions are intended to ensure that the camera is installed
in a manner that avoids danger to persons or property loss.
These precautionary measures are divided into “Warnings” and
“Cautions”
Warnings: Serious injury or death may occur if any of the warnings
are neglected.
Cautions: Injury or equipment/property damage may occur if any of
the cautions are neglected.
Warnings
●In the use of the product, you must be in strict compliance with
the electrical safety regulations of the nation and region. Please
refer to technical specifications for detailed information.
●Input voltage should meet the requirements for both the SELV
(Safety Extra Low Voltage) and Limited Power Source for 12 VDC
Warnings Follow these
safeguards to prevent
serious injury or death.
Cautions Follow these
precautions to prevent
potential injury or material
damage.

KNC-p3BR_IR IP Mini Bullet Camera·Quick Operation Guide
5
5
according to the IEC60950-1 standard; or 802.3af PoE. Please
refer to technical specifications for detailed information.
●If connecting several devices to one power supply, to avoid any
overload that may cause over-heating or a fire hazard insure that
the power supply is adequate for the power load.
●Please make sure that all plugs are firmly connected to the
power sockets. When the product is mounted on wall or ceiling,
the device shall be firmly attached, taking into consideration any
wind, snow loading, or other factors. The mounting surface shall
be capable of supporting several times the base weight of the
camera.
●If smoke, unusual odors or noise come from the device, turn off
the power at once and unplug the power cable, and then
contact authorized service personnel.
Cautions
●Make sure the power supply voltage is correct before using the
camera.
●Do not drop the camera or subject it to physical shock.
●Do not touch lenses or sensor modules with fingers. If cleaning is
necessary, use clean cloth with a bit of ethanol and wipe gently.
If the camera will not be used for an extended period, please
protect the lens openings from damage and/or debris.
●Avoid aiming the camera at the sun or extremely bright light
sources. Blooming or smearing may occur in excessive light

KNC-p3BR_IR IP Mini Bullet Camera·Quick Operation Guide
6
6
(which is not a malfunction), and could compromise the
performance of the sensor.
●The sensor may be damaged if exposed to laser energy, so when
any laser equipment is in use, make sure that the sensor will not
be exposed to the laser beam.
●Do not place the camera in extremely hot or cold (see camera
specifications) locations. Do not exceed the rated environmental
(IP66) conditions. Do not expose the camera to high levels of
electromagnetic (RF) radiation.
●To avoid heat accumulation, good ventilation is required in the
operating environment.
●Keep the camera away from solvents while in use; exposure to
liquids should not exceed IP66 environmental conditions.
●During shipping, the camera shall be packed in its original
packing, or packing providing the equivalent protection.
●Improper use or replacement of any batteries (if so equipped)
may result in the hazard of explosion. Replace with the same or
equivalent type only. Dispose of used batteries according to the
instructions provided by the battery manufacturer.
●If the product does not function properly, Dealers please contact
KT&C; End Users please contact your KT&C Certified Dealer or an
authorized service center. Do not disassemble the camera for
repair or maintenance by yourself. (KT&C shall not assume any
responsibility for problems caused by unauthorized repair or
maintenance.)

KNC-p3DR28V12IR Varifocal Dome Camera Quick Operation Guide
7
7
Table of Contents
1 Appearance and Description .......................................................... 8
2 Installation.................................................................................... 10
2.1 Disassembling ............................................................... 10
2.2 Mounting ...................................................................... 12
2.2.1 Wall/Ceiling Mounting........................................ 12
2.2.2 Wall/Ceiling Mounting with Gang Box ................ 16
2.2.3 Wall Mounting.................................................... 19
2.3 Image and Focus Adjustment ........................................ 22
3 Setting the Network Camera over the LAN ......Error! Bookmark not
defined.
4 Accessing via Web Browser ................Error! Bookmark not defined.

KNC-p3DR28V12IR Varifocal Dome Camera Quick Operation Guide
8
8
1Appearance and Description
The overview of the network dome camera is shown below.
Figure 1-1 Overview
4
23
1

KNC-p3DR28V12IR Varifocal Dome Camera Quick Operation Guide
9
9
Table 1-1 Description
No.
Description
1
Dome cover with clear bubble
2
Black Liner (conceals direction of aim)
3
Lens
4
Mounting Plate
5
Reset Button
6
CVBS Video Output
7
Micro SD Card Slot
8
Network Cable
9
Power Cable
Press RESET about 10s when the camera is powering on or
rebooting to restore the default settings, including the user name,
password, IP address, and port No., etc.

KNC-p3DR28V12IR Varifocal Dome Camera Quick Operation Guide
10
10
2Installation
Before you start:
Make sure the camera is in good condition and all the accessory
parts are included.
Make sure all related equipment is powered-off during the
installation.
Check to insure that the specifications of the camera are correct
for the installation environment.
Make sure the power supply voltage is 12VDC or PoE compliant to
avoid damage to the camera.
If the product does not function properly, Dealers please contact
KT&C; End Users please contact your KT&C Certified Dealer or an
authorized service center. Do not disassemble the camera for
repair or maintenance by yourself.
Make sure that the mounting surface is strong enough to withstand
three times the weight of the camera.
If the IR LEDS in this camera will be active, you must observe the
following precautions to prevent IR reflection:
●Dust or grease on the lens/dome cover will cause IR reflection.
Please do not remove the cover protective film until the
installation is finished. If there is dust or grease on the
lens/dome cover, clean the lens/dome cover with clean soft
cloth and isopropyl alcohol.

KNC-p3DR28V12IR Varifocal Dome Camera Quick Operation Guide
11
11
●Make sure that there is no reflective surface too close to the
camera lens. The IR light from the camera may reflect back into
the lens causing haze, distortion or improper scene exposure.
●The foam ring around the lens must be seated flush against the
inner surface of the cover/bubble to isolate the lens from the IR
LEDS. Fasten the lens/dome cover to camera body so that the
foam ring and the dome cover are attached seamlessly.
2.1 Disassembling
Steps:
1. Loosen the three screws on the cover with the security key wrench
provided.
2. Open the cover and remove the inner black liner as shown in
Figure 2-1.
Figure 2-1 Remove the Cover and Black Liner
Black Liner
Bubble
Screw Hole

KNC-p3DR28V12IR Varifocal Dome Camera Quick Operation Guide
12
12
2.2 Mounting
Wall/Ceiling Mounting
Steps:
1. Disassemble the camera. Refer to the section 2.1.
2. You may mount the camera directly to the surface, or you may use
the included mounting plate and screws (recommended). Attach
the drill template (supplied) to the location where you want to
place the camera. Or, position the plate at that location.
3. Using to the drill template as shown in Figure 2-2, drill three screw
holes in the wall or ceiling. Or, mark and drill the number “1”holes
in the plate.
Figure 2-2 Drill Template/Mounting Base
4. If you want to route the cables inside the wall/ceiling, drill a cable
hole in the ceiling according to the drill template; ff using the plate,
drill the cable hole within the center area. Skip this step if you want
Cable Outlet
Screw Hole
Drilling Template for Outdoor
Day/Night Vandal-proof Dome Camera
Side Cable Outlet

KNC-p3DR28V12IR Varifocal Dome Camera Quick Operation Guide
13
13
to route the cables on the surface of the ceiling. Refer to Conduit
Installation on the Side for side cable routing.
5. Route the cables through the cable hole and connect to network
and power (if used).
6. Attach the camera to the wall/ceiling by aligning the holes of the
back box with the holes on the wall/ceiling. Or, attach the plate and
then align the camera with the holes in the plate.
7. Secure the camera with the supplied screws as shown in Figure 2-
3.
NOTE: THE MOUNTING SCREWS ARE AN INTEGRAL PART OF
THE WEATHER SEAL FOR THE CAMERA. BE CERTAIN TO USE
THE RUBBER “O”RINGS PROVIDED, TO USE SEALER AROUND
THESE SCREWS, AND TO TIGHTEN THEM SECURELY WITHOUT
TEARING THE O-RINGS.
Figure 2-3 Secure the Camera
Screw
Back Box

KNC-p3DR28V12IR Varifocal Dome Camera Quick Operation Guide
14
14
8. Adjust the image and focus. The supplied accessory cable may be
used to access the local CVBS aim/focus video output. Please refer
to the section 2.3 for more detailed information.
9. Install the inner black liner back onto the camera.
10. Install the cover/bubble onto the camera and secure it with the
cover attachment screws as shown in Figure 2-4.
Figure 2-4 Secure Black Liner and Cover/Bubble
Conduit Installation on the Side
If you want to route the cables from side of the camera, you need to
follow the steps below to install a conduit for cable routing.
Steps:
1. Rotate the water-proof plug counterclockwise to remove it from
the camera.

KNC-p3DR28V12IR Varifocal Dome Camera Quick Operation Guide
15
15
Figure 2-5 Remove the water-proof plug
2. Route the power cable and network cable through the side outlet
to the conduit.
3. Align and rotate clockwise the conduit to the side outlet tightly.
Figure 2-6 Install the Conduit to the Camera
Water-proof Plug
Side Cable Outlet
Conduit

KNC-p3DR28V12IR Varifocal Dome Camera Quick Operation Guide
16
16
For wall mounting, position the side outlet directly downward to
insure resistance to infiltration of water.
Figure 2-7 Side Outlet Direction
2.2.2 Ceiling Mounting with Gang Box
Steps:
1. Disassemble the camera. Refer to the section 2.1.
2. Install the gang box in the ceiling. Gang boxes are provided by
others.
3. Attach the mounting base to the gang box with two or four screws,
depending on the size/hole pattern of the box.
Downward

KNC-p3DR28V12IR Varifocal Dome Camera Quick Operation Guide
17
17
Figure 2-8 In-ceiling Mount
4. Route the cables through the hole in the center of the mounting
base and connect them.
5. Align the camera with the mounting base.
6. Tighten the screws to secure the camera with the mounting base.
See Figure 2-9
7. Adjust the image and focus. The supplied accessory cable may be
used to access the local CVBS aim/focus video output. Please refer
to the section 2.3 for more detailed information.
Mounting Base

KNC-p3DR28V12IR Varifocal Dome Camera Quick Operation Guide
18
18
Figure 2-9 Secure Camera
8. Install the inner black liner back to the camera.
9. Align the cover/bubble with the camera.
10. Tighten the cover screws to secure the cover/bubble to the
camera as shown in Figure 2-10.
Ceiling

KNC-p3DR28V12IR Varifocal Dome Camera Quick Operation Guide
19
19
Figure 2-10 Secure the Bubble
2.2.3 Wall Mounting
Accessory wall mounts are sold separately.
Steps:
1. Disassemble the camera. Refer to the section 2.1.
2. Install the wall mount and mounting adapter as shown in Figure 2-
11.
3. Align the screw holes of the mounting base with the corresponding
screw holes of the mounting adapter.
4. Secure the mounting base to the mounting adapter with four
screws.
