OMNIFIT BRAIN OCW-H20 User manual

OMNIFIT BRAIN (OCW-H20) USER MANUAL (Draft)
1. Included in the Package
OMNIFIT OCW-H20 User Manual
Earbuds (1 set) Portable Pouch
2. Description of Parts
EEG Sensors (2 channel)
Power button
Earphone (R)
Earphone (L)

3. Charging
①For charging, do connect USB cable to right under USB charging port
②When the charger is connected, the Bluetooth pairing will be disconnected.
③While charging, the LED indicator will show a solid red light.
LED Indicator
Charging Port
Right
*Charging Status LED Indicator
Charging (Red)
Full charged (Green)

•OCW-H20 Battery status will appear on OMNIFIT Application.
4. Wearing
①Wear OCW-H20 where LED indicator must be located on right-side.
②Contact firmly EEG sensors onto forehead.
③Put in earphones firmly. Earphones have a function of grounding.
5. Application Installation
Download OMNIFIT BRAIN App on Google Play store or Apple App store.
▶Only available for Android 5.0 / iOS 10.0+ OS over, and Bluetooth 4.2 (BLE) enabled mobile
devices (iOS 5s+).
6. Pairing
①Audio Pairing

②EEG Sensors Pairing
7. LED Indicator
8. Specification
Solid Light Blink Dimming
Charging (Red) Charger connected
Fully Charged (Green) Charger connected
Power on (White) Power button pressed for 3sec
Low Battery (Red) When battery left under 5%
BT disconnected(Blue) When Power is on and BT not connected
BT connected (Blue)
When BT connection succeeded, the blue
light stays on for 3 sec and then turn off.
Measuring (Yellow) When measuring
Status
LED Indicator
Action
Press a power button for 3sec for
power ON
On mobile phone setting, activate Bluetooth
and select OMNIFIT Brain Audio from the list.
On mobile phone setting, activate Bluetooth and search Bluetooth devices. Select OMNIFIT Brain Audio
from the list for pairing.

Category
Item
Specification
Main Part
Main Chipset
EFM32BG1
EEG Sensors
2 Channel
Memory
N/A
Bluetooth
BLE 4.2
Connection
BLE
LED
RGB LED
USB
Micro 5pin Connector
Power on / off
Power Button
Reset Switch
Reset switch
Audio Part
Main Chipset
CSR8670
Bluetooth
BT4.0 (16Mb internal memory)
Connection
BT 4.0
Earphone
Earphones/Earbuds
White Color
Battery
Li-polymer battery
3.7V 300mAh (37x15x5t mm, 7g)
Play time
Up to 14Hrs
Standby time
Up to 500Hrs
Charging time
< 2Hrs
Dimension/Weight
Dimension / Weight
157.8 X 181 X 25.4mm / 50g
9. Precautions
Do not drop the device.
Do not modify, repair, or disassemble.
Do not expose directly to water, alcohol, benzene, etc for cleaning.
Do not expose directly to flammables.
Do not place or keep the device near flammables.
Keep the device away from excessive humidity and dust.
Only charge the headset with certified charger, otherwise it may be damaged.
Do not expose the battery to extreme temperatures, never above +60℃ (+140℉) or under -
20℃ (-4℉)
10. Limited Warranty

The warranty is valid only if the original receipt issued to the original purchaser by the
dealer, specifying the date of purchase and serial number, is presented with the product to
be repaired or replaced. OMNIC&S reserved the right to refuse warranty service if this
information has been removed or changed after the original purchase of the product from
the dealer.
This Warranty does not cover any failure of the product due to normal wear and tear, or due
to misuse, including but not limited to use in other than the normal and customary manner,
in accordance with instructions for use and maintenance of the product. Nor does this
warranty cover any failure of the product due to accident, modification or adjustment, acts
of God or damage resulting from liquid.
This warranty does not cover product failures due to improper repair installations,
modifications or service performed by a non-OMNIC&S authorized person. Tampering with
any of seals on the product will void the warranty.
OMNIC&S warrants this product to be free from defects in design, material and
workmanship at the time of its original purchase by a consumer, and for a subsequent
period of one (1) year.
OMNIFIT
www.omnifit.co.kr
2014 OMNIC&S Inc. All rights reserved
This product has been manufactured by, and is sold under the responsibility of OMNIC&S
Inc., and OMNIC&S Inc. is the warrantor in relation to this product.
OMNIFIT©is a registered trade mark of ONNIC&S Inc.
Address: #314, 288 Digital-ro, Guro-gu, Seoul, Republic of Korea

FCC Information
This device complies with part 15 of the FCC Results. Operation is subject to the following two
conditions :
(1) This Device may not cause harmful interface, and
(2) This device must accept any interference received, including interference that
may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for CLASS B digital device,
pursuant to Part 15 of FCC Rules. These limits are designed to provide reasonable protection against
harmful interference when the equipment is operated in a commercial environment This equipment
generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning the equipment off and
on, the user is encouraged to try correct the interference by one or more of the following measures:
1.1. Reorient or relocate the receiving antenna.
1.2. Increase the separation between the equipment and receiver.
1.3. Connect the equipment into an outlet on a circuit different from that to which receiver is connected.
1.4. Consult the dealer or experienced radio/TV technician for help.
WARNING
Changes or modifications not expressly approved by the manufacturer could void the user’s
authority to operate the equipment.
“CAUTION : Exposure to Radio Frequency Radiation.
Antenna shall be mounted in such a manner to minimize the potential for human contact
during normal operation. The antenna should not be contacted during operation to avoid the
possibility of exceeding the FCC radio frequency exposure limit.
