Omron 2JCIE-EV01-AR1 User manual

Sensor Evaluation Board
Sensor Evaluation Board
User’s Manual
A294-E1-02
2JCIE-EV01-AR1

1 2JCIE-EV01-AR1 Sensor Evaluation Board User’s Manual (A294)
Safety Precautions
Be sure to read the data sheet, and use only if you agree to the contents.

2JCIE-EV01- AR1 Sensor Evaluation Board User’s Manual (A294) 2
Contents
1. Overview ...........................................................................................................................................3
2. Items required...................................................................................................................................3
3. Sensor board setup ..........................................................................................................................4
3-1 Checking Sensor Evaluation Board Components ......................................................................... 4
3-2 Soldering........................................................................................................................................ 4
3-3 Connecting the Sensor Evaluation Board to Arduino .................................................................... 6
3-4 Connecting Arduino to your PC ..................................................................................................... 6
4. Downloading the Sample Program...................................................................................................7
5. Running the Sample Program on Arduino IDE .................................................................................8
5-1 Installing the Zip Library on Arduino IDE ....................................................................................... 8
5-2 Reading Sketch ............................................................................................................................. 9
5-3 Arduino Board Settings in Arduino-IDE ....................................................................................... 10
5-4 COM Port Settings in Arduino-IDE .............................................................................................. 10
5-5 Writing to the Microcomputer Board.............................................................................................11
5-6 Serial Monitor .............................................................................................................................. 12
6. Removing the Sensor Evaluation Board.........................................................................................12

3 2JCIE-EV01-AR1 Sensor Evaluation Board User’s Manual (A294)
1. Overview
This manual explains how to use the Arduino (*1) compatible OMRON Sensor Evaluation Board
(2JCIE-EV01-AR1), including special notes and other information. This Sensor Evaluation Board
provides 6 sensing functions (temperature, humidity, barometric pressure, illumination, sound,
acceleration). This manual explains how to acquire these sensing data.
To connect a sensor other than the 6 types of sensors provided on the Sensor Evaluation Board, check
GitHub. For details on the provided sensor types, connector layout, and other specifications, see the
data sheet for this product.
2. Items required
Sensor Evaluation Board (2JCIE-EV01-AR1) x1
Arduino (*1) x1
USB cable (to connect Arduino to your PC) x1
PC with Arduino IDE (*2) installed x1
(*1) Usable Arduino types
Arduino MKR Vidor 4000
Arduino MKR WiFi 1010
Arduino MKR ZERO
(This manual assumes that Arduino MKR WiFi 1010 is used)
(*2)
Arduino IDE can be downloaded for free from the official Arduino website.

2JCIE-EV01- AR1 Sensor Evaluation Board User’s Manual (A294) 4
3. Sensor board setup
3-1 Checking Sensor Evaluation Board Components
Make sure the following components are included with the Sensor Evaluation Board.
Sensor Evaluation Board x1
Pin Headers x2
Fig. 1 Sensor Evaluation Board Components
3-2 Soldering
1) From the back of the Sensor Evaluation Board, insert the provided pin header into the
through-holes (CN10, CN11). We recommend that you use a breadboard to keep the pin header
from shifting out of position.
Sensor Evaluation Board / front Sensor Evaluation Board / back
Fig. 2 Appearance of Sensor Evaluation Board
Note:
This side with the printed OMRON logo is the front side.
If soldering fails and you need to purchase a pin header, purchase a pin header with 14 pins at a
pitch of 2.54 mm.
Recommended pin Header: SAMTEC / TSW-114-07-L-S
CN10
Pin Headers
Sensor Evaluation Board
CN11

5 2JCIE-EV01-AR1 Sensor Evaluation Board User’s Manual (A294)
2) Solder all pins from the front side of the Sensor Evaluation Board to secure them. (28 pins)
Fig. 3 Pin Header Soldering
Note:
Take care not to burn yourself when soldering.
Take care not to inhale smoke when soldering.
The pin header bends easily. Take care not to bend the pin header.

2JCIE-EV01- AR1 Sensor Evaluation Board User’s Manual (A294) 6
3-3 Connecting the Sensor Evaluation Board to Arduino
Insert the pin header on the Sensor Evaluation Board into the Arduino pin socket. The Sensor
Evaluation Board is on top and Arduino is on the bottom.
Fig. 4 Connecting to Arduino
Note:
The temperature sensor on the Sensor Evaluation Board may output a high value due to heat from the
Arduino unit. To eliminate this effect, either connect with a cable to separate the two, or use an
externally connected temperature/humidity sensor.
3-4 Connecting Arduino to your PC
Connect the USB port on Arduino to a USB port on your PC with a USB (A -micro B) cable.

7 2JCIE-EV01-AR1 Sensor Evaluation Board User’s Manual (A294)
4. Downloading the Sample Program
Access GitHub at the URL below, download the zip file, and save it in any folder.
GitHub URL
https://github.com/omron-devhub/2jcieev01-arduino
Fig. 5 Downloading the Zip File
Note:
In some cases it may take time to download the file.
The sample source code is only for testing purposes. OMRON does not guarantee its operation.
OMRON does not assume responsibility to make changes to the sample source code or correct
mistakes or defects in the sample source code for any reason.
We cannot accept any inquiries regarding the sample source code.

2JCIE-EV01- AR1 Sensor Evaluation Board User’s Manual (A294) 8
5. Running the Sample Program on Arduino IDE
5-1 Installing the Zip Library on Arduino IDE
Click [Sketch] >> [Include Library] >> [Add .ZIP Library...].
Select the zip file you saved in 4-1 in "Select a zip file or a folder containing the library you’d like to add",
and click [Open].
Fig. 6 Including the Library

9 2JCIE-EV01-AR1 Sensor Evaluation Board User’s Manual (A294)
5-2 Reading Sketch
Click [File] >> [Examples] >> [2JCIE-EV01], and select the sensing data you want to acquire.
Fig. 7 Reading Sketch
Acceleration sensor sample
accl-ar
Barometric pressure sensor sample
baro-ar
Temperature/humidity sensor sample
humi-ar
Illumination sensor sample
illm-ar
Table 1. Sample Code List
For Microphone, click [Example for Arduino MKR WiFi 1010] >> [I2S] >> [InputSerialPlotter].

2JCIE-EV01- AR1 Sensor Evaluation Board User’s Manual (A294) 10
5-3 Arduino Board Settings in Arduino-IDE
Click [Tools] >> [Board:...] >> [Arduino MKR WiFi 1010].
If you cannot find "Arduino MKR WiFi 1010", open "Board Manager..." and install it.
Fig. 8 Specifying Arduino Board
5-4 COM Port Settings in Arduino-IDE
Specify the COM number in [Tools] >> [Port:...] >>.
You can check the COM number in Windows Device Manager.
Fig. 9 Specifying the Serial Port

11 2JCIE-EV01-AR1 Sensor Evaluation Board User’s Manual (A294)
5-5 Writing to the Microcomputer Board
Compile (verify) the program, and if there are no errors, click to write to the Arduino
microcomputer board.
Fig. 10 Writing to the Microcomputer Board

2JCIE-EV01- AR1 Sensor Evaluation Board User’s Manual (A294) 12
5-6 Serial Monitor
Click [Tools] >> [Serial Monitor], and select the sensing data.
Fig. 11 Serial Monitor
6. Removing the Sensor Evaluation Board
To remove the Sensor Evaluation Board from Arduino, turn off the power to the Sensor Evaluation
Board, grasp the sides of the board without touching the USB port, connector, or other mounted
components, and slowly remove the board.
