ISMART
Inventek Systems Module ARduino Test
IoT Evaluation Board
User’s Manual
802.11a/b/g/n/ac + BT/BLE

ISMART IoT EVB User’s Manual
DOC-DS-201904 www.Inventeksys.com Inventek Systems
Page 2
Contents
1Definitions............................................................................................................................... 3
2Introduction............................................................................................................................. 4
2.1 ORDERING INFORMATION........................................................................................... 5
2.2 ISMART IoT EVB Overview............................................................................................. 5
2.3 ISMART IoT EVB Hardware Features .............................................................................. 6
3System Requirements.............................................................................................................. 7
3.1 ISMART EVB Configuration for UART interface option................................................. 7
4The ISAFE–Arduino Pin Out Map........................................................................................ 8
5ISAFE EVB Schematics ......................................................................................................... 9
5.1 USB Schematic................................................................................................................... 9
5.2 FTDI Schematic................................................................................................................ 10
6Temp Rating.......................................................................................................................... 11
7Revision Control................................................................................................................... 11
8Contact Information.............................................................................................................. 12

ISMART IoT EVB User’s Manual
DOC-DS-201904 www.Inventeksys.com Inventek Systems
Page 3
1 Definitions
eS-WiFi: embedded Serial Wi-Fi
•Inventek’s “modular” wireless product offering (Radio + MCU + Certified
Antenna). These modules consist of 802.11a/b/g/n/ac Wi-Fi radios and
combinations of these radios with BT/BLE.
•All eS-WiFi module options support the same foot print enabling customers to
migrate across the entire eS-WiFi portfolio without requiring any changes to the
customer’s original PCB design.
•eS-WiFi modules include antenna certifications for Chip, Etched, and u.fl
antennas.
IWIN: Inventek Systems Wireless Interoperability Network:
•Inventek’s proprietary AT Command SW.
oAll associated collateral and documentation can be found at
▪https://www.inventeksys.com/iwin/getting-started-guide/
•Requires a Host processor to communicate to the eS-WiFi module serially.
•Video References:
oInventek Systems 802.11 b/g/n Serial to Wi-Fi & IWIN AT Introduction:
▪https://www.youtube.com/watch?v=Tq2-CYm-c8Q
oInventek Systems 802.11 b/g/n Serial to Wi-Fi & IWIN AT Command Set
Tutorial:
▪https://www.youtube.com/watch?v=tkPOLaNAKHo
oInventek 802.11 b/g/n Serial to Wi-Fi Product Overview & AT Command
Set Tutorial:
▪https://www.youtube.com/watch?v=Mzmi-0DcUu0
ISMART: Inventek Systems Module ARduino Test IoT Evaluation Board
•Arduino form factor/footprint, no Arduino driver support.
•No additional hardware is required other than a PC to use the ISMART
evaluation board.
•Please Note: The three-way switch on the ISMART evaluation board must be in
the position closest to the Wi-Fi module (Position 1, UART USB), and use a
USB cable to plug the ISMART evaluation board into your PC.

ISMART IoT EVB User’s Manual
DOC-DS-201904 www.Inventeksys.com Inventek Systems
Page 4
2 Introduction
The Inventek ISMART (Inventek Systems Module Arduino Test) IoT evaluation board
platform is a user-friendly Arduino form factor compliant evaluation board suited for all
of your wireless application needs. Please note that there is no Arduino software
provided for this IoT development board.
The ISMART IoT evaluation board enables customers to quickly launch IoT products
based on Inventek’s eS-WiFi (embedded Serial Wi-Fi), portfolio of 802.11a/b/g/n/ac Wi-
Fi radios and combinations of those radios with BT/BLE, a Host MCU and certified chip,
etched or u.fl antenna options.
The ISMART IoT evaluation board is also supported by Inventek’s IWIN (Inventek
Wireless Interoperability Network), firmware which provides customers a robust user
friendly AT command set to simplify and accelerate IoT design and development. IWIN
enables customers to quickly get a Wi-Fi connected application up and running.
The ISMART IoT evaluation board plugs directly onto any target Arduino compatible
MCU/CPU/Sensor Development Board offering. The ISMART IoT evaluation board also
supports complete HW & SW IoT platform projects for various MCU requirements.
Examples of the ISMART IoT MCU Reference Design Projects include Infineon’s
XMC4500 MCUs, ST Micro’s STM32F MCUs, Analog Devices’ Shark DSP and CUP360
MCUs, and Cypress PSoC MCUs. In addition, the ISMART IoT MCU Reference Design
Projects also support third party Cloud applications such as AWS. For more information
on complete ISMART IoT MCU Reference Design Projects, please visit:
➢www.inventeksys.com
➢AT Command Support
➢IoT MCU Reference Designs
The ISMART IoT Evaluation Board User’s Manual provides a detailed hardware and
software requirements overview as well as all required board connections.

ISMART IoT EVB User’s Manual
DOC-DS-201904 www.Inventeksys.com Inventek Systems
Page 5
2.1 ORDERING INFORMATION
NOTE:
•All ISMART EVBs are configured for the UART interface option.
•For SPI support, please download the appropriate SPI FW update from Inventek’s
website, www.inventeksys.com
•Please reference your target eS-WiFi module of choice Data Sheet for additional
information.
2.2 ISMART IoT EVB Overview
NOTE:
•The L44/L54 foot print compatible option for Inventek’s eS-WiFi modules enables
customers to migrate across Inventek’s portfolio as needed without requiring any
changes to a customer’s original PCB layout, enabling maximum flexibility as future
connectivity design requirements change.
•The ISMART IoT EVB is a 3.3V board not a 5V board (5V input & generates 3.3V IO
•The ISMART Mini USB connects to the Dual Port FTDI (Backside of EVB)
•The ISMART UART Position Switch selects the required UART connection
oPlease reference Section 4, The ISMART –Arduino Pin Out Map for all details.
ISMART EVB EVALUATION BOARD DESCRIPTION eS-WiFi Module
ORDERING P/N
ETCHED/CHIP
ANTENNA OPTION
ORDERING P/N
U.FL ANTENNA
OPTION
ISMART43362 2.4G Wi-Fi, Cortex™ M3 ISM43362-M3G-L44 ISMART43362E-EVB ISMART43362U-EVB
ISMART43903 2.4G Wi-Fi, Cortex™ R4 ISM43903-R48-L54 ISMART43903C-EVB ISMART43903U-EVB
ISMART4343 2.4G Wi-Fi + BT/BLE, Cortex™M4 ISM4343-WBM-L54 ISMART4343C-EVB ISMART4343U-EVB
ISMART43340 2.4G/5G Wi-Fi + BT/BLE, Cortex™M4 ISM43340-M4G-L44 ISMART43340C-EVB ISMART43340U-EVB

ISMART IoT EVB User’s Manual
DOC-DS-201904 www.Inventeksys.com Inventek Systems
Page 6
2.3 ISMART IoT EVB Hardware Features
•The ISMART EVB is a 3.3v board, not a 5v board. The ISAFE EVB takes 5v in
but generates 3.3v IO.
•FCC/CE/IC Certification is included with all eS-WiFi options including Etched,
Chip or u.fl antenna options.
•Configurable using Inventek IWIN AT Commands FW.
•Host interface: UART, SPI.
•Input Power: 5.0 V
•Dual Port FTDI for firmware development and testing.
•SPI Flash for Over The Air (OTA) updates
•All eS-WiFi module portfolio also support a standard L44/L54 package option to
enable customers to migrate between eS-WiFi module options once in mass
production without customers having to make any board layout changes to their
original PCB.
•Please note that there is no Arduino software provided for the ISMART IoT
development board.

ISMART IoT EVB User’s Manual
DOC-DS-201904 www.Inventeksys.com Inventek Systems
Page 7
3 System Requirements
3.1 ISMART EVB Configuration for UART interface option
The ISMART EVB communication is configured using a PC over USB for all evaluation
and test purposes.
1. Set-Up:
a. Download and install the eS-WiFi PC Demo:
i. https://www.inventeksys.com/iwin/demo-software/
b. Run eS-WiFi PC Demo and Install Drivers:
i. Menu > Install Drivers
c. Set the Power source for the ISMART EVB by placing a jumper on J17
from Pin 1 to Pin 2
d. Set SW3 to Position 1, UART_USB (i.e.: Closest to eS-WiFi module)
e. Connect PC to the ISMART EVB using the Mini USB connector
f. Configure Serial Port:
i. Setup > Serial Port > Configure/Open
ii. In the Serial Port Config window:
•Select Serial Port
•Baud rate: 115,200
•Parity None
•Data Width 8
•Stop Bits 1
g. You are now ready to type IWIN AT Commands in to the Terminal window
i. IWIN AT Commands Quick Reference Guide can be found at:
ii. https://www.inventeksys.com/iwin/wp-
content/uploads/WiFi_AT_Command-_Set-Quick-Reference-1.pdf

ISMART IoT EVB User’s Manual
DOC-DS-201904 www.Inventeksys.com Inventek Systems
Page 8
4 The ISAFE– Arduino Pin Out Map

ISMART IoT EVB User’s Manual
DOC-DS-201904 www.Inventeksys.com Inventek Systems
Page 9
5 ISAFE EVB Schematics
5.1 USB Schematic

ISMART IoT EVB User’s Manual
DOC-DS-201904 www.Inventeksys.com Inventek Systems
Page 10
5.2 FTDI Schematic
