Onix Miracle User manual

Miracle
OWNER MANUAL'S
Linear Power Supply XPS10
BALSE
INPUT
DAC Headphone Amplifier X P1 0
COAXIAL
LOCAL/BT
DAP
USB DAC OPTICAL
AUX/

3
ENGLISH
Notices for Use
1. Don't repair disassemble or modify the device without permission. ,
8. This device might get warm during charging or during use.
3. Please don't use this device in extremely hot, cold, dusty or humid circumstances. Avoid any
exposure to liquids.
9. Please enjoy the music in a proper volume to avoid impairing your hearing and damaging the
sound system. Before plugging your headphones into the device, please firstly turn down the
volume.
10. Don't clean this device with chemicals or detergents, otherwise its surface and top coating may be
damaged.
11. Don't disconnect this device during formatting or transferring files. otherwise, a program error
may occur.
12. The USB port is only for data transmission or charging. Please try to avoid using this device when
it is charging.
13. When this device is not in use, please charge it regularly to guarantee battery life.
14. Please replace the battery only with ones of the same type as the original ones, as improper
replacement will bring the risk of explosion.
15. Never expose battery to sunlight, fire or other extremely hot circumstances.
2. For good ventilation, a minimum of 10cm clearance shall be maintained at the back and two sides
and 20cm at the top of the unit.
4. Do not cover any ventilation hole with newspaper, cloth, curtain, etc. in case of ventilation blocking.
5. Allow no exposed flame source on the unit, e.g. burning candle.
6. The unit shall be connected to AC power output socket with grounding protection.
7. If power plug and appliance coupler are used as disconnecting device, the disconnecting device shall
be easily operable.
16. Any batteries requiring disposal must be handled in accordance with local regulations.
17. This device is intended for safe use in an area with elevation under 2000m. (Fig.1)
18. This device is intended for safe use under non-tropical climate conditions. (Fig.2) Fig.1 Fig.2
CAUTION: RISK OF ELECTRIC SHOCK. DO NOT OPEN.
The lightning flash with an arrowhead symbol within an equilateral triangle is intended
to alert the user to the presence of un-insulated dangerous voltage within the product s
enclosure which may be of sufficient magnitude to constitute a risk of electric shock.
'
The exclamation point within an equilateral triangle is intended to alert the user to the
presence of important operating and maintenance (servicing) instructions in the
literature accompanying the product.

Included Items
4
ENGLISH
XM10 Portable Music Player：1
XP10 DAC Headphone Amplifier：1
XPS10 Linear Power Supply：1
：1
Warranty Card：1
Owner's manual
Power Cord：1
USB-A to USB-C cable：1
Power Supply Cable：1
3.5mm to 4.4mm Adapter：1
Card Reader：1

5
Names of Parts
1. Micro SD card slot
2. Type-C USB data port
3. 3.5mm Headphone/Line output/Balanced Headphone Output (Via Adapter)
4. Status indicator
5. 6.0 inch touch screen (1080 x 2160)
6. Power/Lock button/Volume control wheel
7. Previous selection button
8. Play/Pause button
9. Next selection button
USB
DAC
micro DS
12 3
4 5
6
7
8
9
XM10 Portable Music Player

6
Operation Instructions
Power ON / OFF / Screen Locking
1. Power on: Press and hold the power wheel for 2 seconds, then the device turns on.
2. Power off: Press and hold the power wheel for 2 seconds. The display shows the "Power Off" and
"Restart" selection windows. Click on "Power Off" to shut down the device.
3. Screen lock: While the device is powered on, short press the power wheel to lock the screen and
turn the off display. Press power wheel again to unlock the device.
Navigation mode (Settings - General - Navigation mode)
: Return to the previous.
: Back to the main screen.
: Multitasking.
1. Gesture mode
Return to the previous: slide to the right from the left edge of the screen or slide to the left from the
right edge of the screen.
Back to the main screen: slide up from the bottom of the screen.
Multitasking: slide up from the bottom of the screen and keep your finger touching screen.
2. Floating box mode
Return to the previous: click the floating ball on the screen.
Back to the desktop: press and hold the floating ball on the screen.
Multitasking: double click on the floating ball on the screen.
3. Virtual buttons mode
Play & Pause
1. Short press to skip to the previous song or the beginning of the current one.
Previous/Rewind
Short press to play or pause playback.
2. Hold to start rewinding the currently playing song.
XM10 Portable Music Player

1. Short press to skip to the next song.
2. Hold to start forwarding currently playing song.
Next/Forward
7
Volume Control
2. Insert the card into the card slot in the indicated direction and press it gently until it locks
inside. Press again to remove the card.
Micro SD
Micro SD Card Port
1. The port is only for the standard card and supports a capacity up to 2TB.Micro SD
Headphone Output Interface
Turn the wheel to decrease or increase volume.
The device uses special combined 3.5mm output. Normal single-ended headphones can be used
directly. For Balanced headphones, a special 3.5mm to 4.4mm adapter is needed.
Charging
Supports QC3.0 fast charge and standard USB charging. When the USB cable is connected, display
shows battery charging icon and power level. The status indicator light will pulse red while
charging.(only if screen is off)
Micro SD Card Update
1. Please download firmware update from ONIX official website. Copy latest firmware file into root
directory of Micro SD card.
2. Go to "Technical Support - Firmware Update - Local Update", choose the path to firmware file and
click update.
Firmware Update
1. When updating the firmware, please make sure that XM10 is fully charged.
2. Do not do operate the player during the update process.
Over-the-Air Update
While connected to local Wi-Fi network, device will automatically check for new firmware update. To
check for new firmware manually, go to menu "Technical Support - Firmware Update - Online
Update" and click on "Check for Update".
XM10 Portable Music Player

8
Common Problems
1. It is recommended to use DC5V 2A adapter or Quick-charge 3.0 adapter. Using an adapter with
higher voltage may damage device.
2. Unable to start device, it may be caused by low power or exhausted battery, please recharge and
then start up again.
4. If there is noise from headphones, headphone's output interface may not be connected correctly,
please try to insert it again.
3.
restart.
If the system do not react or keeps crashing, hold the power button for 12 seconds to initiate forced
5. When there is no sound, try to use different pair of headphones or different cable and make sure
the system volume is set correctly.
Qualcomm aptX is a product of Qualcomm Technologies, Inc. and/or its subsidiaries.
Qualcomm is a trademark of Qualcomm Incorporated, registered in the United States and other
countries. aptX is a trademark of Qualcomm Technologies International, Ltd., registered in the United
States and other countries.
MQA (Master Quality Authenticated) is an award-winning British technology that delivers the sound of
the original master recording. The master MQA file is fully authenticated and is small enough to
stream or download.
The XM10 includes MQA technology, which enables you to play back MQA audio files and streams,
delivering the sound of the original master recording. The XM10 Now Playing screen shows green or
blue dot next to MQA logo to indicate that the unit is decoding and playing an MQA stream or file, and
denotes provenance to ensure that the sound is identical to that of the source material. It shows blue
dot to indicate it is playing an MQA Studio file, which has either been approved in the studio by the
artist/producer or has been verified by the copyright owner. It shows magenta dot, when in the USB
mode, which confirms that the product is receiving an MQA stream or file. This delivers the final
unfold of the MQA file and displays the original sample rate.
Visit mqa.co.uk for more information.
MQA and the Sound Wave Device are registered trade marks of MQA Limited © 2016
XM10 Portable Music Player

BAL SE
INPUT
DAC Headphone Amplifie r XP10
COAXIAL
LOCAL/B T
DAP
USB DACOPTICAL
AUX/
COAXIAL
XLR - R RCAXLR - L
AUX USB DAC
OPTICAL
ANALOG IN
DIGITAL
OUT
DIGITAL
IN
ANALOG OUT POWER
DC IN
12-24V
L
R
L
R
Names of Parts
9
2
345679
8
12 53 4 76 8 9 10
1. Player Port
(When connecting XM10, switch Input to "DAP Mode")
2. Touchscreen
3. XLR balanced headphone output
4. 4.4mm balanced headphone output
5. 6.35mm single-ended headphone output
6. 3.5mm single-ended headphone output
7. Source input selection knob
8. Input/sampling rate/standby indicator
9. Power Button/Volume Wheel/Lock Screen
1. AUX analog input
2. XLR analog balanced output
3. RCA analog output
4. Digital coaxial input
5. Digital coaxial output
6. Digital optical input
7. Digital optical output
8. USB port for External Drives
9. DC power input
10. USB DAC input
XP10 DAC Headphone Amplifier
1

1. Firstly, connect the XPS10 power supply to a power outlet. Then Connect the XPS10 Power supply to
the XP10 DAC/AMP, using the provided power supply cable. Put XP10 either alongside or on the top of
the XPS10. Finally, insert the XM10 Player into the top slot of the XP10 DAC/AMP.
2. Turn on the XPS10, using the power switch on the back, put it into ON position. XPS10 standby
indicator will light up red and the device will enter standby mode. Press and hold the Power Wheel on
XPS10 for 2 seconds to power on the system. XP10 will automatically power on and "enter AUX/ "
state. Status indicator will turn purple and then goes black.
3. To power off the XP10, press and hold the Power wheel for 2 seconds. Indicator will turn red and the
device will enter standby mode.
4. To power off the XPS10, press and hold the Power wheel for 2 seconds. Indicator will turn red and the
device will enter standby mode. To completely cut off power, switch the power switch on the rear to
the OFF position.
5. If the machine will not be sued for longer period of time, please disconnect it from power outlet.
Operation Instructions
Setup
10
Turn the wheel to increase or decrease volume.
Volume Control
Headphone Outputs
Source Input Selection
COAXIALLOCAL/BT DAP
USB DAC OPTICAL AUX/
BAL SE
Note: 1. When connecting XPS10 and XP10, please make sure XPS10 is powered off completely.
2. When connected, if the XPS10 is powered off, XP10 will also automatically power off.
Rotate the Input knob or go to Audio Source Switching in the menu to switch between different
inputs.
" " " "
Offering 4 standard outputs – balanced 4-pin XLR, balanced 4.4mm, single-ended 6.35mm and
single-ended 3.5mm.
XP10 DAC Headphone Amplifier

11
USB DAC Input
Firmware Update
Bluetooth Input
USB DAP Input
Note: XM10 is not able to charge when the XP10 is set to USB DAP input mode. Please
witch to a different input mode to charge XM10.
" "
1. Switch the Source Input on XP10 to BT ." "
2. Turn on Bluetooth on phone or tablet and search for available devices.
3. Pick ONIX XP10 from the list." "
4. Devices will be connected and the XP10 will now serve as Bluetooth music receiver.
1. In XP10 s setting make sure USB mode is set to UAC 2.0.'
2. Connect XP10 to a computer using USB cable and USB DAC port on the XP10." "
3. Switch the Source Input on XP10 to USB DAC ." "
4. If you are using Windows, Go to Onix website and download matching drivers for XP10. No drivers
needed for Mac.
5. Set XP10 as your output device in system or app settings.
1. Switch the Source Input on XP10 to USB DAP ." "
2. Insert the XM10 into the top slot on the XP10.
3. Now use XM10 as a music source for the XP10.
Go to Onix website to download the firmware update and follow the provided instructions for the
firmware update. USB Flash Drive will be needed for the firmware update.
Note: Firmware update cannot be done when XP10 is set to USB DAP input mode.
Please switch to a different input mode to update XP10.
" "
XP10 DAC Headphone Amplifier

SyncLink Control
Eddict Player app is
available in iOS and
Android Play Stores.
12
1. Go to settings and enable Bluetooth.
2. Turn on the SyncLink function in Bluetooth menu." "
3. Open the Eddict player app on smartphone and go
to SyncLink. Enable "SyncLink Controller" and wait
for it to search for "ONIX XP10". Click on it to connect.
4. Go to Music Scan and let the app scan all the files from the connected USB Drive." "
5. Now you can control playback of local files directly from the app.
Scan Code to Download
Eddict Player
XP10 DAC Headphone Amplifier

Linear Powe r Sup ply XPS10
AC IN
POWER
DC OUT
12-24V
POWER
ON
OFF
Made in China
XPS10
( )
ONIX ELECTRONICS UK LIMITED
Power Consumption: 60W
~230V/5 0 H z
S/N
Linear Power Supply
Names of Parts
13
1. Power Switch
2. Main Power Input
3. Power Output
12
3
1
1. Standby Indicator
2. Display
3. Power Button / Selection Button
2 3
XPS10 Linear Power Supply

Operation Instructions
Setup
14
Voltage Adjustment
Menu Navigation
Note： Switch off XPS10 before connecting its power output to DAC.
1. Connect both power cables to the XPS10.
2. Turn on the XPS10, using the power switch on the back, put it into ON position. XPS10 standby
indicator will light up red and the device will enter standby mode. Press and hold the Power Wheel on
XPS10 for 2 seconds to power on the system.
3. To power off the XPS10, press and hold the Power wheel for 2 seconds. Indicator will turn red and the
device will enter standby mode. To completely cut off power, switch the power switch on the rear to
the OFF position.
4. If the machine will not be sued for longer period of time, please disconnect it from power outlet.
Turn the wheel to select the fine-tuning voltage icon Use wheel to adjust and then press the wheel
to confirm and exit setting.
" "
Turn the wheel and then press to select Settings icon Use the wheel to navigate through the
settings. Go to "Back" and press on the wheel to exit the settings.
" "
XPS10 Linear Power Supply

15
Brightness setting
Other Settings
Output Voltage Setting
Go to Set Output Voltage in settings, use the wheel to adjust voltage and then press the wheel to
confirm.
" "
Go to Display Bright in settings, use the wheel to adjust and then press the wheel to confirm." "
Display Automatic off after set time and Factory reset is also available in the menu, alongside device
information tab.
XPS10 Linear Power Supply

16
简体中文
使用注意事项
8. 充电时机器有轻微发热，属正常现象。
10. 不要使用化学剂或清洁剂清洁本产品，这样会损伤产品表面 涂层。和
9. 请调节适当音量欣赏音乐，以免损伤您的听觉和音响系统， 插入耳机前，请先将音量调小，不
要长时间使用耳机。
在
11. 本产品在格式化或上传/下载过程中不要突然断开连接，否则 能导致程序出错。可
12. USB只用于数据传输或者充电，请尽量避免边充电边使用。
13. 当长期没有使用产品时，需要对产品定期充电，以保证电池 命。寿
14. 电池更换不当会有爆炸危险，只能用同类型或等效类型的电池。
15. 电池不得暴露在诸如日照、火烤或类似过热环境中。
1. 不可自行进行维修、拆卸或改造。
3. 请不要在特别热、冷、多尘或潮湿的环境中使用本产品，也不要放在有液体的地方。
17. 使用电源适配器，应购买获得CCC认证并满足标准要求。
5. 设备上不要放置裸露的火焰源，如点燃的蜡烛。
4. 通风孔不要覆盖诸如报纸、桌布和窗帘等物品而防碍通风。
2. 为了充分通风，设备背面和两侧应最少保留10cm，顶部应最少保留20cm的空间。
7. 用电源插头和器具耦合器作为断开装置，断开装置应当保持能方便地操作。
6. 设备应当连接到带保护接地连接的电网电源输出插座上。
18. 仅适用于海拔2000m以下地区安全使用，标志见图1。
19. 仅适用于非热带气候条件下安全使用，标志见图2。
16. 必须遵照电池废弃的相关地方条例来废弃旧电池。
图1 图2
注意：为防电击，请勿打开机盖。
等边三角形中有箭头闪电符号的图形表示警告使用者在产品内有高压电，会导致人
为的触电。
等边三角形中有叹号的图形表示警告使用者该设备有重要的操作和维护指示。

环保支持
产品中有害物质的名称和含量
零部件名称
PCBA
金属部件
塑胶部件
充电线
显示屏
有害物质
铅
(Pb)
汞
(Hg)
镉
(Cd)
六价铬
(Cr,VI)
多溴联苯
(PBB)
多溴二苯醚
( )PBDE
电 池
本表格依据SJ/T 11364的规定编制。
○：表示该有害物质在该部件所有均质材料中的含量均在 规定的限量要求以下。GB/T 26572
X：表示该有害物质至少在该部件的某一均质材料中的含量超出
成熟的替代方案。
GB/T 26572规定的限量要求，且目前业界没有
本表中标有"X的所有部件都符合欧盟RoHS 2.0法规要求。"
本标识内数字表示产品在正常使用状态下的环保使用期限为10年。
17
简体中文
包装清单
XM10 便携音乐播放器：1台
XP10 解码耳放：1台
XPS10 线性电源：1台
用户手册：1份
保修卡：1份
电源线：1根
USB A转Type-C线：1根
直流电源连接线：1根
3.5mm转4.4mm平衡线：1根
读卡器：1个

USB
DAC
micro DS
部件名称
18
12 3
4 5
6
7
8
9
1. Micro SD卡插口
2. Type-C USB数据接口
3. 3.5mm耳机/线路输出/平衡耳机输出(需转接线)
4. 状态指示灯
5. 6.0英寸触摸屏 (1080 x 2160)
6. 电源/锁屏/音量控制
7. 上一曲选择键
8. 播放/暂停键
9. 下一曲选择键
XM10 便携音乐播放器

操作说明
开机/关机/锁屏
1. 开机: 长按电源键保持2秒，屏幕点亮并进入开机界面。
3. 锁屏: 在开机状态下，短按电源键进入锁屏状态，显示屏自动 闭，再按一次恢复唤醒状态，显示
屏点亮。
关
2. 关机: 长按 2秒， “关机”和 关闭机器。电源键 显示屏显示 “重新启动”选择窗口，点击“关机”
1. 上一曲: 短按可跳至上一首歌曲或当前歌曲的开头。
播放及暂停: 为播放或暂停播放。短按
2. 快退: 长按可在当前播放的歌曲中快退。
1. 短按可跳至下一曲: 下一首歌曲。
2. 长按可在当前播放的歌曲中快进。快进:
上一曲/快退
播放 暂停/
下一曲/快进
19
1. 手势模式
返回上一级: 从屏幕左侧边缘向右滑或右侧边缘向左滑。
返回桌面: 从屏幕下方向上滑。
多任务管理: 从屏幕下方向上滑并停留。
2. 悬浮球模式
返回上一级: 在屏幕上单击悬浮 。球
返回桌面: 在屏幕上长按 。悬浮球
多任务管理: 在屏幕上双击悬浮球。
导航键（设置 - 通用 - 导航键）
: 返回上一级。
。: 返回桌面
。: 多任务管理
3. 虚拟键模式
旋转旋钮可以增加或减小音量。
音量控制
充 电
本机支持QC3.0快充及普通USB充电器，连接USB线充电时显示屏显示电池充电图标及电量，状态指
示灯红色呼吸(关屏状态下)。
XM10 便携音乐播放器

耳机输出接口
本机配备了3.5mm耳机接口，若想使用平衡耳机输出则需要使用标配的3.5mm转4.4平衡线。
1. 插标准 卡，最大支持2TB容量。Micro SD
2. 将 卡按指示方向装入卡槽并轻 下即可，再次按下即可将卡取出。Micro SD 轻按
Micro SD卡插口
20
固件升级
1. 进行固件升级时请确保机器的电量充足，以免升级失败。
2. 升级过程中请不要操作机器。
打开 功能并连接到可用网络，即可自动检测是否有新版本固件更新。若未检测到新版本，可前
往“技术支持 - 固件升级 - 在线升级”，点击“检查更新”进行手动检测更新。
WiFi
OTA在线升级
2. 前往“技术支持 - 固件升级 - 本地升级”，进入存放固件的路径并选择相应的固件点击升级。
Micro SD卡升级
1.
置在根目录下。
前往ONIX官网下载升级固件，将新固件拷贝到机器“内置存储”或“TF卡”上，建议升级文件放
1. 推荐使用DC5V 2A或QC3.0快充适配器，使用适配器电压过高可能会损坏机器。
常见问题
耳机有杂音，耳机输出接口有可能接触不牢靠，请重新拔插复位。
4.
无法输出，请尝试使用原装或合适的音频连接线，并确保输出 常。
5. 正
2. 无法开机时，有可能电池电量过低或耗尽，请充电后再开机。
机器使用出现故障或死机时，请长按 电源键 约12秒强制重启机器
3. “ ” 。
XM10 便携音乐播放器
