HD IP IR High Speed Dome Camera
User Manual
SST-AV-ARYA
Read the user manual carefully before using this product

- 2 -
Important Safeguards
1. During the course of transportation and storage, the product should be
avoided from incorrect operations such as heavy pressing, strong
vibration, soaking etc, which may cause damage to the unit.
2. The product is designed for wall-mount and pendant-mount
installation, it can not be installed upside-down. And the module should
be handled properly so as not to bring about mechanical problems
affecting the integrative functions of it.
3. Do not let any foreign objects or liquid infiltrate into the unit, which
may damage the machine.
4. Please follow all electrical standards for safety when it is being
connected and adopt the particular power supply which is provided with
the unit. The product’s RS-485 and video signal adopt TVS-class
lightning damage preventing technology, which can effectively prevent
such pulse signal damage caused by lightning under 500W or electric
surge. RS-485 and video signal should be kept enough distance from
high voltage equipments and cables when they are in transmission, and
necessary steps should be taken to prevent lightning damage or power
surge.
5. No matter the unit is runing or not, the camera should never be aimed
at the sun or object with extremely bright light. Otherwise, the camera’s
CCD might be permanently damaged.
6. There are no parts inside the unit which can be repaired by the users
themselves. When mechanical problems arise, do not be in a haste to do
any repairing, please refer to the User’s Manual to find the trouble. If
causes can not be located, please refer servicing to qualified
professionals. All servicing must be done by authorized personnel.

- 3 -
Table of Content
1.Technical Data................................................................................. - 6 -
1.1 Dome Camera Technical Data.............................................. - 6 -
1.2 Internal Camera Technical Parameters................................. - 7 -
1.3 Internet Technical Parameters ............................................ - 10 -
2. Characteristics .............................................................................. - 12 -
2.1 Dome Camera Characteristics ............................................ - 12 -
2.2 Network Characteristics...................................................... - 12 -
3. Device Installation and Internet Connection................................. - 13 -
3.1 The outer shape and dimension of Dome Camera.............. - 13 -
3.2 Wall-mounted Dome Camera Installation.......................... - 15 -
3.3 Installation for Pendant-mount Camera.............................. - 17 -
3.4 Sketch Map For Inside Camera .......................................... - 20 -
3.5 Main External Interface For High Speed Camera............... - 20 -
3.6 Alarm Input/Output Connection And Installation .............. - 21 -
3.7 Network Connection Method.............................................. - 23 -
3.7.1 Direct Connect Mode............................................... - 23 -
3.7.2 Network Connect Mode........................................... - 23 -
3.8 Power On............................................................................ - 24 -
4. Camera Function Setting .............................................................. - 25 -
4.1 Camera Protocol, Bit Rate, Address Setting....................... - 25 -
4.2 Camera Function Setting Form........................................... - 25 -
5. IE Log In Interface........................................................................ - 27 -
5.1 Login Home Page............................................................... - 27 -
5.1.1 Device Log In ....................................................... - 27 -
5.1.2 Home Page Instruction.......................................... - 30 -
5.1.3 Home Page Instruction.......................................... - 31 -
5.2 System Setting.................................................................... - 35 -
5.2.1 Basic Information ................................................. - 35 -
5.2.2 User Manage......................................................... - 36 -

- 4 -
5.2.3 Serial Port ............................................................. - 37 -
5.2.4 Device Record ...................................................... - 38 -
5.2.5 Net Record............................................................ - 40 -
5.2.6 Time Setting.......................................................... - 41 -
5.2.7 Multiple Device .................................................... - 42 -
5.2.8 System Status........................................................ - 43 -
5.2.9 IR Sensor .............................................................. - 44 -
5.2.10 IR Setting............................................................... - 44 -
5.2.11 Auto Update........................................................... - 45 -
5.2.12 System Log............................................................ - 46 -
5.2.13 Auto Update........................................................ - 47 -
5.3 Audio Video ....................................................................... - 48 -
5.3.1 Video Channel...................................................... - 48 -
5.3.2 Video Set .............................................................. - 48 -
5.3.3 Video Mask........................................................... - 49 -
5.3.4 Audio Settings ...................................................... - 51 -
5.3.5 Extend Configuration............................................ - 51 -
5.4 Network Settings ................................................................ - 52 -
5.4.1 Ethernet................................................................. - 52 -
5.4.2 PPPOE.................................................................. - 53 -
5.4.3 DDNS Settings...................................................... - 53 -
5.4.4 Port........................................................................ - 54 -
5.4.5 Network Check..................................................... - 55 -
5.4.6 Docking Platform.................................................. - 55 -
5.5 Alarm Setting...................................................................... - 56 -
5.5.1 Alarm In................................................................ - 56 -
5.5.2 Motion Detect....................................................... - 57 -
5.5.3 Linkage Setting..................................................... - 59 -
5.5.4 Alarm Linkage...................................................... - 59 -
5.6 Local Setting....................................................................... - 60 -
6.PTZ Control Basic Function.......................................................... - 62 -

- 5 -
6.1 Preset Setting and Calling................................................... - 62 -
6.1.1 Preset Setting........................................................ - 62 -
6.1.2 Calling for Preset Position.................................... - 62 -
6.2 Special Function Setting and Calling.................................. - 63 -
6.2.1 Left/Right Scan Setting......................................... - 63 -
6.2.2 360º Scan .............................................................. - 63 -
6.2.3 Tour Group Setting............................................... - 63 -
6.2.4 Pattern Scan Setting.............................................. - 64 -
7. FAQ.............................................................................................. - 66 -

- 6 -
1.Technical Data
1.1 Dome Camera Technical Data
Power Supply
DC15V±10％（4A）
Power
Consumption
25W(Open high light IR)
Communication
Baudrate
4800bps（Fix）
Manually
Horizontal
Rotate Speed
0.5º～120º/S，max 350º/S when rotate to preset position
Manually
Vertical Rotate
Speed
0.5º～60º/S，max 120º/S when rotate to preset position
Horizontal
Rotate Range
360º no limit rotate
Vertical Rotate
Range
0 º～90º
Auto Flip
Function
Auto-flip 180º when vertical 90°
Speed
Auto-control as
per the changing
of zoom ratio
The pan/tilt can automatically adjust the running speed
following the change of the zoom ratio
Left & Right
Scan
Yes
Left & Right
Scan Speed
Low,Medium,High
360º Scan
Low,Medium,High
Pattern Scan
Number
4

- 7 -
Preset Position
Number
128
Tour Group
Number
4
Tour Group
Preset Position
Number
16 for each tour group
Guard Function
Yes
Wiper
Manually open or close
Alarm Interface
4 ways in, 1 way out(optional)
IR Lamp
High-power IR
IR Lamp Control
Sensor mode and camera mode
Brightness
control for IR
lamps
Auto/Manual, can open the low, medium, high model
manually
Facial
Recognition
Distance
100m
Max Power
Consumption for
IR Lamp
13W
Working
temperature
-25℃～60℃
Relative
Humidity
≤95% no moisture condensation
Weight
6Kg（including the bracket）
Protection Grade
IP66
1.2 Internal Camera Technical Parameters
Image Sensor
1/2.8-type ‘Exmor’ CMOS

- 8 -
Valid Pixel
3.27 Million
Minimum
Illuminance
0.095lux (ICR 开，F1.6，50IRE)
close-up camera
shooting
distance
10mm(W)～1000mm(T)（default 300 mm)
Aperture value
F1.6(W)～F3.5(T)
Focus
Auto/Manual/Trigger
zooming rate
20 times Optical variable times, 12 times digital varible
times
focal distance
f=4.7mm(Wide-angle end) ～94mm(long distance)
image angle
55.4°(Wide-angle end) ～2.9°(long distance)
electronic
shutter
1/1 to 1/10，000 s，22 step
White Balance
Auto/Manual/Indoor/Outdoor
Gain Control
Auto/Manual
Weight
About260g
Size(W×H×D)
50x60x87.9mm
Working
Temperature
-5°C to 60°C
Storage
Temperature
-20°C to 60°C
Max Power
Consumption
3.8W
Image Sensor
1/2.8’CMOS
Valid Pixel
327 万

- 9 -
Communication
Interface
VISCA protocol (CMOS 5V)
Min Lightness
0.04lx (ICR 开， 1/30sec)
Working
Distance
10mm(W) ～1000mm(T)
Synchronize
Method
Internal synchronize
Scan Method
2：1 progressive scanning
Aperture
Auto
Aperture Value
F1.6(W)～F3.5(T)
Focus
Auto/Manual
Zooming Rate
20 times Optical variable times, 12 times digital varible
times
Focal distance
f=4.7mm(Wide-angle end) ～94mm(long distance)
image angle
55.4°(Wide-angle end) ～2.9°(long distance)
electronic
shutter
Auto/Manual
White Balance
Auto/Manual
Gain Control
Auto/Manual
ICR Switch
Auto/Manual
Mirroring
Up Down/Left Right
Image Adjust
Definition/contrast/color enhancement/brightness
Weight
About 200g
size(W×H×D)
50x60x88mm
Working
‐5℃～+60℃

- 10 -
temperature
Max power
consumption
3.4W
1.3 Internet Technical Parameters
Processor
DavinciTMS320DM368
Switch in
method
Ethernet
Video
Compression
Standard
H.264
Audio
Compression
Standard
AMR，G.711
Max Frame
Rate
25 Frame/S
Video
Resolution
1920*1080(1080P) ，720*576(D1) ，352*288(CIF) ，
176*144(QCIF)
Stream
Dual stream. Main stream can choose 1080P/D1, sub stream
can choose D1/CIF/QCIF
Video
Compression
Bit Rate
16Kbps～8Mbps
Audio
Compression
Bit rate
AMR:4.75Kbps～12.2Kbps；G.711:64Kbps
