Onn 100006556 User manual

Ver.00 08/12/19
3 Speed
Turntable
PRODUCT GUIDE
100006556

2
FCC Warnings
Warning: Changes or modifications to this unit not
expressly approved by the party responsible for
compliance could void the user’s authority to operate
the equipment.
NOTE: This equipment has been tested and found
to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against
harmful interference in a residential installation. This
equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there
is no guarantee that interference will not occur in a
particular installation. If this equipment does cause
harmful interference to radio or television reception,
which can be determined by turning the equipment
o and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment
and receiver.
• Connect the equipment into an outlet on a
circuit dierent from that to which the receiver is
connected.
• Consult the dealer or an experienced radio/TV
technician for help.
Customer Service
For any product related questions,
please call us at: 1-888-999-4215.
Copyright © 2019 Digital Products International (DPI,
Inc.) All other trademarks appearing herein are the
property of their respective owners. Specifications are
subject to change without notice.
Important Safety Instructions
• Read these Instructions.
• Keep these Instructions.
• Heed all Warnings.
• Follow all instructions.
• Do not use this apparatus near water.
• Clean only with a dry cloth.
• Do not block any ventilation openings. Install in
accordance with the manufacturer’s instructions.
• Do not install near any heat sources such as
radiators, heat registers, stoves, or other apparatus
(including amplifiers) that produce heat.
• Do not defeat the safety purpose of the polarized
or grounding - type plug. A polarized plug has two
blades with one wider than the other. A grounding
type plug has two blades and a third grounding
prong. The wide blade or the third prong are
provided for your safety. When the provided plug
does not fit into your outlet, consult an electrician
for replacement of the obsolete outlet.
• Protect the power cord from being walked on
or pinched particularly at plugs, convenience
receptacles, and the point where they exit from the
apparatus.
• Only use attachments/accessories specified by the
manufacturer.
• Unplug this apparatus during lightning storms or
when unused for long periods of time.
• Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or
plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has
been exposed to rain or moisture, does not operate
normally, or has been dropped.
• Use only with a cart, stand, tripod, bracket, or table
specified by the manufacturer, or sold with
the apparatus. When a cart is used, use
caution when moving the cart/apparatus
combination to avoid injury from tip-over.
Information & Safety Instructions

3
Additional Warnings and Precautions
• CAUTION: TO PREVENT ELECTRIC SHOCK, MATCH
WIDE BLADE OF PLUG TO WIDE SLOT, FULLY INSERT.
• Mains plug is used as disconnect device and it
should remain readily operable during intended
use. In order to disconnect the apparatus from
the mains completely, the mains plug should
be disconnected from the mains socket outlet
completely.
• CAUTION: Use of controls or adjustments or
performance of procedures other than those
specified may result in hazardous radiation
exposure.
• WARNING: Changes or modifications to this unit
not expressly approved by the party responsible
for compliance could void the user’s authority to
operate the equipment.
• WARNING: Use of this unit near fluorescent lighting
may cause interference regarding use of the
remote. If the unit is displaying erratic behavior
move away from any fluorescent lighting, as it may
be the cause.
• WARNING: Shock hazard - Do Not Open.
• Caution and marking information is located at the
rear or bottom of the apparatus.
• WARNING: To reduce the risk of fire or electric
shock, do not expose this apparatus to rain,
moisture, dripping, or splashing.
• Objects filled with liquids, such as vases, shall not
be placed on the apparatus.
Warning: To reduce the risk of electric
shock, do not remove cover (or back).
No user-serviceable parts inside. Refer
servicing to qualified service personnel.
ATTENTION
RISQUE D' ÉLECTROCUTION
NE PAS OUVRIR
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The exclamation point within an
equilateral triangle is intended to
alert the user to the presence of
important operating and maintenance
(servicing) instructions in the literature
accompanying the appliance.
This symbol indicates that this product
incorporates double insulation between
hazardous mains voltage and user
accessible parts.
The lightning flash with arrowhead
symbol, within an equilateral triangle, is
intended to alert the user to the presence
of uninsulated “dangerous voltage” within
the product’s enclosure that may be of
sucient magnitude to constitute a risk of
electric shock to persons.
WARNING : This product can expose
you to chemicals including lead, which
is known to the State of California to
cause cancer and birth defects or other
reproductive harm. For more information
go to www.P65Warnings.ca.gov. This
product meets and complies with all Federal
regulations.

4
Table of Contents
Get to Know Your Turntable–5
Features–5
What’s in the Box?–5
Top–6
Rear–6
Controls–7
Let’s Get Started–8
Attach the Counterweight–8
Power –9
Loading a Record–9
Connecting to a Bluetooth Speaker–10
Connecting to External Speakers–11
Hints and Tips–12
Anti-Skating–12
Pitch Adjustment–12
Stylus Replacement–12
Usage Tips–12

5
Features
• Built-in Bluetooth transmitter for
connecting to Bluetooth speakers
• Lift and return action of the tone
arm at the end of a record
• Belt Drive
• Pitch Adjustment
• Anti-Skate Adjustment
• Plays 33, 45, and 78rpm records
• Built-in RIAA preamp
• RCA stereo audio output
• AC power: built-in AC power cable
What’s in the Box?
• Turntable
• 45 rpm adapter
• Phono cartridge
• RCA stereo audio cable 3.9 ft (1.2m)
• Quick Start Guide
• Product Guide
Get to Know Your Turntable

6
Top
Rear
Get to Know Your Turntable
5
1
6
2
4
7
14
8
3
9
10
11
12
15
13
1. 45rpm Adapter
2. Platter
3. Tone Arm
4. Cartridge & Stylus
5. Tone Arm
Counterweight
6. Anti-Skating
Adjustment
7. Tone Arm Lift Switch
8. Tone Arm Lock
9. Pitch Adjustment
10. Bluetooth Pair Button
11. Power ON/OFF/
Record Speed
12. Power/Bluetooth
Indicator
13. Bluetooth ON/OFF
14. RCA Line Out
15. Phono/Line Out
Setting

7
Controls
1. Counterweight Adjustment:
Turn to adjust the amount of
weight placed on the record
by the stylus.
2. Anti-Skating Adjustment:
Turn to adjust the inward
tracking of the stylus on the
record.
3. Pitch Adjustment: Turn to fine
tune the speed of the platter
as it spins.
4. Pair Bluetooth: Press to
begin pairing to a Bluetooth
speaker.
5. 78/45/33/OFF: Turn to power
ON the turntable and select
the play speed. The speed
should match the type of
record you are going to play.
6. Power/Bluetooth Pairing
Indicator: Turn to power ON
the turntable, indicated by a
RED LED. When the turntable
is pairing to a Bluetooth
speaker, the light will quickly
flash blue, then turn solid
when successfully paired.
1
2
3
4
5
6

8
Let’s Get Started
Attach the Counterweight
The counterweight controls how much pressure the stylus will put on a record. If
there is too much pressure, the sound will become distorted. If there is too little
pressure, the stylus will skip out of the grooves on a record.
The tone arm should be balanced without the protective cover over the stylus,
as it will aect the weight. Be careful not to damage the stylus while the cover is
removed.
• Attach the counterweight on the rear of the tone arm and remove the ties
and the tone arm lock securing it in place.
• Adjust the counterweight by turning clockwise or counter-clockwise until the
tone arm floats naturally.
• Rotate the numbered dial (without rotating the counterweight) so that the
marked “0” is at the top, 12 o’clock position, indicating the neutral balance
setting for future reference.
• Grasping both the counterweight and the dial, rotate counter-clockwise so
that the reading “0.4” is at the top, 12 o’clock position, indicating the tone
arm is set for 4 grams of pressure on the record. This is the recommended
setting for the stylus.
Reading “0.4” is at the top

9
Loading a Record
• Place your record on the platter, aligning it with the center spindle.
• Set the speed selector dial to match your record type - 33, 45, or 78. If you
are playing a 45rpm record, be sure to place the 45rpm adapter on the
platter first, so that it is between the platter and the record.
• Remove the protective cover on the stylus, then release the lock on the tone
arm.
• Use the tone arm lift switch to raise the tone arm upwards, then carefully
move it into position over the record.
• As the tone arm moves into position, the platter will start spinning. Use the
tone arm lift switch to lower the tone arm stylus onto the record. When the
stylus comes into contact with the grooves on the record, the turntable will
send audio to the connected speakers.
Power
Plug the DC power adapter into a
standard wall outlet and the DC
Power Input on the unit.
Lock
Unlock

10
Connecting to a Bluetooth Speaker
• Start by enabling Pairing Mode on the Bluetooth Speaker you want to
use. Before beginning the pairing process, be sure no other devices are
connected to the speaker.
• On the turntable, turn Bluetooth Mode ON by adjusting the switch on the
back of the unit.
• Press the Pair button on the turntable to begin pairing to your speaker. The
indicator light on the turntable will quickly flash blue while it attempts to
connect to the speaker.
• When successfully paired, the indicator light on the turntable will turn solid.
Note: If the turntable fails to connect, the indicator light will keep flashing
blue. Press the Pair button to try again.
• Audio from the record will now be heard through the connected speakers.
Use the volume control on the speakers to adjust the audio level.

11
Connecting to External Speakers
Line Out
Phono
• Use an RCA audio cable to connect to a pair of external speakers. Connect
the Line Out ports on the turntable to the corresponding color-coded ports
on the speakers.
• Set the selector switch on the back of the turntable to Line Out to send
audio to the speakers.
• IMPORTANT! If you are connecting the turntable to speakers through a
preamp, set the switch on the back of the turntable to Phono. Improper
selection of the switch will result in either no sound or explosive sound.
• Audio from the record will now be heard through the connected speakers.
Use the volume control on the speakers to adjust the audio level.
Speaker
s
Preamp
Speakers

12
Hints and Tips
Anti-Skating
The Anti-Skating dial adjusts the inward tracking of the tone arm on the record.
Usually, the dial should be left in its lowest setting. However, if the turntable is
experiencing excessive skipping as the record plays, increase the anti-skating
eect in increments of 1 using the dial.
Pitch Adjustment
The Pitch Adjustment dial will increase or decrease the speed of the platter as
it spins. This can be used to fine tune the speed of the record as it plays. If the
speed or sound seems a little o, use the dial to correct the audio distortion.
Stylus Replacement
The stylus is rated for 300 hours of play. However, if you notice a change in
audio quality, you should replace the stylus as soon as you can. Prolonged use
of a worn out stylus can damage records.
• To replace a stylus, first, be sure the turntable is powered OFF, then carefully
pull the stylus simultaneously downward and forward o of the tone arm.
• Insert the new stylus and press upwards until it clicks into place.
Usage Tips
• Close the top cover to prevent dust from collecting on the turntable or your
records. Dust and other particles can interfere with the stylus as it tracks in
the grooves of a record.
• Be sure to lock the tone arm in place before transporting the turntable.
• Do not place anything on the turntable or the top cover, especially when it is
in use.
