ORIGO TFC-1250 User manual

使用說明書
Instruction Manual
TFC-1250
TFC-1250S
涼 夏 冷 風 扇
nigrum tower fan cooler
*使用冷風扇前，請先細閱使用說明，並請妥善保存以便將來翻閱。
*Read all instructions carefully before using the FAN COOLER, and keep this instruction for
furture reference when necessary.

涼 夏 冷 風 扇
nigrum tower fan cooler
Important Safety Information
重要安全提示
1
拔除插頭時不可拉扯電源線，必須緊握插頭
，把插頭拔出。
Do not pull the power cord to disconnect
from power source. Always grasp the plug
to pull out.
請使用獨立插座。使用萬能插頭或拖板，容
易發生危險。
Avoid using extension cord as it may
overheat and casue fire.
使用冷風扇前，請確定規格標貼上所示的
額定電壓與當地供電電壓相同。如有疑問
可向供應商查詢。
Before using the Fan Cooler, check if
the voltage marked on the rating label
corresponds to the mains at your
home.
220-230V~ 50 Hz
包裝物料並非玩具，不可讓小孩玩耍。
Do not let children play parts of
package.
打開包裝，檢查冷風扇。如發現產品有損
壞，請勿使用及即時聯絡供應商。
Open the package and ensure that the
Fan Cooler is undamaged. In case of
doubt do not use the FAN Cooler and
contact your supplier.
必須按照使用說明指示操作冷風扇，否則
可能引致產品損壞、短路、火警或人命損
傷。
Use this Fan Cooler only as described
in this manual. Any other use not
recommended by the manufacturer
may casue fire, electrical shock or
injury to persons.
使用冷風扇前，請先細閱使用說明。
Read all instructions carefully before
using the Fan Cooler.
本機不是為體質、感覺或智力有障礙人士(包
括小孩)或缺乏經驗及知識者使用，除非他們
曾經接受負責安全人士的監督或指示，大人應
指導小孩不可把玩電器。
This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities, or
lack of experience and knowledge, unless
they have been given supervision or
instruction concerning use of the appliance
by a person responsible for their safety.
Children should be supervised to ensure
that they do not play with the appliance.

Important Safety Information
重要安全提示
2
不可在潮濕或有積水的環境使用，不可將冷
風扇擺放於浴缸或大型溶器上面。
The Fan Cooler is not intended for
use in wet or damp locations. Never
locate the Fan where it may fall into a
bathtub or other water container.
請保持清潔以維持 冷 風扇處於良好狀態
(詳細請參閱清理及維護部份)。
Keep the Fan Cooler clean to maintain
in good condition (refer to maintenance
section).
切勿將 冷風扇 擺放在發熱源頭或火源附近。
Do not place the Fan Cooler near a
source of heat or fire.
警告；清理前必須先拔除電源插頭。若電
源線損壞，必須交由製造商或其代理指定
維修服務中心檢查及修理。
WARNING: To avoid danger of electric
shock, unplug from outlet when not
in use and before cleaning. If the
power cord is damaged, it must be
replaced by the manufacturer, its
service agent or similarly qualified
persons in order to avoid hazard.
本冷風扇不適用於室外及作工業用途。
This Fan Cooler is intended for
household use ONLY and not for
industrial or outdoor use.
非使用冷風扇時請拔除插頭，切斷電源。
Do not leave the Fan Cooler
unattended. Always unplug the Fan
Cooler when not in use.
切勿將任何異物放入冷風扇內；或阻擋冷
風扇出風口及入風口，皆因以上一切行為
均可能導致冷風扇損壞。
Do not insert any objects into the Fan
Cooler as it may cause an electric
shock or damage. Do not block or
tamper with the Fan Cooler in any
manner while it is in operation.
警告：開/關鍵不應作為切斷電源的用途。
WARNING: The On/Off switch should
not be used as the sole means of
disconnecting power. Always unplug
the power cord before servicing or
moving the unit.
如須移動冷風扇，請先拔除插頭切斷電源。
Always disconnected the Fan Cooler
from the power supply when moving
it from one location to another.
本產品含有可回收材料，不可把本產
品作為未分類廢物。請聯繫當地就近
指定回收點。
This product contains recyclable
materials. Do not dispose this
product as unsorted municipal
waste. Please contact your local
municipality for the nearest collection
point.
涼 夏 冷 風 扇
nigrum tower fan cooler

Main Parts
各部名稱
3
涼 夏 冷 風 扇
nigrum tower fan cooler
後殼
Rear Housing
插頭
Plug
Air Outlet
出風口
Front Housing
前殼
LED Screen
LED顯示屏
Control Panel
控制面板
底座
Base
電源線
Power Cord
遙控器
Remote Control
Cool Mist Outlet
冷霧出口
水箱
Water Tank
排水栓
Water Stopper

4
Assembly
底座安裝 涼 夏 冷 風 扇
Remote Control
遙控器
送風模式
TIMER
OSC
SPEED
MODE
nigrum
tower fan
風速
冷霧 左右送風
定時
1. Snap the two parts of the base
together.
2. Pass the Power Cord through the
center hole of the base, after
snapping the two pieces together
(The back piece is the one with
the power cord securing channel).
3. Line up the Tower fan on the base,
and fix with the 3 manual screws.
1. 把兩塊底板互相扣緊。
2. 把電源線扣於底板指定位置上(其
中一塊底板設有電源線安全管道)。
3. 把風扇主體垂直放於底座上,使用三
枚螺絲將風扇主體及底座鎖緊。
POWER
開/關
nigrum tower fan cooler
COOL
注意：底座完成安裝前，切勿使用本冷風扇。
Caution: Do not operate the Fan Cooler before base assembling finished.
1.遙控器操作方式與機身按鍵操作方式相同。
2.更換電池 : 使用一枚3伏特鋰電池。
1. All functions performed by the Remote Control work are identical
to the Manual.
2. Battery replacement:Install one 3V Lithium battery.
警告
1)
2)
3)
4)
請把電池放在兒童碰不到的地方，如果孩子吞下電池，需立即致電咨詢醫生。
不要對電池進行充電或隨意棄置在有火源的地方。
應保持電池存放於乾燥，陰涼的地方。
以正確的方向插入電池。
電池的處理 - 請按相關地區的法律規定處理曾經使用的電池。
WARNING
1. Keep batteries out of reach of children. Should a child swallow a battery,
consult a doctor immediately.
2. Do not recharge or dispose in fire.
3. Keep in a dry and cool place.
4. Insert battery in rigdt direction.
Battery disposal - Please dispose the used battery per municipal
or provincial law.

Function Setting
功能設定
5
涼 夏 冷 風 扇
1.
1. Place the Fan Cooler on a stable and flat surface. Plug the Power Cord into an a.c.
220-230V electrical outlet. The LED screen will display the current room temperature.
POWERPOWER
POWER
4. 送風模式 (MODE) : 按送風模式鍵 ，設定所需送風模式：常風、自然風、或睡眠
4. MODE: Press the button to set the Fan Cooler as Normal, Natural, or Sleep mode.
5. 左右送風(OSC): 按下左右送風鍵 ，冷風扇以自動左右搖擺模式送風。如欲停止自
5. OSC: Press the button to allow the Fan Cooler to oscillate the wind direction. To
定時 左右送風 送風模式 風速 開/關
冷霧
The mode is displayed on the LED screen.
風。LED顯示屏將會顯示送風模式。
動左右搖擺送風，再按此鍵一次。
stop the oscillation, press the button again.
將冷風扇擺放於穩固的平面上，將插頭插入交流電壓220-230V/50Hz的獨立插座。室
內溫度顯示LED燈同時亮起。
3. 風速 (SPEED) : 按風速設定鍵 ，設定所需風速：低、中、或高。LED顯示屏將會顯
冷風扇可使用機身頂部按鍵操控(如圖1)，或改用遙控器操控。
3. SPEED: Adjust the Fan Cooler speed to the desired level: Low, medium, or high by
pressing button. The speed setting is displayed on the LED screen .
2.
The Fan Cooler may be operated by the control panel located on top of the Fan Cooler
(as shown in Figure 1) or by your remote control.
2. POWER: Turn the Fan Cooler ON by pressing the button, the Fan Cooler will start
at low speed.
圖1
Figure 1
TIMER OSC SPEEDSPEEDMODEMODE POWERPOWER
SPEEDSPEED
SPEEDSPEED
MODE
MODEMODE
OSC
OSC
示風速。
開/關(POWER) : 按開/關 鍵，冷風扇以低檔啟動。
COOL
nigrum tower fan cooler
6. 定時設置(TIMER): 按下定時設置鍵 ，選定16個不同的自動關機時間，分別由0.5
至8小時，並顯示於LED顯示屏。
6. TIMER: Pressing the button to set desired auto power off time, There are 16 time
TIMER
intervals, from 0.5-hour to 8-hour.
TIMER

Function Setting
功能設定
6
涼 夏 冷 風 扇
nigrum tower fan cooler
Maintenance
清理及維護
警告：不使用冷風扇時，經常保持拔除電源，及切勿將冷風扇浸於水或其他液體中。在清
潔冷風扇前，先將冷風扇關掉及把電源線從插座拔出。
House & Rear Grille: Clean the outside and grille of the Fan Cooler
with a soft cloth. To remove presistent dirt, wipe down with a cloth
that has been dampened with warm soapy water.
外殼及後網：清理時切勿將冷風扇浸於水或其他液體中。使用濕潤軟
布抹擦清潔，頑固污垢可用軟布沾上含肥皂的溫水抹擦。
注意：切勿使用含有腐蝕性的清潔劑或溶液清理冷風扇。
儲存：把水箱及機體的水放乾，連同使用說明，把冷風扇存放於清涼及乾爽的地方。
WARNING: ALWAYS UNPLUG THE POWER CORD BEFORE MOVING OR SERVICING. DO NOT
IMMERSE THE FAN COOLER IN WATER! BEFORE CLEANING, MAKE SURE THAT THE UNIT HAS
BEEN SWITCHED OFF AND IT IS UNPLUGGED FROM THE MAIN OUTLET.
CAUTION: Do NOT use gasoline, benzene, thinner, harsh cleaners,
etc., as they will damage the Fan Cooler. NEVER use ALCOHOL or any other SOLVENTS.
風輪：將後網下方螺絲鬆脫後取出後網，使用濕潤軟布抹擦清潔風輪
。清潔後，放回後網並用螺絲鎖緊，才可使冷風扇。
Wind Wheel: Loose the screw and pull the rear grille out. Clean the
wind wheel with a soft damp cloth, place and fix the rear grille with
the screw after cleaning.
STORAGE: After empty excess watre from the water tank and the reservoir, store the Fan
Cooler with these instructions in the original box in a cool and dry place.
7.冷霧(COOL): 取出水箱及將水箱蓋旋開，注入清水，將水箱蓋旋緊後置入本體及儲水
槽中。按下冷霧鍵 ，冷風扇會產生冷霧(大量-綠色燈顯示，小量-橙色燈顯示)。水
箱缺水時， 標示會閃亮。
*本機可按使用者需要，選擇獨立操作冷霧或風扇功能，或同時使用兩項功能。
7. COOL: Remove the water tank from the main body and unscrew the cap. After fill in
clear water, screw the cap back on and replace water tank into the reservoir. Pressing
the button to start the cool mist function(large - green light, small - orange light).
sign will be flash on when water shortage.
*COOL and FAN function can be operated together or independently.
COOL
!
!
COOL

²D ®L ®°
Crudus Tower Fan
涼 夏 冷 風 扇
nigrum tower fan cooler
6
Specification
技術規格
型號 Model Number
電源 Power Supply
額定功率 Rated Power
包裝尺寸 Package Dimension
TFC-1250/TFC-1250S
220-230V~ 50Hz
80W
1290 x 250 x 245 mm
Origin Map
源澤地圖
辦公時間
10:30am - 12:30pm (星期一至五)
02:30pm - 05:30pm (星期一至五)
10:30am - 12:30pm (星期六)
(星期日及公眾假期休息)
OFFICE HOURS
10:30am - 12:30pm (Mon to Fri)
02:30pm - 05:30pm (Mon to Fri)
10:30am - 12:30pm (Saturday)
(Closed on Sunday and Holiday)

涼 夏 冷 風 扇
nigrum tower fan cooler
產品保用証一年自攜服務
產品: 涼夏冷風扇
型號: TFC-1250/TFC-1250S
此產品由購買日期起計算，本公司將根據下列條款及細則，提供一年保養服務(商業用享3個月)
1. 於購買後一年內，經本公司技術員判斷為正常運作下損壞之產品，
憑零售商之正式發票可獲免費維修和/或零件更換。
2. 以下情況不被包括在保養範圍內：
- 若產品是因為濫用、錯誤使用、疏忽及/或意外而遭致損壞；
- 未經授權之自行處理、維修及/或改裝；
- 任何機殼、面蓋、風輪、底座，以及遙控器。
3. 需要檢查或維修時，請將產品送往本公司服務中心，並於修理妥當後自行取回。
4. 更換後之任何損壞零件，均屬本公司所有。
5. 本保養服務只適用於香港特別行政區。
6. 顧客必須同時出示零售商之正式發票，方可得到免費維修服務。
服務中心
源澤市務有限公司
香港新界葵涌青山公路403號(近華星街12號)匯城集團大廈21樓H室
電話: 2156 8238
www.origin.hk
*** 額外3個月保用: 凡於購買產品後10天內完成網上登記，即可免費延長保用期3個月，即15個月免費保用(商業用途
除外)。請即登入網站: www.origin.hk
Warranty Card(1 year carry-in)
Item : nigrum tower fan cooler
Model : TFC-1250/TFC-1250S
This product is warranted for 1year (commercial use for 3 months) from the date of purchase under the
following conditions:
1. For any defect, in the judgment of our technician, if it is caused under normal use, we are responsible for
repairing the product, and/or replacing parts at free of charge.
2. This warranty DOES NOT apply to:
- If the product has been damaged through abuse, misuse, negligence or accidents;
- Unauthorized repair, alteration/modification ;
- Housing, cover, wheel, base and remote control is excluded from this warranty .
3. The customer is requested to bring the unit to and from our Service Centre whenever
service is needed.
4. Any defective parts, which had been replaced, shall be of our property.
5. This warranty is valid in H.K.S.A.R. only.
6. Please show the Invoice to get free service.
***Extra 3 months warranty: just complete Online Warranty Registration within 10 days from the date of
receipt, free warranty will be extended to 15 months (not applicable to commercial use). Please enter our
website: www.origin.hk
Service Centre
ORIGIN MARKETING LIMITED
Unit H, 21/F., Reason Group Tower (nearby 12 Wah Sing Street), 403 Castle Peak Road, Kwai Chung, N.T., Hong Kong.
Tel: [phone]
www.origin.hk
