Pellet Comfort water boiler with nominal heat capacity of: 7, 10, 16 and 25 kW
with automatic solid fuel feeding, using pellet.
TECHNICAL AND MAINTENANCE DOCUMENTATION
OPERATION AND MAINTENANCE MANUAL
WARRANTY
device version: 04/2017
document version: 13/2018/JK
Orte Polska Sp. z o.o.
Słoneczna 1,
96-321 Oddział
Manufactured in Poland

www.orte.pl
www.orte.pl
Page | 2
I. OPERATION AND MAINTENANCE MANUAL
1. General information ………………………………………..……………………………………………………………………………….………3
2. Technical specification…………………………………………………………………………………………………………………………..…………..4
3. Intended use and characteristics……………………………………………………………………..……………………………………...6
3.1 Intended use……………………………………………………..…………………………………………………………………………………….…6
3.2 Information about the boiler……………………………………………………………..……………………………………………..…..……6
3.3 Installation guide………………………………………………………………………………………………..…..……………………………..…..6
3.4 Operation guide…………………………….…..………...……………………………………………………………………………………….…..7
3.5 Safety systems………………………………………………………………………………………………………..…..……………………………..7
3.6 Boiler construction……………………………………………………………………………………………………………………………..........8
3.6.1. Boiler diagram…………………………………………………………………………………………………………………………………..8
3.6.2. Installation/disassembly diagram of the bin/tray…………………………………………………………………………….10
3.6.3.Burner diagram………………………………………………………………………………………………………………..................11
3.7 Operation and storage conditions…………………………………………………………………………………………………………….11
3.8 Minimal distances and flammability………………………………………………………………………………………………………….12
3.9 Minimal reflux temperature……………………………………………………………………………………………………………………..12
3.10 Tools, materials and auxiliary measures…………………………………………………………………………..……...................12
4. Safety……………………………………………………………………………………………………………………..……….………………………………12
4.1 Safety tips…………………………………………….…………………………………………………..……………………………………………….13
5. Transport and installation……………………………………………………………………………………………………………………..…..…….15
5.1 Transport………………………………………………………………………………………………………………………………..………………..15
5.2 Installation………………………………………………………………………………………………………………………………….…………….16
5.3 Installation conditions…………………………………………………………........................................................................16
5.4 Distance from the walls……………………………………………………………………………………………………………..……..........17
5.5 Distance from flammable materials……………………………………………………………………..…………………………………..17
5.6 Exhaust connection guide……………………………………………………………………………..………………………………………….17
5.6.1.Exhaust connection…………………………………………………………………………..……………………………………………..18
5.6.2. Inlet air connection…………………………………………………..…………………………………………………………………….19
5.7 Hydraulic connections…………………………………………………………………………………………………………………………………………….19
5.7.1.Connection of the boiler to CO system………………………………………………………………………………………………………………19
5.8. Filling the heating system and checking for leaks………………………………………..………………………………………………………….21
6. Starting up……………………………………………………………………………………………………………………………………………………….22
6.1 Before start up……………………………………………………………………………………………………………………………………….…22
6.2 First start up……………………………………………………………………………………………………………………………………………..23
7. Operation……………………………....………………………………………………………………………………………………………………….…...24
7.1 Turning on the device…………………………………………………………………………………………………………….…………………24
7.2 Safe turn off………………………………………………………………………………………………………………………………………………25
7.3 Fuel …………………..………………………………………………………………………………………………………………………………….….25
7.4 Suggested settings…………………………………………………………………………………………………………………………………...25
7.5 Messages on the controller…………………………………………………………………………………………………..…………….……26
7.6 Burner trouble………………………………………………………………………………………………………………………………………....27
7.7 Replacing spare parts…………………………………………………………………………………………………..……………………………28
7.7.1. Lighter replacement………………………………………………………………………………………………………………………..28
7.7.2. Photoelement replacement…………………………………………………………………………………………………………….28
8. Maintenance…………………..……………………………………………………………………………………………………………....................28
8.1 Cleaning the boiler……………………………………………………………………………………………………………....…..……………..28
8.2 Cleaning the burner…………………………………………………………………………………………………………….…….……………..29
8.3 Cleaning the heating system…………………………………………………………………………………………..………………………..30
9. Shut-down………………….…………………………………………………………………………………………………..….……………………………31
10. Wiring diagram of the boiler………………………………………………………………………………………………………….………………..31
11. Warranty terms…………………………………………………………………….………………………………………………………………………...32
12. Warranty card and protocols…………………………………….…………………......................................................................33
13. EC declaration of conformity ...............................................................................................................................39
II. TEMPERATURE CONTROLLER RK-2006 SPGM OPERATING INSTRUCTION

www.orte.pl
www.orte.pl
Page | 3
Operation and maintenance manual
Before installation and operation of the Pellet Comfort boiler (hereinafter referred to as
the device or boiler), read and strictly adhere to this manual and read the terms of your warranty.
REMEMBER!!! IF YOU WANT TO TURN OFF THE DEVICE –USE THE STOP BUTTON ON THE CONTROL
PANEL. DO NOT UNPLUG THE DEVICE BECAUSE OF THE RISK OF EXPLOSION!
National and local provisions regarding installation and operation must be complied with.
A filled Installation Protocol must be sent (scan, xerox) to the Manufacturer within 14 days from the start-up
of the device. OTHERWISE, THE WARRANTY IS INVALID.
1. GENERAL INFORMATION
Boilers comply with the requirements of class 5 according to PN EN 303-5:2012.
This Technical and Maintenance Documentation is an integral part of the device and must be delivered to
the user together with the machine.
Electric connections must be performed by an electrician with appropriate permissions. Electric installation
must be designed and performed by persons with appropriated permissions and additionally secured with
a differential switch (residual current 30mA).
Before connecting the device, a chimney sweeper with appropriate permissions must perform an
acceptance test.
Connection and commissioning of the boiler must be performed by an authorized installer with
appropriate permissions, designated by the Seller.
The manufacturer reserves the right to make technological changes, amend technical data, dimensions,
appearance, equipment, without prior notification, if the differences are not significant and do not affect
the operation of the device.
Orte Polska Sp. z o.o. is not liable for damages resulting from improper installation of the boiler,
unauthorized modifications, using spare parts not authorized by the manufacturer, or failure to comply
with the terms and conditions included in the Technical and Maintenance Documentation (hereinafter:
TMD).

www.orte.pl
www.orte.pl
Page | 4
2. TECHNICAL SPECIFICATION
TYPE with RK 2006-SPGM controller
PELLET
COMFORT 7
PELLET
COMFORT 10
PELLET
COMFORT 16
PELLET
COMFORT 25
TECHNICAL DATA
Area of a house built according to the current energy
standards (m2)
120
150
240
350
Max. power supplied with fuel (kW)
8.3
12
18
26.6
Nominal power
7.3
10.3
16
23.6
Partial power
Not applicable
Not applicable
Not applicable
7.3
Dust emission class according to EN 303-5:2012
5
5
5
5
CO emissions class according to PN EN 303-5:2012
5
5
5
5
OGC emission class according to PN EN 303-5:2012
5
5
5
5
Efficiency class
5
5
5
5
Efficiency for max. power (%)
88.1
88.1
88.4
88.7
Efficiency for min. power (%)
Not applicable
Not applicable
Not applicable
87.2
Power supply (V)
230
230
230
230
Power consumption at stand-by (W)
2.7
2.7
2.7
2.7
Power consumption at rated power (W)
90
90
90
90
Power consumption at partial power (W)
Not applicable
Not applicable
Not applicable
90
Water capacity of the boiler (litres)
59
59
94
94
Max. operating temperature (boiler output) (°C)
80
80
80
80
Max. operating pressure (bar)
1.5
1.5
1.5
1.5
Safety heat exchanger
o
o
o
o
Fuel consumption at rated power (kg/h)
1.74
2.45
3.8
5.58
Exhaust temperature at max. power (°C)
82
100
107
115
Exhaust temperature at min. power (°C)
Not applicable
Not applicable
Not applicable
75
Exhaust stream at max. power (g/s)
18
19
17.5
16.23
Exhaust stream at min. power (g/s)
Not applicable
Not applicable
Not applicable
7.55
Safety temperature limit (°C)
80
80
80
80
Stack effect at max. power (Pa)
20
20
25
25
Required protection (A)
5
5
5
5
Frequency (Hz)
50
50
50
50
Safety systems
6
6
6
6
Min. amount of air required for proper fuel combustion (m3)
80
100
150
150
BOILER DIMENSIONS
Height (mm)
1095
1095
1216
1216
Width of the boiler (mm)
390
390
490
490
Width of the boiler together with the tray (mm)
970
970
1141
1141
Depth with the burner (mm)
1400
1400
1500
1500
Weight (kg)
360
360
520
520
Water outlet/return tube (threaded)
G1 ½ external
thread
G1 ½ external
thread
G1 ½ external
thread
G1 ½ external
thread
Exhaust pipe outlet (mm)
159
159
159
159
Chimney cross-section (cm x cm)
14 x14
14 x14
20 x14
20 x14
TYPE OF FUEL
A1 class pellet according to EN ISO 17225-2:2014
s
s
s
s
TANK
Standard –near the boiler (kg)
100
100
150
150

www.orte.pl
www.orte.pl
Page | 5
1) Ability to set burning parameters for four types of pellet. Changes in the operation of the fan, feeder and lighter are stored for the
currently selected type of fuel.
2) An additional room thermostat with RT-208GT data transmission is required. Ability to control and set all boiler parameters on
the room thermostat.
3) An additional Internet module UMI-1 WI-FI or LAN is required.
The manufacturer reserves the right to make technical changes at any time.
TYPE with RK-2006 SPGM controller
PELLET
COMFORT 7
PELLET
COMFORT 10
PELLET
COMFORT 16
PELLET
COMFORT 25
Custom: 270, 380l, 560l.
o
o
o
o
External feeding
o
o
o
o
Fuel feeding from the tank to the burner
s
s
s
s
BURNER
Steel grade:1.4828
s
s
s
s
Cylindrical burner
s
s
s
s
Furnace made of chrome heat-resistant steel
s
s
s
s
Top-loading burner
s
s
s
s
Automatic ash push-out
s
s
s
s
Heating-burning element
s
s
s
s
Jet fan
s
s
s
s
Motoreducer x 2
s
s
s
s
Photocell –optical flame control sensor
s
s
s
s
Pellet burning grill
s
s
s
s
RK 2006 SPGM CONTROLLER
MEASURING INPUTS
Boiler temperature sensor
s
s
s
s
Return temperature sensor
s
s
s
s
CO temperature sensor behind the valve
s
s
s
s
External temperature sensor
s
s
s
s
Feeder temperature sensor
s
s
s
s
Photodetector
s
s
s
s
Room thermostat
s
s
s
s
CO circuit room thermostat with valve
s
s
s
s
CONTROL OUTPUTS
Fan
s
s
s
s
CO pump
s
s
s
s
CO2 pump behind the valve
s
s
s
s
SWU pump or return pump
s
s
s
s
Mixing valve
s
s
s
s
Lighter
s
s
s
s
External feeder (STOKER)
s
s
s
s
External feeder
s
s
s
s
Cleaning mechanism
s
s
s
s
Fan
s
s
s
s
FUNCTIONS
Memory: 4 types of fuel-pellet. 1)
s
s
s
s
Possibility of using wood
s
s
s
s
Support for two CO circuits
s
s
s
s
Weather-related control
s
s
s
s
Data transmission 2)
s
s
s
s
On-line control 3)
s
s
s
s

www.orte.pl
www.orte.pl
Page | 6
3. INTENDED USE AND CHARACTERISTICS
3.1. Intended use
Water boilers Pellet Comfort are delivered as integrated heating devices that consist of a boiler with a
capacity of 7.3 or 23.6 kW along with a burner, pellet tray and feeder. The devices are designed for heating
in buildings where there is a central heating water installation (C.O.) and/or a usable water installation
(CWU). 7-16 kW boilers are adapted to work in an open system, which means, among others, that the
hydraulic system must have an open expansion vessel with an overflow pipe and be carried out in
accordance with the applicable standards for open systems or adapted to work in the system with closed
buffer.
There are Pellet Comfort boilers where the flow of heated water depends on the type of water system and
water pumps used. The boilers are designed for use with cubic capacity of up to 700 m3.
In standard, the kit includes:
- Technical and Maintenance Documentation along with the warranty,
- Technical and Maintenance Documentation of the controller,
- rake,
- pellet tray
3.2. Information about the boiler
This manual contains important information regarding safe installation, commissioning and maintenance of
the boiler.
The boiler should be installed by a qualified installer.
In order to ensure intended use, you must adhere to the manual, information on the nameplate and
technical data. It is forbidden to install the boiler in apartments and corridors. Boilers can be installed in
accordance with local and national regulations and in accordance with safety rules described in the section
“Safety”.
Installation and use of the boiler are allowed only in rooms with constant and proper ventilation. The
boiler may be used to heat water and for indirect preparation of usable warm water.
The boiler must work at the minimum return temperature of 42÷60˚C. One must ensure this limit
temperature by using appropriate devices, e.g. thermostatic mixing valve.
3.3. Installation guide
INFO One must adhere to regulations and national standards during installation and operation.
During installation of the heating system, one must adhere to the following regulations:
• local building regulations concerning the conditions of installation
• local building regulations concerning air supply for combustion and exhaust discharge.
•regulations and standards concerning equipping the heating system with automation safety devices.

www.orte.pl
www.orte.pl
Page | 7
3.4. Operation guide
When using the heating system, adhere to the following tips:
The boiler should be working at the minimal return temperature from 42 ° C to 60 °C. Do not
exceed 80°C at the system supply.
Ensure this limit temperature by using appropriate device or its settings.
The boiler can only be operated by adults familiar with its use.
Ensure that children do not remain unattended near the working boiler.
Do not add any liquids or water to increase the power of the boiler.
Ash should be placed in a non-combustible container with a lid.
Do not place on the boiler or in its vicinity (within safe minimum distance) flammable objects or
substances (e.g. kerosene, oil).
To clean the boiler, use only gentle cleaning agents.
Do not use the boiler without the recommended operating pressure.
During the boiler operation, do not open the doors of the combustion chamber.
Comply with the operating manual.
The installer must provide the user with information about the operation and proper use of the
boiler.
Do not use the boiler in case of danger of explosion, fire, leaks of combustible gases or vapours (e.g.
when gluing linoleum, PVC etc.).
Pay attention to the flammability of construction materials.
3.5. Safety systems
Each boiler is equipped with 6 interdependent safety systems.
1. Feeder temperature sensor Installed during the commissioning in a smaller tube between the burner
and the flexible pipe connected to the feeder. The sensor informs about the backflow of fire to the tray
and an increase of the feeder temperature above 45°C.
2. Elastic tube between the metal pipe of the burner and the feeder. If the temperature sensor of the
feeder is damaged or improperly installed, the fire that goes back to the feeder dissolves the elastic pipe
within 2-3 seconds, cutting of the fire from the feeder where pellet is stored. Additionally, the elastic pipe
is not placed directly over the burner, but on the side.
3. Boiler overheating sensor. If the water temperature exceeds 80°C, the burner automatically goes into
putting-out mode. This prevents the burner from working in the case of a limited heat perception.
4. Photoelement defines the quality of the combustion process. If there is not enough air in the furnace,
the fire’s brightness drops below the pre-set level. The burner automatically goes from the maximum
power mode (feeding large amount of fuel) to the firing up mode (small amount of fuel). If the situation
does not change, the fire’s brightness remains at the level not exceeding the required brightness. The
burner will display “no fuel” error and will stop fuel supply, which will prevent excessive carbon monoxide
emission.
5. STBwith manual lock deletion.
6. The controller has a password on service parameters.

www.orte.pl
www.orte.pl
Page | 8
3.6. Construction of the boiler
Pellet Comfort boiler consists of the following assemblies: heat exchanger, automation/controller, burner
along with a feeder, electrics, wiring and a tray. The controller is installed in the upper part of the boiler
cover. Near the controller, there are fuses 5A (a) and 2.5A (b) a central switch is on the top plate of the
boiler (c). STP is near the controller, on the left side of the boiler (d). The feeder is made of high-quality
powder-coated sheet metal. The combustion chamber is lined with ceramic tiles.
3.6.1. Boiler diagram

www.orte.pl
www.orte.pl
Page | 9

www.orte.pl
www.orte.pl
Page | 10
1 –steel body; 19 –side ceramic tile II;
2 –upper door; 20 –upper ceramic tile I;
3 –lower door; 21 –upper ceramic tile II;
4 –flue; 22 –back ceramic tile I;
5 –external jacket; 23 –back ceramic tile II;
6 –water drain pipe; 24 –front ceramic tile;
7 –chimney chamber cleaning hole; 25 –drawer;
8 –upper cleaning hole; 26 –ceramic cover of the burner;
9 –lower cleaning hole; 27 –external feeder;
10 –hardware; 28 –feeder drive assembly;
11 –clamp; 29 –bearing assembly;
12 –burner; 30 –feeder flexible pipe;
13 –charging hopper; 31 –band clip;
14 –adjustment foot; 32 –boiler attachment;
15 –bin cleaning hole; 33 –burner back cover;
16 –controller; 34 –burner upper cover;
17 –controller run-time module; 35 –feeder snail;
18 –side ceramic tile I;
3.6.2.
Diagram presenting the disassembly of the bin and the feeding system on the opposite side of the boiler.

www.orte.pl
www.orte.pl
Page | 11
3.6.3. Diagram of the burner
1 - fireplace inlet 4 - burner front panel
2 -burner pipe 5 - fan cover
3 -burner grill 6 - burner upper and back cover
3.7. Operation and storage conditions
Before installation, read the requirements of this manual and the requirements of national and local laws.
The installation design should be performed by a contractor with appropriate permissions which, in
consultation with a chimney sweeper specialist and fire-fighting specialist, will issue a written opinion on
the condition of installation and operation of the device, in particular on the insulation, floor bearing
capacity, ventilation and gas exhaust installation.
During installation, take into consideration the requirements of applicable regulations. In case of doubt,
consult a fire protection expert.
The room where the heating device is placed must have insulation, floor bearing capacity and ventilation in
accordance with appropriate provisions, and must be connected to an individual exhaust pipe/chimney.
Storage conditions:
•temperature between -10°C and 50°C
•humidity between 5% and 70%
•atmospheric pressure between 800hPa and 1200hPa
•good ventilation –meeting the required standards (supply air at least as
extract air)
•low dust level and lack of chemical pollution
•room free of flammable materials
If the boiler is stored longer than 2 years from the date of manufacture, it should be started in the
premises of the manufacturer in order to verify proper operation.

www.orte.pl
www.orte.pl
Page | 12
3.8. Minimal distances and flammability of construction materials
INFO: Depending on the country, different minimum distances may apply –please consult an installer or
a chimney-sweeper.
No flammable materials allowed in the room.
3.9. Minimal reflux temperature
The boiler must operate with a minimum reflux temperature of 42 ÷ 60 ° C.
Ensure the limit temperature by using appropriate device (mixing valve with pump).
3.10. Tools, materials and auxiliary measures
Installation and maintenance of the boiler require standard tools used by installers of heating and water
systems.
Cleaning tools are delivered along with the boiler.
4. SAFETY
The device must be installed and accepted only by an authorized installer with confirmed qualifications.
The boiler must be installed, placed and used in accordance with applicable regulations. Strictly adhere to
the instructions contained in Technical and Maintenance Documentation. Do not install the boiler in places
at risk of fire, explosion, flooding or freezing. The boiler must be connected to an electrical outlet –
grounded and with a differential protection. The boiler is adapted to an open system, which means that
the hydraulic system must have an open expansion vessel with an overflow pipe.
Unattended minors and pets cannot be near the operating boiler.
Do not exceed maximum power. Ensure proper air circulation –in accordance with appropriate
regulations. Ensure chimney-sweep inspection in accordance with applicable regulations, not less
frequently than once every 3 months or in accordance with local regulations.
Ventilation of the room where the boiler is placed must be made in accordance with applicable
regulations.
In order to operate properly, the boiler needs fresh air and the required chimney draft.
Air should be supplied to the burner in order to carry out proper combustion processes in the boiler
chamber.
Do not connect several heating devices to the same chimney. However, if there are other heating devices
installed in the room (connected to other chimneys), supply sufficient amount of air to ensure combustion
in each device and ensure sufficient air for room ventilation, taking into account all the devices.
It is forbidden to open the device during operation due to the risk of burns.
No flammable materials allowed in the room.
Fuel storage –in accordance with relevant regulations and standards (in a different room than the boiler).
An ABC type powder extinguisher must be placed near the device.
In the event of a chimney fire, immediately put out the burner by pressing the central switch –position 0,
placed above the controller. Do not open the ash pan, cut off all access of air needed for combustion. Do

www.orte.pl
www.orte.pl
Page | 13
not open windows. Then, secure the chimney outlet using the chimney sieve. It is intended to reduce the
intensity of soot combustion in the chimney by suppressing the fire, and to prevent the escape of burning
soot from the chimney, consequently protecting the roofs and nearby buildings against fire. The chimney
sieve can be replaced with a wet cloth to cover the chimney outlet in case of fire. Damp the cloth with
water until the soot is burnt-out. Do not extinguish chimney fire with water, because rapid cooling of the
chimney and water evaporation can cause cracks in the chimney and the spreading of fire.
If the device is operating in adverse weather conditions, e.g. during an unfavourable chimney draft (too
low draft) or bad weather conditions (e.g. cold, strong wind), extinguish the device to avoid the return of
fumes. Before re-igniting the device, wait until weather conditions improve.
In the case of a longer break in operation, perform chimney sweep inspection, because there is a risk of
clogging.
Basic requirements and standards of fire protection in the Republic of Poland applicable in the case of
Pellet Comfort devices:
1) regulations of the Minister of Internal Affairs and Administration:
on the reconciliation of a construction project in terms of fire safety, of 16 June 2003, Journal of
Laws no 121, item 1137 (amendments –regulation of the Ministry of Internal Affairs and
Administration of 16 July 2009, Journal of Laws no. 119, item 998)
on fire-fighting water supply and access roads, of 24 July 2009, Journal of Laws no. 124, item 1030,
on the fire protection of buildings, other construction works and areas, of 07 June 2010, Journal of
Laws no. 109, item 719,
2) regulation of the Minister of Infrastructure:
on the technical requirements to be met by buildings and their location, of 12 April 2002, Journal of
Laws no. 75, item 690 with further amendments),
3) PN-B-02411 Heating. Built-in solid fuel boilers –Requirements.
The owner must strictly comply with the Technical and Maintenance Documentation.
4.1. Safety Tips
General Safety Tips
Failure to follow these instructions can result in serious injuries, including death, and can cause damage to
property and the environment.
Ensure that the system, connection of the flue duct connector, as well as the first start-up,
maintenance and repairs are performed only by an authorized installation company.
Ensure that the installation acceptance is performed by an authorized supervisory body.
Clean the boiler depending on the intensity of use. Follow the frequency of cleaning indicated in the
chapter “Cleaning”. Immediately remove any identified deficiencies.
Perform maintenance at least once a year. During maintenance, check the proper operation of the
entire system. Immediately remove any identified deficiencies.

www.orte.pl
www.orte.pl
Page | 14
Before starting up the system, carefully read safety tips.
Threat due to non-compliance with safety rules in emergency situations, e.g. in case of fire
Never put yourself in life-threatening situations. Your own safety
always comes first.
Damage due to improper operation
Operation errors can lead to injuries and/or damage to property.
Ensure that the boiler can only be accessed by persons who are able to properly operate it.
Only authorized installers can install, commission and maintain the boiler.
Installation and operation
Only an authorized installation company can install the boiler.
Do not modify any parts of the exhaust system.
Do not use the boiler without enough water.
Do not connect the boiler directly to a hydrophore.
During operation, openings (doors, inspection hatch, filling holes) must always be closed.
Use fuels according to the nameplate.
Do not close or decrease supply-exhaust openings in doors, walls and windows.
Inspection/maintenance
Recommendation: conclude an agreement for inspection and maintenance with an installation
company; order boiler maintenance every year.
The user is responsible for the safety, environmental performance and reliable operation of the
system.
Adhere to the safety instructions contained in the chapter “Maintenance and cleaning”.
The manufacturer is not responsible for damages due to the use of parts not delivered by the
manufacturer.
Use only original spare parts and hardware.
Risk of carbon monoxide poisoning
Insufficient air supply can cause the production of carbon monoxide during the combustion process.
Do not close or decrease supply-exhaust openings.
Appropriate carbon monoxide and smoke sensors should be installed in the boiler room.
If this deficiency is not removed immediately, further use of the boiler is not allowed.
If fumes are present in the boiler room, ventilate and leave the room; call the fire department, if
necessary.
Burn hazard
Hot air on the boiler, exhaust system and pipes, exhaust gas, as well as hot water flowing from the
protection automation devices can cause burns.
Touch hot surfaces only when using appropriate safety equipment.
Opening the boiler doors is forbidden.
Before performing any work on the boiler, wait until it cools down.
Children must not remain near the hot boiler unattended.
Risk of damage to the system due to deviations from the minimal chimney draft.
In case of major chimney drafts, the fumes temperature increases and the boiler system is under
heavier load and may be damaged. The efficiency of the boiler decreases.
Ensure that the chimney and exhaust connections correspond to applicable regulations.
Ensure proper chimney drafts.
Ask an authorized company to check that the required chimney draft is ensured.
Adhere to local regulations regarding maintenance of the chimney.
Explosives and flammable materials

www.orte.pl
www.orte.pl
Page | 15
No flammable materials allowed in the room.
Combustion air/air in the room
Combustion air/air in the room must be isolated from aggressive substances (e.g. alkyl
halides/fluorocarbons, substances containing chlorine or fluorine compounds). This is to avoid
corrosion.
Ensure the supply of a sufficient amount of air through the openings leading to the outside.
Risk of damage to the system due to overpressure
In order to avoid damage to the system due to overpressure, hot water can flow from the heating
circuit safety valve when heating water and preparing usable warm water.
Never close safety valves.
Never cut off the heating water circuit.
Never turn off the cooling water circuit.
Instruction to the customer (user)
Explain the method of operation to the customer.
Explain that the customer may not make any modifications or repairs.
Instruct the customer that children cannot be in the vicinity of the heating system without adult
supervision.
Fill up the commissioning and handover protocol included in this document and provide it to the
user.
Deliver the technical documentation to the customer.
5. TRANSPORT AND INSTALLATION
5.1 Transport
The device is protected against damage in transit. During transport, loading and unloading, the device must
be protected against impact, damage, crushing and against adverse environmental conditions, as they may
cause damage to the device. In case of damage to the device in transit (consignments must always be
checked on delivery), return the device to the service department in order to remove the resulting defects.
On delivery, check the completeness of the shipment. Potential objections and problems should be
reported to the supplier who is responsible for insurance.
WARNING: Risk of injuries due to moving too heavy objects and due to improper protection during
transport!
Ensure that the boiler is lifted and moved by a sufficient number of people.
Use appropriate means of transport, e.g. trolleys with fastening belts or lift trolleys.
Secure the boiler against falling.
NOTE: Damage to the system due to frost!
Install the heating system in a room protected from frost.
INFO: Observe construction supervision provisions, in particular, the current provisions related to
furnaces, construction requirements with respect to installation rooms and their ventilation.
In order to reduce the weight of the boiler during transport, the tray and the exchanger are packed
separately.
The boiler is delivered on a pallet.
Position a lift trolley to the back wall of the packaged boiler.
Secure the boiler on the transport device with a fastening belt.

www.orte.pl
www.orte.pl
Page | 16
Move the boiler to the place of installation.
During transport, make sure not to damage the boiler.
If possible, transport the boiler secured on the pallet to the place of installation.
Unpack the boiler.
Dispose of the packaging in accordance with environmental protection requirements.
5.2. Installation
The Pellet Comfort boiler (if not otherwise requested by the customer) is delivered, depending on the
power and the selected tray, on one or two wooden pallets. The burner is fixed to the device. The tray is
delivered folded. The boiler must be connected to the tray as shown in the picture.
Ensure that the tray overheating sensor is inserted into a thin tube secured to the fireplace tube (stainless
steel chimney-elbow). Connect the chimney with a flexible tube, and then connect the tube with the tray
outlet.
DANGER: Putting any objects into the tray during operation of the boiler can cause serious injuries.
The tray should be covered from the top with the cover. It is forbidden to insert any objects into the tray
during feeder operation, as this may cause disability. Remember to fill up the tray with pellet before
operating the burner with the operating mode on the display set to “STOP”.
After installing the feeder inside the tray and filling up with pellet, disconnect the flexible pipe from the
burner and check the feeder usage. In order to determine the correct amount of the fuel quantity, use the
following formula: 0.2 kg / h pellet times the amount of kW of device power. E.g .: 0.2 x 24 = 4.8. The
obtained result will give us in kilograms per hour (kg / h) the information we need the amount of fuel from
obtaining the desired thermal power in kW. The burner, when working in a given cycle, should give the
amount of fuel for an hour that comes out of the formula. It is recommended that the feeder's working
cycle should not exceed 75%. So if the feeder gives, for example, 25 kg in a fixed cycle, set the FUEL FOR
MAX POWER at 19% (4.8: 25 = 0.19).
5.3. Installation conditions
In order to install the boiler, certain conditions (at the site) must be met. The user and the installation
company are responsible for meeting these conditions.
The installation site must meet the following conditions:
• Safe operation of the boiler must be ensured at the site of installation.
• The site of installation must be protected from frost.
• Installation and use of the boiler are allowed only in rooms with constant and proper ventilation.
• Ensure the supply of a sufficient amount of air.
• The floor under the boiler must have sufficient bearing capacity, and must be levelled and flat.
• The boiler can be placed only on a non-combustible surface.
The chimney must meet the following conditions:
• The chimney and exhaust gas connection must comply with applicable regulations.
• The chimney must be insensitive to moisture.
5.4. Distance from the walls

www.orte.pl
www.orte.pl
Page | 17
DANGER: Fire hazard due to flammable materials or liquids!
Do not place or store flammable materials or liquids in the boiler room.
WARNING: Damage to the system due to too small distance from the walls!
In case of non-compliance with the minimum distances, cleaning of the boiler is impossible.
Keep minimum distances.
Place the boiler on an incombustible surface, keeping the required distances from the walls. The surface or
foundation for the boiler must be level and flat. If the foundation is not level, in order to provide better
ventilation and flow, the side with the connection (back wall) can be placed 5 mm higher. The foundation
must be larger than the boiler base: at the front, at least 300 mm, and approx. 100 mm on other sides.
5.5. Distance from flammable materials
DANGER: Fire hazard due to flammable materials or liquids!
Do not place or store flammable materials or liquids in the boiler room.
Instruct the user to keep minimum distances from flammable materials in relation to flash
resistant materials.
5.6. Exhaust connection
DANGER: Fire hazard due to improper connection to the chimney and incorrect selection of the chimney!
Chimney sweep acceptance must be performed before operating the boiler.
INFO: The boiler draws in air needed for combustion from the environment.
Install and operate the boiler only in rooms with constant and proper ventilation.

NOTE: Damage to the system and the boiler due to insufficient chimney draft!
Ensure the required chimney draft.
INFO: Chimney draft depends on the diameter, height, surface unevenness inside the chimney and the
temperature difference between combustion products and external air. It is recommended to use a
chimney with liner.
Before connecting the boiler to the chimney, check whether the chimney diameter is sufficient and
the chimney is not connected to other heating devices.
The internal surface of exhaust pipes should be resistant to the destructive effects of exhaust gases.
An installer or a chimney sweeper should precisely calculate the chimney.
The chimney must be insulated and not shorter than 5 m (minimum 1 m protruding above the roof).
Chimney sweep acceptance must be performed before operating the boiler.
5.6.1 Exhaust connection to the chimney
INFO: The boiler must be connected to the chimney in accordance with local construction
laws and in cooperation with a chimney sweeper.

www.orte.pl
www.orte.pl
Page | 18
A chimney with a proper chimney draft is the main factor determining the correct operation of the boiler.
This has a significant impact on the power and efficiency of the system. The boiler can be connected to a
chimney with sufficient chimney draft –see technical data.
In order to make calculations, use the exhaust mass flow at the total rated heat output. The effective
length of the chimney is calculated from the point of entry of exhaust gases to the chimney.
Install the flue gas outlet with inspection opening for cleaning.
Mount the exhaust pipe to the chimney with a 5 mm rivet or screw, using the existing holes. The
exhaust pipe should be as short as possible and should be elevated upwards from the boiler to the
chimney.
Connect the flue to the chimney with the boiler connection (figure 3, item 32)
made of 3 mm sheet metal. Place it onto the flue outlet, embed inside
the chimney and seal.
Exhaust pipe, mounted only to the chimney and placed onto the exhaust connection pipe, should
be mounted very carefully to prevent sliding out.
Pipes longer than 2 m should be additionally fastened. All parts of the exhaust pipe must be made
of non-combustible materials.
TIP Chimneys made of steel pipes should be higher by 15-20% than brick chimneys.
INFO: Due to the low temperature of exhaust gases at the rated thermal output, the boiler can emit wet
fumes, lead to the deposition of soot, and cause insufficient chimney draft. This can lead to moisture and
corrosion of brick chimneys.
It is recommended to use a chimney liner:
–in the case of modernization of the existing chimney ducts and adapting them to year-round
operation of the boiler, it is recommended to use one-sided or double-sided (depending on the
place of installation) exhaust system made of stainless steel (acid- and heat-resistant),
–in newly-constructed buildings and in the case of year-round operation of the boiler, it is
recommended to use a ceramic exhaust system resistant to condensate, thermally insulated, with
ventilation and condensate discharge.
The boiler room should comply with the requirements of PN-87 B-02411 on solid fuel central heating
boilers.
The boiler room should be protected against the ingress of ground water and should be equipped with
adequate ventilation to ensure free inflow of combustion air, including:
–ventilation duct (a hole in the window or wall without shutters) with a cross-section not less
than 200 cm2,
–ventilation duct placed, if possible, near the chimney with an inlet hole (without shutters) under
the ceiling with a cross-section not less than 140 x 140 mm.
5.6.2. Inlet air connection
DANGER: Lethal danger caused by a deficiency of oxygen in the boiler installation room!
Ensure the supply of a sufficient amount of air through the openings leading to the outside.

www.orte.pl
www.orte.pl
Page | 19
DANGER: Risk of injuries/damage to the system due to shortage of combustion air!
Insufficient amount of combustion air can lead to the formation of tar and low-temperature gases.
Ensure the supply of a sufficient amount of air through the openings leading to the outside.
Instruct the user that air inlet holes must
always remain open.
5.7. Hydraulic connections
Hydraulic system must be done by a plumber with appropriate permissions, in accordance with
appropriate standards and hydraulic expertise. Each hydraulic system should be made on the basis of a
proper design and accepted by an authorized person.
NOTE: Damage to the installation due to leaking connection!
Mount connection tubes to the boiler ports without tension.
INFO: In order to ensure fuel-efficient operation, we recommend installing a buffer tray.
When using a buffer tray (buffer), combustion can take place at the optimum point of operation, both in
terms of energy use and emissions. Heat that cannot be used for heating at the time of production is
stored in the buffer. When the fuel inside the boiler is used, the heat stored in the buffer will be put into
heating circuit.
Both with and without buffer, the boiler works fully automatically. The buffer improves the efficiency of
the entire system.
5.7.1. Connecting the boiler to the central heating system
After placing the boiler and connecting it to the chimney, perform the following installation works:
connect the boiler to the central heating system by screwing the pipes (supply pipe and return pipe)
to appropriate connection stubs 1 ½”,
screw in the drain plug delivered with the boiler,
use appropriate seals to ensure the tightness of connections (tow,
seal tape etc.),
Before connecting the boiler to an old central heating system, rinse it to remove sludge from
radiators and pipes.
At the supply connection, connect the sensor and the thermal protection of hot water outflow
(additional equipment)
INFO: The thermal outflow protection (accessory) should be installed between the cooling water inflow A
or B and the heat exchanger inlet (cooling pipe coil).

www.orte.pl
www.orte.pl
Page | 20
A and B. Heating circuit supply connections (optional). Hot water outlet.
C. Exhaust output.
D. Drain hole.
E. Return water connection. Cold/cooling water inflow.
DANGER: Injury and/or damage to the system due to overheating!
The boiler can operate only with an active thermal outflow protection and/or safety heat
exchanger.
Always ensure that cooling water is supplied to the thermal outflow protection and safety heat
exchanger to maintain the required water pressure.
Inform the user about the operation of the thermal outflow protection and safety heat
exchanger.
DANGER: Danger to health due to contamination of usable water!
Ensure compliance with national regulations and standards on the prevention of usable water
contamination (e.g. water from heating systems).
Ensure compliance with EN 1717.
Put a filter in the cooling water inlet, in front of the thermostatic valve.
Do not place mountings allowing for the total or partial closure of the flow or devices and
mountings reducing the internal cross-section on safety pipes, expansion pipe, overflow pipe and
venting pipe.
INFO: The minimum capacity of the expansion vessel is calculated according to the formula [1] - PN-91/B-
02413 p. 2.5.1.
INFO: Equipment and placement of the expansion vessel is determined by PN-91/B-02413 p. 2.5.2.÷2.5.4.
Expansion vessel, safety pipes, expansion pipe, signal pipe and overflow pipe must be at a place where the
air temperature is not lower than 0 ° C.
INFO: If the expansion vessel is at a place where the air temperature drops below 0°C, use circulation
pipes and safety pipes connecting the expansion vessel with the boiler, as well as thermal insulation
according to PN-91/B-02413 p. 2.11. Thermal insulation of safety devices is to protect them against
freezing only during short interruptions of heating.
NOTE! –The lack of thermal insulation and placing the expansion vessel not in accordance with PN-91/B-
02413 identified during warranty claims for leaks during temperature drops below 0°C
can be grounds for not accepting the complaint and refusing to repair or replace the boiler.
