Panasonic CV-CPW201L User manual

HD Analog Camera
User’s Manual
Model No. CV-CPW201L
Version 1.0.0

2
Table of Contents
1General Introduction ..................................................................................................................1
1.1 Overview........................................................................................................................1
1.2 Features.........................................................................................................................1
1.3 Specifications................................................................................................................2
2Device Framework .....................................................................................................................3
3Installation....................................................................................................................................5
4Menu.............................................................................................................................................7
4.1 Settings ..........................................................................................................................7
4.2 Menu Operation ............................................................................................................7

i
Welcome
Thank you for purchasing our HD analog camera!
This user’s manual is designed to be a reference tool for your system.
Please read the following safeguard and warnings carefully before you use this series product!
Please keep this user’s manual well for future reference!

ii
Important Safeguards and Warnings
1．Electrical safety
All installation and operation here should conform to your local electrical safety codes.
The power shall conform to the requirement in the SELV (Safety Extra Low Voltage) and the Limited
power source is rated DC 12V in the IEC60950-1. (Power supply requirement is subject to the device
label).
Please install easy-to-use device for power off before installing wiring, which is for emergent power off
when necessary.
Please check if the power supply meets the requirements of working voltage of the camera before
operating the device (The material and length of the power supply cable will influence terminal voltage
value).
Please prevent the line cord from being trampled or pressed, especially the plug, power socket and the
junction from the device.
We assume no liability or responsibility for all the fires or electrical shock caused by improper handling
or installation.
2．Environment
Please don’t aim the device at strong light (such as lighting, sunlight and so on) to focus.
Please transport, use and store the device within the range of allowed humidity and temperature.
Please do not allow water and other liquid falling into the camera in case that the internal components
are damaged.
Please keep the sound ventilation in case of heat accumulation.
Heavy stress, violent vibration or water splash are not allowed during transportation, storage and
installation.
Please pack the device with standard factory packaging or material with same quality when transporting
the device.
It is recommended to use the device together with lightning protection device to enhance lightning
protection effect.
It is recommended to GND the device to enhance device reliability.
It is advised to use qualified video transmission cable to improve video quality.
3．Daily Maintenance
Please shut down the device and then unplug the power cable before you begin daily maintenance
work.
Use the dry soft cloth to clean the device.
If there is too much dust, please use the water to dilute the mild detergent first and then use it to clean
the device. Finally use the dry cloth to clean the device.
Please put the dustproof cap to protect the CMOS component when you do not use the camera.

iii
Warning
Please use the standard accessories provided by manufacturer and make sure the device is installed
and fixed by professional engineers.
Please prevent the device surface from the radiation of laser beam when using laser beam device.
Please do not provide two or more power supply modes for the device, otherwise it may cause damage
to the device.
Statement
Please refer to the actual product for more details; the manual is just for reference.
The manual will be regularly upgraded according to the product update; the upgraded content will be
added in the manual without prior announcement.
Please contact the customer service for the latest procedure and supplementary documentation.
The company is not liable for any loss caused by the operation which is not followed by the manual.
Please refer to the company’s final explanation if there is any doubt or dispute.

1
1General Introduction
1.1 Overview
This series HD analog camera conforms to the HDCVI standard. It supports video signal high-speed
long distance transmission without any delay. It can be controlled by the DVR conforming to the
HDCVI.
1.2 Features
High-performance CMOS image sensor.
Support 1080p@25fps (PAL)/ 30fps (NTSC)
Support 75-3 coaxial cable (Belden 9259 or equivalent) transmission up to 500m.
High speed & long distance real-time transmission.
Support ICR for day time and night time operation.
Support auto exposure, auto white balance, auto electronic shutter and auto gain
function.
Support DC12V power supply.
IP66 compliance.

2
1.3 Specifications
Parameter
CV-CPW201L
Camera
Image Sensor
1/2.9" 2.0 Mega Pixels CMOS
Effective Pixels
1936 (H) x 1097 (V)
Min Illumination
0.02Lux/ F1.4, 0Lux IR on
Electronic Shutter
PAL : 1/25s~1/100,000s
NTSC: 1/30s~1/100,000s
Video Frame Rate*
PAL : 25fps
NTSC: 30fps
Synchronization
Internal
Day & Night
Auto (ICR)/ Color/ B/W
Max IR Distance
30m
Digital Noise Reduction
2D
White Balance
Auto
AGC
Auto
BLC
Auto
Lens
Focal Length
2.7-12mm
Angular Field of View
H: 33° (Tele) ~ 96° (Wide)
V: 18° (Tele) ~ 51° (Wide)
Lens Type
M12
Input / Output
Video Output
1CH BNC HD-CVI video output
General
Power
DC 12V±25%
Power Consumption
2.5W MAX
Working Temperature
-40℃~+60℃.
Less than 90% RH (no condensation)
Dimensions
Φ90.4 mm × 213.0 mm
Weight (approx.)
550g
External Case
Metal
*Refer to DVR spec sheet for recording frame rate limitation

3
2Device Framework
Please refer to the following figures for dimension information. The unit is mm.
Figure 2-1
Figure 2-2

4
Figure 2-3

5
3Installation
Important
Before the installation, please make sure the installation surface can sustain at
least 3X weight of the bracket and the camera.
Figure 3-1
Step 1
Take out the camera cable through cable exit of the bracket chassis and install camera
bracket. If it is cement wall, you need to install expansion bolt first (the installation hole of
expansion bolt need to be in accordance with the bracket), then use self-tapping bolt to
install bracket, which is shown in Figure 3-1.
If it is wooden wall, you can skip the first step and use self-tapping bolt to install bracket
directly.
Step 2
Unscrew the M3×20 and M3×5 screws on the bracket in the direction shown in Figure 3-2,
adjust the camera to an exact location which needs to be monitored by rotating the bracket
and camera body, then secure the bolts.

6
Figure 3-2
Step 3
Connect the video output port of the device cable to the terminal encode devices, and connect
the power port of the device cable to the power.
Step 4
After the image is shown on the proper monitor area, open the lower cover of the camera and
adjust lens focal length by focus/zoom lever to make the image clear and secure the lever.
Retighten the camera lower cover and complete the installation.

7
4Menu
This is only applicable for Philippines.
4.1 Settings
After connected the camera to the HDCVI series DVR, from MAIN MENU->GENERAL-
>PAN/TILT/ZOOM, you need to select the channel number for access and set control mode as
HDCVI and the protocol as HD-CVI. Click “Save”button to save current setup. See Figure 4-1.
Figure 4-1
4.2 Menu Operation
Click the right mouse button and select “PAN/TILT/ZOOM”, then you will see the
“PAN/TILT/ZOOM” setup menu, which is as shown in Figure 4-2 and Figure 4-3.
Figure 4-2

8
Figure 4-3
See Sheet 4-1 for the details of button functions.
Button
Function
Open menu
、
Select menu item
、
Select menu value
Sheet 4-1
If there is “ ”, click the “Confirm”button in “Menu Operation”interface to go to the 2nd menu.
Click “Return” button to go back to the previous menu interface.
Note
This manual is for reference only. Slight difference may be found in the user
interface.
All the designs and software here are subject to change without prior written
notice.
All trademarks and registered trademarks mentioned are the properties of their
respective owners.
If there is any uncertainty or controversy, please refer to the final explanation of
us.
Please visit our website or contact your local service engineer for more
information.
