HIK VISION DS-2CC192P(N)-IRT User manual

Hikvision Technical Manual
©2006 – 2010 by HIKVISION. All rights reserved.
1
DS-2CC192P(N)-IRT Analog Camera
Technical Manual

Hikvision Technical Manual
©2006 – 2010 by HIKVISION. All rights reserved.
2
Notices
The information in this documentation is subject to change without notice and does not represent any
commitment on behalf of HIKVISION. HIKVISION disclaims any liability whatsoever for incorrect data
that may appear in this documentation. The product(s) described in this documentation are furnished
subject to a license and may only be used in accordance with the terms and conditions of such license.
Copyright © 2006-2010 by HIKVISION. All rights reserved.
This documentation is issued in strict confidence and is to be used only for the purposes for
which it is supplied. It may not be reproduced in whole or in part, in any form, or by any means or
be used for any other purpose without prior written consent of HIKVISION and then only on the
condition that this notice is included in any such reproduction. No information as to the contents or
subject matter of this documentation, or any part thereof, or arising directly or indirectly therefrom,
shall be given orally or in writing or shall be communicated in any manner whatsoever to any third party
being an individual, firm, or company or any employee thereof without the prior written consent of
HIKVISION. Use of this product is subject to acceptance of the HIKVISION agreement required to use
this product. HIKVISION reserves the right to make changes to its products as circumstances may
warrant, without notice.
This documentation is provided “as-is,” without warranty of any kind.
Please send any comments regarding the documentation to:
[e-mail]
Find out more about HIKVISION at www.hikvision.com

Hikvision Technical Manual
©2006 – 2010 by HIKVISION. All rights reserved.
3
Contents
1. Key Features
2. Specifications
3. Dimension

Hikvision Technical Manual
©2006 – 2010 by HIKVISION. All rights reserved.
4
1.Key Features
1/3 inch SONY CCD
Vari-focal Lens , Adjusted by Remote Control
Compact Structure Design
Minimum Illumination: 0.1Lux @ F1.2 (0 Lux With IR)
Auto White Balance, Auto Gain Control, Electronic Shutter Control and Backlight
Compensation
Internal Synchronization
Digital Signal Processing
Weather Proof: IP66
Advanced Engineering Design, High Reliability

Hikvision Technical Manual
©2006 – 2010 by HIKVISION. All rights reserved.
5
2.Specifications
Model
parameter DS-2CC192P(N)-IRT
Image Sensor 1/3“ SONY CCD
Signal System PAL/NTSC
Effective Pixels PAL:752(H)×582(V)
NTSC:768(H)×494(V)
Min. Illumination 0.1Lux @ F1.2(0 LUX with IR)
Electronic Shutter 1/50(1/60)s~1/100,000s
Lens 4 to 9mm, Adjusted by Remote Control
Horizontal Resolution 540TVL
Synchronization Internal Synchronization
Video Output 1Vp-p Composite Output (75Ω / BNC)
S/N Ratio More than 48 dB
BLC ON
Working Temperature -10℃~60℃
Weather Proof IP66
IR Distance Approx 30 meters to 40 meters
Power Supply DC12V/AC24V, ±10%
Power Consumption 13W MAX
Dimension (mm) 190×104.2×87.8
Weight 1000g

Hikvision Technical Manual
©2006 – 2010 by HIKVISION. All rights reserved.
6
3.Dimension
