Easy Setting Guide
The order of setting
Prepare the
speakers
See below
Place the
speakers
See below
Connect the
cables
See over
Turn on the
main unit
See over
Prepare the speakers Place the speakers
STEP 1
Label each speaker cable by attaching the
numbered sticker at the position indicated in
the illustration. Be sure to match the number
on each sticker with the circled number in the
illustration.
e.g., Front speaker Lch
WHITE
speaker
Connect the speaker cables.
Insert the wire fully, taking care not to insert
beyond the wire insulation.
: White
: Blue line
PUSH!
STEP 2
White
Blue line
Refer to the rear label of the speaker before connecting the corresponding
cable.
Verify the type of speaker with the label on the rear of the speaker.
Speakers 
Front speakers FRONT/AVANT
Centre speaker CENTER/CENTRE
Surround speakers SURROUND/AMBIOPHONIE
Front speakers Surround speakersCentre speakerSubwoofer
PURPLE GREEN
Lch
WHITE
Rch
RED
Lch
BLUE
Rch
GREY
Easy setup
See Easy setup screen
GREEN
C
GREY
RS
RED
R
WHITE
PURPLE
SW
L
LS
BLUE
Blu-ray Disc Home Theater Sound System
Recommended
Front speakers
(L, R)
Surround speakers
(LS, RS)
60
120
Model No. SC-BTT350
e.g.,
VQC7712eng.indd2-3VQC7712eng.indd2-3 2010/07/0513:10:552010/07/0513:10:55

3
4
3
12 4
AC IN
AUDIO OUT
L
R
AV IN
OPTICAL
OUT
VIDEO IN
521
FRONT SURROUND CENTER
R L
SUBWOOFER
643
R L
6 Ω 6 Ω 3 Ω 3 Ω


AUX
OPTICAL
(STB/TV)
DIGITAL AUDIO IN
FM ANT
L
R
(75Ω)
AV
OUT
(ARC)
VIDEO
OUT
 
iPod EXT-IN
RADIO
R6/LR6, AA


LAN
(
10BASE-T/
100BASE-TX)
OK
RETURN
Easy setup
Would you like to start easy setup?
No
Yes
Connect the cables by colour or by the numbers indicated in the illustration
to the appropriate terminals on the rear panel of the unit.
Main unit
Main unit’s speaker
terminals (rear panel)
PURPLE GREEN RED WHITE GREY BLUE
Connect the cables For detailed information, refer to the operating instructions.
Audio connection
For best quality audio, use the HDMI
cable (with an ARC compatible TV)
or an optical digital audio cable.
If your TV does not support the
above, use the audio cable.
*1Make sure that the video cable connection is
made to view photos/videos from the iPod/iPhone.
FM indoor antenna
(supplied)
Adhesive tape
TV
Video cable*1(supplied)
HDMI cable (not supplied)
(Recommended for highest quality picture)
Optical digital audio cable (not supplied)
Turn on the main unit
Connect the AC mains lead
Connect the AC mains lead to the
main unit before connecting to the
household mains socket.
To a household mains socket
(AC 220 V to 240 V, 50 Hz)
Turn on the TV
Turn on your TV and select the appropriate video input mode
(e.g., VIDEO 1, AV 1, HDMI, etc.) to suit the connections to this
unit.
Broadband Network Connections
(Optional)
By connecting this unit to the network, you can use the
BD-Live and VIERA CAST features.
Main unit
Shielded LAN cable
(not supplied)
Modem (Broadband)
•Provided by ISP
Press [, ] to select [Yes].
*2If you want to restart the Easy setup:
Refer to “STEP 6: Easy setup” in the operating instructions.
Broadband router, etc.
Other connection
Audio cable (not supplied)
Press [ ] to turn
on the main unit.
Installing batteries in the
remote control
The Easy setup starts
The on screen display will guide you through the steps.*2
Turn on the main unit
AC mains lead (supplied)
For the United Kingdom
and Republic of Ireland
For Australia and
New Zealand
