Panasonic TC-L42U12L User manual

TM
Quick Start Guide
(See page 6-14)
Operating Instructions
42” Class 1080p LCD HDTV
(42.0 inches measured diagonally)
Model No. TC-L42U12L
Customer’s Record
The model number and serial number of this product can be found on its back cover. You should note this serial number in
the space provided below and retain this book, plus your purchase receipt, as a permanent record of your purchase to aid
in identification in the event of theft or loss, and for Warranty Service purposes.
Model Number Serial Number
Web Site: http://panasonic.net/
©Panasonic Corporation 2009 Printed in U.S.A.
This product has a fluorescent lamp that contains mercury.
Disposal may be regulated in your community due to environmental
considerations. For disposal or recycling information, please contact your
local authorities, or the Electronic Industries Alliance:
http://www.eiae.org.
TQB2AA0818
English
Please read these instructions before operating your set and retain them for future reference.
The images shown in this manual are for illustrative purposes only.

2
3
Viewing Advanced FAQs, etc.
Quick Start
Guide
HDMI, the HDMI logo and High-
Definition Multimedia Interface are
trademarks or registered trademarks of
HDMI Licensing LLC.
VIERA Link™ is a trademark of
Panasonic Corporation. SDHC Logo is a trademark.
This product qualifies for ENERGY STAR
in the “Home” setting and this is the setting
in which energy savings will be achieved.
Any modifications to the “Home” setting or
other factory default settings could result in
greater energy consumption beyond levels
that meet ENERGY STAR qualifications.
HDAVI Control™ is a trademark of
Panasonic Corporation.
Manufactured under license from Dolby
Laboratories.
DOLBY and the double-D symbol are
trademarks of Dolby Laboratories.
Watching TV··············································· 15
Using VIERA TOOLS ································· 17
Viewing from SD Card ······························· 18
Watching Videos and DVDs······················· 20
Displaying PC Screen on TV ····················· 22
How to Use Menu Functions
(picture, sound quality, etc.) ······················· 24
VIERA LinkTM “HDAVI ControlTM” ················ 28
Lock ··························································· 34
Editing and Setting Channels····················· 36
Closed Caption ·········································· 38
Input Labels ··············································· 39
Using Timer················································ 40
Recommended AV Connections ················ 41
Ratings List for Lock ·································· 42
Technical Information ································· 43
Care and Cleaning····································· 47
FAQ···························································· 48
Specifications············································· 50
Enjoy your TV!
Basic Features
Advanced Features
FAQs, etc.
Safety Precautions······································· 4
Please read before using the unit
Turn your own living room into a movie theater!
Experience an amazing level of multimedia excitement
Accessories/Optional Accessory ····· 6
Basic Connection····························· 8
Identifying Controls ························ 12
First Time Setup····························· 13
Quick Start Guide
Enjoy rich multimedia
SD memory card
Camcorder
Amplifier
Home theater
system
VCR
DVD recorder/
Blu-ray Disc
recorder
DVD player/
Blu-ray Disc player
Set Top Box
Contents
Personal
computer

4
5
ANTENNA
LEAD-IN WIRE
ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)
GROUNDING
CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)
ELECTRIC
SERVICE
EQUIPMENT
GROUND
CLAMP
EXAMPLE OF ANTENNA
GROUNDING AS PER
(NEC) NATIONAL
ELECTRICAL
CODE
Safety Precautions
Note to CATV System Installer
This reminder is provided to direct the CATV system installer’s attention to Article 820-40 of the NEC that provides guidelines for
proper grounding and, in particular, specifies that the cable ground shall be connected to the grounding system of the building, as
close to the point of cable entry as practical.
Secure Ventilation
Slots and openings in the cabinet and the back or bottom are provided for ventilation, and to ensure reliable operation of the LCD
TV and to protect it from overheating. These openings must not be blocked or covered. There should be at least 10 cm of space
from these openings. The openings should never be blocked by placing the LCD TV on a bed, sofa, rug or other similar surface.
This LCD TV should not be placed in a built-in installation such as a bookcase unless proper ventilation is provided.
Important Safety Instructions
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
8) Do not install near any heat sources such as radiators, heat registers, stoves or other apparatus (including amplifiers) that
produce heat.
9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than
the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are provided for
your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.
10) Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles,
and the point where they exit from the apparatus.
11) Only use attachments / accessories specified by the manufacturer.
12) Use only with the cart, stand, tripod, bracket or table specified by the manufacturer, or sold with the
apparatus. When a cart is used, use caution when moving the cart / apparatus combination to avoid injury
from tip-over.
13) Unplug this apparatus during lightning storms or when unused for long periods of time.
14) Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any way,
such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does not operate normally, or has been dropped.
15) Operate only from the type of power source indicated on the marking label. If you are not sure of the type of power supplied to
your home consult your television dealer or local power company.
16) Follow all warnings and instructions marked on the LCD TV.
17) Never push objects of any kind into this LCD TV through cabinet
slots as they may touch dangerous voltage points or short out parts
that could result in a fire or electric shock. Never spill liquid of any
kind on the LCD TV.
18) If an outside antenna is connected to the television equipment,
be sure the antenna system is grounded so as to provide some
protection against voltage surges and built up static charges.
In the U.S. Section 810-21 of the National Electrical Code
provides information with respect to proper grounding of the mast
and supporting structure, grounding of the lead-in wire to an
antenna discharge unit, size of grounding conductors, location of
antenna discharge unit, connection to grounding electrodes, and
requirements for the grounding electrode.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING: To reduce the risk of electric shock, do not remove cover or back.
No user-serviceable parts inside. Refer servicing to qualified service personnel.
The lightning flash with
arrowhead within a triangle is
intended to tell the user that
parts inside the product are a
risk of electric shock to persons.
The exclamation point within
a triangle is intended to
tell the user that important
operating and servicing
instructions are in the
papers with the appliance.
19) An outside antenna system should not be located in the vicinity of overhead power lines, other electric light, power circuits, or
where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be taken to
keep from touching such power lines or circuits as contact with them might be fatal.
20) Unplug this LCD TV from the wall outlet and refer servicing to qualified service personnel under the following conditions:
a. When the power cord or plug is damaged or frayed.
b. If liquid has been spilled into the LCD TV.
c. If the LCD TV has been exposed to rain or water.
d. If the LCD TV does not operate normally by following the operating instructions.
Adjust only those controls that are covered by the operating instructions as improper adjustment of other
controls may result in damage and will often require extensive work by a qualified technician to restore the LCD
TV to normal operation.
e. If the LCD TV has been dropped or the cabinet has been damaged.
f. When the LCD TV exhibits a distinct change in performance - this indicates a need for service.
21)
When replacement parts are required, be sure the service technician uses replacement parts specified by the manufacturer that
have the same characteristics as the original parts. Unauthorized substitutions may result in fire, electric shock, or other hazards.
22) WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPARATUS TO RAIN,
MOISTURE, DRIPPING OR SPLASHING.
DO NOT PLACE LIQUID CONTAINERS (FLOWER VASES, CUPS, COSMETICS, ETC.) ABOVE THE SET
(INCLUDING ON SHELVES ABOVE, ETC.).
23) WARNING: SMALL PARTS CAN PRESENT CHOKING HAZARD IF ACCIDENTALLY SWALLOWED. KEEP SMALL
PARTS AWAY FROM YOUNG CHILDREN.
DISCARD UNNEEDED SMALL PARTS AND OTHER OBJECTS, INCLUDING PACKAGING MATERIALS
AND PLASTIC BAGS/SHEETS TO PREVENT THEM FROM BEING PLAYED WITH BY YOUNG CHILDREN,
CREATING THE POTENTIAL RISK OF SUFFOCATION.
24) CAUTION: TO PREVENT ELECTRIC SHOCK, DO NOT USE THIS PLUG WITH A RECEPTACLE OR OTHER OUTLET
UNLESS THE BLADES CAN BE FULLY INSERTED TO PREVENT BLADE EXPOSURE.
25) CAUTION: USE WITH OTHER STAND MAY RESULT IN INSTABILITY POSSIBLY CAUSING INJURY.
26) CAUTION: DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY REPLACED. REPLACE ONLY WITH THE SAME
OR EQUIVALENT TYPE.
27) CAUTION: This LCD TV is for use only with the following optional accessory. Use with any other type of optional
accessories may cause instability which could result in the possibility of injury.
(All of the following accessories are manufactured by Panasonic Corporation)
• Wall-hanging bracket: TY-WK3L2RW
Always be sure to ask a qualified technician to carry out set-up.

6
7
Quick Start
Guide
Accessories/Optional Accessory
AA
Accessories/Optional Accessory
Check you have all the items shown.
Optional Accessory
Wall-hanging bracket
TY-WK3L2RW
Please contact your nearest Panasonic dealer to
purchase the recommended wall-hanging bracket.
For additional details, please refer to the wall-hanging
bracket installation manual.
Attaching the pedestal to TV
Fix securely with assembly screws
A
. (Total 4 screws)
Tighten screws firmly.
Accessories
WARNING
Always be sure to ask a qualified technician to carry out set-up.
Incorrect fitting may cause equipment to fall, resulting in injury and product damage.
Do not disassemble or modify the pedestal.
Otherwise the TV may fall over and become damaged, and personal injury may result.
Caution
Do not use any other TV and displays.
Otherwise the TV may fall over and become damaged, and personal injury may result.
Do not use the pedestal if it becomes warped or physically damaged.
If you use the pedestal when it is physically damaged, personal injury may result. Contact your nearest Panasonic
Dealer immediately.
During set-up, make sure that all screws are securely tightened.
If sufficient care is not taken to ensure screws are properly tightened during assembly, the pedestal will not be
strong enough to support the TV, and it might fall over and become damaged, and personal injury may result.
Foam mat or
thick soft cloth
Antenna terminal Pin terminals HDMI terminal
greenbluered
green
Firmly tighten by hand. Match colors of plugs and terminals.
Insert firmly.
Insert firmly.
Reference of connection
Accessories
Remote Control
Transmitter
N2QAYB000321
Batteries for the
Remote Control
Transmitter (2)
AA Battery
Operating Instructions
Quick setup guide
(For viewing programming)
Cleaning cloth
Pedestal
TBL2AX0028
Installing the remote’s batteries
Open
Hook
Note the correct polarity
(+ or -).
Close
Caution
Incorrect installation may cause
battery leakage and corrosion,
resulting in damage to the remote
control.
•
Do not mix old and new batteries.
•
Do not mix different battery types (such
as alkaline and manganese batteries).
•
Do not use rechargeable (Ni-Cd)
batteries.
Do not burn or break batteries.
Accessories
Assembly screws (4)
M4 × 10
AC Plug Converter

8
9
Quick Start
Guide
Basic Connection (TV + DVD Recorder or VCR)
(Antenna + TV)
To connect the antenna terminal and Cable Box
To connect the antenna terminal and DVD recorder or VCR
ANT OUTANT IN
ANTENNA
Cable In
DIO
HDMI 1 HDMI 2
DIO
HDMI 1
HDMI 2
ANT OUTANT IN
ANTENNA
Cable In
Y
P R
PB
R
L
AUDIO
R
L
AUDIO
VIDEO
HDMI 1 HDMI 2
COMPONENT IN VIDEO IN 1
AUDIO IN
PC
DIGITAL
AUDIO OUT
AUDIO IN
PC
DIGITAL
AUDIO OUT
A
B
C
Basic Connection
Note
Not all cables and external equipment shown in this book are supplied with the TV.
For more details on the external equipment’s connections, please refer to the operating manuals for the equipment.
ATSC is not available except in U.S.A., Canada, and/or Mexico.
Example 1 Connecting Antenna (To watch TV)
Cable TV
VHF/UHF Antenna
TV VHF/UHF Antenna
•
NTSC (National Television System Committee):
Conventional broadcasting
•
ATSC (Advanced Television Systems Committee):
Digital TV Standards include digital high-definition television
(HDTV), standard-definition television (SDTV), data broadcasting,
multi-channel surround-sound audio and interactive television.
(If no Cable Box)
Cable Box/Cable
•
You need to subscribe to a cable TV service to enjoy viewing their
programming.
•
If using a Cable Box set the TV channel to CH3 or CH4 for regular cable.
•
You can enjoy high-definition programming by subscribing to a high-
definition cable service.
The connection for high-definition can be done with the use of HDMI or
Component Video cable. (p. 11)
•
To view high-definition programming select the correct video input. (p. 20)
Power Cord
(Connect after all the
other connections.)
Back of the TV
Cable TV
AC 110-127 V
60 Hz
VHF/UHF Antenna
Cable Box
or
or
Example 2 Connecting DVD recorder (VCR) (To record/playback)
DVD Recorder
If the source has a higher resolution signal
(480p/720p/1080i/1080p), connection can be made
with the use of a Component Video or HDMI cable.
VCR
Connection can be made with the use of an RF
cable and Composite Video/S Video cable. (p. 11)
VHF/UHF Antenna
TV
AV Equipment
(e.g. DVD Recorder
or VCR)
Back of the TV
Power Cord
AC 110-127 V
60 Hz
VHF/UHF Antenna
AV Equipment
(e.g. DVD Recorder or VCR)
(with TV tuner)
Connecting TV and AV equipment
Please refer to
A
-
C
on p. 11

10
11
Quick Start
Guide
Basic Connection (AV cable connections)
(TV + DVD Recorder or VCR + Satellite Receiver)
To connect the antenna terminal and Satellite Receiver and DVD recorder or VCR
High-Definition
Standard-Definition
Note
Some programs contain a copyright protection signal to prevent recording.
When the copyright protection program is displayed, do not connect the other TV monitor through a VCR. Video signals fed
through VCRs may be affected by copyright protection systems and the picture will be distorted on the other TV monitor.
For more details on the external equipment’s connections, please refer to the operating manuals of this equipment.
ANT IN ANT OUTANT IN
ANTENNA
Cable In
Y
P R
PB
R
L
AUDIO
R
L
AUDIO
VIDEO
HDMI 1 HDMI 2
COMPONENT IN VIDEO IN 1
AUDIO IN
PC
DIGITAL
AUDIO OUT
AUDIO IN
PC
DIGITAL
AUDIO OUT
A
B
C
Basic Connection (Continued)
Example 3 Connecting DVD recorder (VCR) and satellite receiver
DVD Recorder
or
VCR
Satellite
Receiver
TV
VHF/UHF Antenna
You can enjoy high-definition
programming by subscribing to
high-definition satellite service.
Connection can be done with the
use of HDMI or Component Video
cable. (p. 11)
Note
For details of external equipment connections, please refer to the operating manuals for the equipment.
Satellite Receiver DVD Recorder or VCR
(with TV tuner)
VHF/UHF Antenna
Back of the TV
AC 110-127 V
60 Hz
Connecting TV and AV equipment
Please refer to
A
-
C
on p. 11.
A
To use HDMI terminals
HDMI 1 HDMI 2
HDMI
AV OUT
e.g. Blu-ray Disc
player
AV Equipment
Connecting to the HDMI terminals will enable you to enjoy high-definition digital images and high-quality sound.
The HDMI connection is required for a 1080p signal.
For “VIERA LinkTM connections”, please refer to p. 29.
B
To use COMPONENT terminals
Y
P R
P B
R
L
AUDIO
COMPONENT IN
L
R
Y
PB
PR
COMPONENT
VIDEO OUT
AUDIO
OUT
white
red
green
blue
red
white
red
green
blue
red
white
red
green
blue
red
e.g. Blu-ray Disc
player
AV Equipment
Recorders may also be connected to COMPOSITE or S VIDEO terminals. (see below)
C
To use COMPOSITE terminals
R
L
AUDIO
VIDEO
VIDEO IN 1
OUT
UT
L
R
COMPOSITE
OUT
yellow
white
red
yellow
white
red
yellow
white
red
or
e.g. DVD Recorder
AV Equipment
e.g. VCR
AV cable connections
Power Cord

12
13
Quick Start
Guide
First Time Setup Identifying Controls
Identifying Controls
Remote control sensor
Within about 23 feet (7 meters) in front of the TV set.
Power indicator
(on: red,
off: no light)
Note
The TV consumes a limited amount of power as long as the power cord is inserted into the wall outlet.
Do not place any objects between the TV remote control sensor and remote control.
TV controls/indicators
Changes the input mode
Chooses menu and submenu entries.
Volume up/down
Selects channels in sequence
Front of the TV
POWER button
Menu navigations
Remote control
Switches TV On or Off (Standby)
Changes the input mode (p. 20)
VIERA Link menu (p. 32-33)
Displays Sub Menu (p. 15, 26)
Colored buttons
(used for various functions)
(for example, p. 14, 18, 32)
Volume up/down
Sound mute On/Off
Changes aspect ratio (p. 16)
Switches to previously viewed channel
or input modes.
External equipment operations
(p. 33)
Closed Caption On/Off (p. 15)
Selects Audio Mode for TV viewing (p. 15)
Exits from menu screen
Displays Main Menu (p. 24)
Displays VIERA TOOLS (p. 17)
Viewing from SD Card (p. 18-19)
Selects/OK/Change
Returns to previous menu
Channel up/down
Displays or removes the channel
banner (p. 16)
Operates the Favorite channel list
function. (p. 16)
Numeric keypad to select any channel
(p. 15) or press to enter alphanumeric
input in menus.
(p. 14, 20, 32, 34, 36, 39, 40)
Use for digital channels. (p. 15)
First Time Setup
“First time setup” is displayed only when the TV is turned on for the first time after the power cord is
inserted into a wall outlet and when “Auto power on” (p. 26-27) is set to “No”.
or
■Press to exit from
a menu screen
■
Press to return
to the previous
screen
Turn the TV On with the POWER button
or
(Remote)(TV)
* This setting will be skipped next time if you select “Home”.
Select your language
Language
English FrançaisEspañol
select
ok
Be sure to select “Home”
Please select your viewing environment.
Home Store
select
ok
Please confirm your selection (Home) before pressing OK button.
■
If you select “Store” by mistake in , confirmation screen will be
displayed.
You are selecting the mode for store demonstration
Yes No
select
ok
Select “No” and return to previous screen .
If you select “Yes”, Screen enters store demonstration mode.
To display the “Please select your viewing environment” screen again as shown
above and select “Home”, do one of the following:
• Press and hold down the front POWER button.
• Unplug the TV and plug it again.
Adjust the clock
First time setup
Language
Clock
ANT/Cable setup
Input labels
next
select
2009
1
7
10 AM
10
Clock
Year
Month
Day
Hour
Minute
set
select item
Year: Select the year
Month: Select the month
Day: Select the day
Hour: Adjust the hour
Minute: Adjust the minute

14
15
Quick Start
Guide
Viewing Watching TV
First Time Setup
First Time Setup (Continued) Watching TV
Connect the TV to a cable box/cable, set-top-box, satellite box or antenna cable (p. 8-11)
To watch TV and other functions
Turn power on
(TV)
or
Note
If the mode is not TV, press and
select TV. (p. 20)
Select a channel number
up
down
or
■
To directly input the digital
channel number
When tuning to a digital
channel, press the button to
enter the minor number in a
compound channel number.
example: CH15-1:
(TV)
Note
Reselect “Cable” or “Antenna” in “ANT in” of “ANT/Cable setup” to switch the
signal reception between cable TV and antenna. (p. 14, 37)
The channel number and volume level remain the same even after the TV is
turned off.
Listen
with SAP
(Secondary
Audio
Program)
■
Select Audio Mode for watching TV
Digital mode
Press SAP to select the next audio track (if available) when receiving a digital
channel.
Audio track 1 of 2
(English)
Analog mode
Press SAP to select the desired audio mode.
• Each press of SAP will change the audio mode. (Stereo/SAP/Mono)
Closed
caption
■
Switches Closed caption mode On or Off
Closed caption On Closed caption Off
Display the
SUB MENU
■
Press SUB MENU to show sub menu screen. (p. 26)
This menu consists of shortcuts to convenient functions.
SUB
MENU
All
Setup SUB MENU
Edit CH caption
Signal meter
Set favorite
Channel surf mode
■
Press to exit from
a menu screen
Note
To change setting
(Language/Clock/
Auto program/Input
labels) later, go to
Menu screen
(p. 26)
About broadcasting
systems
Analog (NTSC):
Conventional
broadcasting
Digital (ATSC):
New programming
that allows you
to view more
channels featuring
high-quality video
and sound
ATSC is not available
except in U.S.A.,
Canada, and/or
Mexico.
Auto channel setup
Select “ANT/Cable setup”
First time setup
Language
Clock
ANT/Cable setup
Input labels
next
select
Select “ANT in”
Cable
ANT/Cable setup
ANT in
Auto program
set
select
ANT in
Cable: Cable TV
Antenna : Antenna
Not used : Skip TV tuning go to
Select "Not used" when no wire is connected to the "Antenna/Cable" terminal.
Typical when Cable/Satellite box is connected to a TV input.
Prevents accidental tuning to an unavailable signal.
Select “Auto program”
Cable
ANT/Cable setup
ANT in
Auto program
next
select
Select scanning mode (ALL channels/Analog only/Digital only)
Auto program
All channels
Analog only
Digital only
ok
select
Auto program
Progress
Number of analog channels
Number of digital channels
8%
10
0
Press RETURN to quit.
RETURN
Start scanning the channels
Available channels (analog/digital) are automatically set.
All channels: Scans digital and analog channels
Analog only: Scans Analog channels only
Digital only: Scans Digital channels only
Confirm registered channels
program
CancelApply
Caption Favorite Add
...
... Yes
...
... Yes
l
select
“Apply”
ok
If OK is not pressed after selecting “Apply”, the channels will not be saved.
The channel will be saved when no operation is performed for 60 seconds and the “Manual
program” menu will also exit automatically.
If you perform scanning more than twice, previously saved channels are erased.
Set the Input labels
First time setup
Language
Clock
ANT/Cable setup
Input labels
next
select
Label: [BLANK] SKIP/VCR/DVD/
CABLE/SATELLITE/DVR/GAME/
AUX/RECEIVER/COMPUTER/
Blu-ray/CAMERA/DVD REC/
HOME THTR/MONITOR/MEDIA
CTR/MEDIA EXT/OTHER
GAME
Input labels
Component
HDMI 1
HDMI 2
HDMI 3
Video 1
Video 2
PC
select
set
or
GAME
Select
OK
RETURN
DeleteABC →abc
G Y
Video 2
PC GA A
Switches Input mode alphabet to
numeric

16
17
Viewing
Using VIERA TOOLS Watching TV
Watching TV (Continued)
■
Other Useful Functions (Operate after )
Information
Recall
■
Displays or removes the channel banner.
15-2 12:30 PM
30
THE NEWS
CC SAP
TV-G 108 0i Standard 4:3
ABC-HD
Channel
Station
identifier
SAP
indication
Signal
resolution
Rating Level
mode
Sleep timer
remaining time
Aspect ratio
Closed caption
Clock
Change
aspect
ratio
■
Press FORMAT to cycle through the aspect modes. (p. 43)
• 480i, 480p: FULL/JUST/4:3/ZOOM
• 1080p, 1080i, 720p: FULL/H-FILL/JUST/4:3/ZOOM
Call up
a favorite
channel
■
FAVORITE
Channel numbers registered in Favorite are displayed on the favorite tune
screen. Select the desired broadcast station with the cursor or use number
buttons. (see below)
■Set Favorite Feature
1Display the SUB MENU.
SUB
MENU
2Select “Set favorite”
All
Setup SUB MENU
Edit CH caption
Signal meter
Set favorite
Channel surf mode
select
ok
3Set the displayed channel
Set favorite 1/3
26-1
1
2
3
4
5
select the list
number
save the displayed
channel
select the list number
(to save the channel
without pressing OK)
or
Delete a favorite channel
Set favorite 1/3
26-1
1
2
3
4
5
select
delete
(while holding down)
Favorite Feature
■Use Favorite Feature
1Display “Favorite channels”
2Select the channel
Favorite channels 1/3
26-1
1
2
3
4
5
select
or
3Set Favorite channel
Favorite channels 1/3
26-1
1
2
3
4
5
ok
■To change the page
Press repeatedly to change between
pages(1/3, 2/3, 3/3 or exit)
Changes the page forward/backward
Using VIERA TOOLS
VIERA TOOLS are the easy way to access high use menu items. They are displayed as shortcut icons on
the TV screen.
Unlike a conventional menu, you can enjoy using, playing or setting a function quickly.
■Press to exit from
a menu screen
■
Press to return
to the previous
screen
Display VIERA TOOLS
Select the item
select
next
Displayed “VIERA Link control” menu (p. 32-33)
Start Slideshow (p. 18-19)
Set “Sleep”(Off timer) (p. 40)
Displayed “ECO/energy saving” (p. 26)

18
19
Viewing
Viewing from SD Card
SD Card
Insert the card Remove the card Compliant card type (maximum
capacity): SDHC Card (16 GB), SD
Card (2 GB), miniSD Card (1 GB)
(requiring miniSD Card adapter)
For cautions and details on SD
Cards (p. 44)
Label surface
Push until a
click is heard
Press in lightly
on SD Card,
then release.
Sort
■To sort by Folder, month or date
In
Select sort type
Slideshow Folders
R Y
Sort by month
G
Sort by date
B
OK
Select
RETURN
Name
Pana0001
Date
03/04/2009
Size
1029×1200
Photo viewer
All photos
Total 238
Pana0001 Pana0002 Pana0003 Pana0004
Pana0005 Pana0006 Pana0007 Pana0008
Pana0009 Pana0010 Pana0011 Pana0012
Folders (ascending order of numeric/alphabet)
Sort by month (descending order of the month)
Sort by date (descending order of the date )
Select the directory.
Accessing
Slideshow
R YG B
OK
Select
RETURN
03/04/2009
32 photos
02/15/2009
16 photos
01/01/2009
10 photos
12/25/2008
24 photos
11/20/2008
8 photos
10/10/2008
3 photos
09/28/2008
58 photos
09/23/2008
28 photos
Date
03/04/2009
Number of photos
32 photos
Photo viewer
All photos
Sort by date
15
Accessing
Slideshow
R YG B
OK
Select
RETURN
Name
Pana0001
Date
03/04/2009
Size
1029×1200
Photo viewer
All photos
03/04/2009
Total 32
Pana0001 Pana0002 Pana0003 Pana0004
Pana0011 Pana0012 Pana0013 Pana0014
Pana0055 Pana0056 Pana0057 Pana0058
select
view Return to
previous
screen
settings
In or ■Adjust the picture
Display “Photo settings”
example :Picture menu
Picture menu/Audio menu (p. 24)
0
+20
Vivid
Picture 1/2
Picture mode
Contrast
Back light
Reset to defaults
Select
Adjust
Select the item
Off
Photo settings
Audio
Slideshow settings
Background music
select
change
next
■Set the Background music
Off
Background music
select
change
Select the Background music from 3 types.
Each Background music plays for 90 seconds.
(Off/Music 1/Music 2/Music 3)
■Slideshow settings
Fast
Off
Off
Sepia
Slideshow settings
Speed
Repeat
Transition
Effect
Select
Adjust
Note
To stop in mid-cycle Press
Speed You can set how many seconds each image is displayed in Slideshow mode.
(Very fast/Fast/Medium/Slow/Very slow)
Repeat Turn the slideshow Repeat function on or off (On/Off).
Transition Select transition effect (Off /Wipe ↓/Wipe ↑/Wipe →/Wipe ←/Comb ↑↓
/Comb →←/Dissolve/Checker wipe/Random)
Effect Select conversion effect (Off/Sepia/Gray scale)
Viewing from an SD Card
You can view photos taken with a digital camera or digital video camera and saved on an SD card.
(Media other than SD Cards may not be reproduced properly.)
■
Press to exit from
a menu screen
■
Press to return
to the previous
screen
Insert the SD card
* This setting will be skipped next time unless you select “Set later”.
Set “SD card setting” and select “Play SD card now”
“SD card setting” will be displayed automatically each time an SD card is
inserted for the first time.
Set later
SD card setting
Play SD card automatically
Play SD card now
select
change
set
Slideshow: A Slideshow will start
automatically next time.
Thumbnail: The Photo viewer menu will be
displayed automatically next time.
Set later: “SD card setting” menu will be
displayed repeatedly.
Off: The data can be played manually.
■
Manual operation (“Play SD card automatically” is “Off”)
Display “Photo viewer” Start Slideshow
select
next
Slideshow
Select the data to be viewed
Slideshow Folders
R Y
Sort by month
G
Sort by date
B
OK
Select
RETURN
Name
Pana0001
Date
03/04/2009
Size
1029×1200
Photo viewer
All photos
Total 238
Pana0001 Pana0002 Pana0003 Pana0004
Pana0005 Pana0006 Pana0007 Pana0008
Pana0009 Pana0010 Pana0011 Pana0012
select
view
Thumbnail view
To Slideshow
Selected picture information is displayed.
Total number of images.
Note
Depending on the JPEG format, “Information” contents may not be displayed
correctly. Refer to p. 44 (Data format for SD card browsing) for details.
View
Next
Rotate
Prev.
RETURN
Play
Displays one at a time
To display/hide Navigation area
Return to Thumbnail view
Accessing
Next
Prev.
Rotate
RETURN
Accessing
Pause
Next
Prev.
RETURN
Play
Navigation area Present status
(While reading the data)
Single photo view Slideshow
Rotate 90 degrees (counter-clockwise)
To next photo
Rotate 90 degrees (clockwise)
To previous photo
Photo viewer
VIERA IMAGE VIEWER
The VIERA Image Viewer is a function that lets you easily view still and motion images on a VIERA television by
simply inserting an SD card into the VIERA SD card slot.

20
21
Viewing
Watching Videos and DVDs
VIERA LinkTM Setting
Watching Videos and DVDs
If you have applicable equipment connected to the TV, you can watch videos and DVDs on the TV’s
screen.
Input Select
You can select the external equipment to access.
■
To return to TV
With the connected equipment turned On
Display the Input select menu
Select the input mode
Input select
TV
1
2
3
4
5
6
7
8
Component
HDMI 1
HDMI 2
HDMI 3
Video 1
PC
Video 2
AUX
GAME
GAME
GAME
(example)
or
select
enter
Press corresponding NUMBER
button on the remote control to
select the input of your choice.
Select the input of your choice,
then press OK.
During the selection, if no action
is taken for several seconds, the
“Input select” menu disappears.
HDMI 1
GAME
Terminal
(example)
Label
The terminal and label of the
connected equipment are
displayed.
To label each of the inputs,
please refer to p. 39.
Note
The input label will be displayed on “Input select” screen if Input label is set on p. 39.
For side input terminals (HDMI 3/Video 2), “GAME” input label is set as default.
For more details for Input label, refer to p. 39.
Operate the connected equipment using the remote
control supplied with the equipment
Note
For details, see the manual of the connected equipment.
If you connect equipment that has the “HDAVI Control” function to a TV using an HDMI cable,
you will find it easier to use. Please refer to p. 28-33. Before using these functions, you need to
set “VIERA Link” setting to “On” as shown below.
■Press to exit from
a menu screen
■
Press to return
to the previous
screen
Display menu
Select “Setup”
Menu
Audio
VIERA Link
SD card
Closed caption
Setup
select
next
Select “VIERA Link settings”
Setup 2/2
Advanced setup
About
VIERA Link settings
ECO/energy saving
select
next
Select “VIERA Link”
On
Yes
Yes
TV
No
No
VIERA Link settings
VIERA Link
Power on link
Power off link
Default speakers
Stand-by power save
Auto power stand-by
select
Select “On”
(default is On) change
Now you can set each “VIERA Link” function according to your preference
(p. 30-33).
Note
If no HDMI equipment is connected or standard HDMI equipment (non- “VIERA
Link”) is used, set it to “Off”.
For more details on the external equipment’s connections, please refer to the
operating manuals for the equipment.

22
23
Viewing
Displaying PC Screen on TV
Displaying PC Screen on TV
The screen of the PC connected to the unit can be displayed on the TV.
You can also listen to PC sound with the audio cable connected. To connect PC (p. 41)
■
PC menu setting (change as desired)
Making settings “How to Use Menu Functions” to (p. 24)
Menu Item Adjustments/Configurations (options)
PC
adjustments
Reset to
defaults Resets PC adjust
Sync
H & V : The H and V sync signals are input from the HD/VD connector. (p. 46)
On green: Uses a synchronized signal on the Video G signal, which is input from the G
connector. (p. 46)
Dot clock Alleviates the problem if a picture appears to be vertically-striped, flickers partially or is
blurred.
H-position
Adjusts the horizontal position.
V-position
Adjusts the vertical position.
Clock phase
Alleviates the problem if the whole picture appears to flicker or is blurred.
First adjust the Dot Clock to get the best possible picture, then adjust the
Clock Phase so that a clear picture appears.
Note
It may not be possible to display a clear picture due to poor input signals.
Input
resolution
Switches to wide display.
Input signal switched from 640×480 to 800×480
Input signal switched to 1024×768, 1280×768 or 1366×768
H-frequency
V-frequency
Displays the H (Horizontal)/V (Vertical) frequencies.
Display range
Horizontal:15 - 110 kHz
Vertical: 48 - 120 Hz
Audio menu (p. 24)
Display the Input select menu
Input select
TV
1
2
3
4
5
6
7
8
Component
HDMI 2
HDMI 3
Video 1
PC
Video 2
AUX
GAME
HDMI 1 GAME
GAME
Select “PC”
PC
Displays
PC screen
Corresponding signals
(p. 46)
■
To return to TV /

24
25
Advanced
How to Use Menu Functions
(picture, sound quality, etc.)
In AV mode, the Audio menu and Setup menu give fewer options.
Bass boost sound feature does not work when using headphones.
Menu Item Adjustments/Configurations (alternatives)
Reset to defaults Resets all picture adjustments to factory default settings except for “Advanced picture”.
Reset to defaults
Picture mode Basic picture mode (Vivid/Standard/Cinema/Custom) (p. 45)
Picture mode
Vivid
Back light Adjusts luminance of the back light.
Back light +20
Contrast, Brightness,
Color, Tint, Sharpness
Adjusts color, brightness, etc. for each picture mode to suit your taste
• Display range
Contrast/Brightness/Color/Sharpness: 0 - 100
Tint: -50 - +50
Contrast +20
Brightness 0
Color 0
Tint 0
Sharpness 0
Color temp. Selects a choice of Cool(blue), Normal, or Warm(red) color. (Cool/Normal/Warm)
Color temp. Cool
Color mgmt. On: Enhances green and blue color reproduction, especially outdoor scenes. (On/Off)
Color mgmt. On
x.v.Color
Auto: Provide the appropriate picture when images corresponding to “x.v.Color” are input via the HDMI input of this TV. (Off/Auto)
x.v.Color Auto
A.I. picture Controls dark areas without affecting the black level or brightness in the overall picture (On/Off)
A.I. picture On
Video NR Reduces noise, commonly called snow. Leave it off when receiving a strong signal. (Off/On)
Video NR Off
Zoom adjustments Adjusts vertical alignment and size when aspect setting is “ZOOM” (p. 43)
Zoom adjustments
PC adjustments Sets PC display (p. 22)
PC adjustments
Advanced picture
3D Y/C filter Minimizes noise and cross-color in the picture. (On/Off)
3D Y/C filter On
Color matrix
Selects image resolution of component-connected devices (HD/SD)
• SD: Standard Definition HD: High Definition
• Only 480p signal accepted; regular TV (NTSC) is not available.
Color matrix SD
MPEG NR Reduces noise of specific digital signals of DVD, STB, etc. (On/Off)
MPEG NR Off
Black level Selects Dark or Light. Valid only for external input signals. (Dark/Light)
Black level Light
HD size
Selects between 95 % (Size 1) or 100 % (Size 2) for the scanning area with High-definition signal. (Size 1/ Size 2)
Select “Size 1” if noise is generated on the edges of the screen.
• Size 1: Selected item for “HD size”. Scanning 95%
• Size 2: Selected item for “HD size”. Scanning 100%
HD size Size1
H size Adjust horizontal display range to reduce noise of both side edges of an image. (Size 1/Size 2)
Size 2: Adjust image size according to aspect mode for reducing noise. (p. 46)
H size Size 1
Audio
Reset to defaults Resets Bass, Treble and Balance adjustments to factory default settings.
Reset to defaults
Bass Increases or decreases the bass response.
Bass 0
Treble Increases or decreases the treble response.
Treble 0
Balance Emphasizes the left / right speaker volume.
Balance 0
Advanced audio
A.I. sound Equalizes overall volume levels across all channels and external inputs. (On/Off)
A.I. sound On
Surround Enhances audio response when listening to stereo. (On/Off)
Surround Off
Bass boost Enhances bass sound and provides powerful sound. (On/Off)
This setting will not function if “Off” is set in “TV speakers”.
Bass boost Off
Volume leveler Minimizes volume disparity after switching to external inputs.
Volume leveler
0
TV speakers Switch to “Off” when using external speakers (On/Off)
• “A.I. sound”, “Surround”, “Volume leveler” and “Bass boost“ do not work if “Off” is selected.
TV speakers On
HDMI 1 in
HDMI 2 in
HDMI 3 in
The default setting is “Digital” for HDMI connection. (Digital input signal)
Select audio input terminal when DVI cable is connected. (Analog audio input signal)
(Digital/Component/Video 1/Video 2)
HDMI1 in Digital
HDMI2 in Digital
HDMI3 in Digital
Timer
Sleep, Timer 1-5 The TV can automatically turn On/Off at the designated date and time (p. 40)
Lock
Locks the channels and programs (p. 34)
VIERA
Link
Record now
Stop recording
VIERA Link control
Speaker output
[Record now/Stop recording]
Records programs on the recorder immediately with the TV’s remote control (p. 32-33).
[VIERA Link control]
Selects equipment to access and operate. (Recorder/Home theater/Player/Camcorder/LUMIX) (p. 32-33)
[Speaker output]
Selects an audio output. (Home theater/TV) (p. 32-33)
• VIERA Link menu is accessible directly by pressing the VIERA Link button on the remote control. (p. 32)
SD card
SD card Displays SD card data (p. 18-19)
SD card
Closed
caption
Closed caption Displays subtitles (Closed caption) (p. 38)
Closed caption
How to Use Menu Functions
■
Menu listVarious menus allow you to make settings for the picture, sound, and
other functions so that you can enjoy watching TV best suited for you.
■
Press to exit from
a menu screen
■
Press to return
to the previous
screen
Display menu
Displays the functions that can be set
(varies depending on the input signal)
Select the menu
Menu
VIERA Link
Audio
Timer
Lock
SD card
Closed caption
Setup
select
next
Select the item
0
+20
0
0
0
0
Vivid
Picture 1/2
Brightness
Color
Tint
Sharpness
Picture mode
Contrast
Back light
Reset to defaults
(example: Picture menu)
select
Adjust or select
0
+20
0
0
0
0
Vivid
Picture 1/2
Brightness
Color
Tint
Sharpness
Picture mode
Contrast
Back light
Reset to defaults
(example: Picture menu)
adjust
or
select

26
27
Advanced
How to Use Menu Functions
(picture, sound quality, etc.)
Menu Item Adjustments/Configurations (alternatives)
Setup
SUB MENU
Channel surf mode
Sets the mode to select the channel with Channel up/down button (All/Favorite/Digital only/Analog only)
Set favorite Sets favorite channels. (p. 16)
Edit CH caption Changes the station identifier. (p. 37)
Signal meter Checks the signal strength if interference or freezing occurs on a digital image. (p. 37)
Menu Item Adjustments/Configurations (alternatives)
Setup
Channel surf mode
Sets the mode to select the channel with Channel up/down button
(All/Favorite/Digital only/Analog only)
• Favorite: Only channels registered as FAVORITE (p. 16)
Channel surf mode
All
Language Selects the screen menu language (p. 13)
Language
Clock Adjusts the clock (p. 13)
Clock
ANT/Cable setup Sets channels (p. 37)
ANT/Cable setup
Input labels Selects the terminal and label of the external equipment (p. 39)
Input labels
VIERA Link settings
VIERA Link Controls equipment connected to HDMI terminals (p. 30) (On/Off)
• “Power off link”, “Power on link”, and “Default speakers” cannot be selected if “Off” is set.
VIERA Link On
Power on link Sets “Power on link” of HDMI connection equipment (p. 30) (Yes/No)
Power on link
Yes
Power off link Sets “Power off link” of HDMI connection equipment (p. 30) (Yes/No)
Power off link
Yes
Stand-by power
save Set “Stand-by power save” of HDMI connection equipment. (p. 30) (No/Yes)
Stand-by power save
No
Auto power
stand-by
Set “Auto power stand-by” of HDMI connection equipment. (p. 30)
(No/Yes (with reminder)/Yes (no reminder)
Auto power stand-by
No
Default speakers Selects the default speakers (p. 30) (TV/Theater)
Default speakers
TV
ECO/energy saving
Power save Reduces screen brightness to lower power consumption. Eye-friendly for viewing in a dark room.
(Standard/Saving)
Power save Standard
No signal for 10
minutes
To conserve energy, the TV automatically turns off when NO SIGNAL and NO OPERATION is performed
for more than 10 minutes. (Enable/Disable)
Note
• Not in use when setting “Auto power on”, “On/Off Timer”, “Lock”, “SD mode” or Digital channel.
• “No signal for 10 minutes was activated” will be displayed for about 10 seconds when the TV is turned
on for the first time after turning the power off by “No signal for 10 minutes”.
•
The on-screen display will flash 3, 2 and 1 to indicate the last three (3) remaining minutes prior to the shut-off.
No signal for 10 minutes
Enable
No activity for 3
hours
To conserve energy, the TV automatically turns off when no operation of remote or side panel key
continues for more than 3 hours. (Enable/Disable)
Note
• Not in use when setting “Auto power on”, “On/Off Timer or PC input display.
• “No activity for 3 hours was activated” will be displayed for about 10 seconds when the TV is turned on
for the first time after turning the power off by “No activity for 3 hours”.
•
The on-screen display will flash 3, 2 and 1 to indicate the last three (3) remaining minutes prior to the shut-off.
No activity for 3 hours
Disable
Advanced
setup
Auto power on
Turns TV On automatically when the cable box or a connected device is turned On. (No/Yes)
TV AC cord must be plugged into this device. TV comes on every time the power is restored.
•
The “Sleep” timer, “On / Off timer”, and “First time setup” will not function if “Auto power on” is set. (p. 40)
Auto power on
No
Play SD card
automatically
Set “Thumbnail” or “Slideshow” to play back SD cards automatically. (Slideshow/Thumbnail/Set later/Off)
Play SD card automatically
Set later
About Displays TV version and software license.
About
Reset to defaults Performing Reset will clear all items set with Setup, such as channel settings. (p. 36)
Reset to defaults
How to Use Menu Functions (Continued)
■
Menu list
■
Sub menu list
Various menus allow you to make settings for the picture, sound, and
other functions so that you can enjoy watching TV best suited for you.
■
Press to exit from
a menu screen
■
Press to return
to the previous
screen
Display menu
Displays the functions that can be set
(varies depending on the input signal)
Select “Setup”
Menu
Audio
Timer
Lock
VIERA Link
SD card
Closed caption
Setup
next
select
Select the item
All
Setup 1/2
Clock
ANT/Cable setup
Input labels
Language
Channel surf mode
next
select
Display Sub Menu
SUB
MENU
Select the item
All
Setup SUB MENU
Edit CH caption
Signal meter
Set favorite
Channel surf mode
select
set
or
next

28
29
Advanced
VIERA LinkTM “HDAVI ControlTM”
ANTENNA
Cable In
Y
P R
P B
R
L
AUDIO
R
L
AUDIO
VIDEO
HDMI 1 HDMI 2
COMPONENT IN VIDEO IN 1
AUDIO IN
PC
DIGITAL
AUDIO OUT
ANTENNA
Cable In
Y
P
R
P
B
R
L
AUDIO
R
L
AUDIO
VIDEO
COMPONENT IN
AUDIO IN
PC
VIERA LinkTM “HDAVI ControlTM”
Simultaneously control all Panasonic “HDAVI Control” equipped components using one button on the TV remote.
Enjoy additional HDMI Inter-Operability with Panasonic products which have the “HDAVI Control” function.
This TV supports “HDAVI Control 4” function.
Connections to the equipment (DVD recorder DIGA, HD Camcorder, Player theatre, RAM theater, Amplifier, etc.) with
HDMI cables allow you to interface with them automatically.
Equipment with the “HDAVI Control” function enables the following operations:
■
For the first time/When adding new equipment, reconnecting equipment or changing the setup
after the connection, turn the equipment on and then switch the TV on. Set the input mode to
HDMI1, HDMI2 or HDMI3 (p. 20), and make sure that the image is displayed correctly.
VIERA Link “HDAVI Control”, based on the control functions provided by HDMI which is an industry standard known
as HDMI CEC (Consumer Electronics Control), is a unique function that we have developed and added. As such, its
operation with other manufacturers’ equipment that supports HDMI CEC cannot be guaranteed.
Please refer to the individual manuals for other manufacturers’ equipment supporting the VIERA Link function.
Version Operations
HDAVI Control or later •
Automatic Input Switching (p. 31)
•
Power on link (p. 31)
•
Power off link (p. 31)
•
Default speakers (p. 31)
•
One-touch theater playback (p. 31)
•
Speaker control (p. 33)
HDAVI Control 2 or later •
VIERA Link control only with the TV’s remote control(P. 33)
•
Auto power stand-by (for available equipment only) (p. 31)
•
Direct TV recording (p. 33)
HDAVI Control 3 or later •
Providing the setting information (p. 31)
•
Automatic lip-sync function (p. 31)
HDAVI Control 4 •
Stand-by power save (with quick start mode) (p. 31)
■
HDMI cable
This function needs an HDMI compliant (fully wired) cable. Non-HDMI-compliant cables cannot be utilized.
It is recommended that you use Panasonic’s HDMI cable. Recommended part number:
RP-CDHF15 (4.9 ft/1.5 m), RP-CDHG15 (4.9 ft/1.5 m), RP-CDHF30 (9.8 ft/3.0 m),
RP-CDHG30 (9.8 ft/3.0 m), RP-CDHG50 (16.4 ft/5.0 m)
* For more details on the external equipment’s connections, please refer to the operating manuals for the equipment.
VIERA LinkTM Connections
Follow the connection diagrams below for HDAVI control
of a single piece of AV equipment such as a DVD recorder
(DIGA), RAM theater, or Player theater system.
Refer to page 30-33 for Setup Menu settings and additional
control information.
•Optional HDMI and/or optical cables are not included.
If connection (or setting) of equipment compatible with
HDAVI control is changed, switch the power of this unit Off
and On again while the power of all equipment is On (so that
the unit can correctly recognize the connected equipment)
and check that the DVD recorder (DIGA), RAM theater, and
Player theater playback operate.
Note
HDMI 1 is recommended.
When connecting to HDMI 2/HDMI 3, set the input mode to HDMI 2/HDMI 3 (p. 20) initially before connecting to
HDMI 2/HDMI 3. After connection, confirm the HDMI control functions (p. 30-33).
■
Connecting this unit to the DVD recorder (DIGA), RAM
theater, or Player theater
For DVD recorder (DIGA): Connect with HDMI cable
For RAM theater and Player theater:
Connect with the HDMI and audio cables.
If audio cable is not connected, you cannot listen to the TV program
through the theater system.
■
Connecting this unit to a DVD
recorder (DIGA) and AV amp
When using a “VIERA Link” audio-
video amplifier and a compatible DVD
recorder (DIGA) use a daisy chain
connection as shown below.
One AV amp and one DVD recorder (DIGA) can be operated with this unit.
Be sure to connect the AV amp between this unit and the DVD recorder (DIGA).
■
Setting of this unit after connection
After making connections as shown above, set “VIERA Link” (under “VIERA Link settings”) to “On” using the Setup
menu. (p. 21, 30-33).
Note
Individual HDMI equipment may require additional menu settings specific to each model. Please refer to their
respective operating instruction manuals.
When audio from other equipment connected to this unit via HDMI is output using “DIGITAL AUDIO OUT” of this
unit, the system switches to 2CH audio.
(When connecting to an AV amp via HDMI, you can enjoy higher sound quality.)
For details about HDMI cable for connecting Panasonic HD camcorder, read the manual for the equipment.
HDMI cable
HDMI
(AV OUT)
HDMI
(AV OUT)
Home Theater
Systems with VIERA
Link function
or
HDMI
(AV OUT)
AV amp with
VIERA Link function
DVD recorder (DIGA)
with VIERA Link
function
HD Camcorder
with VIERA Link
function
HDMI
(AV IN)
Digital Audio out
HDMI
(AV OUT)
DVD recorder (DIGA)
with VIERA Link
function
Back of the TV
or
or or

30
31
Advanced
VIERA LinkTM “HDAVI ControlTM”
VIERA LinkTM “HDAVI ControlTM” (Continued)
Automatic
Input
Switching
At the start of the DIGA, Player theater, or RAM theater playback, the TV’s input automatically switches to the input
based on the playback equipment.
For the RAM theater, the speakers automatically switch to the theater system.
If using the DIGA operation, the TV’s input automatically switches to the DIGA and DIGA menu is displayed.
Power on
link When “Yes” is selected (p. 27), TV is turned on automatically and switches to the appropriate HDMI input whenever
VIERA Link compatible equipment is initially turned on and Play mode is selected.
Power off
link
When “Yes” is selected (p. 27) and the TV is turned off, all connected VIERA Link compatible equipment is also
automatically turned off.
DIGA (Panasonic DVD Recorder) will not turn off if it is still in rec mode.
Caution: The TV remains on even if the VIERA Link compatible equipment is turned off.
Stand-by
power save
(for “HDAVI
Control 4” (with
quick start mode))
Condition
Power off link: Yes, Stand-by power save: Yes
The equipment has “HDAVI Control 4 (with quick start mode)” connected with HDMI cable.
When TV is turned off, all connected VIERA Link compatible equipment is moved to ECO standby mode*
automatically under above conditions.
* Minimum power consumption of standby condition for the equipment.
Auto power
stand-by
(for “HDAVI
Control 2 or
later”)
Condition
Auto power stand-by: Yes,
The equipment has “HDAVI Control 2 or later” (for available equipment only) connected with HDMI cable.
[ Examples of timing for operation ]
• When the input is switched from HDMI.
• When the “Speaker output” is changed from “Home theater” to “TV”.
The connected VIERA Link compatible equipment will be turned off automatically when not in use.
Default
speakers “TV” is the default setting. To set the Home Theater system as default speakers, change the default speakers
setting from “TV” to “Theater”. Sound will be output from the Home Theater whenever the TV is powered on.
One-touch
theater
playback
If the “ONE TOUCH PLAY” key is pressed on the remote control for Panasonic Home Theater system, the following
sequence of operations is performed automatically.
Home Theater power switches On, and playback begins.
TV power switches On, and the playback screen is displayed.
Audio is muted on the TV and switches to the theater system.
Providing
the setting
information
(for “HDAVI
Control 3 or
later”)
The following information about the TV settings can be transmitted to each piece of equipment (Recorder/Home
theater/Player) that has “HDAVI Control 3 or later” function connected to a TV with HDMI cable.
Transmittable data Recorder Home
theater Player
On Screen Display Language setting
(English/Español/Français) ○○○
Panel Aspect Ratio
(16:9 fixed) ○○○
Closed caption information
(Mode/CC type/Digital setting) ○--- ---
Channel information
(Input signal/Channel list/Caption information)
○--- ---
Note
There is a possibility that all the GUI language information might be set from equipment that has HDMI CEC
function connected to TV with HDMI cable. Depending on operating conditions or the specification for each piece
of equipment the setting may or may not be applied.
For more details on the external equipment’s operation, please refer to the operating manuals for the equipment.
[For Recorder]
You cannot operate other functions while transmitting TV’s information above except Power On/Off key operation.
When you turn off this unit, the transmission will be interrupted (only when you are transmitting Channel information).
Automatic lip-
sync function
(for “HDAVI
Control 3 or later”)
Minimizes lip-sync delays between the picture and audio when you connect to a Panasonic theater system or
Amplifier.
■
Press to exit from
a menu screen
■
Press to return
to the previous
screen
Display menu
Select “Setup”
Menu
Audio
VIERA Link
SD card
Closed caption
Setup
select
next
Select “VIERA Link settings”
Setup 2/2
Advanced setup
About
VIERA Link settings
ECO/energy saving
select
next
Select “VIERA Link”
On
Yes
Yes
TV
No
No
VIERA Link settings
VIERA Link
Power on link
Power off link
Default speakers
Stand-by power save
Auto power stand-by
select
Select “On”
(default is On) change
Select settings
On
Yes
Yes
TV
No
No
VIERA Link settings
VIERA Link
Power on link
Power off link
Default speakers
Stand-by power save
Auto power stand-by
select
Set
On
Yes
Yes
Theater
No
No
VIERA Link settings
VIERA Link
Power on link
Power off link
Default speakers
Stand-by power save
Auto power stand-by
change

32
33
Advanced
VIERA LinkTM “HDAVI ControlTM”
VIERA LinkTM “HDAVI ControlTM” (Continued)
You can enjoy more convenient operation with the “HDAVI Control” function in the “VIERA Link”
menu.
For more details on the “HDAVI Control” function, refer to p. 28
or
■
Press to exit from
a menu screen
■
Press to return
to the previous
screen
Display VIERA Link menu
select
next
VIERA Link
or
Select the item
Recorder
TV
VIERA Link control
Speaker output
Record now
Stop recording
select
set or next
Select
Home theater
TV
VIERA Link control
Speaker output
Record now
Stop recording
change
Set
Speaker
control
You can select Home theater or TV speakers for audio output.
Control theater speakers with the TV’s remote control.
This function is available only when Panasonic Amplifier or
Player theater is connected.
■Home theater: Adjustment for equipment
Volume up / down
Mute
The sound of the TV is muted.
When the equipment is turned off, the TV speakers take over.
Selecting “Home theater” turns the equipment on
automatically if it is in standby mode.
■
TV: The TV speakers are on.
Select “Speaker output”
Select “Home theater” or “TV”
Recorder
TV
Record now
Stop recording
VIERA Link control
Speaker output
select
change
VIERA Link
control
only with the
TV’s remote
control
(for “HDAVI
Control 2 or
later”)
In the VIERA Link menu, you can select HDMI connected equipment and access it quickly. Continue using your
TV’s remote control to operate the equipment, pointing it at the TV.
Select “VIERA Link control”
Select the equipment you want to access.
(Recorder/Home theater/Player/Camcorder/LUMIX)
If there is more than one equipment item, a
number after the name indicates the number of
items. (e.g. Recorder 1/Recorder 2/Recorder 3)
The number of equipment items that can be
connected is three for recorders, and a total
of three for Home theater/Player/Camcorder/
LUMIX.
Note
There is a limit to the number of HDMI
connectors.
Recorder
TV
VIERA Link control
Speaker output
Record now
Stop recording
select
change
You can select available items only.
Operate the equipment with the TV’s remote control, pointing it at the TV.
To operate the equipment, read the manual of the equipment.
■
Available TV’s remote control buttons
Whether an operation is available differs depending on the connected equipment.
Move the cursor/Select Play
Set/Access Stop
Return to previous menu Reverse/Forward
SUB
MENU
Display the functions
menu on the equipment Skip Reverse/Forward
Available when the purpose of the keys is
displayed on screen Pause
Exit Closed caption
Channel Up/Down SAP (Select Audio Mode)
-
0-9 Select digital subchannel
Direct TV
recording
(for “HDAVI
Control 3 or
later”)
Records the current program on the recorder immediately.
Select “Record now”
Select “Stop recording”, when you want to stop recording
Recorder
TV
VIERA Link control
Speaker output
Record now
Stop recording
select
set
Recorder
TV
VIERA Link control
Speaker output
Record now
Stop recording
select
set
For optimal recording, the settings of the recorder might
be required. For details, read the manual of the recorder.
Recording will not stop automatically when the
program is finished.

34
35
Advanced
Lock
Lock
You can lock specified channels or shows to prevent children from watching objectionable content.
■
Press to exit from
a menu screen
Caution
Make a note of your
password in case
you forget it. (If you
have forgotten your
password, consult
your local dealer.)
Note
When you select a
locked channel,
a message will be
displayed that allows
you to view the
channel if you input
your password.
Display menu
Select “Lock”
Menu
VIERA Link
Audio
Timer
Lock
SD card
Closed caption
Setup
next
select
You will be asked to enter your
password each time you display
the Lock menu.
Input your 4-digit password
A 4-digit code must be entered to view a blocked program or change rating settings.
RETURN
Password
Enter password.
- - - -
If it is your first time entering the
password, enter the password
twice in order to register it.
Select the Lock mode
Off
Off
Off
Off
Lock
Mode
Channel
Game
Change password
Program
set
select
Off: Unlocks all the lock
settings of “Channel”,
“Game” and “Program”.
All: Locks all the inputs
regardless of the lock
settings of “Channel”,
“Game” and “Program”.
Custom: Locks specified inputs of
“Channel”, ”Game” and
“Program”.
Select the item
Custom
Off
Off
Off
Lock
Mode
Channel
Game
Change password
Program
select
“Channel”, ”Game” and
“Program” are not accessible
unless “Custom” is selected in
“Mode”.
Set
set
■
To select the channel or the rating of the program to be locked
Channel
lock
Select up to 7 (1-7) channels to be blocked. These channels will be blocked regardless of the
program rating.
Select “Mode” and set to “Custom”
Select channel to lock.
Custom
3
4
-
-
-
Channel lock
Mode
Channel 1
Channel 2
Channel 3
Channel 4
Channel 5
select
set
To lock/unlock all channels:
Select “Mode” and set to “All” or “Off”.
All: Locks all channels
Off: Unlocks all channels
Game lock
Locks Channel 3, Channel 4 and external
inputs.
Select “Game” in
5
and set to “On”.
select
set
On: Locks
Off: Unlocks
Program
lock
■
To set a rating level
“V-chip” technology enables restricted shows
to be locked according to TV ratings.
Select “Mode” and set to “On”.
On
Off
Off
Off
Off
Program lock
Mode
MPAA
U.S.TV
C.E.L.R.
C.F.L.R.
set
select
Select the rating category you wish
to follow
On
Off
Off
Off
Off
Program lock
Mode
MPAA
U.S.TV
C.E.L.R.
C.F.L.R.
next
select
MPAA: U.S movie ratings
U.S.TV: U.S TV program ratings
C.E.L.R.:Canadian English ratings
C.F.L.R.:Canadian French ratings
Select the rating to be locked
select
Example of “MPAA” (U.S movie ratings)
Change
password
■
To change the password
In , select “Change password” and
press OK
Input the new 4-digit password twice
Off
Off
Off
Off
Lock
Mode
Channel
Game
Change password
Program
RETURN
Change password
Enter new password.
- - - -
Note
This television is designed to support the “Downloadable U.S. Region Rating System” when available.
(Available only in U.S.A.)
The Off rating is independent of other ratings.
When placing a lock on a specific-age-based-rating level, the Off rating and any other more restrictive ratings will
also be blocked.
NR No rating
G General Audience: All ages admitted
PG Parental Guidance Suggested
PG-
13
Parents Strongly Cautioned: Inappropriate
for children under 13
RRestricted: Under 17 requires
accompanying parent or adult guardian
NC-
17 No one 17 and under admitted
X Adults only
To get more information (p. 42)

36
37
Advanced
Editing and Setting Channels
Editing and Setting Channels
■To reset the settings of setup menu
Select “Reset to defaults” in Setup menu ( ) and
press OK
Input your 4-digit password with number buttons
Select “YES” on the confirmation screen and press OK
If “Lock” (p. 34) is activated and “ANT/Cable setup” is selected, “Enter password.” will be displayed.
The current channel settings can be changed according to your needs and reception
conditions.
■
Press to exit from
a menu screen
Display menu
Select “Setup”
Menu
Audio
Timer
Lock
VIERA Link
SD card
Closed caption
Setup
next
select
Select “ANT/Cable setup”
Setup 1/2
Clock
ANT/Cable setup
Input labels
Reset to defaults
Language
All
Channel surf mode
next
select
Select the function
Cable
ANT/Cable setup
ANT in
Auto program
Manual program
Signal meter
next
select
Set
Auto
program
Set
automatically
Automatically searches and adds available channels to the memory.
Select “ANT in”
Select Cable or Antenna.
Or select “Not used”. (p. 14)
Select “Auto program”
Cable
ANT/Cable setup
ANT in
Auto program
Manual program
Signal meter
next
select
Select a scanning mode (p. 14)
Auto program
All channels
Analog only
Digital only
ok
select
Settings are made automatically
After the scanning is completed, select “Apply”
(see below ).
All previously saved channels are erased.
Manual
program
Set
manually
Use this procedure when changing the channel setup or
changing the channel display.
Also, use this to add or skip channels from the channel
list manually.
You can select a channel tuning mode (Digital only/
Analog only) in “Channel surf mode”(p. 26)
Edit
Caption
---
80-101
Change
OK
RETURN
DeleteABC →abc
G Y
Edit CH caption
Caption
Channel
select
change
set/next
or
Caption
Select or edit the station identifier.
(maximum 7 characters available)
Favorite
Set favorite 1/3
26-1
1
2
select
next
Set favorite Select the number
Add
Press OK to select “Yes (add)” or “No (skip)”
Move cursor to channel number
Manual program
Edit CancelApply
Caption Favorite Add
2 ...
... Yes
3 ...
... Yes
Channel
select
Press OK to tune
to the channel.
Select “Apply”
program
CancelApply
Caption Favorite Add
...
... Yes
el
select “Apply”
ok
Select “Edit”
Manual program
Edit CancelApply
Caption Favorite Add
2 ...
... Yes
3 ...
... Yes
4 ...
... Yes
5 ...
... Yes
Channel
select
next
Select the item to be edited
R G B Y
Select
RETURN
OK
Manual program
Edit CancelApply
Caption Favorite Add
2 ...
... Yes
3 ...
... Yes
4 ...
... Yes
5 ...
... Yes
6 ...
... Yes
7 ...
... Yes
8 ...
... Yes
9 ...
... Yes
Channel
Prev.page Next page
Caption
Favorite
Add
Proceed to
next page
Go back to previous page
select the item
to edit (Caption/
Favorite/Add)
next
• Caption:
Changes the station identifier
• Favorite:
Registers channel to Favorite
List
• Add:
Adds or skips channels
To cancel the Edit
Manual program
Edit CancelApply
Caption Favorite Add
2 ...
... Yes
3 ...
... Yes
4 ...
... Yes
5 ...
... Yes
Channel
select
next
Changes will be lost. Continue?
Yes No
ok
(returns to “ANT/
Cable setup”)
select “Yes”
Signal
meter
Check
signal
strength
Check the signal strength if an interference is found or freezing occurs on a digital image.
1-1
Signal meter
Channel
Tune manually
Signal strength
Current 30%
Peak level 45%
Signal intensity
change
channel
ok
or
If the signal is weak, check the antenna.
If no problem is found, consult your local dealer.
Note
Not available if “Cable” is selected in “ANT in”
(see above).
Available only for digital antenna channels.

38
39
Advanced
Input Labels
Closed Caption
Closed Caption Input Labels
Closed caption
Display
Closed
caption
The television includes a built-in decoder that is capable of providing a text display of the audio.
The program being viewed must be transmitting Closed caption (CC) information. (p. 43)
■
Select the item and set
Primary
CC1
On
Closed caption
Digital
Mode
Analog
Digital setting
Reset to defaults
select
set
Mode Select “On” (when not using, select
“Off”).
Analog (Choose the Closed caption service
of Analog broadcasting.)
CC1-4: Information related to pictures
(Appears at bottom of screen)
T1-4: Textual information
(Appears over entire screen)
Digital (The Digital Closed caption
menu lets you configure the way
you choose to view the digital
captioning.)
Select the setting.
“Primary”, “Second.”, “Service 3”, “Service
4”, “Service 5”, “Service 6”
The settings in “Analog” or “Digital”
depend on the broadcaster.
■
To make more in-depth display settings in digital programs
Select “Digital setting” and press OK
Select the item and set
Automatic
Automatic
Automatic
Automatic
Automatic
Automatic
Automatic
Automatic
Digital setting
Size
Foreground
Font
Style
Fore. opacity
Background
Back. opacity
Outline
select
set
Size: Text size
Font: Text font
Style: Text style (Raised, Depressed, etc.)
Foreground: Color of text
Fore. opacity: Opacity of text
Background: Color of text box
Back. opacity: Opacity of text box
Outline: Outline color of text
(Identify the setting options on the screen.)
■
To reset the settings
Select “Reset to defaults” and press OK
Input labels
Display
labels of
Connected
devices
Devices connected to external input terminals can be labeled for easier identification during
input selection. (In selecting input mode from p. 20 )
■
Select the terminal and label of the external equipment
GAME
GAME
Input labels
Component
HDMI 1
HDMI 2
HDMI 3
Video 1
Video 2
PC
or
GA A
Select
OK
RETURN
DeleteABC →abc
G Y
Input labels
Component
Switches Input mode from alphabetical to numeric
select
set
Video 1
VCR
Label Terminal
[example]
Terminals: Component/HDMI 1-3/Video 1-2/PC
Label: [BLANK] SKIP/VCR/DVD/CABLE/SATELLITE/DVR/GAME/
AUX/RECEIVER/COMPUTER/Blu-ray/CAMERA/DVD REC/
HOME THTR/MONITOR/MEDIA CTR/MEDIA EXT/OTHER
For the PC terminal, only “SKIP” is available.
* If “SKIP” is selected, the INPUT button press will skip its input.
Each selected label will be displayed on “Input select” screen.
(p. 20)
■
Press to exit from
a menu screen
Display menu
Select “Closed caption”
Menu
VIERA Link
Audio
Timer
Lock
SD card
Closed caption
Setup
next
select
■
Press to exit from
a menu screen
Display menu
Select “Setup”
Menu
Audio
Timer
Lock
VIERA Link
SD card
Closed caption
Setup
next
select
Select “Input labels”
Setup 1/2
Clock
ANT/Cable setup
Input labels
Language
All
Channel surf mode
next
select
