Panasonic TH-32LRU60 User manual

Model No.
TH-32LRU60
TH-39LRU60
TH-42LRU60
TH-50LRU60
TH-65LRU60
Simple Owner’s Manual
Hospitality LCD HDTV
English
Thank you for purchasing this Panasonic product.
Please read these instructions before operating your set
and retain them for future reference. The images shown in
this manual are for illustrative purposes only.
Manufactured under license from Dolby
Laboratories. Dolby and the double-D symbol
are trademarks of Dolby Laboratories.
Energy Star is a joint program of the US Environmental
Protection Agency and the U.S. Department of Energy.
It is administered in Canada by Natural Resources
Canada (NRC) through the Office of Energy Efficiency
(OEE). This program is helping to protect the
environment and save money through energy efficient
products and practices. This product qualifies for
ENERGY STAR in the factory default setting and this is
the setting in which energy savings will be achieved.
Any modifications to the factory default setting could
result in greater energy consumption beyond levels that
meet ENERGY STAR qualifications.
Pro: Idiom is
a trademark
of Zenith
Corporation.
Safety Precautions
Secure Ventilation
Slots and openings in the cabinet and the back or bottom are provided for ventilation, and to ensure reliable operation of the LCD
TV and to protect it from overheating. These openings must not be blocked or covered. There should be at least 4 inches (10 cm)
of space around the TV. The openings should never be blocked by placing the LCD TV on a bed, sofa, rug or other similar surface.
This LCD TV should not be placed in a built-in installation such as a bookcase unless proper ventilation is provided.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING: To reduce the risk of electric shock, do not remove cover or back.
No user-serviceable parts inside. Refer servicing to qualified service personnel.
The lightning flash with arrowhead
within a triangle is intended to tell the
user that parts inside the product are
a risk of electric shock to persons.
The exclamation point within a
triangle is intended to tell the
user that important operating
and servicing instructions are in
the papers with the appliance.
Important Safety Instructions
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
8) Do not install near any heat sources such as radiators, heat registers, stoves or other apparatus (including amplifiers) that
produce heat.
9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider
than the other. A grounding type plug has two blades and a third grounding prong. The wide blade or the third prong are
provided for your safety. If the provided plug does not fit into your outlet, consult an electrician for replacement of the
obsolete outlet.
10) Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles, and
the point where they exit from the apparatus.
11) Only use attachments / accessories specified by the manufacturer.
12) Use only with the cart, stand, tripod, bracket or table specified by the manufacturer, or sold with the
apparatus. When a cart is used, use caution when moving the cart / apparatus combination to avoid injury
from tip-over.
13) Unplug this apparatus during lightning storms or when unused for long periods of time.
14) Refer all servicing to qualified service personnel. Servicing is required when the apparatus has been damaged in any
way, such as power-supply cord or plug is damaged, liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
15) Operate only from the type of power source indicated on the
marking label. If you are not sure of the type of power supplied to
your home consult your television dealer or local power company.
16) Follow all warnings and instructions marked on the LCD TV.
17) Never push objects of any kind into this LCD TV through cabinet
slots as they may touch dangerous voltage points or short out
parts that could result in a fire or electric shock. Never spill liquid
of any kind on the LCD TV.
18) If an outside antenna is connected to the television equipment,
be sure the antenna system is grounded so as to provide some
protection against voltage surges and built up static charges.
In the U.S. Section 810-21 of the National Electrical Code
provides information with respect to proper grounding of the mast
and supporting structure, grounding of the lead-in wire to an
antenna discharge unit, size of grounding conductors, location of
antenna discharge unit, connection to grounding electrodes, and
requirements for the grounding electrode.
19) An outside antenna system should not be located in the vicinity of overhead power lines, other electric light, power circuits,
or where it can fall into such power lines or circuits. When installing an outside antenna system, extreme care should be
taken to keep from touching such power lines or circuits as contact with them might be fatal.
20) Unplug this LCD TV from the wall outlet and refer servicing to qualified service personnel under the following conditions:
a. When the power cord or plug is damaged or frayed.
b. If liquid has been spilled into the LCD TV.
c. If the LCD TV has been exposed to rain or water.
d. If the LCD TV does not operate normally by following the operating instructions.
Adjust only those controls that are covered by the operating instructions as improper adjustment of
other controls may result in damage and will often require extensive work by a qualified technician to
restore the LCD TV to normal operation.
e. If the LCD TV has been dropped or the cabinet has been damaged.
f. When the LCD TV exhibits a distinct change in performance - this indicates a need for service.
21)
When replacement parts are required, be sure the service technician uses replacement parts specified by the manufacturer that
have the same characteristics as the original parts. Unauthorized substitutions may result in fire, electric shock, or other hazards.
22) WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPARATUS TO RAIN,
MOISTURE, DRIPPING OR SPLASHING.
DO NOT PLACE LIQUID CONTAINERS (FLOWER VASES, CUPS, COSMETICS, ETC.) ABOVE THE SET
(INCLUDING ON SHELVES ABOVE, ETC.).
23) WARNING: SMALL PARTS CAN PRESENT CHOKING HAZARD IF ACCIDENTALLY SWALLOWED. KEEP SMALL
PARTS AWAY FROM YOUNG CHILDREN.
DISCARD UNNEEDED SMALL PARTS AND OTHER OBJECTS, INCLUDING PACKAGING MATERIALS
AND PLASTIC BAGS/SHEETS TO PREVENT THEM FROM BEING PLAYED WITH BY YOUNG CHILDREN,
CREATING THE POTENTIAL RISK OF SUFFOCATION.
24) WARNING: To prevent the spread of fire, keep candles or other open flames away from this product at all
times.
25) WARNING: Do not place this TV in any medical institutions or locations with medical devices.
Radio waves from this TV may interfere with the medical devices and cause accidents due to the
malfunction.
26) WARNING: Do not use this TV near any automatic control devices such as automatic doors or fire alarms.
Radio waves from this TV may interfere with the automatic control devices and cause accidents due to the
malfunction.
27) WARNING: Keep this TV away at least 9 inches (22 cm) from the location where a cardiac pacemaker is implanted.
Radio waves from this TV may interfere with the operation of the pacemaker.
28) CAUTION: The Power switch on this unit will not completely shut off all power from AC outlet. Since the power cord serves
as the main disconnect device for the unit, you will need to unplug it from the AC outlet to shut down all power.
Therefore, make sure the unit has been installed so that the power cord can be easily unplugged from AC outlet
in case of an accident. To avoid fire hazard, the power cord should also be unplugged from the AC outlet when
left unused for a long period of time (for example, when on vacation).
29) CAUTION: TO PREVENT ELECTRIC SHOCK, DO NOT USE THIS PLUG WITH A RECEPTACLE OR OTHER OUTLET
UNLESS THE BLADES CAN BE FULLY INSERTED TO PREVENT BLADE EXPOSURE.
30) CAUTION: USE WITH OTHER STAND MAY RESULT IN INSTABILITY POSSIBLY CAUSING INJURY.
31) CAUTION: DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY REPLACED. REPLACE ONLY WITH THE SAME
OR EQUIVALENT TYPE.
NOTE: This equipment is designed to operate in North America and other countries where the broadcasting system and AC
house current are exactly the same as in North America.
FCC STATEMENT
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur
in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may
not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause
undesired operation.
FCC Caution:
To assure continued compliance, follow the attached installation instructions and use only shielded interface cables when
connecting to computer or peripheral devices. Any changes or modifications not expressly approved by Panasonic Corp. of North
America could void the user’s authority to operate this device.
FCC Declaration of Conformity
Model No. TH-32LRU60, TH-39LRU60, TH-42LRU60, TH-50LRU60, TH-65LRU60
Responsible Party: Panasonic Corporation of North America
Two Riverfront Plaza, Newark, NJ 07102-5490
Contact Source: Panasonic System Communications Company of North America
1-800-973-4390
Please visit the Panasonic website
for more information.
http://panasonic.net/
TQB2AA0719-3
ANTENNA
LEAD-IN WIRE
ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)
GROUNDING
CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)
ELECTRIC
SERVICE
EQUIPMENT
GROUND CLAMP
EXAMPLE OF ANTENNA
GROUNDING AS PER
(NEC) NATIONAL
ELECTRICAL
CODE
Care and Cleaning
First, unplug the Power cord plug from the wall outlet.
Display panel
The front of the display panel has been specially treated. Wipe the panel surface gently using only a cleaning cloth or a soft,
lintfree cloth.
If the surface is particularly dirty, soak a soft, lint-free cloth in diluted mild liquid dish soap (1 part mild liquid dish soap diluted
by 100 times the amount of water) and then wring the cloth to remove excess liquid. Use this cloth to wipe the surface of the
display panel, then wipe it evenly with a dry cloth of the same type until the surface is dry.
Do not scratch or hit the surface of the panel with fingernails or other hard objects. Furthermore, avoid contact with volatile
substances such as insect sprays, solvents, and thinner; otherwise, the quality of the surface may be adversely affected.
Cabinet
If the cabinet becomes dirty, wipe it with a soft, dry cloth.
If the cabinet is particularly dirty, soak the cloth in a weak mild liquid dish soap and then wring the cloth dry. Use this cloth to
wipe the cabinet and then wipe it dry with a dry cloth.
Do not allow any mild liquid dish soap to come into direct contact with the surface of the LCD TV.
If water droplets get inside the unit, operating problems may result.
Avoid contact with volatile substances such as insect sprays, solvents, and thinner; otherwise, the quality of the cabinet
surface may be adversely affected or the coating may peel off. Furthermore, do not leave it for long periods in contact with
articles made from rubber or PVC.
Pedestal
Cleaning
Wipe the surfaces with a soft, dry cloth. If the unit is particularly dirty, clean it using a cloth soaked with water to which a small
amount of mild liquid dish soap has been added and then wipe with a dry cloth.
Do not use products such as solvents, thinner, or household wax for cleaning, as they can damage the surface coating.
(If using a chemically-treated cloth, follow the instructions supplied with the cloth.)
Do not attach sticky tape or labels, as they can make the surface of the pedestal dirty. Do not allow long-term contact with
rubber, vinyl products, or the like. (Doing so will cause deterioration.)
Power cord plug
Wipe the plug with a dry cloth at regular intervals. (Moisture and dust can lead to fire or electrical shock.)
CHILD SAFETY:
It Makes A Difference How and Where
You Use Your Flat Panel Display
Congratulations on your purchase! As you enjoy your new product,
please keep these safety tips in mind:
THE ISSUE
• The home theater entertainment experience is a growing trend
and larger flat panel displays are popular purchases. However,
flat panel displays are not always supported on the proper stands
or installed according to the manufacturer’s recommendations.
• Flat panel displays that are improperly situated on dressers,
bookcases, shelves, desks, speakers, chests or carts may fall
over and cause injury.
THIS MANUFACTURER CARES!
• The consumer electronics industry is committed to making home
entertainment enjoyable and safe.
TUNE INTO SAFETY
• One size does NOT fit all. Follow the manufacturer’s
recommendations for the safe installation and use of your flat panel
display.
• Carefully read and understand all enclosed instructions for proper
use of this product.
• Don’t allow children to climb on or play with furniture and television
sets.
• Don’t place flat panel displays on furniture that can easily be
used as steps, such as a chest of drawers.
• Remember that children can become excited while watching a
program, especially on a “larger than life” flat panel display. Care
should be taken to place or install the display where it cannot be
pushed, pulled over, or knocked down.
• Care should be taken to route all cords and cables connected to
the flat panel display so that they cannot be pulled or grabbed by
curious children.
WALL MOUNTING: IF YOU DECIDE TO WALL
MOUNT YOUR FLAT PANEL DISPLAY, ALWAYS:
• Use a mount that has been recommended by the display
manufacturer and/or listed by an independent laboratory (such as
UL, CSA, ETL).
• Follow all instructions supplied by the display and mount
manufacturers.
• If you have any doubts about your ability to safely install your flat
panel display, contact your retailer about professional installation.
• Make sure that the wall where you are mounting the display is
appropriate.
Some wall mounts are not designed to be mounted to walls with
steel studs or old cinder block construction. If you are unsure,
contact a professional installer.
• A minimum of two people are required for installation. Flat panel
displays can be heavy.
Optional Accessory
Back of the TV
Holes for wall-hanging bracket
installation
Screw for fixing the TV onto the wall-hanging bracket
(not supplied with the TV)
(View from the side)
a
b
Depth of screw:
(for 32 ”) M4
Minimum: 0.36 ” (9 mm)
Maximum: 0.66 ” (17 mm)
(for 39 ”) M6
Minimum: 0.40 ” (10 mm)
Maximum: 0.59 ” (15 mm)
(for 32”)
a: 7.9” (200 mm)
b: 3.9” (100 mm)
(for 39”/42”)
a: 7.9” (200 mm)
b: 7.9” (200 mm)
(for 50”/65”)
a: 15.7” (400 mm)
b: 15.7” (400 mm)
(for 42 ”) M6
Minimum: 1.26 ” (32 mm)
Maximum: 1.53 ” (39 mm)
(for 50 ”) M6
Minimum: 0.44 ” (11 mm)
Maximum: 0.66 ” (17 mm)
(for 65 ”) M6
Minimum: 0.75 ” (19 mm)
Maximum: 0.82 ” (21 mm)
WARNING
Always be sure to ask a qualified technician to carry out set-up.
Do not mount the unit directly below ceiling lights (such as spotlights, floodlights or halogen lights) that typically give off
high heat. Doing so may warp or damage plastic cabinet parts.
Take care when fixing wall brackets to the wall. Always ensure that there are no electrical cables or pipes in the wall
before hanging bracket.
To prevent fall and injury, remove the TV from its fixed wall position when it is no longer in use.
Incorrect wall-hanging bracket or incorrect fitting may cause equipment to fall, resulting in injury and product damage.
Panasonic disclaims liability for any damage or injury arising from incorrect wall-hanging bracket, incorrect fitting or
otherwise failure to follow the above instructions.
Accessories/Optional Accessory
Accessories
Check you have all the items shown.
Accessories
Batteries for the
Remote Control
Transmitter (2)
AA Battery
Simple Owner’s Manual
Installing the remote’s batteries
Open
Hook Note the correct polarity
(+ or -).
Close Caution
Incorrect installation may cause
battery leakage and corrosion,
resulting in damage to the remote
control.
•
Do not mix old and new batteries.
•
Do not mix different battery types (such
as alkaline and manganese batteries).
•
Do not use rechargeable (Ni-Cd)
batteries.
Do not burn or break batteries.
Remote Control
Transmitter
N2QAYB000820
Pedestal
(For details, see
“Installing the TV”.)
(image)
Power cord
Wall-hanging bracket
Please contact a professional installer to purchase the recommended UL qualified wall-hanging bracket. For
additional details, please refer to the wall-hanging bracket installation manual.
Installing the TV
WARNING
These instructions are for use by qualified service personnel only. To reduce the risk of electric shock and injury do not perform
any servicing other than that contained in the operating instructions unless you are qualified to do so.
To prevent injury, this device must be properly secured to the furniture, which is installed on the floor or wall, in accordance
with the installation instructions for this device.
■
Assembling the pedestal
(1) Install securely with assembly screws . (Total 4 screws)
(2) The rotation angle can be set at 0°, 30°, 60° or 90°. Install screws to each angle control position.
It is not necessary to install screws if 90° angle rotation is desired.
Tighten screws firmly.
For TH-50LRU60/TH-65LRU60, only (1) is needed in “Assembling the pedestal”.
0°
30°
60°
B
B
F
F
For TH-32LRU60, one of the screws can be
replaced with a security screw if necessary.
(3) Install neck cover.
(4) Install securely with an assembly screw .
Tighten screws firmly.
E
Accessories
Bracket (1)
TBL5ZA34841 (TH-32LRU60)
TBL5ZA34831 (TH-39LRU60)
TBL5ZA34811 (TH-42LRU60)
TBL5ZA34801 (TH-50LRU60)
TBL5ZA34611 (TH-65LRU60)
Base (1)
TBL5ZX07281 (TH-32LRU60)
TBL5ZX07321 (TH-39LRU60/
TH-42LRU60)
TBL5ZX07381 (TH-50LRU60)
TBL5ZX07161 (TH-65LRU60)
Neck cover (1)
TBL2AB30081
(TH-32LRU60/TH-39LRU60/
TH-42LRU60)
Assembly screws
Screws (4) Screws (4) Security screw (1) Security screw (1)
XYN4+F12FJK
size (M4 × 12)
(TH-32LRU60/
TH-39LRU60/
TH-42LRU60/
TH-50LRU60)
XYN4+F25FNK
size (M4 × 25)
(TH-65LRU60)
XSS5+12FNK
size (M5 × 12)
(TH-32LRU60/
TH-39LRU60/
TH-42LRU60)
XSS5+15FNK
size (M5 × 15)
(TH-50LRU60/
TH-65LRU60)
THE2AC004J
size (M4 × 12)
(TH-32LRU60/
TH-39LRU60/
TH-42LRU60/
TH-50LRU60)
THM2AA001N
size (M5 × 12)
(TH-32LRU60)
Screw (1) Screws (2) Screw (1)
Security screw (1)
Wood screws (4)
THEC1509
size (M3 × 5)
(TH-32LRU60/
TH-39LRU60/
TH-42LRU60)
XVE6A10FJK
size (M6 × 10)
(TH-32LRU60/
TH-39LRU60/
TH-42LRU60)
XTB3+30AFJK
size (M3 × 30)
(TH-32LRU60/
TH-39LRU60/
TH-42LRU60/
TH-50LRU60)
THT2AA002J
size (M3 × 30)
(TH-32LRU60/
TH-39LRU60/
TH-42LRU60/
TH-50LRU60)
XTS5+20AFJK
(TH-32LRU60/
TH-39LRU60/
TH-42LRU60/
TH-50LRU60)

HDMI terminals
COMPONENT terminals
COMPOSITE terminals
AUDIO OUT terminal
DATA/MTI terminal
SERIAL terminal
PC terminal
USB terminal
*1:TH-42LRU60/TH-50LRU60
*2:For more details on the external equipment’s
connections, please refer to the operating manuals
for the equipment.
■Side panel ■Back panel
Connection panel
Power cord connection
Connections
Panasonic Hospitality LCD HDTV
Limited Warranty
Models or Parts Part
Warranty
Labor
Warranty
Professional Flat
Panel Display
LIMITS AND EXCLUSIONS
There are no express warranties except as listed above.
THE WARRANTOR SHALL NOT BE LIABLE FOR
INCIDENTAL OR CONSEQUENTIAL DAMAGES
(INCLUDING, WITHOUT LIMITION, DAMAGE
TO DISCS) RESULTING FROM THE USE OF THIS
PRODUCT, OR ARISING OUT OF ANY BREACH OF
THE WARRANTY. ALL EXPRESS AND IMPLIED
WARRANTIES, INCLUDING THE WARRANTIES
OF MERCHANTABILITY AND FITNESS FOR
PARTICULAR PURPOSE, ARE LIMITED TO THE
APPLICABLE WARRANTY PERIOD SET FORTH
ABOVE.
Some states do not allow the exclusion or limitation
of incidental or consequential damages, or limitations
on how long an implied warranty lasts, so the above
exclusions or limitations may nor apply to you. This
warranty gives you specific legal rights and you may
other rights, which vary from state to state.
If you have a problem with this product that is not
handled to your satisfaction, then write the Consumer
Affairs Department at the Company address indicated
above.
In the USA and Puerto Rico
FOR SERVICE
CALL TOLL FREE
1-800-973-4390
2 Years 2 Years
This warranty is extended only to the original purchaser
and is non transferable. A purchase receipt or other
proof of date of original purchase will be required before
warranty service is rendered.
This warranty only covers failures due to defects in
materials or workmanship, which occur during normal
use. The warranty does not cover damage which occur
in shipment, or failures which are caused by products
not supplied by the warrantor, or failures which result
from improper installation, set-up adjustments, improper
antenna, inadequate signal pickup, maladjustment of
consumer controls, improper operation, power line surge,
improper voltage supply, lighting damage, or service by
anyone other than an authorized repair facility, or
damage that is attributable to acts of God.
Panasonic System Communications Company of North
America (referred to as “the Warrantor”) will repair this
product and all included accessories with new or
refurbished parts, free of charge in the USA or Puerto
Rico, of the original purchase in the event of a defect in
materials or workmanship as follows:
On-site or carry-in service in the USA and Puerto Rico
may be obtained during the warranty period by contacting
Panasonic System Communications Company of North
America Service toll free at 1-800-973-4390.
USA only:
Disposal may be regulated in your community due to environmental considerations. For disposal or recycling information, please visit
Panasonic website: http://www.panasonic.com/environmental or call 1-888-769-0149.
Customer’s Record
The model number and serial number of this product can be found on its back cover. You should note this serial number in the space provided below and retain this book,
plus your purchase receipt, as a permanent record of your purchase to aid in identification in the event of theft or loss, and for Warranty Service purposes.
Model Number Serial Number
©Panasonic Corporation 2013
Panasonic System Communications
Company of North America
Unit of Panasonic Corporation of North America
Executive Office :
Two Riverfront Plaza, Newark, NJ 07102-5490 U.S.A.
Panasonic Canada Inc.
5770 Ambler Drive
Mississauga,Ontario
L4W 2T3 CANADA
Printed in Mexico
M0413-3073
Specifications
TH-32LRU60 TH-39LRU60
Power Source AC 110-127 V, 60 Hz
Power
Consumption
Rated Power
Consumption 60 W 80 W
Standby condition Under 1.0 W Under 1.0 W
Display panel
Panel System LCD panel (LED backlight) 16:9 Aspect Ratio
Visible screen size
(W × H × Diagonal)
(No. of pixels)
32” class
(31.5 inches measured diagonally)
39” class
(38.5 inches measured diagonally)
27.5 ” × 15.4 ” × 31.5 ”
(698 mm × 392 mm × 800 mm)
33.6 ” × 18.9 ” × 38.5 ”
(854 mm × 480 mm × 980 mm)
1,049,088 (1,366 (W) ×
768 (H)) [4,098 × 768 dots]
2,073,600 (1,920 (W) ×
1,080(H)) [5,760 × 1,080
dots]
Dimensions
(W × H × D)
Including TV stand 29.2 ”
× 21.3 ” × 7.3 ”
(741 mm × 539 mm × 183 mm)
35.3 ” × 24.4 ” × 9.0 ”
(896 mm × 618 mm × 227 mm)
TV Set only 29.2 ”
× 17.8 ” × 3.0 ”
(741 mm × 450 mm × 76 mm)
35.3 ” × 21.2 ” × 3.4 ”
(896 mm × 536 mm × 85 mm)
Mass
Including TV stand 19.9 lb. (9.0 ) NET 23.4 lb. (10.6 ) NET
TV Set only 15.5 lb. (7.0 ) NET 19.9 lb. (9.0 ) NET
Sound
Speaker 1-way 2 bottom SP System
Audio Output 10 W [5 W + 5 W] 20 W [10 W + 10 W]
TH-42LRU60 TH-50LRU60 TH-65LRU60
Power Source AC 110-127 V, 60 Hz
Power
Consumption
Rated Power
Consumption 105 W 125 W 170 W
Standby condition Under 1.0 W Under 1.0 W Under 1.0 W
Display panel
Panel System LCD panel (LED backlight) 16:9 Aspect Ratio
Visible screen size
(W × H × Diagonal)
(No. of pixels)
42” class
(41.9 inches measured diagonally)
50” class
(49.5 inches measured diagonally)
65” class
(64.5 inches measured diagonally)
36.5 ” × 20.5 ” × 41.9 ”
(928 mm × 522 mm × 1,065 mm)
43.1 ” × 24.3 ” × 49.5 ”
(1,096 mm × 616 mm × 1,257 mm)
56.2 ” × 31.6 ” × 64.5 ”
(1,428 mm × 804 mm × 1,639 mm)
2,073,600 (1,920 (W) × 1,080(H)) [5,760 × 1,080 dots]
Dimensions
(W × H × D)
Including TV stand 38.3 ” × 26.1 ” × 9.0 ”
(972 mm × 662 mm × 227 mm)
45.0 ” × 29.1” × 11.1 ”
(1,141 mm × 739 mm × 280 mm)
57.5 ” × 35.6 ” × 13.2 ”
(1,459 mm × 902 mm × 333 mm)
TV Set only 38.3 ” × 22.9 ” × 3.5 ”
(972 mm × 580 mm × 87 mm)
45.0 ” × 26.6 ” × 3.5 ”
(1,141 mm × 674 mm × 87 mm)
57.5 ” × 33.4 ” × 2.1 ”
(1,459 mm × 846 mm × 52 mm)
Mass
Including TV stand 27.8 lb. (12.6 ) NET 41.9 lb. (19.0 ) NET 82.7 lb. (37.5 ) NET
TV Set only 24.3 lb. (11.0 ) NET 35.3 lb. (16.0 ) NET 72.8 lb. (33.0 ) NET
Sound
Speaker 1-way 2 bottom SP System
Audio Output 20 W [10 W + 10 W]
Note
Design and Specifications are subject to change without notice. Mass and Dimensions shown are approximate.
Panasonic Canada Inc.
5770 Ambler Drive, Mississauga, Ontario L4W 2T3
LIMITED WARRANTY STATEMENT
Item Video Tape P2/SD Cards Video Heads D5 Video heads Maintenance Items Colour Camera CCD Imaging Block All LCD Monitors * DLP™ Projectors * LCD Projectors above
2,500 ANSI Lumens
* LCD Projectors below
2,500 ANSI Lumens
Projector Lamps 103 inch Plasma displays Hard Drive Disk Unit
Parts 30 days—Replacement only (content not covered) (Content not covered) 1 year or 2,000 hrs. (prorated) Whichever comes first 1 year or
1,0
00 hrs.
Whichever comes first 90 days 2 years 2 years (burn-in not covered) 3 years or 17,000 hrs. Whichever comes first 3 years or 2,500 hrs.
Whichever comes first 3 years or 1,500 hrs. Whichever comes first
50% of the rated lamp life or 1 year. Whichever comes first 3 years (burn-in not covered) 1 year plus balance (if any) of the original Manufacturer’s Limited Warranty. (Content not covered)
Labour N/A N/A 1 year or 2,000 hrs. Whichever comes first 1 year or 1,000 hrs. Whichever comes first 90 days 2 years 2 years 3 years or 17,000 hrs. Whichever comes first 3 years or 2,500 hrs.
Whichever comes first. 3 years or 1,500 hrs. Whichever comes first
50% of the rated lamp life or 1 year. Whichever comes first. 3 years 1 year
WARRANTY COVERAGE PERIOD EXCEPTIONS
Panasonic Canada Inc. (also known as PCI) warrants this product to be free of defects in material and workmanship under normal use during the applicable warranty coverage period described below. PCI agrees to repair, or at its option, exchange, any part that becomes defective. However, the product must be purchased and serviced in Canada. The product or part that shows evidence of defect must be delivered prepaid or carried in to an authorized Panasonic Broadcast Service Center. This warranty does not cover shipping costs. The warranty coverage period is one year for both parts and labour beginning with the date of original end user purchase, subject to the exceptions as stated below. Repaired or replacement parts supplied during the warranty coverage period carry the unexpired portion of the original warranty coverage period. Proof of product purchase is a condition of warranty service. The owner must produce the product purchase receipt or other satisfactory evidence of date of original purchase. This warranty does not apply to external appearance items, such as handles, knobs, safety windows, etc. This warranty does not apply to any part, or parts, of the product, installed, altered, repaired or misused in any way that, in the opinion of PCI, affects the reliability of or detracts from the performance of the product. For products requiring routine preventive maintenance, that maintenance must be performed in order to maintain warranty coverage. Serial numbers that have been altered, defaced or removed void this warranty. This warranty does not cover replacements or repairs necessitated by loss or damage resulting from any cause beyond the control of PCI. Marking or retained images (sometimes called “burn-in”) resulting from the display of fixed images on video display products are not defects and are not covered under this warranty. In certain instances, some jurisdictions do not allow the exclusion or limitation of incidental or consequential damages, or the exclusion of implied warranties, so the above limitations and exclusions may not be applicable. Warranty Service
If the product needs to be shipped for service, carefully pack (preferably in the original carton) and enclose a letter, detailing the complaint. Send prepaid and adequately insured to the local authorized Panasonic Service Centre in your area or to Panasonic Technical Support and Product Services Department, 5770 Ambler Drive, Mississauga, Ontario, L4W 2T3. Shipping to the latter location requires a return authorization before shipment. No liability is assumed for loss or damage to the product while in transit.
THIS EXPRESS, LIMITED WARRANTY IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING ANY IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT WILL PANASONIC CANADA INC. BE LIABLE FOR ANY SPECIAL, INDIRECT OR CONSEQUENTIAL DAMAGES. • Dust, smoke, rental/staging environment and twenty-four/seven operation,
dramatically decreases the interval between performances of routine preventive maintenance required to maintain this warranty coverage.
2 years (burn-in not covered) 2 years
All Plasma displays
(for Canada)
(for the U.S.A and Puerto Rico)
FEATURES 3D Y/C FILTER, CLOSED CAPTION,
V-Chip, Vesa compatible, Integrated Pro: Idiom
Operating Conditions Temperature: 32 °F – 95 °F (0 °C – 35°C)
Humidity: 20 % – 80 % RH (non-condensing)
Channel Capability-
ATSC/NTSC (Digital/Analog) VHF/ UHF: 2 - 69, CATV: 1 - 135 (support MPEG4 H.264 decode)
PC signals
VGA, SVGA, XGA, WXGA, SXGA
Horizontal scanning frequency 31 - 69 kHz
Vertical scanning frequency 59 - 86 Hz
Connection Terminals
VIDEO IN 1-2 VIDEO: RCA PIN Type × 1
1.0 V[p-p] (75 Ω)
AUDIO L - R: RCA PIN Type × 2
0.5 V [rms]
COMPONENT IN
Y: RCA PIN Type × 1 1.0 V [p-p] (including synchronization)
Pb: RCA PIN Type × 1 ±0.35 V [p-p]
Pr: RCA PIN Type × 1 ±0.35 V [p-p]
AUDIO L - R:RCA PIN Type × 2 0.5 V [rms]
HDMI 1-3 TYPE A Connector × 3
•This TV supports “HDAVI Control 5” function.
PC IN
D-SUB 15PIN: R,G,B / 0.7 V [p-p] (75 Ω)
HD, VD / 1.0 - 5.0 V [p-p] (high impedance)
AUDIO: M3 JACK × 1 0.5 V [rms]
SERIAL CTRL M3 Jack × 1 (RS232C)
DATA/MTI RJ-11C (6pin)
•Multiple Television Interface (MTI)
AUDIO OUT M3 JACK × 1 0.5 V [rms] (high impedance)
DIGITAL AUDIO OUT PCM / Dolby Digital, Fiber Optic (TH-42LRU60, TH-50LRU60, TH-65LRU60)
USB USB2.0 Type A connector DC 5V, Max. 500mA
■
Set-up
Place the TV at a comfortable distance for viewing. Avoid placing it where sunlight or other bright light (including reflections)
will fall on the screen. Use of some types of fluorescent lighting can reduce remote control transmitter range. Adequate
ventilation is essential to prevent an internal component failure. Keep away from areas of excessive heat or moisture.
Please visit the Panasonic website about
screw location template.
http://panasonic.net
Put the template where the TV is installed.
A
Install securely with assembly screws .
(Total 4 screws)
Tighten screws firmly.
For TH-65LRU60, only installing screws is
needed in “Set-up”.
One of the screws
can be replaced with
a security screw
if necessary.
I
Bottom plate
screw hole
Screw location template
Insert
0.24 ”(6 mm)
Slide
Install the TV firmly to the desk using the
hole of bottom plate.
Install screws through screw eyelid guide
as indicated on the template. (Total 4 screws)
G
A screw can be replaced
with a security screw if
necessary.
Install securely with an assembly screw .
Tighten screws firmly.
WARNING
Do not disassemble or modify the pedestal.
The TV may fall over and become damaged, and personal injury may result.
Caution
Do not use any other TV and displays.
The TV may fall over and become damaged, or cause personal injury.
Do not use the pedestal if it becomes warped or physically damaged.
If you use the pedestal when it is physically damaged, personal injury may result. Contact your nearest Panasonic dealer
immediately.
During set-up, make sure that all screws are securely tightened.
If sufficient care is not taken to ensure screws are properly tightened during assembly, the pedestal will not be strong
enough to support the TV, and it might fall over and become damaged, and personal injury may result.
RF connection*2
RF connection*2
(TH-32LRU60/TH-39LRU60/
TH-42LRU60/TH-50LRU60)
(TH-65LRU60)
*1
Back of the TV
Insert the power cord plug
(included) firmly into place.
When disconnecting the power cord,
be absolutely sure to disconnect the
power cord plug from the wall outlet
first.
The included power cord is for use
with this unit only.
