Panasonic NE-1856-2 User manual

A
1234567890
x2
x3
B
A
1234567890
x2
x3
B
NE-1856-2
Except for
NE-1856-2

- 8 -
(1) Digital Display Window (see below)
(2) Power Level Indicator Display
(3) Program pad
(4) Shift (A/B) pad
(5) Power Level Selector pad
(6) Double Quantity pad
(7) Treble Quantity pad
(8) Number/Memory pads
(9) Stop/Reset pad
(10) Start pad
(11) Oven Lamp Cover
(12) Door Handle
(13) Air Filter
(14) Splatter Shield (top of inner cavity)
(15) Middle Shelf (NE-1856-2 only)
A –– Program Display
B –– Heating Time Display (min. sec.)
C –– Memory Pad Number Display
D –– 1st Stage Heating Indicator
E –– 2nd Stage Heating Indicator
F –– 3rd Stage Heating Indicator
G –– Power Level Indicator
:HIGH
: MEDIUM
: DEFROST
A
1234567890
B
(13)
(11)
(12)
(14)
(15)
(8)
(1) (2) (3)(4) (5) (6)(7) (9) (10)
x2
x3
PROG
231
AB
C
DE F
G
This oven is preset at the factory for the following:
◆Manual operation
◆Number/Memory pads preset HIGH power at the indicated heating times for single stage heating
1 = 10 sec. 2 = 20 sec. 3 = 30 sec. 4 = 40 sec. 5 = 50 sec.
6 = 1 min. 7 = 1 min. 15 sec.8 = 1 min. 30 sec.9 = 1 min. 45 sec.0 = 2 min.
(There are two sides, A and B. Only A-side is preset.)
◆Program Unlock
◆Cycle Counter set to “0”on all pads
If you wish to change these times, please consult the operating instructions to find how to program them.
Outline Diagram NE - 2156/NE - 1856/NE - 1856-2/NE - 1456

- 9 -
A. MANUAL HEATING –– single stage heating ––
Example: To cook food at HIGH power for 2 minutes
INSTRUCTION DIGITAL DISPLAY WINDOW PAD
2Press Power Level Selector pad once.
☛The selected power level will be indicated and 1st Stage Heating
Indicator “1”will start to blink.
Note: To select HIGH power, press once. To select MEDIUM power, press
twice. To select DEFROST power, press three times.
1
3Press Number/Memory pads “2”,“0”and “0”.
☛The set heating time will appear.
Note: up to 15 min. on HIGH or MEDIUM power, 30 min. on DEFROST
2 0 0
1
4Press Start pad.
☛The oven lamp will turn on and heating will start. Power Level Indicator
will start to blink, and heating time will count down.
1
1
•When all time expires, beep tone will sound and heating will stop. The oven lamp will
turn off. “0”will blink until the door is opened. One minute later, cooling fan will stop.
•Open the door and take the food out. The oven lamp will turn on. Digital Display Window
will show the originally selected time and power.
•Close the door. The oven lamp will turn off. One minute later, Digital Display Window will
go blank.
1
1Open the door and put the food in the oven.
☛The oven lamp will turn on and “0”will appear.
Note: While “0”appears, operation is available. One minute after the door
is closed, “0”will disappear.
How to Operate NE - 2156/NE - 1856/NE - 1856-2/NE - 1456
