8 EXPLODED VIEW AND PARTS LIST 8.1. EXPLODED VIEW
29
NN-CS596A / NN-CS596S

8.2. PARTS LIST
NOTE:
1. When ordering replacement part(s), please use part number(s) shown in this part list.
Do not use description of the part.
2. Important safety notice:
Components identified by mark have special characteristics important for safety.
When replacing any of these components, use only manufacture’s specified parts.
Ref. No. Part No. Part Name & Description Pcs/Set Remarks
1F00066V00HP CAUTION LABEL 1EXCEPT ZPE
1F00066W10ZP CAUTION LABEL 1ZPE
2F10016Y40XPG BASE 1
3F10087J60XP RUBBER FOOT 2
4F10084T00AP RUBBER FOOT 1
5F1008-1F90 RUBBER FOOT 1
6F110D6Y40SXP CABINET BODY 1EXCEPT HPE & QPQ
6F110D6Y40SHP CABINET BODY 1HPE
6F110D6Y40SBP CABINET BODY 1QPQ
7F200A6Y40HP OVEN 1
92M261-M32JY MAGNETRON 1
10 F400A7J70MP FAN MOTOR 1
11 F40085G10XN FAN BLADE 1
12 F40257J70XPG AIR GUIDE A 1
13 F40267J70XPG AIR GUIDE B 1
14 F30977J70XP SPRING 2
15 F31027J70XP LATCH SWITCH LEVER 1
16 F31037J70XP DOOR HOOK 1
17 F31057J70XP LATCH BRACKET 1
18 F32497J70XP LATCH SWITCH LEVER 1
19 F612E6Y40BP INCANDESCENT LAMP(U) 1
20 F60746Y40XPG INCANDESCENT LAMP BRACKET 1
21 F64377J70XP GLASS 1
22 F010T6Y40HP CERAMIC PLATE (U) 1HPE,YPQ,YTE,MPQ
22 F010T6Y40BP CERAMIC PLATE (U) 1KTE,PTE,QPQ
22 F010T6Y40ZP CERAMIC PLATE (U) 1ZPE
23 F202K6Y40XPG ANTENNA STIRRER (U) 1
24 F61447J70XP STIR MOTOR 1
25 F20197J70XP ANTENNA BRACKET 3
26 F61425U30XN MICRO SWITCH 1(V-15G-3C25) (PRIMARY LATCH SWITCH)
27 A61425180AP MICRO SWITCH 1(D3V-16G-3C25) (SECONDARY LATCH SWITCH)
28 A61785180AP MICRO SWITCH 1(D3V-1G-2C25) (SHORT SWITCH)
29 F603Y6Y40XP D.P.CIRCUIT (DU) 1
30 F62306V60BP FUSE 110A/250V
31 F692Y6Y40XP NOISE FILTER(U) 1HPE,YPQ,YTE,MPQ,KTE,PTE
31 F692Y6Y40ZP NOISE FILTER(U) 1QPQ,ZPE
32 F45006Y40XP JACKET 1
33 F900C6Y40YK AC CORD W/PLUG 1HPE,YTE,MPQ,KTE
33 F900C6Y40YP AC CORD W/PLUG 1YPQ
33 F900C6Y40PT AC CORD W/PLUG 1PTE
33 F900C7J70ZP AC CORD W/PLUG 1ZPE
33 F900C6Y40QP AC CORD W/PLUG 1QPQ
34 F20347J70XPG REINFORCE BRACKET A 1
35 F2036-1K00 REINFORCE BRACKET B 1
36 F606YM300BP H.V.INVERTER (U) 1QPQ
36 F606YM300GP H.V.INVERTER (U) 1EXCEPT QPQ
37 F80236Y40BP DECORATING PLATE (COLLECTOR PAN) 1
38 F6585-1K00 INVERTER BRACKET A 1
39 F67637J70XP INVERTER BRACKET B 1
40 F630G6Y40XP HEATER 2HPE,YTE,KTE,PTE,ZPE
40 F630G6Y40MP HEATER 2YPQ,MPQ,QPQ
41 F630F6Y40HP HEATER 1HPE,YTE,KTE,PTE,ZPE
41 F630F6Y40MP HEATER 1YPQ,MPQ,QPQ
43 F611E6Y40HP HEATER (DU) 1HPE,YTE,KTE,PTE,ZPE
43 F611E6Y40MP HEATER (DU) 1YPQ,MPQ,QPQ
44 F61457J70XP THERMAL CUTOUT 2
45 F66266Y40XPG THERMAL CUTOUT BRACKET 1
48 F01506W50XP NO TOUCHING LABEL 1EXCPTE HPE
48 F01508G60HP NO TOUCHING LABEL 1HPE
49 F22377J70XPG LEFT HEATER PANEL 1
30
NN-CS596A / NN-CS596S

Ref. No. Part No. Part Name & Description Pcs/Set Remarks
50 F22367J70XPG RIGHT HEATER PANEL 1
51 F300B7J70XP LEFT HINGE (U) 1
52 F300U7J70XP RIGHT HINGE (U) 1
53 F601L7J70XP IR SENSOR (U) 1
54 A6760-1E20 SWING MOTOR 1
55 F44966Y40XP NOZZLE A 1
56 F45137J70XP TIE-IN C 1
57 F92017J70XP COPPER PIPE 1
58 F46507J70XP TUBE C 1
59 F92047J70XP TUBE D 1
60 F03346Y40HP MENU LABEL 1HPE,YPQ,YTE,MPQ
60 F03346Y40KT MENU LABEL 1KTE,PTE
60 F03346Y40ZP MENU LABEL 1ZPE
60 F03346Y40QP MENU LABEL 1QPQ
61 F90717J70XP SUPPORTER 1
62 XTWFA4+12T SCREW 4FOR MAGNETRON
63 XTWFA4+12D SCREW 4FOR CABINET BODY
65 F202Q6Y40BP UPPER HEATER PANEL 1
66 F15676Y40XP DRIP PLATE 1
67 F22776Y40XP LOWER HEATER PANEL 1
68 F10596Y40BP BACK COVER 1
69 F10586Y40BP SIDE COVER 1
70 F10576Y40XP BACK COVER C 1
71 F40306Y40BP EXHAUST GUIDE D 1
72 F41706Y40BP HEATER MOUNTING PLATE 1
74 F22394V00BP CONVECTION FAN BLADE 1
75 F41594V00BP COOLING FAN BLADE 1
79 F41806Y40BP CONVECTION FAN BRACKET 1
80 F490S6Y40XP CONVECTION FAN MOTOR 1
81 F631D6Y40XP CONVECTION HEATER 1HPE,YTE,KTE,PTE,ZPE
81 F631D6Y40BP CONVECTION HEATER 1YPQ,MPQ,QPQ
82 F64174V00BP HEATER BRACKET A 1
83 F66796Y40BP CONVECTION INSIDE COVER A 1
85 F607J6Y40BP CONVECTION ASSEMBLY(BU) 1(INCLUDING IN CONVECTION OUTSIDE COVER B &
ADIABATIC MATERIAL)
86 F67356Y40XP HEATER PROTECTOR 1
87 F02395E20KN CORD CAUTION LABEL 1KTE,PTE
89 F40276Y40BP INVERTER AIR GUIDE 1
90 F50586Y40XP BRACKET 1
91 F50596Y40XP COVER 1
92 F60586Y40XP CIRCUIT BREAKER 1
93 F03586Y40XP CIRCUIT BREAKER HARNESS 1
94 F66286Y40BP THERMAL CUTOUT BRACKET 1
98 F15607J70ZP ALUMINUM PLATE 1QPQ,ZPE
100 F01576Y40HP NAME PLATE 1HPE
100 F01576Y40YP NAME PLATE 1YPQ
100 F01576Y40YT NAME PLATE 1YTE
100 F01576Y40MP NAME PLATE 1MPQ
100 F01576Y40KT NAME PLATE 1KTE
100 F01576Y40PT NAME PLATE 1PTE
100 F01576Y40ZP NAME PLATE 1ZPE
101 F00066W10MP CAUTION LABEL 1YPQ
101 F00068H00YT CAUTION LABEL 1YTE
102 F02846Y40YP NO. LABEL 1YPQ
103 F11656Y40KT REINFORCE BRACKET E 1
31
NN-CS596A / NN-CS596S

8.3. WATER TANK ASSEMBLY
Ref. No. Part No. Part Name & Description Pcs/Set Remarks
T1 F060Q6Y40XP WATER TANK (U) 1(INCLUDING TANK COVER & SEAL)
T2 F061A6Y40XP WATER TANK 1
T3 F06116Y40XP TANK COVER 1
T4 F44247J70XP SEAL 1
32
NN-CS596A / NN-CS596S

8.4. ESCUTCHEON BASE ASSEMBLY
8.4.1. NN-CS596A HPE/YPQ/MPQ/YTE/KTE/PTE
Ref. No. Part No. Part Name & Description Pcs/Set Remarks
E1 F603L6Y40HP D.P.CIRCUIT (AU) 1HPE
E1 F603L6Y40YP D.P.CIRCUIT (AU) 1YPQ
E1 F603L6Y40YT D.P.CIRCUIT (AU) 1YTE
E1 F603L6Y40MP D.P.CIRCUIT (AU) 1MPQ
E1 F603L6Y40PT D.P.CIRCUIT (AU) 1KTE,PTE
E2 F605S6Y40XP D.P.CIRCUIT (HU) 1
E3 F630Y6Y40SHP MEMBRANE SWITCH(U) 1HPE,YPQ,YTE,MPQ
E3 F630Y6Y40SKT MEMBRANE SWITCH(U) 1KTE,PTE
E4 F800A6Y40SHP ESCUTCHEON BASE (U) 1HPE,YPQ,YTE,MPQ (INCLUDING MEMBRANE SWITCH(U))
E4 F800A6Y40SKT ESCUTCHEON BASE (U) 1KTE,PTE (INCLUDING MEMBRANE SWITCH(U))
E5 F800B6Y40SXP ESCUTCHEON BASE (BU) 1
E6 F803G8J00SXP POP-UP DIAL (U) 2HPE,YPQ,YTE,MPQ,KTE,PTE
E7 F80186Y40XP BRACKET 1HPE,YPQ,YTE,MPQ,KTE,PTE
E8 F81246Y40XP BREAKWATER 1HPE,YPQ,YTE,MPQ,KTE,PTE
E9 F80876Y40XP EARTH LEAD 1HPE,YPQ,YTE,MPQ,KTE,PTE
E10 F400L6Y40XP PUMP-LED(U) 1(INCLUDING PUMP & LED PCB)
E11 F83876Y40XP BUTTON 1HPE,YPQ,YTE,MPQ,KTE,PTE
E12 F06397J70XP PUMP BRACKET 1
E13 F66166Y40BP FLAT CABLE 1(WIDE ONE)
E14 F66166Y40XP FLAT CABLE 1(NARROW ONE)
E15 F44266Y40BP SEAL B 1
E16 F46487J70XP TUBE A 1
E17 F46497J70XP TUBE B 1
E18 F45126Y40BP TIE-IN B 1
33
NN-CS596A / NN-CS596S

8.5. ESCUTCHEON BASE ASSEMBLY
8.5.1. NN-CS596S QPQ/ZPE
Ref. No. Part No. Part Name & Description Pcs/Set Remarks
E21 F603L6Y40ZP D.P.CIRCUIT (AU) 1ZPE
E21 F603L6Y40QP D.P.CIRCUIT (AU) 1QPQ
E22 F605S6Y40XP D.P.CIRCUIT (HU) 1
E23 F630Y6Y40SQP MEMBRANE SWITCH(U) 1QPQ
E23 F630Y6Y40SZP MEMBRANE SWITCH(U) 1ZPE
E24 F800A6Y40SQP ESCUTCHEON BASE (U) 1QPQ (INCLUDING MEMBRANE SWITCH(U))
E24 F800A6Y40SZP ESCUTCHEON BASE (U) 1ZPE (INCLUDING MEMBRANE SWITCH(U))
E25 F800B6Y40SBP ESCUTCHEON BASE (BU) 1QPQ,ZPE
E26 F803G6Y40SBP POP-UP DIAL (U) 2QPQ,ZPE
E30 F400L6Y40XP PUMP-LED(U) 1(INCLUDING PUMP & LED PCB)
E31 F83876Y40QP BUTTON 1QPQ
E31 F83876Y40BP BUTTON 1ZPE
E32 F06397J70XP PUMP BRACKET 1
E33 F66166Y40BP FLAT CABLE 1(WIDE ONE)
E34 F66166Y40XP FLAT CABLE 1(NARROW ONE)
E35 F44266Y40BP SEAL B 1
E36 F46487J70XP TUBE A 1
E37 F46497J70XP TUBE B 1
E38 F45126Y40BP TIE-IN B 1
E39 F80876Y40BP GROUNDING PANEL 1QPQ,ZPE
E40 F01576Y40QP NAME PLATE 1QPQ
34
NN-CS596A / NN-CS596S

8.6. DOOR ASSEMBLY
Ref. No. Part No. Part Name & Description Pcs/Set Remarks
D1 F390L6Y40SXP DOOR(U) 1HPE,YPQ,YTE,MPQ,KTE,PTE (INCLUDING DOOR C & SEAL)
D1 F390L6Y40SEP DOOR(U) 1QPQ,ZPE (INCLUDING DOOR C & SEAL)
D2 F30856Y40XP DOOR C 1
D3 A3334-1K00 SEAL 1
D4 F30546Y40BP DOOR ARM (LEFT) 1
D5 F30446Y40BP DOOR ARM (RIGHT) 1
D6 F32316Y40XP DOOR KEY SPRING A 1
D7 F32307J70XP DOOR KEY SPRING B 1
D8 F302A6Y40SXP DOOR B (U) 1HPE,YPQ,YTE,MPQ,KTE,PTE
D8 F302A6Y40SEP DOOR B (U) 1QPQ,ZPE
D9 F01726V00JP CAUTION LABEL B 1QPQ
8.7. WIRING MATERIALS
Ref. No. Part No. Part Name & Description Pcs/Set Remarks
W1 F030A6Y40XP LEAD WIRE HARNESS 1
W2 F030E7J70XP H.V.LEAD WIRE 1
35
