Panasonic SCHC20 - COMPACT STEREO SYSTEM User manual

g Common problems
Incorrect display or play will not start
You have not inserted the disc properly. Insert it correctly.
The disc is scratched or dirty (Tracks skipped).
There is moisture on the lens. Wait for about an hour and then try again.
MP3 cannot be read
You may not be able to play MP3 if you have copied a multi-session disc that has no data between
sessions.
When creating a multi-session disc, it is necessary to close the session.
The amount of data on the disc is too small. Set the amount of data to above 5 MB.
Noise is heard or no sound
While playing MP3, noise may occur if the recording is poor.
Keep this unit away from mobile phones if the interference is apparent.
Turn the volume up.
Switch the unit off, check and correct the connection and then switch the unit on. Causes include
straining of the speakers through excessive volume or power and using the unit in a hot environment.
Humming heard during play
An AC mains lead or fluorescent light is near the cords. Keep other appliances and cords away from
this unit’s cables.
A beat sound or noise is heard while receiving radio broadcast
Switch the television or other audio player off or separate it from the unit.
Switch the portable audio player off if connected to the AUX port.
A low hum or noise is heard during AM broadcast
Keep the antenna away from other cables and cords.
Keep the AM antenna away from the unit.
The picture on the television near the unit disappears or stripes appear on the screen
The location and orientation of the antenna are incorrect.
The television antenna wire is too close to the unit. Separate the antenna wire of the television from
the unit.
No response when remote control buttons are pressed
Check that the batteries are inserted correctly (➡ Section 2).
g Display
“--:--”
You plugged the AC mains lead in for the first time or there was a power failure recently. Set the time
(➡ Section 6).
“ADJUST CLOCK”
Clock is not set. Adjust the clock accordingly.
“ADJUST TIMER”
Play timer is not set. Adjust the play timer accordingly.
“PGM FULL”
The number of programmed tracks is limited to 24. No further tracks can be programmed.
“NO PLAY”
A CD-ROM disc that is not in CD-DA or MP3 format is inserted. It cannot be played.
“ERROR”
Incorrect operation is performed. Read the instructions and try again.
“F61” or “F76”
There is a power supply problem. Consult the dealer.
“AUTO OFF”
The unit has been left unused for about 29 minutes and will shut down in a minute. Press any button to
cancel it.
“ILLEGAL OPEN”
Sliding door is not in correct position. Turn the unit off and on again.
“NODEVICE”
The iPod/iPhone device is not inserted correctly. Read the instructions and try again
(➡ Section 8).
“REMOTE 1”
The main unit is in “REMOTE 1” mode. Switch the remote control to “REMOTE 1” mode
(➡ Section 9).
“REMOTE 2”
The main unit is in “REMOTE 2” mode. Switch the remote control to “REMOTE 2” mode
(➡ Section 9).
g iPod/iPhone
iPod/iPhone does not turn on
Verify that the iPod/iPhone battery is not depleted before connecting it to the unit.
Before inserting the iPod/iPhone into the dock, turn both the unit and the iPod/iPhone off. Turn the
power on and select the appropriate source.
No sound is heard from the speakers
The iPod/iPhone is not inserted correctly into the dock. Turn the iPod/iPhone off and remove it from
the dock connector. Reinsert it and turn it on again.
Make sure that the iPod/iPhone is actually playing something.
Adjust the volume.
Distorted sound or the sound level is too low
Make sure the equalizer function of the
iPod/iPhone is turned off.
iPod/iPhone cannot be controlled by the remote control or main unit
Make sure the iPod/iPhone is inserted properly into the dock.
Check the dock connection and make sure that iPod/iPhone is selected as the source of music
(➡ Section 8).
iPod/iPhone does not charge
Check all connections (➡ Section 1, 8 ).
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
g AMPLIFIER SECTION
RMS Output Power Stereo mode
Front Ch (both ch driven)
5 W per channel (6 Ω), 1 kHz, 10 % THD
Phone jack
Terminal Stereo, 3.5 mm jack
Output level (CD, 1 kHz, -20 dB)
max. 0.385 mW + 0.385 mW, 32 Ω
Aux (Rear)
Sensitivity
Normal level 504 mV, 12.4 kΩ
High level 100 mV, 12.4 kΩ
Terminal Stereo, 3.5 mm jack
g TUNER SECTION
Preset Memory FM 30 stations
AM 15 stations
Frequency Modulation (FM)
Frequency range
87.50 MHz to 108.00 MHz (50 kHz step)
Antenna terminals 75 Ω (unbalanced)
Amplitude Modulation (AM)
Frequency range
522 kHz to 1629 kHz (9 kHz step)
520 kHz to 1630 kHz (10 kHz step)
g DISC SECTION
Disc played [8 cm or 12 cm]
(1) CD-Audio (CD-DA)
(2) CD-R/RW (CD-DA, MP3)
(3) MP3*
* MPEG-1 Layer 3, MPEG-2 Layer 3
Pick up
Wavelength 785 nm
Laser power CLASS 1
Audio Output (Disc)
Number of channels FL, FR, 2 channel
g SPEAKER SECTION
Type 1 way, 1 speaker system (Bass reflex)
Speaker unit(s)
Full range 8 cm Cone type
Impedance 6 Ω
Output sound pressure 83 dB/W (1.0 m)
Frequency range 60 Hz to 25 kHz (-16 dB)
90 Hz to 22 kHz (-10 dB)
g GENERAL
Power supply AC 220 V to 240 V, 50 Hz
Power consumption 18 W
Dimensions (W x H x D)
384 mm x 214 mm x 112 mm
(D = 69 mm minimum)
(D = 147 mm tray open)
Mass Approx. 2.1 kg
Operating temperature range 0 °C to +35 °C
Operating humidity range
35 % to 80 % RH (no condensation)
CAUTION!
DO NOT INSTALL OR PLACE THIS UNIT
IN A BOOKCASE, BUILT-IN CABINET OR
IN ANOTHER CONFINED SPACE. ENSURE
THE UNIT IS WELL VENTILATED. TO
PREVENT RISK OF ELECTRIC SHOCK OR
FIRE HAZARD DUE TO OVERHEATING,
ENSURE THAT CURTAINS AND ANY OTHER
MATERIALS DO NOT OBSTRUCT THE
VENTILATION VENTS.
DO NOT OBSTRUCT THE UNIT’S
VENTILATION OPENINGS WITH
NEWSPAPERS, TABLECLOTHS, CURTAINS,
AND SIMILAR ITEMS.
DO NOT PLACE SOURCES OF NAKED
FLAMES, SUCH AS LIGHTED CANDLES, ON
THE UNIT.
DISPOSE OF BATTERIES IN AN
ENVIRONMENTALLY FRIENDLY MANNER.
•
•
•
•
or
WARNING:
TO REDUCE THE RISK OF FIRE, ELECTRIC
SHOCK OR PRODUCT DAMAGE,
* DO NOT EXPOSE THIS APPARATUS
TO RAIN, MOISTURE, DRIPPING OR
SPLASHING AND THAT NO OBJECTS
FILLED WITH LIQUIDS, SUCH AS VASES,
SHALL BE PLACED ON THE APPARATUS.
* USE ONLY THE RECOMMENDED
ACCESSORIES.
* DO NOT REMOVE THE COVER (OR BACK);
THERE ARE NO USER SERVICEABLE
PARTS INSIDE. REFER SERVICING TO
QUALIFIED SERVICE PERSONNEL.
Inside of product
RQLS0418
CAUTION!
THIS PRODUCT UTILIZES A LASER.
USE OF CONTROLS OR ADJUSTMENTS
OR PERFORMANCE OF PROCEDURES
OTHER THAN THOSE SPECIFIED HEREIN
MAY RESULT IN HAZARDOUS RADIATION
EXPOSURE.
DO NOT OPEN COVERS AND DO NOT
REPAIR YOURSELF. REFER SERVICING TO
QUALIFIED PERSONNEL.
THIS UNIT IS INTENDED FOR USE IN
MODERATE CLIMATES.
The socket outlet shall be installed near the
equipment and easily accessible.
The mains plug of the power supply cord shall
remain readily operable.
To completely disconnect this apparatus from the
AC Mains, disconnect the power supply cord plug
from AC receptacle.
This product may receive radio interference caused
by mobile telephones during use. If such
interference is apparent, please increase
separation between the product and the mobile
telephone.
MPEG Layer-3 audio decoding technology licensed
from Fraunhofer IIS and Thomson.
H0310HU2050
Operating Instructions
Compact Stereo System
Model No. SC-HC20
RQTX1058-2B
GN En
Panasonic Corporation
Web Site: http://panasonic.net
Dear customer
Thank you for purchasing this product.
Before connecting, operating or
adjusting this product, please read the
instructions completely. Please keep
this manual for future reference.
Operations in these instructions are
described using remote control, but you
can do the operations with the main
unit if the controls are the same.
Your unit may not look exactly as
illustrated
Please check and identify the supplied
accessories.
Supplied accessories
The included AC mains lead is for use with this unit only.
Do not use it with other equipment.
Do not use an AC mains lead of other equipment.
•
•
 1 AC mains lead
 1 FM indoor antenna
 1 AM loop antenna
 2 Batteries
CAUTION
Danger of explosion if battery is incorrectly
replaced. Replace only with the same
or equivalent type recommended by the
manufacturer. Dispose of used batteries
according to the manufacturer’s instructions.
The remote control and main unit are factory-set to “REMOTE 1” mode.
If you find the remote control unintentionally also controls other equipment, you can switch to operate in
“REMOTE 2” mode.
To switch to “REMOTE 2” mode (by main unit
only)
 Press [FM/AM/AUX] to select ‘‘AUX’’.
 Press and hold [FM/AM/AUX] and then press
[2] until “REMOTE 2” is displayed.
 Press and hold [OK] and [2] for at least 2
seconds.
To return to “REMOTE 1” mode
Repeat the steps (➡ left) but replace [2] with [1].
(“REMOTE 1” will be displayed.)
Troubleshooting guide
Before requesting service, make the following checks. If you are in doubt about some of the check
points, or if the remedies indicated in the chart do not solve the problem, consult your dealer for
instructions.
10
“Made for iPod” means that an electronic accessory has been designed to connect specifically to iPod
and has been certified by the developer to meet Apple performance standards.
“Works with iPhone” means that an electronic accessory has been designed to connect specifically to
iPhone and has been certified by the developer to meet Apple performance standards.
Apple is not responsible for the operation of this device or its compliance with safety and regulatory
standards.
iPod is a trademark of Apple Inc., registered in the U.S. and other countries. iPhone is a trademark of
Apple Inc.
g Pull out the power plug from the outlet for
maintenance beforehand and then wipe it
using a soft and dried cloth.
When dirt is heavy, wring the cloth moistened
in water tightly to wipe the dirt, and then wipe it
with a dried cloth.
Do not use solvents such as benzine, thinner,
alcohol and detergent, which may deform the
coating of the outer case.
•
•
When using a chemical cloth, follow the
precautions.
g Care on the CD lens
Clean the lens regularly to prevent malfunctions.
Use a blower to remove dust and a cotton swab
if it is extremely dirty.
Do not use the lens cleaner of the CD type.
•
•
•
Maintenance
Power consumption in standby mode:
0.3 W (approx.)
Specifications are subject to change without
notice.
Total harmonic distortion is measured by the
digital spectrum analyser.
•
•
Specifications
11
Placement
Set the unit up on an even surface away
from direct sunlight, high temperatures, high
humidity, and excessive vibration. These
conditions can damage the cabinet and other
components, thereby shortening the unit’s
service life.
Do not place heavy items on the unit.
Voltage
Do not use high voltage power sources.
This can overload the unit and cause a fire.
Do not use a DC power source. Check the
source carefully when setting the unit up on
a ship or other place where DC is used.
AC mains lead protection
Ensure the AC mains lead is connected
correctly and not damaged. Poor connection
and lead damage can cause fire or electric
shock. Do not pull, bend, or place heavy
items on the lead.
Grasp the plug firmly when unplugging the
lead. Pulling the AC mains lead can cause
electric shock.
Do not handle the plug with wet hands.
This can cause electric shock.
Foreign matter
Do not let metal objects fall inside the unit.
This can cause electric shock or malfunction.
Do not let liquids get into the unit. This
can cause electric shock or malfunction. If
this occurs, immediately disconnect the unit
from the AC mains supply and contact your
dealer.
Do not spray insecticides onto or into the
unit. They contain flammable gases which
can ignite if sprayed into the unit.
Service
Do not attempt to repair this unit by
yourself. If sound is interrupted, indicators
fail to light, smoke appears, or any other
problem that is not covered in these
instructions occurs, disconnect the AC
mains lead and contact your dealer or an
authorized service centre. Electric shock or
damage to the unit can occur if the unit is
repaired, disassembled or reconstructed by
unqualified persons.
Extend operating life by disconnecting the
unit from the AC mains if it is not to be used
for a long time.
Safety precautions
12
9Changing the main unit and remote
control mode
RQT4389ZAA
 1 Remote control (N2QAYB000518)
Information on Disposal in other Countries outside the European Union
This symbol is only valid in the European Union.
If you wish to discard this product, please contact your local authorities or dealer and ask for
the correct method of disposal.
-If you see this symbol-
Notes on CD-R and CD-RW
This unit can play CD-R and CD-RW recorded
with CD-DA or MP3.
Use an audio recording disc for CD-DA and
finalise* it when you finish recording.
* A process performed after recording that
enables CD-R or CD-RW players to play
audio CD-R and CD-RW.
The unit may not be able to play some discs
due to the condition of the recording.
Do not use irregularly shaped CDs.
Do not attach extra labels and stickers.
Do not use CDs with labels and stickers that
are coming off or with excessive adhesive
under the labels and stickers.
Do not attach scratch-proof covers or any other
kind of accessories.
Do not write anything on the CDs.
Do not clean CDs with liquids (Wipe with a soft
and dried cloth).
Creating MP3 files playable on this unit
Maximum number of tracks and albums: 999
tracks and 255 albums.
Compatible compression rate: Between 64
kbps and 320 kbps (stereo). 128 kbps (stereo)
is recommended.
Disc formats: ISO9660 level 1 and level 2
(except for extended formats).
The time for reading TOC depends on
the number of the tracks, folders or folder
structures.
•
•
•
•
•
•
•
•
•
•
•
•
•
Limitations on MP3
This unit is compatible with multi-sessions and
it takes more time to start playing.
This unit cannot play files recorded using
packet write.
If the disc includes both MP3 and normal audio
data (CD-DA), the unit plays the type recorded
in the inner part of the disc.
If the disc includes both MP3 and other types of
audio data (e.g. WMA or WAV), the unit plays
only the MP3.
Depending on how you create the MP3 files,
they may not play in the order you numbered
them or may not play at all.
Notes on iPhone:
All phone features can only be controlled by the
iPhone’s touch screen.
The unit does not display incoming calls or the
phone status.
The ringtone of incoming call can be heard
from the iPhone’s speaker. When the unit is in
iPod/iPhone mode, the ringtone can also be
heard from the unit’s speakers.
The voice of caller cannot be heard on the
unit’s speakers. The user can use the iPhone
internal microphone though.
Connecting or disconnecting the iPhone from
the unit will not cancel a call.
There is no Apple Inc. specification that will
guarantee the iPhone responses (➡ Section 8).
iPhone responses may vary on new iPhone
models or iPhone new software updates.
•
•
•
•
•
•
•
•
•
•
■ Compatible iPod
Name Memory size
iPod nano 5th generation (video camera) 8 GB, 16 GB
iPod touch 2nd generation 8 GB, 16 GB, 32 GB, 64 GB
iPod classic 120 GB, 160 GB (2009)
iPod nano 4th generation (video) 8 GB, 16 GB
iPod classic 160 GB (2007)
iPod touch 1st generation 8 GB, 16 GB, 32 GB
iPod nano 3rd generation (video) 4 GB, 8 GB
iPod classic 80 GB
iPod nano 2nd generation (aluminum) 2 GB, 4 GB, 8 GB
iPod 5th generation (video) 60 GB, 80 GB
iPod 5th generation (video) 30 GB
iPod nano 1st generation 1 GB, 2 GB, 4 GB
iPod 4th generation (colour display) 40 GB, 60 GB
iPod 4th generation (colour display) 20 GB, 30 GB
iPod 4th generation 40 GB
iPod 4th generation 20 GB
iPod mini 4 GB, 6 GB
■ Compatible iPhone
Name Memory size
iPhone 3GS 16 GB, 32 GB
iPhone 3G 8 GB, 16 GB
iPhone 4 GB, 8 GB, 16 GB
Compatibility depends on the software version of the iPod/iPhone.•
© Panasonic Corporation 2010
When the following situations occur, reset the memory:
There is no response when buttons are pressed.
You want to clear and reset the memory contents.
To reset memory
 Disconnect the AC mains lead. (Wait for at least 3 minutes before proceeding to step 2.)
 While pressing and holding down [8] on the main unit, reconnect the AC mains lead.
“--------” appears on the display.
 Release [8].
All the settings are returned to the factory preset. You will need to reset the memory items.
•
•
Memory reset (Initialization)
13

Preset EQ Press [PRESET EQ] repeatedly to select “HEAVY”, “SOFT”, “CLEAR”,
“VOCAL” or “FLAT”.
Bass or Treble  Press [BASS/TREBLE] repeatedly to select “BASS” or “TREBLE”.
 Press [e,r] to adjust the level (-4 to +4).
Surround Sound Press [SURROUND] repeatedly during play to select “ON SURROUND” or
“OFF SURROUND”.
If interference in FM stereo reception increases, cancel the surround sound
effect.
D.Bass Press [D.BASS] repeatedly during play to select “ON D.BASS” or
“OFF D.BASS”.
Re-master (MP3) Press [RE-MASTER] repeatedly during play to select “ON RE-MASTER” or
“OFF RE-MASTER”.
 Insert the suitable dock adapter (not
included) for the iPod/iPhone.
Insert the side of the iPod/iPhone dock adapter
with the clips facing towards you first and then
push the opposite side until it clicks into place.
 Connect the iPod/iPhone (not included)
firmly.
Be sure to remove the iPod/iPhone from its
case.
To remove, simply pull the iPod/iPhone
straight out to disconnect it.
When inserting an iPod/iPhone into the unit, be
sure to use the dock adapter either supplied
with the iPod/iPhone or commercially available
from Apple Inc.
When not using the dock, push it back until it
locks.
Reduce the volume of the main unit to
minimum before connecting or disconnecting
the iPod/iPhone.
•
•
•
Standby/on switch [^], [8] (4, 6, 13)
Press to switch the unit from on
to standby mode or vice versa.
In standby mode, the unit is still
consuming a small amount of
power.
[DIMMER]
Dims the display panel. Press
again to cancel.
Numeric buttons [1-9, 0, ≧ 10]
(4, 5, 9)
To select a 2-digit number
e.g. 16: [≧ 10]  [1]  [6]
To select a 3-digit number
e.g. 226: [≧ 10]  [≧ 10]  [2]  [2]  [6]
[DEL] (4)
[PROGRAM] (4, 5)
[REPEAT] (4)
[PLAY MODE] (4, 5)
[RADIO] (5)
[CD q/h] (4)
[iPod q/h] (8)
[u/t], [y/i] (4, 5, 8)
[g] (4, 8)
[RE-MASTER] (7)
[PRESET EQ] (7)
[e,r], [w, q] (4, 6, 7, 8)
[OK] (4, 6, 8, 9)
[DISPLAY] (4)
[AUTO PRESET] (5)
[TUNE MODE] (5)
[z, PLAY] (6)
[CLOCK/TIMER] (6)
[AUTO OFF]
This function allows you to turn
the unit off (except in radio
mode) after the unit is left
unused for about 30 minutes.
Press twice to turn it on.
[SLEEP] (6)
[+, VOL , –], [– VOLUME +]
[MUTE]
Mutes the sound. Press again
to cancel. “MUTE” is also
cancelled when the volume is
adjusted or the unit is turned off.
[AUX] (1)
[D.BASS] (7)
[iPod MENU] (8)
[BASS/TREBLE] (7)
[SURROUND] (7)
[INPUT LEVEL] (1)
[FM MODE] (5)
[FM/AM/AUX] (5, 9)
[CD ;, OPEN/CLOSE] (4)
iPod/iPhone dock (8)
Remote control signal sensor
Aim the remote control at the
sensor, avoiding obstacles, at a
maximum range of 7 m directly
in front of the unit.
■ Batteries
Use a manganese dry battery or an alkaline dry battery.
Insert so the poles (+ and –) match those in the remote control.
Remove if the remote control is not going to be used for a long period of time.
Store in a cool and dark place.
Do not heat or expose to flame.
Do not leave the batteries in an automobile exposed to direct sunlight for a long period of time with
doors and windows closed.
Mishandling of batteries in the remote control can cause electrolyte leakage, which may cause a fire.
•
•
•
•
•
•
•
■ Do not:
mix old and new batteries.
use different types of batteries at the same time.
take apart or short-circuit the batteries.
attempt to recharge alkaline or manganese batteries.
use the batteries if the coverings have been peeled off.
•
•
•
•
•
R6/LR6, AA
Place this side in before the other side.
Preparing the remote control
2
Control guide
3
Top View
VOLUME
30
20
29981
7
Refer to the numbers in parentheses for section reference.•
Front View
PUSH-OPEN
iPod
Display
Transmission window
Approx. 30°
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
Remote control
Main unit
AUD I O SYSTEM
28
27
26
25
24
23
22
21
20
2
18
17
16
3
1
4
5
6
7
8
9
10
11
12
13
19
14
15
1
2
3
g Notes on speakers
These speakers do not have magnetic shielding. Do not place them near televisions,
personal computers or other devices easily influenced by magnetism.
The speaker nets cannot be removed.
•
•
Connections
1
Tape the antenna to a wall or
column, in a position with the
least amount of interference.
•
Connect the FM indoor antenna.
1
1
2
Connect the AM loop antenna.
Stand the antenna up on
its base.
AM loop antenna
2
Click!
Keep the loose antenna cord away from other wires
and cords.
•
Avoid listening for prolonged periods of time to prevent hearing damage.
Excessive sound pressure from earphones and headphones can cause hearing loss.
Listening at full volume for long periods may damage the user’s ears.
Be sure to use the supplied or recommended headphones or earphones.
•
•
•
Reduce the volume level and connect the headphones.
Plug type: 3.5 mm stereo
Headphones (not included)
4
Connect the AC mains lead after all other connections are
complete.
Connect the AC mains lead.
3
To household mains socket
Switch the equalizer off or turn the volume of the portable equipment down to reduce
the input signal. High level of input signal will distort the sound.
For details, refer to the instruction manual of the other equipment.
Cords and equipment are not included.
•
•
•
You can select the sound input level of the portable audio equipment.
Press [INPUT LEVEL] repeatedly to select “HIGH” or “NORMAL”.
 Plug the audio cord into the AUX jack.
Plug type: 3.5 mm stereo
 Press [AUX] and start playback from the portable audio source.
5Portable audio equipment (during AUX mode)
g Placing the unit
Keep a minimum of 50 mm clearance space at the front of the unit to prevent iPod/iPhone
or the unit from dropping.
•
7Sound adjustment
5 Radio operations
Basic play
Press [DISPLAY] repeatedly during play or
pause to view the current track’s information.
Maximum number of displayable characters:
approximately 30
This unit supports ver. 1.0 and 1.1 ID3 tags.
Text data that is not supported will not be
displayed.
•
•
 Press [CD q/h].
 Press [PLAY MODE] repeatedly to select
the following modes.
Play Mode function
Display function
Disc operations
4
 Press [^] to turn the unit on.
 Press [CD ;, OPEN/CLOSE] on the main
unit to open the sliding door.
 Tilt the disc into the disc tray under the
sliding door and then set the CD in place.
 Press [CD ;, OPEN/CLOSE] to close the
sliding door.
Keep fingers away from the sliding door when it
is closing to avoid possible minor injuries.
 Press [CD q/h] to start play.
Damage may occur if the sliding door is forced
closed.
Be careful of CD hitting the sliding door while
being removed.
•
•
Program play
Enables you to program up to 24 tracks.
 Press [CD q/h] and then [g].
 Press [PROGRAM].
CD:  Press the numeric buttons to select
the track.
To program more tracks, continue by
pressing the numeric buttons.
 Press [OK] or [CD q/h] to start play.
 Press [RADIO] to select “FM” or “AM”.
 Press [TUNE MODE] to select “MANUAL”.
 Press [u/t] or [y/i] to select the
frequency of the required station.
To tune automatically
 Repeat step  and  (➡ above).
 Press and hold [u/t] or [y/i] until
the frequency starts changing rapidly.
To cancel auto tuning, press [u/t] or
[y/i] once again.
Auto tuning may not function when there is
excessive interference.
To improve FM sound quality
Press [FM MODE] to display “MONO”
indicator. Press again to cancel.
“MONO” is also cancelled if the frequency is
changed.
Turn “MONO” off for normal listening.
To improve AM sound quality
 Press [RADIO] to select “AM”.
 Press and hold [TUNE MODE] repeatedly
to change the beat proof setting (“BP 1” or
“BP 2”).
•
•
•
•
Manual tuning
Automatic presetting
 Press [PLAY MODE] to switch between
“LOWEST” and “CURRENT” frequency.
 Press [AUTO PRESET] to start presetting.
Manual presetting
 Press [TUNE MODE] to select “MANUAL”.
 Press [u/t] or [y/i] to tune to the
required station.
 Press [PROGRAM].
 Press the numeric buttons to select a
channel.
The station occupying a channel is erased if
another station is preset in that channel.
 To preset more stations, repeat step  to .
Selecting a preset station
 Press [TUNE MODE] to select “PRESET”.
 Press [u/t] or [y/i] to select the
channel.
Alternatively, press the numeric buttons to
select the channel.
•
MP3:  Press [e,r] to select the album.
 Press [y/i] once and then the
numeric buttons to select the track.
 Press [OK].
To program more tracks, repeat step 
to .
 Press [CD q/h] to start play.
Click!
6 Timer
You can set the timer to come on at a certain time
to wake you up.
This unit offers 3 optional play timers.
Preparation:
Turn the unit on and set the clock (➡ above).
Prepare the music source (disc, radio,
iPod/iPhone or AUX) and set the volume.
 Press [CLOCK/TIMER] repeatedly to select
play timer.
 Within 5 seconds, press [e,r] to set the
starting time.
 Press [OK].
 To set the finishing time, repeat step 
and .
To activate the timer
 Press [z, PLAY] repeatedly to turn the
selected play timer on.
 Press [^] to turn the unit off.
•
•
The sleep timer can turn the unit off after a set
time.
Press [SLEEP] to turn the sleep function on or
off.
Press [SLEEP] once to check the remaining
time.
The play timer and sleep timer can be used
together. The sleep timer always has the
priority. Be sure not to overlap the timer
settings.
When AUTO OFF is ON and the unit is left
unused for about 30 minutes, the unit will shut
down even if the play time or sleep time has not
expired.
•
•
Sleep timer
30MIN 60MIN 90MIN 120MIN
OFF (Cancelled)
This is a 24-hour clock.
 Press [CLOCK/TIMER] to select “CLOCK”.
 Within 5 seconds, press [e,r] to set the
time. (Press and hold to change the time
faster.)
 Press [OK].
To display the clock, press [CLOCK/TIMER].
Reset the clock regularly to maintain accuracy.
•
•
Setting the clock
5 Radio operations (continued)
AM allocation setting
The unit may also receive AM broadcast allocated
in 10 kHz step.
To change the step to 10 kHz (by main unit
only)
 Press [FM/AM/AUX] to select “AM”.
 Press and hold [FM/AM/AUX].
After a few seconds the display changes to
display current minimum frequency.
 Continue to hold down [FM/AM/AUX].
When the minimum frequency changes, release
the button.
To return to the original step, repeat step  to
 (➡ left).
After the setting is changed, any previously
preset frequency will be cleared.
•
•
Ventilation holes
1
2
3
45
Back View
Inserting or removing an iPod/iPhone
Charging the iPod/iPhone
When iPod/iPhone is being charged in standby
mode, “IPOD CHARGING” is shown on the
main unit’s display.
Check iPod/iPhone to see if the battery is fully
charged. If you are not using iPod/iPhone for
an extended period of time after recharging has
completed, disconnect it from the main unit as
the battery will be depleted naturally. (Once
fully recharged, additional recharging will not
occur.)
•
•
External unit
8
31
32
FM indoor antenna
Adhesive tape
PUSH-OPEN
iPod
Push!
Stop Press [g].
Pause Press [CD q/h]. Press again
to resume play.
Skip track Press [u/t] or
[y/i].
Search the
current track
(CD)
Press and hold [u/t] or
[y/i].
Skip album
(MP3)
Press [e,r].
Direct access
play
(Play starts with
the track you
select.)
CD: Press the numeric
buttons to select the
track.
MP3: Press [e,r] to select
the album.
 Press [y/i] once
and then the numeric
buttons to select the
track.
Mode To play
1TR
1-TRACK
one selected track on the disc.
Press the numeric buttons to
select the track.
1ALBUM
1-ALBUM
(MP3)
one selected album on the disc.
Press [e,r] to select the album.
RND
RANDOM
a disc randomly.
1ALBUM RND
1-ALBUM
RANDOM
(MP3)
all tracks in one selected album
randomly.
Press [e,r] to select the album.
During random play, you cannot skip to the
previous track.
The current play mode is cleared when you
open the sliding door.
To repeat program play or selected play
mode, press [REPEAT]. Press again to
cancel.
•
•
•
Cancel program
mode
Press [PROGRAM] in the
stop mode to clear “PGM”
indicator from the display.
Replay the
program
Press [PROGRAM] in the
stop mode and then
[CD q/h].
Check program
contents
Press [u/t] or
[y/i] when “PGM”
is displayed in the stop
mode. To check while
programming, press
[PROGRAM] twice after
“PGM” appears and then
press [u/t] or
[y/i].
Delete last
programmed
track
Press [DEL] in the stop
mode.
Clear all
programmed
tracks
Press [g] in the stop mode.
“CLR ALL” is displayed.
Within 5 seconds, press
the button again to clear all
tracks.
The program memory is cleared when you open
the sliding door.
•
Play timer
 Push to open the dock.
Play Press [iPod q/h].
Pause Press [iPod q/h] or [g].
Skip track Press [u/t] or
[y/i].
Search the
current track
Press and hold [u/t] or
[y/i].
Display
iPod/iPhone
menu/return to
previous menu
Press [iPod MENU] in the
play mode.
(Remote control only)
Select
contents from
iPod/iPhone
menu
Press [e,r] and then [OK].
(Remote control only)
Enjoying audio from iPod or iPhone
Change the source
or volume
 Press [z, PLAY]
twice to clear zPLAY
indicator from the
display.
 Make changes to the
source or volume.
 Perform step  and 
(➡ left).
Check the settings
(When the unit is
on or in standby
mode)
Press [CLOCK/TIMER]
repeatedly to select
“zPLAY 1”, “zPLAY 2” or
“zPLAY 3”.
Cancel Press [z, PLAY] twice to
clear the timer indicator
from the display.
The timer will start at the preset time, with the
volume increasing gradually to the preset level.
•
Change the
settings
Repeat step  to 
(➡ above).
4
You can preset up to 30 FM channels and 15 AM
channels.
Preparation: Press [RADIO] to select “FM” or
“AM”.
Memory preset
Approx. 30°
