Panasonic NA-S178X1 Product guide

Operating & Installation Instructions
Washer Dryer
Model No.
NA-S178X1
(Household Use )
Contents
Safety precautions................................................. 2
Part Names / Accessories ..................................... 4
Operation Buttons / Touch Key .............................. 5
Laundry Procedure................................................ 6
Selecting the Programs ......................................... 8
Laundry check and Preparations......................... 10
How to put in Detergemt & Softener.................... 12
Wash / Wash+Dry................................................ 14
Door lock ............................................................. 16
Normal / Normal • StainMaster+.......................... 17
Wash gentle hand wash clothes.......................... 18
Wash large sheets or bedding............................. 19
Drying .................................................................. 20
Maintenance........................................................ 22
• Drain / Dry filter ................................................. 22
• Drum Clean / Drum Dry..................................... 24
Other Notes ......................................................... 25
For Better Results................................................ 26
FAQ...................................................................... 28
Error Messages ................................................... 30
Troubleshooting ................................................... 31
Program Details................................................... 36
Changing the Settings ......................................... 38
Installation ........................................................... 39
Specifications ...................................................... 47
It is essential to read
these instructions.
Correct use will help save more energy and
water!
• Thank you for purchasing this appliance.
- For optimum performance and safety,
please read these instructions carefully.
- Before connecting, operating or adjusting
this appliance, please read the instructions
completely. Please keep this manual for
future reference.
Read Before
Using
Maintenance
References
W9901-S7E10
Wash Instruction

2
CAUTION
May cause minor or moderate
injury or property damage.
4
Safety Precautions
Observe fully.
To prevent the risk of danger to humans or property damage, make sure to follow the precautions described below.
The descriptions are classified according to the degree of harm or damage caused by misuse.
WARNING
May cause serious
injury or death.
Drum/Main Unit
Do not allow children to get
inside the drum.
(Children may get locked inside the drum, which will cause
suffocation, burns, electric shock, injury, or drowning.)

To prevent children from easily climbing on the
appliance, do not put a table, etc. near the appliance.
This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience
and knowledge, unless they have been given
supervision or instruction concerning use of the
appliance by a person responsible for their safety.
Children should be supervised to ensure that they
do not play with the appliance.
Do nothang on the door.
(The appliance may fall over, resulting in injury.)
Never disassemble, repair or remodel.
(Fire or abnormal operation may occur, resulting in injury.)
When taking out the laundry...
Do not touch the laundry inside
the drum until it completely stops.
(Your fingers may be entangled in the laundry even
during slow rotation, resulting in injury.)
Do not put flame or inflammable materials
in or close to the drum/main unit.
(Fire may occur.)
Pyrethrum coil, cigarette, candle, etc.
Do not splash water over the appliance.
Do notinstall at a damp place orplace
which may be exposed to rain, water, etc.
(Electric shock or fire from a short circuit may occur.)
Bathroom
(Lots of
moisture)
Balcony
(Exposed to wind
and rain)

Maintenance
During Use
Never dry the following items.
(even after washing).
(Spontaneous ignition or inflammation may occur
due to heat of combustion of oil.)
Items that have been soiled with substances such
as cooking oil, acetone, alcohol,
petrol, kerosene, spot removers,
turpentine, waxes, wax removers
and cosmetic oils must not be
dried in the appliance even after
having been washed.
Matters to beobserved
The lint filters have to be cleaned frequently.
The lint must not be allowed to accumulate around
the appliance.
Make sure that no objects are left in any of the
pockets. Pay particular attention to cigarette
lighter and matches. They may cause fire.
Fabric softeners, or similar products, should
be used as specified by the fabric softener
instructions.
Prohibited matters
The appliance is not to be used if industrial
chemicals have been used for cleaning.
Do not dry unwashed items in the appliance.
Do not dry items made of polypropylene fibre.








To prevent fire, electric
shock orinjury
WARNING
Saftey Precautions Obesrve fully.
●●The nal part of a tumble dryer cycle occurs without
heat (cool down cycle) to ensure that the items are left
at a temperature that ensures that the items will not be
damaged.
●●Exhaust air must not be discharged into a ue which is
used for exhausting fumes from appliances burning gas
or other fuels.
●●The appliance must not be installed behind a lockable
door, a sliding door or a door with a hinge on the opposite
side to that of the tumble dryer, in such a way that a full
opening of the tumble dryer door is restricted.
4 5
Read before Use
Safety Precautions
Observe fully.
Drum/Main Unit
During Use
To prevent the risk of danger to humans or property damage, make sure to follow the precautions described below.
The descriptions are classied according to the degree of harm or damage caused by misuse.
WARNING
May cause serious
injury or death.
CAUTION
May cause minor or moderate
injury or property damage.
WARNING
Do not allow children to get
inside the drum.
(Children may get locked inside the drum, which will cause
suffocation, burns, electric shock, injury, or drowning.)

To prevent children from easily climbing on the
appliance, do not put a table, etc. near the appliance.
This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience
and knowledge, unless they have been given
supervision or instruction concerning use of the
appliance by a person responsible for their safety.
Children should be supervised to ensure that they
do not play with the appliance.
Do not hang on the door.
(The appliance may fall over, resulting in injury.)
Never disassemble, repair or remodel.
(Fire or abnormal operation may occur, resulting in injury.)
When taking out the laundry...
Do not touch the laundry inside
the drum until it completely stops.
(Your ngers may be entangled in the laundry even
during slow rotation, resulting in injury.)
Do not put ame or inammable materials
in or close to the drum/main unit.
(Fire may occur.)
Pyrethrum coil, cigarette, candle, etc.
Do not splash water over the appliance.
Do not install at a damp place or place
which may be exposed to rain, water, etc.
(Electric shock or re from a short circuit may occur.)
Bathroom
(Lots of
moisture)
Balcony
(Exposed to wind
and rain)

Maintenance
Never dry the following items.
(even after washing).
(Spontaneous ignition or inammation may occur
due to heat of combustion of oil.)
Items that have been soiled with substances such
as cooking oil, acetone, alcohol,
petrol, kerosene, spot removers,
turpentine, waxes, wax removers
and cosmetic oils must not be
dried in the appliance even after
having been washed.
Matters to be observed
The lint lters have to be cleaned frequently.
The lint must not be allowed to accumulate around
the appliance.
Make sure that no objects are left in any of the
pockets. Pay particular attention to cigarette
lighter and matches. They may cause re.
Fabric softeners, or similar products, should
be used as specied by the fabric softener
instructions.
Prohibited matters
The appliance is not to be used if industrial
chemicals have been used for cleaning.
Do not dry unwashed items in the appliance.
Do not dry items made of polypropylene bre.
Ground the appliance.
(Electric shock may occur in electric leakage.)
Be sure to have your dealer perform grounding
work. (The grounding cost is not included in the
product price.)
To prevent re, electric
shock or injury
Power Plug and Cord
WARNING
CAUTION
Prohibited matters
(Fire or electric shock may occur.)
Do not damage, modify, immoderately bend, twist, pull, or bundle
them. Do not put them close to heating appliances. Do not put
anything heavy on them.
Do not connect/disconnect them with wet hand.
Do not hold the cord when pulling out of the socket.
Matters to be observed
(Fire or electric shock may occur.)
Use the socket solely. (Using in combination with
other appliances could cause re.)
Insert the plug all the way seated.
Wipe the plug periodically with dry cloth.
(Accumulated dust collects moisture, which may
cause insulation failure, resulting in re.)
Be sure to pull out the cord before cleaning or
when it is not used for a long period of time.

If the power cord is damaged, it must be replaced by the manufacturer,
its service agent or similarly qualied persons in order to avoid a hazard.
In case of emergency
or malfunction, stop
using the appliance
immediately and pull
out the power plug.
(Fume, re or electric shock may
occur.)
Emergency and malfunction
examples:
The appliance does not operate
at times when the power is
turned on.
Dust or moisture has
accumulated on the plug.
An abnormal sound is heard
during operation.
Burnt odour smell comes from
the appliance. (Consult your
dealer for inspection and repair
immediately.)
To prevent
water leak, etc.
Check before operation. (Water leak may occur.)
Turn on the water faucet and check the connection.
Be sure to turn off the water faucet
after operation has nished.
Do not allow the laundry to be caught
when closing the door.
(This may cause water leak,
malfunction of the appliance or
breakage of clothing.)
*Do not close the door with the
laundry on the window seal.
Drain Filter (P.30)
(A large amount of water (hot water)
may spill out.)
Do not remove during operation.
Be sure to perform the “Spin”
operation before removal. (P.26)
Observe the following when drying.
Never stop the appliance before the end of the
drying cycle unless all items are quickly removed
and spread out so that the heat is dissipated.
Do not “Wash”, “Rinse” or “Spin”
waterproof sheets and clothes.
(Intense vibration during spin or falling of the appliance
may result in injury, damage to the main unit, wall,
oor, etc., damage to the laundry, water leakage, etc.)
Raincoat, sauna suit, wet suit, diaper cover, sleeping
bag, ski wear, car cover, waterproof sheet, etc.
Prohibited matters
New hose-sets supplied with the appliance are to be
used and old hose-sets should not be reused.
Do not obstruct the openings of the bottom face with
carpet, etc.
Items such as foam rubber (latex foam), shower
caps, waterproof textiles, airtight fabrics, rubber
backed articles and clothes or pillows tted with foam
rubber pads should not be dried in the appliance.
Such materials may be destroyed and thereby
damage the appliance.
Do not insert your hand or foot under the main unit.
(Your limb may be cut.)

Do not climb up or put fragile things on the appliance.
(Deformation or damage may be caused, resulting in
injury.)
Do not connect to a water heater (50 °C or more).
(Plastic parts of water supply pathway may be
deformed or damaged, resulting in electric shock or
electric leakage.)
lnstallation
● Do not block the opening on the bottom with an object,such as a carpet.
● New hose-sets supplied with the appliance are to be used and old hose-sets should not be
reused.

3
CAUTION
May cause minor or moderate
injury or property damage.
4
Safety Precautions
Observe fully.
To prevent the risk of danger to humans or property damage, make sure to follow the precautions described below.
The descriptions are classified according to the degree of harm or damage caused by misuse.
WARNING
May cause serious
injury or death.
Drum/Main Unit
Do not allow children to get
inside the drum.
(Children may get locked inside the drum, which will cause
suffocation, burns, electric shock, injury, or drowning.)

To prevent children from easily climbing on the
appliance, do not put a table, etc. near the appliance.
This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience
and knowledge, unless they have been given
supervision or instruction concerning use of the
appliance by a person responsible for their safety.
Children should be supervised to ensure that they
do not play with the appliance.
Do nothang on the door.
(The appliance may fall over, resulting in injury.)
Never disassemble, repair or remodel.
(Fire or abnormal operation may occur, resulting in injury.)
When taking out the laundry...
Do not touch the laundry inside
the drum until it completely stops.
(Your fingers may be entangled in the laundry even
during slow rotation, resulting in injury.)
Do not put flame or inflammable materials
in or close to the drum/main unit.
(Fire may occur.)
Pyrethrum coil, cigarette, candle, etc.
Do not splash water over the appliance.
Do notinstall at a damp place orplace
which may be exposed to rain, water, etc.
(Electric shock or fire from a short circuit may occur.)
Bathroom
(Lots of
moisture)
Balcony
(Exposed to wind
and rain)

Maintenance
During Use
Never dry the following items.
(even after washing).
(Spontaneous ignition or inflammation may occur
due to heat of combustion of oil.)
Items that have been soiled with substances such
as cooking oil, acetone, alcohol,
petrol, kerosene, spot removers,
turpentine, waxes, wax removers
and cosmetic oils must not be
dried in the appliance even after
having been washed.
Matters to beobserved
The lint filters have to be cleaned frequently.
The lint must not be allowed to accumulate around
the appliance.
Make sure that no objects are left in any of the
pockets. Pay particular attention to cigarette
lighter and matches. They may cause fire.
Fabric softeners, or similar products, should
be used as specified by the fabric softener
instructions.
Prohibited matters
The appliance is not to be used if industrial
chemicals have been used for cleaning.
Do not dry unwashed items in the appliance.
Do not dry items made of polypropylene fibre.








To prevent fire, electric
shock orinjury
WARNING
Do not “Wash”, “Rinse” or “Spin”
waterproof sheets and clothes.
(Intense vibration during spin or falling of the appliance may result
in injury, damage to the main unit, wall, floor, etc., damage to the
laundry, water leakage, etc.)
Raincoat, sauna suit, wet suit, diaper cover, sleeping bag, ski
wear, car cover, waterproof sheet, etc.
Prohibited matters
Items such as foam rubber (latex foam), shower caps, waterproof
textiles, airtight fabrics, rubber backed articles and clothes or
pillows fitted with foam rubber pads should not be dried in the
appliance.
Such materials may be destroyed and thereby damage the
appliance.
Do not insert your hand or foot under the main unit.
(Your limb may be cut.)
Do not climb up or put fragile things on the appliance.
(Deformation or damage may be caused, resulting in injury.)
Do not connect to a water heater (50 °C or more).
(Plastic parts of water supply pathway may be deformed or
damaged, resulting in electric shock or electric leakage.)
The appliance must not be supplied through an external
switching device, such as a timer, or connected to a circuit that
is regularly switched on and off by a utility.
This appliance is intended to be used in household.
This appliance is not intended to be used in applications such as:
– staff kitchen areas in shops, ofces and other working
environments;
– farm houses;
– by clients in hotels, motels and other residential type environments;
– bed and breakfast type environments;
– areas for communal use in blocks of ats or in launderettes.
Maximum mass of dry cloth in kilograms, specied. Please see
page 47.
Presure of water faucet, Please see page 47.
Restart function
In case of power failure during washing operation:
When power is on again, press power ON key, the “Running” light
flashes for 3 seconds before the original operation resume from where
it is interrupted.
Operating Instruction can be download in the following
website:
https://www.panasonic.com/middleeast/en/
Pull out from the pump hose,
remove the cap and take the
plug out to drain the water.
The water inside must be
drained in the following cases:
1. When the machine has been idle for a long time.
2. To lift or move the machine
There is no need to do that in normal
circumstances.
3. To prevent from water leak,
please do not open the drain filter during operation.
Check before operation. (Water leak may occur.)
Turn on the water faucet and check the connection.
Be sure to turn off the water faucet
after operation has finished.
Do not allow the laundry to be caught
when closing the door.
(This may cause water leak, malfunction
of the appliance or breakage of clothing.)
* Do not close the door with the laundry on
the window seal.
Drain Filter (P.23)
(A large amount of water (hot water)
may spill out.)
Do not remove during operation.
Be sure to perform the “Spin” operation before removal.
Observe the following when drying.
Never stop the appliance before the end of the drying cycle
unless all items are quickly removed and spread out so that
the heat is dissipated.
Power Plug and Cord
Prohibited matters
(Fire or electric shock may occur.)
Do not damage, modify, immoderately bend, twist, pull, or bundle them.
Do not put them close to heating appliances. Do not put anything heavy on them.
Do not connect/disconnect them with wet hand.
Do not hold the cord when pulling out of the socket.
Matters to be observed
(Fire or electric shock may occur.)
Use the socket solely. (Using in combination with other appliances
could cause fire.)
Insert the plug all the way seated.
Wipe the plug periodically with dry cloth.
(Accumulated dust collects moisture, which may cause insulation failure, resulting
in fire.)
Be sure to pull out the cord before cleaning or when it is not used for a long period
of time.
If the power cord is damaged, it must be replaced by the manufacturer, its
service agent or similarly qualified persons in order to avoid a hazard.
In case of emergency
or malfunction, stop
using the appliance
immediately and pull out
the power plug.
(Fume, fire or electric shock may
occur.)
Emergency and malfunction
examples:
The appliance does not operate at
times when the power is turned on.
Dust or moisture has accumulated
on the plug.
An abnormal sound is heard during
operation.
Burnt odour smell comes from the
appliance. (Consult your dealer for
inspection and repair immediately.)
CAUTION To prevent
water leak, etc.
WARNING
Read Before Using

4
To prevent malfunction, damage, or abnormal operation
Bottom cover
(1 pc.)
Spanner
(1 pc.)
*For disassembly
orpacking to fix bolts.
(3 pcs.)
Adjustable stand
pad
●●When the body (especially the door and operation panel) touches the laundry detergent or softener, immediately wipe it with
dry towels (to prevent printed texts peeling off, resin demaged, metal corrosion damage, or abnormal operation). In particular, if
concentrated liquid detergent touches the resin part it may cracked. Please be extra careful.
●●To prevent moisture condensation during Dry, the ventilation should be sufficient.
●●Do not place object on top of the Wash machine during operation (to prevent the vibration causes the object to fall).
●●Even when the Wash machine is off, avoid having the basket touching the water supply hose (to prevent the hose from deforming).
●●When using the collar wash, do not spray it onto the plastic parts to prevent damage.
●●Do not spray insecticides, hair products, or deodorant spray, etc. onto the Wash machine (to prevent malfunction or breakage).
●●Do not put home electric appliances such as TV, radio, etc. close to the main unit. (Images may be interrupted, or noise may occur.)
●●After closing the door and starting the Wash machine, the door will automatically be locked. *(when the door lock is locked or
unlocked there will be a loud [cracking] sound. It is not a malfunction.)
●●Even when Dry, please turn on the water faucet! (the Wash machine uses the water for cooling and dehumidifying, so if the water
faucet is turned off the Dry cannot be proceeded.)
●●When Dry, do not place object on top of the air vent at the top back side of the body (to prevent the Dry time to become longer.)
Instruction
After the completion of the operation (in about 120 minutes), opening
the door will turn on the light; closing the door and the power will be
automatically shut off.
If the door is kept open, the light will go off after 20 minutes, and the
power will be automatically shut off.
 When the power is on and the door is open, the drum light will
light up
Cover
(3 pcs) (6 pcs)
Screws
Accessories
1 Water supply
hose for COLD
(Blue line)
Part Names / Accessories
Dry exhaust port
Power plug*1
Do not bundle the power
cord while using.
Water supply hose
Do not hang on the door
or apply excessive force
(The door will become
difficult to close.)
Door handle
Drum
Door lock
Drum light
Detergent case
Drain filter
Level
Drain hose
Do not connect the water supply
hose to the water heater Dry filter
*1 The shape of the plug
differs depending on the
country.

5


D

After starting, the touch buttons will no longer function. To
activate the buttons, please press the [start / pause] button
first.
If water, detergent or softener is attached to the touch panel,
turn the power off, and wipe it off with a wrung-out towel, etc.
immediately. (Operation error may occur.)
Do not touch the panel with the sharp point such as a nail, pin,
ballpoint pen, etc.
Do not operate the touch panel with wet hands or with rubber
gloves.
Power On
●●If you do not press the Start/Pause button within 10 minutes after the
appliance has been switched on, the appliance automatically turns off.
●●When the power is turned on, the program will be set at [Normal].
Power OFF
●●When the power is turned off, there will be a beep sound.

Start/Pause
To start or pause the operation, and press to open the door during
operation.
●●After starting, no switching between [Wash], [Wash+Dry], and [Dry] can
be performed.

Program
Select preferred program according to the laundry type and dirtiness.
●●The method to select program →(P. 8)
●●Different programs can be selected for [Wash], [Wash+Dry] and [Dry].
3
Stain Master +
Child lock/Unlock(press 5 sec)
May select program using heated water for Wash, when the water
temperature is low.
●●To prevent children from opening the door and dropping into the drum,
press for 5 sec. to proceed with [Child lock] setting.
4
Reserve time
May set after how many hours the Wash and Dry should complete within
24 hours in unit of 1 hour.
●●The presetable time varies depending on program.(P.37)
●●When preseting for [Wash+Dry], the time will be adjusted automatically
basing on the type of laundry and the Dry condition, so the Dry may
complete before the Reserve.
5
Dry Mode
(Press for 5 sec. to chang [Wash] and [Dry Mode])
May select [Normal], [Gentle Dry], [Extra Dry], [Timed Dry] Dry modes
basing on the laundry type.(P.9)
●●May select only [Dry Mode] by pressing 5 sec. (P.20)
6
Manual Setting
May select the duration and circle number of
[Wash], [Rinse], and [Spin].
●●Press Start/Pause during operation and you may change the program.
(You may not change the program when it rinse started.)
●●To set the combination of [Wash], [Rinse], [Spin] individually for
specific purpose.
7
Water Level
(press for 5 sec. to relieve during Dry.)
If you want to select the water level manually over the auto water level for
the laundry, press pause then press this button.
●●Please select [Water Level].
●●Depending on different program, some water levels cannot be selected.
(P. 37)
●●When cooling after Dry is completed, you may press this button for 5
sec. to cancel the Dry and relieve the door lock to remove the clothes in
advance.
8
ECONAVI
Light on: ECONAVI is running.
Flashing: ECONAVI is detecting.
A
Child Lock
Light on: The child lock is on.
B
Door Lock: Light on: Door lock is activated during the program.
●●After the program starts, the door will automatically be locked.
Fluffy: Light on:Fluffy is set after the program is completed.
Cleaning: Flashing: Please proceed to clean and maintain the Dry filter/
Drain filter. (P.22/23)
C
Displaying the [Time (min)] / [Reserve]
While switching the power from [off] to [on],
when is displayed, the power cannot be turned on.
D
Wash+Dry setting
Light on: The selected program is [Wash+Dry].
E
Operation Buttons / Touch Key
A
BC
E
Read Before Using

6
Wash
˙in
Wash+ Dry
Wash+Dry
Dry
(Press 5 seconds
or more to set)
Prepare the laundry (P.10)
Preparation Selection
1. Clothes classification 2. Preprocessing
Drum type Wash machine uses less water,
so the concentration of the dye or dirt will
be higher, and there may be circumstances
clothing becoming significantly blackened or
dyed
●●For clothes that are easy to fade or heavily soiled, please wash
separately.
●●When using [Wash], [Hygiene] or [Super Soak] programs, the clothes
may be dyed more easily. Please check the care label of the clothes. (P.
11)
●●Add the right amount of detergent(P. 13)
●●Do not add too much softener. Especially when combined with liquid
detergent, there may be significant blackening situation. In such case,
please use powder detergent.
●●When clothes are blackened or dyed→(P. 26)
●●When the clothes are prone to wrinkles…
• Select Dry mode basing on type of clothes (P. 9)
• Reduce the amount of clothes for each Dry
• Use [Gentle Dry] program
• Open the door midway, take the half-dry clothes
out and hang to dry.
• Dry after removing the wrinkle from draining.
• Clothes that are easy to dry such as
chemical fiber should be taken out as
soon as possible.
For Better Dry result
The darkening and dying of clothes
Select the operation contents and program
Select program basing on purpose (P. 8)
Select the operation contents and program
Select preferred setting
(P. 14)
When the water temperature is low…
Wash with Heated Program 1. Water temperature is not adjustable in some program
(P. 8)
2. Rinsing is not use warm water.
Capacity
guideline:
Approx.
8 kg(in dried
condition)
Select [Low - Extra high]
(some program cannot select
water level)
Adjust preferred Wash
time/Rinse/Spin time.
(not adjustable in some
program)
• For [Wash+Dry], do not [Spin]
cannot be set.
Select dry mode
• [Normal]
• [Intensive]
• [Gentle Dry]
• [10 min. - 2.5 hr. (Timing)]
May set after how many
hours the program should
complete.
• Press [Preset] may
change depending on
different program. (P. 37)
Laundry Procedure

7
Wash
˙in
Wash+ Dry
Wash+Dry
Dry
(Press 5 seconds
or more to set)
Selection Wash Dry
●●Some clothes shrink due to dry.
• Depending on the materials, some clothes will
shrink even only stained with water, washed, or
dried. (The tension applied on the fabric during
processing will be lost when washed so the
fabric will restitute.)
• Some clothes will shrink more seriously due to
dry plus the mechanical force.
●●
Please prepare for ventilation
 If ventilation is not sufficient, there will be
little or condensation or increase in Dry time
depending on the temperature difference.
When cotton, linen and other woven
goods, underwears, T-shirts, POLO
shirt, or sportswears shrink →(P. 26)
●●Please remove the cotton residue
adhering on the (inside of the) Dry filter
(P. 22).
If there is soil on the Dry filter, it may
lengthen the dry time or prevent the
clothes from dry completely.(P. 29)
●●After [Wash], [Hygiene] or [Super Soak] programs are
completed, please wipe away the water droplets on the
(inside of the) Dry filter. (P. 22)
(Adhered water droplets can cause mold.)
For Better Dry result Maintenance of the
Dry filter
Start
Put in the detergent
＊
Wash
＊
Wash
＊
Rinse ＊
Spin
＊
Spin
＊
Rinse
Auto Drum
Clean
Auto Drum
Clean
Fluffy
Dry
Fluffy The placement of the clothes after Dry can reduce wrinkles.
Reduce
Wrinkles
When dry
When Wash
When dry...
Use ECONAVI…
Save time, save water
Soften
clothes
Read Before Using

8
󲕡1. [Intensive] program
Wash with double amount of detergent. (detergent amount→P. 13)
After draining the detergent with the soil dissolved after wash, fill in water again and thoroughly clean with
a little more time so as to remove dirt and sebum dirt.
󲕡2. [Super Soak] program
Use warm water of approximately 40 ˚C and double amount of detergent to soak for 6 hours before rinsing
to remove the soil on the clothes.
󲕡3. [Wash] program
Use warm water of approximately 40 ˚C to remove the sebum and dirt on the underwears that the rinsing
did not remove.
󲕡4. [Hygiene] program
Use warm water of approximately 60 ˚C to remve the bacterial on the clothes (white clothes only).
󲕡5. [Gentle Hand Wash] with caring label such as wool sweaters, hemp shirts, suit pants
󲕡6. For [Wash+Dry] program, soft cooling can only be used after dry is completed
󲕡7. NA-S178X1-17kg
Selecting the Programs
FUZZY can detect the laundry amount to decide the water amount. To select
the water amount, please select manually
After the wash is completed, the Fluffy will start.
: Based on the maximum capacity of each model
Underline: with Auto Drum Clean.
Select basing on the type of clothes and dirtiness
Select operation
(Wash /Wash+Dry /Dry)
Program selection
30˚C Program
maximum capacity
30˚C Program
Dry
Wash, Dry
Daily clothes
Daily Wash
Wash
Normal 17 kg
(8 kg)
Yes

7 kg
Wash+Dry Yes Yes
Quick Wash
Wash
Quick 8 kg
Yes
8 kg
Want to design my own
program
Wash
My Favorite 17 kg
(8 kg)
Yes

7 kg
Wash+Dry Yes Yes
Want to reduce the
volume during operation
Wash
Silent wash 17 kg
(8 kg)
Yes

7 kg
Wash+Dry Yes Normal / intensive
Use a bit more time to
wash and dry thoroughly
Wash
Eco Soak 8 kg
(8 kg)
Yes
8 kg
Wash+Dry Yes Yes
Wash
Intensive 117 kg
(8 kg)
Yes

7 kg
Wash+Dry Yes Normal / intensive
Remove stubborn stains
Wash
Super Soak 22 kg
(2 kg)
Wash+Dry Normal / intensive
Deodorizing Wash
Wash
Wash 317 kg
(4 kg)
Wash+Dry Normal / intensive
White clothes that you want to keep
clean
(Underwear, etc.)
Remove clothing bacteria
dust mites
Wash
Hygiene 417 kg
(2 kg)
Wash+Dry Normal / intensive
Delicate clothing Gentle Wash
Wash
Gentle Hand Wash 51.5 kg
Blankets, sheets Synthetic single size quilt
Wash
Bedding 5 kg
(4 kg)
Yes
5 kg
Wash+Dry Yes Normal
Maintenance
Maintenance of the drum Remove and prevent black
mold keep the drum dry
Drum Clean
Drum Dry
Empty
Drum

9
Semi-dry clothes that you want to dry
during final modification.
Clothes that are easy to have wrinkles
Thick clothes that are difficult to dry
Remove the clothes immediately
after dry and hang to dry. (Otherwise
wrinkles will occur)
If the capacity is below 3 kg…
Set [Gentle Dry] will reduce the wrinkles.
1. For expensive clothes or clothes that cannot be water-washed, please do not use the wash machine to wash or
dry so as to prevent deformation or damages.
2. Some clothes are not suitable for wash in warm water. Such as colorful clothes or ones that are easy to fade or
have wrinkles.
Select the Dry
mode basing on the
type of clothes
Normal
Extra Dry
Timed Dry
Gentle Dry
Daily clothes that you do not mind about
wrinkles
towels
sportwears
underwears
thick towel,
etc.
Note!
• Shirts • Jeans
• Bedsheet • Nightdress
• Trousers
• Thin plain weave and crepe, etc.
maximum
capacity Wash
(Wash+Dry, Dry)
Select basing on the type of clothes and dirtiness
Select operation
(Wash /Wash+Dry /Dry)
Program selection
30˚C Program
maximum capacity
30˚C Program
Dry
Wash, Dry
Daily clothes
Daily Wash
Wash
Normal 17 kg
(8 kg)
Yes

7 kg
Wash+Dry Yes Yes
Quick Wash
Wash
Quick 8 kg
Yes
8 kg
Want to design my own
program
Wash
My Favorite 17 kg
(8 kg)
Yes

7 kg
Wash+Dry Yes Yes
Want to reduce the
volume during operation
Wash
Silent wash 17 kg
(8 kg)
Yes

7 kg
Wash+Dry Yes Normal / intensive
Use a bit more time to
wash and dry thoroughly
Wash
Eco Soak 8 kg
(8 kg)
Yes
8 kg
Wash+Dry Yes Yes
Wash
Intensive 117 kg
(8 kg)
Yes

7 kg
Wash+Dry Yes Normal / intensive
Remove stubborn stains
Wash
Super Soak 22 kg
(2 kg)
Wash+Dry Normal / intensive
Deodorizing Wash
Wash
Wash 317 kg
(4 kg)
Wash+Dry Normal / intensive
White clothes that you want to keep
clean
(Underwear, etc.)
Remove clothing bacteria
dust mites
Wash
Hygiene 417 kg
(2 kg)
Wash+Dry Normal / intensive
Delicate clothing Gentle Wash
Wash
Gentle Hand Wash 51.5 kg
Blankets, sheets Synthetic single size quilt
Wash
Bedding 5 kg
(4 kg)
Yes
5 kg
Wash+Dry Yes Normal
Maintenance
Maintenance of the drum Remove and prevent black
mold keep the drum dry
Drum Clean
Drum Dry
Empty
Drum
Read Before Using

10
Laundry Check and Preparations
Tights, pantyhose
(Damage or deformation
may occur.)
Curtain
(Damage or malfunc-
tion may occur.)
• Follow care labels
of curtains before
washing.
Starched shirt
(The dry filter may
be clogged.)
Clothes decorated with em-
broidery or lace and new
chemical fibre (micro fibre)
(Deformation may occur.)
Mats and other items with
hair of pets attached
(Lint may block the drying
pathway, or damage or
malfunction may occur.)
Other items
Items other than
clothes (paper dia-
per, etc.)
Items that easily
deform
(jacket, tie, dress,
etc.)
Crease or em-
boss-processed
items
Items of which
threads easily wear
down
(velvet, etc.)
Silk, rayon and
cupro products.
(Blended fabric)
(Discolouration or
deformation may
occur.)
Leather and fur
products.
(Deformation may
occur.)
Large or thick mat or carpet
cover with urethane or rub-
ber processed back surface.
(Damage or malfunction
may occur.)
Commercially sold washing aids, wash-
ing net with hard core material, etc.
(Deformation or damage may occur
due to heat. Also, damage to clothes or
malfunction may occur.)
Cushion, pillow, etc.
with cotton, sponge
or beads used
(Damage or malfunc-
tion may occur.)
Waterproof sheets
and clothes
(Damage or mal-
function may oc-
cur.)
Cap with hard core
materials.
(Damage or malfunc-
tion may occur.)
Cannot Wash or Dry
Items with any of the
symbols on the left
(Damage may occur.)
Wool clothes
Laundry Check and Preparations
Cannot Dry
Laundry capacity guideline
Sheets (cotton 100%) A pair of pyjamas (cotton 100%)
Skirt (chemical fibre)
Bath towel (cotton 100%)
Dress shirt (blended fabric)
Long sleeve underwear (cotton 100%)
Socks (blended fabric) Briefs (cotton 100%)
• Weight varies depending on the material.
(Weight guideline per one item)
500 g
400 g
300 g
200 g
150 g
50 g

11
12 13
Read before Use
Laundry Check and Preparations
Items with any of the
symbols on the left
(Damage may occur.)
Wool clothes
(Shrink or loss of hair
may occur.)
Tights, pantyhose
(Damage or deformation
may occur.)
Curtain
(Damage or malfunc-
tion may occur.)
•
Follow care labels
of curtains before
washing.
Starched shirt
(The dry lter may
be clogged.)
Clothes decorated with em-
broidery or lace and new
chemical bre (micro bre)
(Deformation may occur.)
Mats and other items with
hair of pets attached
(Lint may block the drying
pathway, or damage or
malfunction may occur.)
Other items
Items other than
clothes (paper dia-
per, etc.)
Items that easily
deform
(jacket, tie, dress,
etc.)
Crease or em-
boss-processed
items
Items of which
threads easily wear
down
(velvet, etc.)
Silk, rayon and
cupro products
(Blended fabric)
(Discolouration or
deformation may
occur.)
Leather and fur
products
(Deformation may
occur.)
Large or thick mat or carpet
cover with urethane or rub-
ber processed back surface.
(Damage or malfunction
may occur.)
Commercially sold washing aids, wash-
ing net with hard core material, etc.
(Deformation or damage may occur
due to heat. Also, damage to clothes or
malfunction may occur.)
Cushion, pillow, etc.
with cotton, sponge
or beads used
(Damage or malfunc-
tion may occur.)
Waterproof sheets
and clothes
(Damage or mal-
function may oc-
cur.)
Cap with hard core
materials.
(Damage or malfunc-
tion may occur.)
Pre-treatment for tough stains
Collar and cuffs stains
→Apply detergent for collar and cuffs.
Stains
→Apply detergent for stains or oxygen
liquid bleach. (For blood, tea, juice
stains, etc., pre-wash with water.)
Dirt containing mud
→Apply detergent for partial stains or
bathing soap, and wash by rubbing.
Cannot Wash or Dry
Cannot Dry
Due to less water used for drum type washing machines, stain or dye concentration may become high, resulting in
noticeable darkening or colour transfer of clothes.
Note the following
Separately wash new coloured clothes or clothes that easily lose
colour or are heavily soiled.
(
If the lost colours transfer to white clothes, darkening of clothes may occur. )
“Cotton (40 °C)”, “ECONAVI (40 °C)”, “ECONAVI (60 °C)” and
“Soak” programs in particular tend to cause colour transfer. Check
care labels of clothes carefully. (P.17)

Use the correct amount of detergent. (P.21) (Using too small amount
of detergent may cause once-removed soil to stick to the clothes
again, resulting in darkening of clothes.)

Do not put in excessive amount of softener. (Softener residue
on clothes may cause darkening of clothes.) When using in
combination with liquid detergent in particular, darkening of clothes
may be noticeable. If it worries you, use powder detergent.
Select the dry mode that best
suits your clothes. (P.29)
Decrease the amount of clothes
for drying at a time.
Open the door in the middle of
drying operation, take out the
half-dry clothes. Then, hang the
clothes to dry.
Smooth out creases formed
during spin, and then dry.
After drying operation is
complete, take out clothes made
of chemical bre, etc. as quickly
as possible that easily dry.
Clothes that shrink by drying
Some clothes may shrink just by soaking
in water, washing or drying.
(Because tension generated in fabric
processing is restored to the original
level by washing)
Some may shrink more by mechanical
force in drying.
• Knit products made of cotton,
linen, etc.
• Underwear shirt • T-shirt.
• Polo shirt • Sweat shirt, etc.
If shrinkage worries you (P.36)
To prevent darkening of colour and colour transfer
To prevent creases and shrinkage caused by drying
To prevent damage of clothes, drainage failure and malfunctions
Fasten buttons.
Close zippers.
Tie strings, etc. Using a brush, remove hairs
of pet and person, sands, etc.
Reverse uffy
clothes.
Remove metallic
fragments and coins.
Note the following
20ml
8ml
4ml
How to check loss of colour
Dip white cloth in undiluted mild liquid
detergent and rub a hidden part of
clothes.
→If the lost colour transfers, wash
separately.
If darkening or colour transfer
of clothes occurs (P.36)

Be sure to put only delicate underwear and small items in the net
for washing.
(Do not put in items in the net other than these.)
• Pantyhose and brassiere (Put wired brassieres in a
commercially sold “brassiere-dedicated net”.)
• Clothes and lingerie decorated with lace
• Socks, handkerchief, etc. (Put the claw of the
zipper into the cover.)
When drying
Do not dry items
remaining in the net. (To
prevent uneven dry and
wrinkle)
Use washing nets for delicate underwear and small items
12 13
Read before Use
Laundry Check and Preparations
Items with any of the
symbols on the left
(Damage may occur.)
Wool clothes
(Shrink or loss of hair
may occur.)
Tights, pantyhose
(Damage or deformation
may occur.)
Curtain
(Damage or malfunc-
tion may occur.)
•
Follow care labels
of curtains before
washing.
Starched shirt
(The dry lter may
be clogged.)
Clothes decorated with em-
broidery or lace and new
chemical bre (micro bre)
(Deformation may occur.)
Mats and other items with
hair of pets attached
(Lint may block the drying
pathway, or damage or
malfunction may occur.)
Other items
Items other than
clothes (paper dia-
per, etc.)
Items that easily
deform
(jacket, tie, dress,
etc.)
Crease or em-
boss-processed
items
Items of which
threads easily wear
down
(velvet, etc.)
Silk, rayon and
cupro products
(Blended fabric)
(Discolouration or
deformation may
occur.)
Leather and fur
products
(Deformation may
occur.)
Large or thick mat or carpet
cover with urethane or rub-
ber processed back surface.
(Damage or malfunction
may occur.)
Commercially sold washing aids, wash-
ing net with hard core material, etc.
(Deformation or damage may occur
due to heat. Also, damage to clothes or
malfunction may occur.)
Cushion, pillow, etc.
with cotton, sponge
or beads used
(Damage or malfunc-
tion may occur.)
Waterproof sheets
and clothes
(Damage or mal-
function may oc-
cur.)
Cap with hard core
materials.
(Damage or malfunc-
tion may occur.)
Pre-treatment for tough stains
Collar and cuffs stains
→Apply detergent for collar and cuffs.
Stains
→Apply detergent for stains or oxygen
liquid bleach. (For blood, tea, juice
stains, etc., pre-wash with water.)
Dirt containing mud
→Apply detergent for partial stains or
bathing soap, and wash by rubbing.
Cannot Wash or Dry
Cannot Dry
Due to less water used for drum type washing machines, stain or dye concentration may become high, resulting in
noticeable darkening or colour transfer of clothes.
Note the following
Separately wash new coloured clothes or clothes that easily lose
colour or are heavily soiled.
(
If the lost colours transfer to white clothes, darkening of clothes may occur. )
“Cotton (40 °C)”, “ECONAVI (40 °C)”, “ECONAVI (60 °C)” and
“Soak” programs in particular tend to cause colour transfer. Check
care labels of clothes carefully. (P.17)

Use the correct amount of detergent. (P.21) (Using too small amount
of detergent may cause once-removed soil to stick to the clothes
again, resulting in darkening of clothes.)

Do not put in excessive amount of softener. (Softener residue
on clothes may cause darkening of clothes.) When using in
combination with liquid detergent in particular, darkening of clothes
may be noticeable. If it worries you, use powder detergent.
Select the dry mode that best
suits your clothes. (P.29)
Decrease the amount of clothes
for drying at a time.
Recommended
guideline:
Approx. 3 kg
Open the door in the middle of
drying operation, take out the
half-dry clothes. Then, hang the
clothes to dry.
Smooth out creases formed
during spin, and then dry.
After drying operation is
complete, take out clothes made
of chemical bre, etc. as quickly
as possible that easily dry.
Clothes that shrink by drying
Some clothes may shrink just by soaking
in water, washing or drying.
(Because tension generated in fabric
processing is restored to the original
level by washing)
Some may shrink more by mechanical
force in drying.
• Knit products made of cotton,
linen, etc.
• Underwear shirt • T-shirt.
• Polo shirt • Sweat shirt, etc.
If shrinkage worries you (P.36)
To prevent darkening of colour and colour transfer
To prevent creases and shrinkage caused by drying
To prevent damage of clothes, drainage failure and malfunctions
Fasten buttons.
Close zippers.
Tie strings, etc. Using a brush, remove hairs
of pet and person, sands, etc.
Reverse uffy
clothes.
Remove metallic
fragments and coins.
Note the following
20ml
8ml
4ml
How to check loss of colour
Dip white cloth in undiluted mild liquid
detergent and rub a hidden part of
clothes.
→If the lost colour transfers, wash
separately.
If darkening or colour transfer
of clothes occurs (P.36)

Be sure to put only delicate underwear and small items in the net
for washing.
(Do not put in items in the net other than these.)
• Pantyhose and brassiere (Put wired brassieres in a
commercially sold “brassiere-dedicated net”.)
• Clothes and lingerie decorated with lace
• Socks, handkerchief, etc. (Put the claw of the
zipper into the cover.)
When drying
Do not dry items
remaining in the net. (To
prevent uneven dry and
wrinkle)
Use washing nets for delicate underwear and small items
12 13
Read before Use
Laundry Check and Preparations
Items with any of the
symbols on the left
(Damage may occur.)
Wool clothes
(Shrink or loss of hair
may occur.)
Tights, pantyhose
(Damage or deformation
may occur.)
Curtain
(Damage or malfunc-
tion may occur.)
•
Follow care labels
of curtains before
washing.
Starched shirt
(The dry lter may
be clogged.)
Clothes decorated with em-
broidery or lace and new
chemical bre (micro bre)
(Deformation may occur.)
Mats and other items with
hair of pets attached
(Lint may block the drying
pathway, or damage or
malfunction may occur.)
Other items
Items other than
clothes (paper dia-
per, etc.)
Items that easily
deform
(jacket, tie, dress,
etc.)
Crease or em-
boss-processed
items
Items of which
threads easily wear
down
(velvet, etc.)
Silk, rayon and
cupro products
(Blended fabric)
(Discolouration or
deformation may
occur.)
Leather and fur
products
(Deformation may
occur.)
Large or thick mat or carpet
cover with urethane or rub-
ber processed back surface.
(Damage or malfunction
may occur.)
Commercially sold washing aids, wash-
ing net with hard core material, etc.
(Deformation or damage may occur
due to heat. Also, damage to clothes or
malfunction may occur.)
Cushion, pillow, etc.
with cotton, sponge
or beads used
(Damage or malfunc-
tion may occur.)
Waterproof sheets
and clothes
(Damage or mal-
function may oc-
cur.)
Cap with hard core
materials.
(Damage or malfunc-
tion may occur.)
Pre-treatment for tough stains
Collar and cuffs stains
→Apply detergent for collar and cuffs.
Stains
→Apply detergent for stains or oxygen
liquid bleach. (For blood, tea, juice
stains, etc., pre-wash with water.)
Dirt containing mud
→Apply detergent for partial stains or
bathing soap, and wash by rubbing.
Cannot Wash or Dry
Cannot Dry
Due to less water used for drum type washing machines, stain or dye concentration may become high, resulting in
noticeable darkening or colour transfer of clothes.
Note the following
Separately wash new coloured clothes or clothes that easily lose
colour or are heavily soiled.
(
If the lost colours transfer to white clothes, darkening of clothes may occur. )
“Cotton (40 °C)”, “ECONAVI (40 °C)”, “ECONAVI (60 °C)” and
“Soak” programs in particular tend to cause colour transfer. Check
care labels of clothes carefully. (P.17)

Use the correct amount of detergent. (P.21) (Using too small amount
of detergent may cause once-removed soil to stick to the clothes
again, resulting in darkening of clothes.)

Do not put in excessive amount of softener. (Softener residue
on clothes may cause darkening of clothes.) When using in
combination with liquid detergent in particular, darkening of clothes
may be noticeable. If it worries you, use powder detergent.
Select the dry mode that best
suits your clothes. (P.29)
Decrease the amount of clothes
for drying at a time.
Open the door in the middle of
drying operation, take out the
half-dry clothes. Then, hang the
clothes to dry.
Smooth out creases formed
during spin, and then dry.
After drying operation is
complete, take out clothes made
of chemical bre, etc. as quickly
as possible that easily dry.
Clothes that shrink by drying
Some clothes may shrink just by soaking
in water, washing or drying.
(Because tension generated in fabric
processing is restored to the original
level by washing)
Some may shrink more by mechanical
force in drying.
• Knit products made of cotton,
linen, etc.
• Underwear shirt • T-shirt.
• Polo shirt • Sweat shirt, etc.
If shrinkage worries you (P.36)
To prevent darkening of colour and colour transfer
To prevent creases and shrinkage caused by drying
To prevent damage of clothes, drainage failure and malfunctions
Fasten buttons.
Close zippers.
Tie strings, etc. Using a brush, remove hairs
of pet and person, sands, etc.
Reverse uffy
clothes.
Remove metallic
fragments and coins.
Note the following
20ml
8ml
4ml
How to check loss of colour
Dip white cloth in undiluted mild liquid
detergent and rub a hidden part of
clothes.
→If the lost colour transfers, wash
separately.
If darkening or colour transfer
of clothes occurs (P.36)

Be sure to put only delicate underwear and small items in the net
for washing.
(Do not put in items in the net other than these.)
• Pantyhose and brassiere (Put wired brassieres in a
commercially sold “brassiere-dedicated net”.)
• Clothes and lingerie decorated with lace
• Socks, handkerchief, etc. (Put the claw of the
zipper into the cover.)
When drying
Do not dry items
remaining in the net. (To
prevent uneven dry and
wrinkle)
Use washing nets for delicate underwear and small items
12 13
Read before Use
Laundry Check and Preparations
Items with any of the
symbols on the left
(Damage may occur.)
Wool clothes
(Shrink or loss of hair
may occur.)
Tights, pantyhose
(Damage or deformation
may occur.)
Curtain
(Damage or malfunc-
tion may occur.)
•
Follow care labels
of curtains before
washing.
Starched shirt
(The dry lter may
be clogged.)
Clothes decorated with em-
broidery or lace and new
chemical bre (micro bre)
(Deformation may occur.)
Mats and other items with
hair of pets attached
(Lint may block the drying
pathway, or damage or
malfunction may occur.)
Other items
Items other than
clothes (paper dia-
per, etc.)
Items that easily
deform
(jacket, tie, dress,
etc.)
Crease or em-
boss-processed
items
Items of which
threads easily wear
down
(velvet, etc.)
Silk, rayon and
cupro products
(Blended fabric)
(Discolouration or
deformation may
occur.)
Leather and fur
products
(Deformation may
occur.)
Large or thick mat or carpet
cover with urethane or rub-
ber processed back surface.
(Damage or malfunction
may occur.)
Commercially sold washing aids, wash-
ing net with hard core material, etc.
(Deformation or damage may occur
due to heat. Also, damage to clothes or
malfunction may occur.)
Cushion, pillow, etc.
with cotton, sponge
or beads used
(Damage or malfunc-
tion may occur.)
Waterproof sheets
and clothes
(Damage or mal-
function may oc-
cur.)
Cap with hard core
materials.
(Damage or malfunc-
tion may occur.)
Pre-treatment for tough stains
Collar and cuffs stains
→Apply detergent for collar and cuffs.
Stains
→Apply detergent for stains or oxygen
liquid bleach. (For blood, tea, juice
stains, etc., pre-wash with water.)
Dirt containing mud
→Apply detergent for partial stains or
bathing soap, and wash by rubbing.
Cannot Wash or Dry
Cannot Dry
Due to less water used for drum type washing machines, stain or dye concentration may become high, resulting in
noticeable darkening or colour transfer of clothes.
Note the following
Separately wash new coloured clothes or clothes that easily lose
colour or are heavily soiled.
(
If the lost colours transfer to white clothes, darkening of clothes may occur. )
“Cotton (40 °C)”, “ECONAVI (40 °C)”, “ECONAVI (60 °C)” and
“Soak” programs in particular tend to cause colour transfer. Check
care labels of clothes carefully. (P.17)

Use the correct amount of detergent. (P.21) (Using too small amount
of detergent may cause once-removed soil to stick to the clothes
again, resulting in darkening of clothes.)

Do not put in excessive amount of softener. (Softener residue
on clothes may cause darkening of clothes.) When using in
combination with liquid detergent in particular, darkening of clothes
may be noticeable. If it worries you, use powder detergent.
Select the dry mode that best
suits your clothes. (P.29)
Decrease the amount of clothes
for drying at a time.
Open the door in the middle of
drying operation, take out the
half-dry clothes. Then, hang the
clothes to dry.
Smooth out creases formed
during spin, and then dry.
After drying operation is
complete, take out clothes made
of chemical bre, etc. as quickly
as possible that easily dry.
Clothes that shrink by drying
Some clothes may shrink just by soaking
in water, washing or drying.
(Because tension generated in fabric
processing is restored to the original
level by washing)
Some may shrink more by mechanical
force in drying.
• Knit products made of cotton,
linen, etc.
• Underwear shirt • T-shirt.
• Polo shirt • Sweat shirt, etc.
If shrinkage worries you (P.36)
To prevent darkening of colour and colour transfer
To prevent creases and shrinkage caused by drying
To prevent damage of clothes, drainage failure and malfunctions
Fasten buttons.
Close zippers.
Tie strings, etc. Using a brush, remove hairs
of pet and person, sands, etc.
Reverse uffy
clothes.
Remove metallic
fragments and coins.
Note the following
20ml
8ml
4ml
How to check loss of colour
Dip white cloth in undiluted mild liquid
detergent and rub a hidden part of
clothes.
→If the lost colour transfers, wash
separately.
If darkening or colour transfer
of clothes occurs (P.36)

Be sure to put only delicate underwear and small items in the net
for washing.
(Do not put in items in the net other than these.)
• Pantyhose and brassiere (Put wired brassieres in a
commercially sold “brassiere-dedicated net”.)
• Clothes and lingerie decorated with lace
• Socks, handkerchief, etc. (Put the claw of the
zipper into the cover.)
When drying
Do not dry items
remaining in the net. (To
prevent uneven dry and
wrinkle)
Use washing nets for delicate underwear and small items
(P. 9)
(P. 25)
Read Before Using

12
• If detergent or softener is attached to the main unit (especially door, operation panel and touch panel),
immediately wipe it off with a wrung-out towel, etc. (Peeling of print, damage to resin, metal corrosion or
malfunction may occur.)In particular, if liquid concentrated detergent is attached to the resin part, it may crack.
• If you have forgotten putting in the detergent or water is already in the drum, put the detergent in the detergent
case and pour with a cup of water. (Because water to flow the detergent is not supplied)
●●You can use powder detergent, liquid
detergent, liquid soap.
●●Liquid soap is easy to solidificate, so
dissolve it in the warm water before use.
(Do not use liquid soap when using Timing,
so as to prevent leakage or malfunction
caused by solidification).
●●low foaming detergent is recommended
●●Do not use soap
powder.
(to prevent dissolve
difficulty in water,
blockage problem,
leakage or
malfunction)
 Detergent
Powder
(detergent/bleach)
●●To prevent the detergent from remaining
• Wipe the case if it is wet.
• Break block of detergent before putting in.
Note
Liquid (detergent/bleach)
●●Do not use chlorine-based bleach when using the Timing
reservation. (Leaving the appliance for a long time may result
in metal corrosion or malfunction.)
●●Do not use chlorine-based bleach for coloured clothes. (Loss
of colour may occur.)
Softener
●●Dissolve in water if it is diff
cult to flow.
(Max.: approx. 100 ml)
• Do not put the softener
exceeding the guideline
“MAX” position.
(The softener flows out quickly and no effect is given.)
●●Do not leave the softener in the softener compartment for 12
hours or longer. (It easily becomes hard.)
●●Do not use a separated or solidified softener.
(The softener or water may remain in the case.)
●●Small amount of softener may remain in the case due to its
siphonic structure. (This is not a malfunction.)
Undiluted
softener
(Same amount of)
water
Do not use soap
powder
How to put in the Detergent & Softener

13
Note
21
• For detergent with more foam, use less.
• Follow the instructions of detergent usage.
• Adjust the volume of detergent basing on type of clothes and
degree of dirtiness.
• Add Detergent, bleach, softener before water is filled (otherwise there may be residual)
• If the water starts filling when you are adding detergent, press to pause and restart after adding detergent.
• When the wash machine (especially the door and operation panel) touches the laundry detergent or softener, immediately wipe it with
dry towels (to prevent printed texts peeling off, resin demaged, metal corrosion damage, or abnormal operation).
In particular, if concentrated liquid detergent touches the resin part it may cracked. Please be extra careful.
• For [Gentle Hand Wash] and [Bedding] programs, the liquid detergent is recommended.
• Since the ingredients different detergent brands are not the same, the above data are for reference
only.
Note
Put in the laundry, close the
door Start
Detergent amount according
to the laundry
Put in the
detergent by
the mark
Use Standard detergent
Standard detergent
Powder Liquid
approx. 30 gapprox. 25 ml
approx. 27 gapprox. 22 ml
approx. 24 gapprox. 20 ml
approx. 18 gapprox. 15 ml
approx. 12 gapprox. 10 ml
approx. 50 gapprox. 38 ml
approx. 45 gapprox. 33 ml
approx. 40 gapprox. 30 ml
approx. 30 gapprox. 23 ml
Water Level
Water
indicator
Extra High
High
Middle
Low
Extra Low
Extra High
High
Middle
Low
 For [Intensive] and [Super Soak] programs
●●If the powder detergent is poorly soluble.
• Dissolve it in warm water (approx. 30 ˚C) and then add
it directly into the drum
Put in the detergent little by little while
stirring to prevent it from remaining in a
powder state.
Read Before Using

14
Preparation
Operate
1 Turn the power on
●●When the power is turned on, the setting will be on
[Normal] cycle.
3
4
2 Select Program (P. 8)
5
When [Wash+Dry]
(1) Turn on the water faucet
●●Please do not turn off the water faucet when Dry (because
the machine needs the water for cooling and dehumidifying,
so if you turn the faucet off, the Dry cannot be proceeded.
The machine also uses water to bring away the filament scrap
accumulated in the Dry path inside the wash tub.)
(2) Put the laundry in the drum, and close the door.
Wash+Dry Normal
StainMaster+ Cycle
●●capacity 8 kg or less. ●●According to the maximum capacity
of each model (P. 9)
●●17 kg or less.
* Caution: After pressing the Timing button you cannot change
cycle.
●●Each press will switch to the next option.
Normal →Eco Soal →My Favorite →Intensive
→Silent Wash →Quick →Bedding→
Gentle Hand Wash →Drum Clean →Drum
Dry
Start
Select water temperature
Select Dry
●●The door will be automatically locked (P. 16)
●●[Water warm up] light on
●●Use when water temperature is lower such as winter
●●If there is no need to select water temperature,
please do not press.
●●[Wash + Dry] light on
●●If there is no need to dry, please do not press.
●●When you only want to select [Dry Mode]→ (P. 20)
Select time for Timing setting
Normal > Extra Dry > Gentle Dry > 10 (min.) > 30
(min.) > 1:00 (hr.) > 1:30 (hr.) > 2:00 (hr.) > 2:30 (hr.)
> light off > Normal
Select the Dry mode (P. 9)
Adjust the water amount (P. 5)
●●You can pause the operation and change from
turning on the power until the end of [Wash].
●●You may select to your preferred wash time/number
of rinse cycle/spin time (not adjustable in some
cycles)
●●Caution: When there is Dry, the spinning time must
be 3 minutes or above
●●Setting the Timing
You may choose your preferred setting
The amount of water is
displayed for about 20
seconds.
Detect the amount of laundry
(Tub rotates for about 15
seconds)
• Do not put in too many clothes (to avoid damaging the
clothing or the machine)
• Please follow the capacity Normal (approximately 8kg.)
when Dry (to avoid wrinkles or uneven Dry)
• Check whether any clothes are clamped when closing
the door (to avoid leakage, mechanical failure or clothing
rupture)
• Please complete
the ventilation
process
Caution
Capacity:
approximately
8kg or less.
(dry state)
Wash / Wash+Dry

15
Wash Instruction
After Dry or Wash is completed… automatically start [Fluffy].
6According to the indication
Put in the detergent (P. 13)
The remaining time is displayed, and water
supply begins in approx. 35 seconds.
When the buzzer sounds, it means that Wash and Dry are
completed.
 After starting, if you want to change
Pause first, and then you can change the cycle (you
may change from starting until the end of wash)
Light on: Fluffy is set
Flashing: Fluffy is running
●●You may remove clothing during Fluffy operation (once you
open the door, the operation will stop).
(1) Open the door to remove clothing
(2) Turn off the faucet
Prevent wrinkles due to placing of clothing after Dry is completed.
[Fluffy]
• After the [Gentle Dry] cycle of Dry, Fluffy will not be
proceeded.
• When setting Fluffy after the completion of Dry →(P.38)
Note
5 1234

16
The door will be locked during operation.
Setting Child lock
The door is locked if the water temperature is high.
The door will be locked when the temperature inside the Wash tub is high.
• If the door is opened while washing, bubble may spill out. Receive it with a towel, etc.
(Water droplets may also fall from the inside the door.)
• With the Child Lock set, the door does not open even if the appliance is not operating.
• The door does not open while the Reserver is being set. Turn the power off, and make the setting again.
• Do not disconnect the power plug. The lock cannot be cancelled even if the power is turned off.
Note
To prevent accidents of children, this function disables door opening even if the power is turned off or after the operation has finished.
 How to set  To cancel
2 2
1 1
Close the door and
turn the power on.
Close the door and
turn the power on.
Press and hold for at
least 5 seconds.
Press and hold for at
least 5 seconds.
The setting is complete when [Child lock] and is
displayed after a double beep is heard.
The setting is complete when [Child lock] and is
disappears after a double beep (x2) is heard.
During operation, when the temperature inside the Wash tub is high, the door will be locked, and Door locked light will be on. Even if
you pause the operation or turn off the power, the door cannot be opened.
<To open the door immediately>
Turn the power off →Turn the power on →Start [Spin] (Water supply may start to lower the water temperature inside the
drum.)
●●Wash is not over. Please re-run.
During Dry, when the temperature inside the Wash tub is high, the door will be locked. Even if you pause operation or turn off the
power, the door still cannot be opened.
Before the temperature drops, the door cannot be opened.
<To open the door immediately>
Turn the power off →Turn the power on →press and hold for at least 5 seconds →[Fluffy] light is on
●●The cooling operation will start (5 to 25 minutes), and the draining and air blowing will lower the temperature inside the tank.
●●When the cooling is completed, there will a rattle sound, and the door will be locked.
※Cooling time may vary depending on temperature inside the wash tub.
• When the power is turned on after Child Lock has been set, is displayed for approx. 2 seconds each time.
Note
is displayed during operation. The door does not open.
<Open the door>
●●Pressing [Start/Pause] button during operation stops the drum rotation and cancels
the lock with clicking sound. The door does not open while the drum is rotating.
Door lock

17
Wash Instruction
Wash+Dry Wash
When Wash+Dry.
If there is no need for Dry, do not press the [Dry Mode] button.
 Preparation
(1) Getting laundry ready (P. 10)
classification pre-treatment
(2) Turn on the faucet
• You must turn on the faucet even for Dry cycle.
(3) Put the laundry in the drum and close the door.
 When you select【Wash+Dry】
or【Dry】cycles, the display
when you put in too much
clothes (exceed capacity)
When the clothing exceeds capacity, [U15] message
will appear, and the operation will stop. Remove
excessive clothing then restart.
Reach the upper portion
of the entry for about
8kg. Normal.
If you put in too
much clothing, the
clothes may not be
completely dry or the
Dry time will become
longer.
 Please refer to P. 9 and select the proper Dry cycle.
 After the Dry is completed, start the [Fluffy]
operation (about 2 hours and the [Fluffy] light will
flash.)
※Since the Dry is completed, please remove the
clothes soon.
To cancel the [Fluffy] after Dry (P. 38)
●●Capacity 8 kg or less.●●Normal / Stain Master +
According to the
maximum capacity of
each model (P. 9)
1Put in the clothing, close the door, and
press the power button.
●●When Wash, do not put the clothing over the top
of the entry, or it will likely to cause damage to the
product.
[Normal] display light is on
2Press [Heated Program] to [Water Warm Up]
Select [Water Warm UP] to [Hygiene] to [Super Soak] to
[Wash]
3Press [Dry Mode] to (Wash+Dry)
●●Select [Normal], [Extra Dry], [Gentle Dry] or
[Timed Dry].
4Start
5Put in the detergent (P. 13)
The operation is complete with buzzer.
(Take out the laundry.)
Wash normal
clothing
Normal / Normal • StainMaster+
4 123

18
 Preparation
(1) Laundry preparation (P. 10)
clothing classification Pre-treatment
(2) Turn on the water faucet.
(3) Put the laundry in the drum and close the door
1Turn the power on.
2Press [Wash Program] select to
[Gentle Hand Wash]
3Add neutral liquid detergent into the
detergent box.
Note
●●Since liquid detergents are recommended using in
[Gentle Hand Wash] program.
4Start
●●When the sweaters to rise, [pause]
operation, open the door and gently press
them, then start again.
●The operation is complete with buzzer.
(Take out the laundry.)
(Not handling immediately may cause wrinkle or dyeing)
Note
• Shrinkage →(P. 26)
• [Stain Master +], [Fluffy], [Auto Drum clean], [Reserve] and [Dry]
cannot be used.
• Do not use bleach.
• Use water temperature below 30˚C.
• Delicate clothes as wired bras, lace items and small items,
please put into laundry net before washing. (P. 11)
Washable items
Unwashable Items
By softly shaking the drum, this program gently washes delicate clothes, etc.
(maximum capacity of 1.5 kgor less)
Washable items
With or markings
Cashmere sweater and
summer sweater, etc.
Casual pants Blouse
●●Some clothing cannot be washed even with the
marking→(P. 10)
Note
●●Do not wash clothes with no laundry labels, with unclear
material marking or one that fades.
●●You may apply non-fluorescent detergent agent on collars and
cuffs for sebum and dirt, and then remove those by brushing
lightly with a soft bristle brush.
●●For the following scenarios, clothes will need pre-treatment.
situación.
Wrap buttons of darker color
with plastic wrap.
Fix ruffle hem
with thread.
●●If you wash only 1 sweater or other clothing, you may wash
1-2 additional bath towels together
(to achieve balance during spinning).
 Usable detergent
●●For commercially available detergents, buy cold wash
detergent (to wash sweaters, and delicate clothes,
without fluorescent agent)
●●Do not use detergents other than the above ones
because other detergent may not be completely
dissolved and may have an adverse effect on the fibers.
●●According to different types of detergents, some of
them may create excessive foams and cannot wash the
clothes clean.
Method to put in laundry
Lay the laundry flat and overlap
when putting them inol
(weight Normal)
Sweaters about 400 g
Blouse about 200 g
Capacity 1.5 g
Casual pants about 400 g
1
2 4
[Gentle Hand Wash] Program
Wash gentle hand wash clothes

19
Wash Instruction
How to put in the bedding
2
1
1
3 2 5
1Turn the power on.
2Press [Wash Program] select to
[Bedding]
3Press [Stain Master +] to [Water Warm
Up]
(※Suitable when water temperature is lower
such as winter)
4Press [Dry Mode] to (Wash+Dry)
●●Select [Normal] to turn on the lamp.
5Start
6Put in liquid detergent
※Liquid detergent is recommended.
The operation is complete with buzzer.
(Take out the laundry.)
Wash+Dry Wash
4
Washable bedding and sheets
Bedding and quilts that cannot be washed
 Types and weight
100% synthetic fiber or
100% cotton blankets
with marking of
double size or below.
Synthetic fiber (polyester,
acrylic) sheets with
marking of single size or
below.
Double size Single size Single size Single size
Thick bedding of under
about 5 kg.
Thick bedding
under about
3 kg.
Cashmere bedding,
cotton blankets
under about 1.4 kg.
Towels, quilts (cotton
products included) of under
1 kg.
●●Bedding with burr of 10 mm or above (plush) (or the burr
may be damaged)
●●100% wool blankets
●●2 or more bedding
●●duvet
●●2 or more sheets
 Preparation
(1) Turn on the water faucet.
(2) Put the laundry in the drum and close the door
Fold the bedding or sheet
●●Fold into 4 layers
Put in the blanket
Fold it in zig zag shape (6 layers) inside the drum.
Direct the
both ends to
the back.
●●Capacity 4 kg or less. ●●Normal 5 kg or less
●●Stain Master + 4 kg or less
Caution
• Do not wash clothes without laundry label, waterproof cover
cloth or cover.
[Bedding] Program
Note
• [Fluffy] and [Auto Tub Clean] cannot be used.
• For [Bedding] cycle, only [Normal] Dry cycle can be selected
for [Wash+Dry].
• Water volume cannot be changed to [Middle], [Low] or [Extra
Low].
Wash large sheets or bedding

20
1Turn the power on
Note
• For everyday clothing, make them fluffy after spinning
before putting in again.
• When exceeding capacity limit or putting in too many
clothes, while the operation will be proceeded, but the
clothes will not fully dry
(Dry time will be elongated, uneven Dry, or wrinkling,
etc.)
2Dry Select [Dry Mode]
(Press and hold for at least 5 seconds)
3Select [Dry Mode] mode
4Start
The operation is complete with buzzer.
(Take out the laundry.)
●●Select Dry mode basing on the type of clothes →(P. 9)
●●Clothes that cannot be dried →(P. 10)
●●Methods to improve the Dry effect (P. 6)
●●Each press will switch to the next option.
Normal →Extry Dry →Gentle Dry →10 min. →30 min.
→1:00 (hr.) →1: 30 (hr.) →2: 00 (hr.) →2:30 (hr.) →light
off →Normal
●●For small amount of laundry (1 kgor less) or clothes that are
half-dried, it is suggested to use [Timed Dry] function. (Using
Dry method outside of Timing will make the operation time
longer).
●●For clothes that are not easy to dry, please proceed with
spinning (15 minutes) before Dry.
Select time when setting the
time.
Proceed with Dry operation only.
 Preparation
(1) Laundry preparation (P. 11)
●●Even for Dry cycle, the water faucet must still be turned
on.
(2) Put the laundry in the drum and close the door
(3) Please proceed with ventilation.
Note
• For [Gentle Dry] program, [Fluffy] operation will not be
proceeded.
• If ventilation is not sufficient, basing on the temperature
difference, there will be a little condensation on window and
groove wall or Dry time becomes longer.
• [Preset] and “Auto Tub Clean” cannot be used.
4 12,3
Drying
