Panduit CJS588 User manual

For Technical Support: www.panduit.com/resources/install_maintain.asp
INSTALLATION INSTRUCTIONS
© Panduit Corp. 2014 PN348A
Page 1 of 3
Individual foil
Conductors
Braid
STP / PIMF
pair screen
0.5 in
(12.7 mm)
3.0 in
(76.2 mm)
Mini-Com Mini-Jack Shielded Jack Module
Part Number: CJS588
CABLE PREPARATION
3.0 in
(76.2 mm)
0.60 in
(15.2 mm)
Drain wire
Drain wire
Overall foil
Conductors
Drain wire
FTP / ScTP
screen
with
drain wire
without
drain wire
Conductors
Braid
S-FTP
Overall foil
screen
0.5 in
(12.7 mm)
3.0 in
(76.2 mm)
Note: May also use S-STP / PIMF cable type (conductors, individual foil pair screen, overall foil screen, and braid).
Remove all but one twist per pair, smooth conductors and arrange
in proper color sequence.
1
2
1
3
5
4
6
8
7
GREEN
WHITE/GREEN
WHITE/ORANGE
WHITE/BLUE
BLUE
ORANGE
BROWN
WHITE/BROWN
R3
T3
T2
T1
R1
R2
R4
T4
2
1
3
5
4
6
8
7
ORANGE
WHITE/ORANGE
WHITE/GREEN
WHITE/BLUE
BLUE
GREEN
BROWN
WHITE/BROWN
R2
T2
T3
T1
R1
R3
R4
T4
Mini-Com Mini-Jack Color-Coded Wire Positions
T568A T568B
78645 312
TERMINATION

For Technical Support: www.panduit.com/resources/install_maintain.asp
INSTALLATION INSTRUCTIONS
© Panduit Corp. 2014 PN348A
Page 2 of 3
2
CWST
snipping
tool
3
4
5
CWST
6
CJT
Snap
tool
7
(OR)
SHIELD INSTALLATION
1
2
3
Drain wire
4
For FTP / ScTP with drain wire
5
Drain wire
6
Crimp
RG59 coax crimp tool recommended
for crimping shield ring.
ring
All Metal patch
panel shielding

INSTALLATION INSTRUCTIONS
© Panduit Corp. 2014 PN348A
E-mail:
[email protected]m
Phone:
866-405-6654
For Instructions in Local Languages
and Technical Support:
www.panduit.com/resources/install_maintain.asp www.panduit.com
Page 3 of 3
TERMINATION CAP REMOVAL
1
2
SHIELD INSTALLATION
For FTP / ScTP without drain wire,
S-FTP, STP / PIMF, S-STP / PIMF
1
Foil or braid
2
3
4
5
6
RG59 coax crimp tool recommended
for crimping shield ring.
Crimp
ring
All metal patch
panel shielding
Notes:
1. For specified performance, follow TIA/EIA 568-B installation guidelines.
2. Jack modules can terminate PVC or Plenum rated 22-24 AWG solid or stranded IWC cable with 0.048 in. (1.2 mm) maximum insulated
conductor outside diameter.
3. Jack modules may be re-terminated a minimum of 10 times.
4. For technical and performance information, consult Panduit Technical Support.
As with all Wiring Accessories, the following statements apply:
1. Never install communications wiring during a lightning storm.
2. Never install communications wiring in wet locations unless the jack is specifically designed for use in wet locations.
3. Never touch uninsulated communications wiring or terminals unless the communication line has been disconnected at the network interface.
4. Use caution when installing or modifying communication wiring.
1
2
3
4
5
6
2
1
3
5
4
6
78
87
WIRING DIAGRAM
Part Number - CJS588
Modular Plug
Contacts
Insulation
Displacement
Contacts
18
Pin #’s
2
1
3
5
4
6
8
7
GREEN
BLACK
RED
WHITE
BLUE
ORANGE
BROWN
YELLOW
R3
T3
T2
T1
R1
R2
R4
T4
2
1
3
5
4
6
8
7
ORANGE
RED
BLACK
WHITE
BLUE
GREEN
BROWN
YELLOW
R2
T2
T3
T1
R1
R3
R4
T4
IEC 60708-1
“A” wire “B” wire
