Parallel Audio Perfomer-100 Series User manual

PAGE 2 OPERATION MANUAL V1.0
Thank you for purchasing this wireless microphone system.
Please take a few moments to read this operating manual to gain a thorough understanding of the function and
operation of both transmitter and receiver.
In the Box
Important
1. Please make sure that the output DC voltage range of the switching power covers that specied by the receiver
before turning it on.
2. The receiver and transmitter must be the same frequency.
3. The antenna diversity indicator will ash to denote RF signal received aer turning on the transmitter.
4. While speaking to the transmitter, the audio signal indicator will ash to denote signal received.
Live-100/Performer-100
IrDA Receiver
1 Transmitter
(Handheld/Beltpack)
Switching Adaptor
(plugvaries from countryto country)
Pair ofAntennas
Audio Cable Operation Manual
Note: The above specications are subject to change without prior notice.
CH:001
VOL:15

OPERATION MANUAL V1.0 PAGE 3
Parts and Functions
1. Power switch
2. IR sensor area
3. Diversity indicator
4. Audio signal indicator
5. LCD display
6. UP button
7. DOWN button
8. IrDA synchronisation button
9. SET button
10. Antenna B socket (TNC)
11. Balanced audio output
12. Unbalanced audio output
13. Antenna A socket (TNC)
14. DC in
Live-100
Performer-100

PAGE 4 OPERATION MANUAL V1.0
Channel Setting
1. Press and release SET button until the CHANNEL | FREQUENCY page appears.
2. Press p(UP) or q(DOWN) button to change the channel number. The corresponding frequencywill change
accordingly. 5 seconds aer selecting a channel, it will be automatically saved.
For an interference- free operation, a cleaner channel might be necessary if the current one receives too much
interference. To select a new channel:
Align infrared areas of the receiver and transmitter within 10~30cm.
Channel Synchronising ofthe Receiver and Transmitter
CHANNEL:001
FREQ:650.000MHz
CHANNEL:010
FREQ:652.250MHz
Volume Adjusting
The setting can be made right on the homepage.
Aer the setting is made, wait 5 seconds to store the setting.
CH:001
VOL:15
CH:001
VOL:10

OPERATION MANUAL V1.0 PAGE 5
Sync Channel from Receiver ÚTransmitter
STEP 1: Press the SYNC button of the receiver.
STEP 2: The receiver’s LCD will display IRDA DATA SEND to denote
synchronising signal being sent.
STEP 3: The channel/frequency of the transmitter will change and then
the synchronisation is complete.
Sync Channel from Transmitter ÚReceiver
STEP 1: Press the synchronising button of the transmitter.
STEP 2: The transmitter’s LED will glow to denote
transmitting the frequencyto the receiver and
synchronising the channels.
STEP 3: The channel/frequency of the receiver will change
and then the synchronisation is complete.
If it doesn’t work check that you have the IR sensor panels aligned, that they are facing each other, devices are within
30cm of each other, and try again.
Channel Scanning
For an interference-free operation, a cleaner channel might be necessary if the current one receives too much
interference. Before scanning, the transmitter must be switched o.
1. Press and release SET button until the AUTO SCAN page appears.
2. Press p(UP) or q(DOWN) button to nd a clear, interference-free channel. 5 seconds aer selecting a channel,
it will be automatically saved.

PAGE 6 OPERATION MANUAL V1.0
Since increasing the squelch level will also reduce the reception distance, it’s recommended to choose the lowest level
that can eliminate the interference.
If this still does not solve the problem it means this frequency is not suitable. Adjust the squelch back to its preset level
and use the scan function to locate a clear, interference-free channel.
Audio Output Connection
Balanced Output: XLR connector provides balanced audio output signal from this jack to the mixer/amplier. Use an
audio output cable with “XLR” or “Cannon” connector, connect one end to the balanced output jack of the receiver, and
the other end to the “MIC IN” jack of the mixer/ amplier.
Adjusting Squelch Level
When interference is encountered try reducing the sensitivity ofthe receiver, thus making it less susceptible
to interference.
1. Press and release SET button until the SQUELCH SETUP page appears.
2. Press p(UP) or q(DOWN) button to choose a new level between 1 and 10.
5 seconds aer selecting a level, it will be automatically saved.
SQUELCH SETUP
LEVEL:01
SQUELCH SETUP
LEVEL:03

OPERATION MANUAL V1.0 PAGE 7
Unbalanced Output: ¼” PHONE PLUG connector provides unbalanced audio output signal from this jack to the mixer/
amplier. Use an audio output cable with ¼” PHONE PLUG connectors. Connect one end from the unbalanced output
jack of the receiver, and the other end to the “LINE IN” jack of the mixer/ amplier.
Receiver Installation
For best operation, the receiver should be at least 1m above the ground and 1m away
from a wall or metal surface to minimise reections. The transmitter should also be
at least 1m away from a wall or metal surface to minimise reections. The transmitter
should also be at least 1m away from the receiver. Keep antennas away from noise
source such as motors, automobiles, neon light and large metal objects.
Rack Mounting
The receiver can be cabinet-mounted by either one or two units. If only one receiver is to be mounted, an optional kit is
available and it’s installed as shown in Fig 1. If two receivers are to be mounted, they can be assembled by another kit and
installed as shown in Fig 2.

PAGE 8 OPERATION MANUAL V1.0
