Parallel Audio Stage-100 Series User manual

PAGE 2 OPERATION MANUAL V1.0
Thank you for purchasing this wireless microphone system.
Please take a few moments to read this operating manual to gain a thorough understanding of the function and
operation of both transmitter and receiver.
In the Box
Stage-100
IrDA Receiver
1 Transmitter
(Handheld/Beltpack)
Switching Adaptor
(plugvaries from countryto country)
Pair ofAntennas
Operation Manual
Note: The above specications are subject to change without prior notice.

OPERATION MANUAL V1.0 PAGE 3
Parts and Functions
1. Power switch
2. IR sensor area
3. Diversity indicator
4. Radio frequency indicator
5. Audio frequency indicator
6. LCD display
7. UP button
8. DOWN button
9. IrDA synchronisation button
10. SET button
11. Antenna B socket (TNC)
12. Balanced audio output
13. Unbalanced audio output
14. DC in
15. Antenna A socket (TNC)
FRONT PANEL
REAR PANEL

PAGE 4 OPERATION MANUAL V1.0
Channel Setting
1. Press and release SET button until the CHANNEL | FREQUENCYpage appears.
2. Press p(UP) or q(DOWN) button to change the channel number. The corresponding frequencywill change
accordingly. 5 seconds aer selecting a channel, it will be automatically saved.
For an interference- free operation, a cleaner channel might be necessary if the current one receives too much
interference. To select a new channel:
Channel Scanning
For an interference-free operation, a cleaner channel might be necessary if the current one receives too much
interference. Before scanning, the transmitter must be switched o.
1. Press and release SET button until the AUTO SCAN page appears.
2. Press p(UP) or q(DOWN) button to nd a clear, interference-free channel. 5 seconds aer selecting a channel,
it will be automatically saved.
CHANNEL:001
FREQ:650.000MHz
CHANNEL:010
FREQ:652.250MHz

OPERATION MANUAL V1.0 PAGE 5
Sync Channel from Receiver ÚTransmitter
Channel Synchronising ofthe Receiver and Transmitter
STEP 1: Press the SYNC button of the receiver.
STEP 2: The receiver’s LCD will display IRDA DATA SEND to
denote synchronising signal being sent.
STEP 3: The channel/frequency of the transmitterwill
change. Synchronisation is complete when the LCD displays
PLL CHANNEL COPIED BY IRDA.
STEP 4: Please try again if LCD displays IRDA SEND FAIL..
Sync Channel from Transmitter ÚReceiver
STEP 1: Press the synchronising button of the
transmitter.
STEP 2: The transmitter’s LED will glow to denote
transmitting the frequencyto the receiver and
synchronising the channels.
STEP 3: The channel/frequency of the receiver will
change and then the synchronisation is complete.
If it doesn’t work check that you have the IR sensor panels aligned, that they are facing each other, devices are within
30cm of each other, and try again.
Align infrared areas of the receiver and transmitter within 10~30cm.
CH:001
VOL:15
CH:010
VOL:15
PLL CHANNEL
COPIED BY IRDA
CH:001 650.000M
IRDA DATA SEND
Volume Adjusting
1. The setting can be made right on the homepage.
2. Press p(UP) or q(DOWN) button to choose volume level. 5 seconds aer selecting a channel, it will be
automatically saved.
CH:001
VOL:15
CH:001
VOL:10

PAGE 6 OPERATION MANUAL V1.0
Adjusting Squelch Level
Since increasing the squelch level will also reduce the reception distance, it’s recommended to choose the lowest level
that can eliminate the interference.
If this still does not solve the problem it means this frequency is not suitable. Adjust the squelch back to its preset level
and use the scan function to locate a clear, interference-free channel.
When interference is encountered try reducing the sensitivity of the receiver, thus making it less susceptible
to interference.
1. Press and release SET button until the SQUELCH SETUP page appears.
2. Press p(UP) or q(DOWN) button to choose a new level between 1 and 10.
5 seconds aer selecting a level, it will be automatically saved.
Receiver Installation
For best operation, the receiver should be at least 1m above the ground and 1m away
from a wall or metal surface to minimise reections. The transmitter should also be
at least 1m away from a wall or metal surface to minimise reections. The transmitter
should also be at least 1m away from the receiver. Keep antennas away from noise
source such as motors, automobiles, neon light and large metal objects.
SQUELCH SETUP
LEVEL:01
SQUELCH SETUP
LEVEL:03
Rack Mounting
The receiver can be cabinet-mounted by either one or two units. If only one receiver is to be mounted, an optional kit is
available and it’s installed as shown in Fig 1. If two receivers are to be mounted, they can be assembled by another kit and
installed as shown in Fig 2.

OPERATION MANUAL V1.0 PAGE 7
Audio Output Connection
There are two audio outputs on the back of the receiver, Mic-level balanced and Line-level unbalanced.
Use shielded audio cable for the connection between the receiver and the amplier/mixer. If the amplier/mixer has
a 1/4”(6.3mm) phone jack, connect a cable from the 1/4”(6.3mm) unbalanced audio output from the receiver to the
amplier/mixer.
If the amplier/mixer has an XLR input, connect a cable from the balanced XLR audio output from the receiver to the
amplier/mixer input.

PAGE 8 OPERATION MANUAL V1.0
Parts and Functions
1. Cartridge
2. Battery power LED
3. Power switch
4. LCD
5. Menu button
6. Setting button
7. IrDA synchronising button
8. Battery compartment
9. Colour cap
10. IrDA sensor area
11. Charging port
UHF HANDHELD MICROPHONE (HH9000)
Channel Synchronising ofthe Receiver and Transmitter
Align infrared areas of the receiver and transmitter within 10~30cm.
Sync Channel from Receiver ÚTransmitter
STEP 1: Press the SYNC button of the receiver.
STEP 2: The receiver’s LCD will display IRDA DATA SEND to
denote synchronising signal being sent.
STEP 3: The channel/frequency of the transmitterwill
change. Synchronisation is complete when the LCD displays
PLL CHANNEL COPIED BY IRDA.
STEP 4: Please try again if LCD displays IRDA SEND FAIL..
Sync Channel from Transmitter ÚReceiver
STEP 1: Press the synchronising button of the
transmitter.
STEP 2: IRDA PLL CALL will appear on the microphone’s
LCD to denote synchronising the receiver’s channel.
STEP 3: If the receiver’s channel is synchronised,
PLL SEND OK will appear. Please try again if the LCD
shows IRDA FAIL.
If it doesn’t work check that you have the IR sensor panels aligned, that they are facing each other, devices are within
30cm of each other, and try again.
IRDA
PLL CALL
PLL SEND
OK
CH:001
650.000M
CH:010
652.250M

OPERATION MANUAL V1.0 PAGE 9
Battery Installation and Indicator
This microphone requires 2 x AA batteries to operate.
To install, remove the battery cover and slide the batteries according to the correct polarity into the battery
compartment and replace the battery cover.
Note: Batteries contain a corrosive acid that may leak and damage the microphone when stored for a long period.
Batteries should be removed from the microphone if it is not to be used for a prolong period of about 4 weeks or more.
When the microphone is switched ON a blue LED (2) will blink once to indicate the batteries installed are in good
condition. Ifthe LED remains illuminated, it means the batteries are weak and replacement is required.
Channel Setting
1. Use MENU button (5) to go to the CHANNEL | BATTERY STATUS page.
2. The upper-right channel number will ash to allow changes to be made.
3. Press SET button to change the channel number. 5 seconds aer selecting a channel, it will be automatically saved.
BatteryType Setting
1. Use MENU button (5) to go to the BATTERYTYPE page.
2. Press SET button (6) for 3 seconds, then the cursor Ù will ash to allow changes to be made.
3. Press SET button to select either NiMH (rechargeable battery) or AKLN (alkaline battery). 5 seconds aer selecting
a battery type, it will be automatically saved.
Important: NiMH battery must be selected when rechargeable battery is being used. Never select AKLN (alkaline) when
microphone is intended for charging as alkaline battery isn’t rechargeable. Wrong battery selection will result in battery
sensing electronics to display wrong and misleading status information.
CH:001 CH:010
NIMH
AKLN
NIMH
AKLN

PAGE 10 OPERATION MANUAL V1.0
Parts and Functions
1. Antenna
2. LCD
3. Cover release button
4. Power switch
5. IrDA synchronising button
6. Menu button
7. Setting button
8. High-impedance gain control (GT)
9. Low-impedance gain control (MT)
10. Battery compartment
11. Audio mute switch
12. Battery power LED
13. IrDA sensor area
14. Mini XLR connector
15. Charging contacts
UHF BELTPACK TRANSMITTER (BP9000)
Channel Synchronising ofthe Receiver and Transmitter
Align infrared areas of the receiver and transmitter within 10~30cm.
Sync Channel from Receiver ÚTransmitter
STEP 1: Press the SYNC button of the receiver.
STEP 2: The receiver’s LCD will display IRDA DATA SEND to
denote synchronising signal being sent.
STEP 3: The channel/frequency of the transmitterwill
change. Synchronisation is complete when the LCD displays
PLL CHANNEL COPIED BY IRDA.
STEP 4: Please try again if LCD displays IRDA SEND FAIL..
Sync Channel from Transmitter ÚReceiver
STEP 1: Press the synchronising button of the
transmitter.
STEP 2: IRDA PLL CALL will appear on the transmitter's
LCD to denote synchronising the receiver’s channel.
STEP 3: If the receiver’s channel is synchronised,
PLL SEND OK will appear. Please try again if the LCD
shows IRDA FAIL.
If it doesn’t work check that you have the IR sensor panels aligned, that they are facing each other, devices are within
30cm of each other, and try again.
IRDA
PLL CALL
PLL SEND
OK
CH:001
650.000M
CH:010
652.250M

OPERATION MANUAL V1.0 PAGE 11
Battery Installation and Indicator
This transmitter requires 2 x AA batteries to operate.
To install, remove the battery cover and slide the batteries according to the correct polarity into the battery
compartment (10) and replace the battery cover.
Note: Batteries contain a corrosive acid that may leak and damage the microphone when stored for a long period.
Batteries should be removed from the microphone if it is not to be used for a prolong period of about 4 weeks or more.
When the transmitter is switched ON a red LED (12) will blink once to indicate the batteries installed are in good
condition. Ifthe LED remains illuminated, it means the batteries are weak and replacement is required.
Channel Setting
1. Use MENU button (6) to go to the CHANNEL | BATTERY STATUS page.
2. The upper-right channel number will ash to allow changes to be made.
3. Press SET button to change the channel number. 5 seconds aer selecting a channel, it will be automatically saved.
BatteryType Setting
1. Use MENU button (6) to go to the BATTERYTYPE page.
2. Press SET button (7) for 3 seconds, then the cursor Ù will ash to allow changes to be made.
3. Press SET button to select either NiMH (rechargeable battery) or AKLN (alkaline battery). 5 seconds aer selecting
a battery type, it will be automatically saved.
Important: NiMH battery must be selected when rechargeable battery is being used. Never select AKLN (alkaline) when
transmitter is intended for charging as alkaline battery isn’t rechargeable. Wrong battery selection will result in battery
sensing electronics to display wrong and misleading status information.
CH:001 CH:010
NIMH
AKLN
NIMH
AKLN
Gain Setting (GT/MT)
Gain control enables the user to set dierent output levels. GT (8) is for the use of
instrument with high impedance, such as guitar while MT (9) is for the use of low
impedance such as lapel or headset microphones.

PAGE 12 OPERATION MANUAL V1.0
PARALLEL AUDIO WARRANTY INFORMATION – 5 YearWarranty Term
Consumer Guarantees
When you purchase a NAS distributed product, you have the peace of mind in knowing that your product is covered by the NAS warranty. The NAS warranty is provided by:
In Australia: National Audio Systems Pty Ltd, ABN 50 085 679 894 [‘NAS’], 127 Merrindale Drive, Croydon, Victoria 3136.
In New Zealand: NAS Solutions Limited, NZBN 9429046800992 [‘NAS’], 7F Douglas Alexander Parade, Rosedale, Auckland 0632.
The Australian ConsumerLaw protects consumers by giving them certain guaranteed rights when they buy goods and services. Rights guaranteed under theAustralian Consumer
Law include;
• The goods are of acceptable quality;
• The goods match their description or any sample ordemonstration model;
• The goods are t for any represented purpose or purpose which the consumer has made known;
• Repairs and spare parts are reasonably available (unless notice has been providedthat repairs orspare parts would not be available); and
• The services are carried outwith reasonable care and skill and are completed within a reasonable time
These rights are called ‘Consumer Guarantees’ and apply automatically whenever goods or services are supplied to a consumer. These Consumer Guarantees cannot be refused, changed or
limited.
Consumer Guarantees have no set time limit and depending on the price and quality of goods a Consumer may be entitled to a remedy aer any manufacturers’ or NAS’s extended warranty
has expired.
The Specic Warranty Table Information outlines the warranty period, warranty type and any specic exclusions for your NAS product. NAS considers the warranty period specied in the
Specic Warranty Table to be a reasonable warranty period having regard to the price, design, manufacture and expected use of the product.
General Warranty (‘Warranty’)
NAS products come with guarantees that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure or if the goods fail to be of
acceptable quality. You are also entitled to have the goods repaired or replaced if the goods fail to be ofacceptable qualityand failure does not amount to a majorfailure. What constitutes a
major failure is set out in the Australian Consumer Law.
Subject to the terms and conditions set out below, and unless otherwise specied in the Specic Warranty Information for your NAS product, NAS agrees to repair or replace, at NAS’s cost,
the NAS product purchased by you in Australia or New Zealand from NAS or a NAS authorised reseller when the product does not perform substantially in accordance with the specications
during the warranty period specied in the Specic Warranty Table for your NAS product. NAS makes no other express warranties in respect of your NAS product. To make a claim under this
Warranty, valid proof of purchase must be presented when the warranty claim is made, along with any other required information. The Warranty oered by NAS is not transferable.
The Warranty will only apply ifyour NAS product has been installed and used in accordance with NAS’s recommendations as noted in the operating instructions.
Warranty Exclusions
The Warranty does not cover damage caused by;
• Misuse or abuse of the product by You;
• Incorrect operation or not following the operation instructions (as noted in the operating instructions);
• Improper installation;
• Incorrect orimproper maintenance or failure to maintain the product;
• Failure to clean or improper cleaning ofthe product;
• Incorrectvoltage or non-authorised electrical connections;
• Adverse external conditions such as incorrect or uctuations in electrical voltage, thunderstorm activity, acts of God, acts of terrorism, damage caused by vermin, or any other circumstance
beyond NAS’s control;
• Exposure to excessive heat, moisture or dampness;
• Exposure to abnormally corrosive conditions;
• Alterations or modications to the product made by You or a third party; or
• Damage as a result of accident, liquid, grit, impact or lack of proper care as indicated in the operating instructions;
• Damage resulting from the use of cleaning solvents such as acetone
The Warranty does not apply if any serial number or appliance plate on the product has been tampered with, removed or defaced.
The Warranty does not apply if the product has been repossessed under any nancial agreement.
The Warranty excludes accessories and consumable goods which have ceased working through normal wear and tear such as, but not limited to, batteries, lamps and other parts classiable
as a consumable part.
The Warranty does not cover the loss of any data howsoever caused. You shall be responsible for backing up and protecting data against loss, damage or destruction.
Products presentedfor repair may be replaced byrefurbished products of the sametype rather than being repaired. Refurbished parts may be used to repair the products. Replacementof the
product or a part does not extend or restart the Warranty Term.
The product will be at the owner’s risk whilst in transit to and from all NAS authorised service centres, unless transported by NAS or its authorised representatives.
NAS and its authorised service centres may seek reimbursement of anycosts incurred bythem whenthe product is found to be in good working order.
The cost of claiming under this warranty, including return of any product to NAS is to be borne by the consumer.
The Warranty excludes removal or reinstallation costs.
* All Parallel Audio products come with a 5 year warranty term, excluding Parallel Audio batteries and CD players (see below).
Parallel Audio Limited Batteryand CD PlayerWarranty: Batteries and CD players tted to all Parallel Audio portable PA products carry a 3 months warranty.
For further information and warranty claims, refer to our Support page at www.nas.solutions.
