Parrot Uncle F4503 Manual

TECHNICAL INFORMATION
F4503
Installation & Operating Instructions for the
Owner’s Installation ,Manual
WARNING: SHUT POWER OFF AT FUSE OR CIRCUIT BREAKER
THANK YOU FOR YOUR PURCHASE
SAFETY RULES
SKU Rated Voltage Light CCT.Rated power(motor).
110-120V AC E26 5*40W(MAX) EXCLUDE
F4503 56W
110-120V AC E26 5*40W(MAX) EXCLUDE
F4503AG 56W
110-120V AC E26 5*40W(MAX) EXCLUDE
F4503DWH 56W
110-120V AC E26 5*40W(MAX) EXCLUDE
F4503DWOW 56W
110-120V AC E26 5*40W(MAX) EXCLUDE
F4503SN 56W
Thank you for purchasing this quality product. To ensure correct function and safety, please read and save all
instructions before using the product
1. Mounting Bracket
2. Canopy screws
3. Canopy
4. Downrod&hanger ball
5. Bolt
6. Coupling cover
7. Lock pin
8. Top housing
9. Blades
10. Fan motor assembly
11. Base plate
12. Light kit
13. Wood screws
14. Expansion screws
15. Plastic anchor
16. Balance tapes
17. Remote control set
BEFORE INSTALLATION
Unpack your fan and check the contents.You should have followings:
CAUTION
READ INSTRUCTIONS CAREFULLY FOR SAFE
INSTALLATION AND FAN OPERATION. IF UNSURE CONSULT
A QUALIFIED ELECTRICIAN
INSTALLING THE FAN
Tools Required: Phillips screwdriver, Pair of pliers, straight slot screwdriver, adjustable wrench, step ladder, and wire cutters.
INSTALLLING THE MOUNTING BRACKET
The ceiling fan must be installed in a location so that the blades are 300mm spacing from the tip of the blade to the nearest o
NOTE:Hanger after the installation must be able to withstand the weight of 45kg or more
bjects or walls. When hanging the Fan REMEMBER to turn off the power..
Follow the instruction below to hang your fan properly:
1. For the concrete ceiling, drill two holes in the ceiling
and secure the mounting bracket to the ceiling with two
Φ8 (distance between the two holes should be
appropriate)expansion screws, flat washers,nuts
provided and tighten with a spanner.
2. For the wood ceiling, Secure the mounting bracket to the
ceiling is capable of carrying a load of at least 45KGS with
two long mounting screws and washers provided. Be sure
at least 30mm of the screw is threaded into the support.
3. Refer to the Fig. in right for mounting when the ceiling is
angled max. 15 degree angle.
1. To reduce the risk of electric shock, insure electricity has been turned off at the circuit breaker or fuse box before
beginning.
2. All wiring must be in accordance with the National Electrical Code and local electrical codes. Electrical installation
should be performed by a qualified licensed electrician.
3. WARNING: To reduce the risk of electrical shock and fire, do not use this fan with any solid-state fan speed control
device.
4. WARNING: To reduce the risk of fire, electric shock, or personal injury, mount to outlet box marked "Acceptable for
Fan Support of 45kg (99.12 lbs.) Or Less" and use mounting screws provided with the outlet box. Most outlet boxes
commonly used for the support of light fixtures are not acceptable for fan support and may need to be replaced. Due
to the complexity of the installation of this fan, a qualified licensed electrician is strongly recommended.
5. The outlet box and support structure must be securely mounted and capable of reliably supporting a minimum of
45KGS. Use only UL Listed outlet boxes marked FOR FAN SUPPORT.
6. The fan must be mounted with a minimum of 7 feet clearance from the trailing edge of the blades to the floor.
7. Avoid placing objects in the path of the blades.
8. To avoid personal injury or damage to the fan and other items, be cautious when working around or cleaning the
fan.
9. Do not use water or detergents when cleaning the fan or fan blades. A dry dust cloth or lightly dampened cloth will
be suitable for most cleaning.
10. After making electrical connections, spliced conductors should be turned upward and pushed carefully up into the
outlet box. The wires should be spread apart with the grounded conductor and the equipment-grounding conductor
on one side of the outlet box.
11. Electrical diagrams are for reference only.
12. The fan is suitable for indoor use only.
13. Please do not use the fan in a specific environment like high temperature environment, high
radiation environment, lampblack or other abnormal use environments.
110-120V AC E26 4*40W(MAX) EXCLUDE
F3602 41W

F4503
Installation & Operating Instructions for the
Owner’s Installation ,Manual
WARNING: SHUT POWER OFF AT FUSE OR CIRCUIT BREAKER
INSTALL THE DOWNROD
Changing the Downrod (Optional)
NOTE: Your fan comes with a 25cm downrod attached to the hanger ball. In addition, a 10cm downrod has
been provided to be used in case the ceiling is lower. In this case, perform the following steps for correct
installation:
1. Remove the hanger ball from downrod by loosening the setscrew at the top of the downrod which holds
the hanger ball to the downrod.
2. Slide the hanger ball down the downrod and remove the support pin.
3. Insert the support pin in the holes at the top of the 10cm downrod and slide the hanger ball up the 10cm
downrod. Make sure the support pin is properly seated in the grooves in the top of the hanger ball.
4. Tighten the set crews firmly .
Safety Cable Installation
For Canadian installation and for USA fan and light kit combinations over 35 lbs, the safety cable must be installed into the house structure beams. Make sure that when the safety cable is fully
extended the lead wires are longer than the cable and no stress is placed on the lead wires. Note: If Installing The Secondary Support Safety Cable in the U.S., Do Not Remove Knockouts In The
Outlet Box.
Hanging the Fan REMEMBER to turn off the power. Follow the steps below to hang your fan properly:
1) Remove the bolt, lock pin and set screws from the top of the housing assembly
2) Route wires exiting from the top of the fan motor through the coupling cover, canopy and then through the ball / downrod.
3) Align the holes at the bottom of the downrod with the holes in the coupling on top of the top housing .
4) Carefully insert the Bolt through the holes in the Coupling and downrod. Be careful not to jam the Bolt against the wiring inside the downrod. Insert the locking pin through the hole near the end
of the Bolt until it snaps into its locked position.
5) Tighten two set screws on top of the fan housing firmly
INSTALLING THE FAN TO MOUNTING BRACKET ON CEILING
1.Install ball end of downrod into mounting bracket opening. Align
(engage) slot on ball with tab on mounting bracket. Warning: Failure
to align slot on ball with tab may result in serious injury.
2.Slide the canopy up to ceiling andalign the keyhole slots on the
canopy with the preassembled screws on the hanger bracket. Twist
clockwise till lock. Tighten two screws securely.
USING YOUR CEILING FAN
REMOTE CONTROL
Turn on the power and check the operation of the fan
.OFF –Fan Shutdown
.HI, MED,LOW – Speed Controller
.LIGHT – Lamp Switch

F4503
Installation & Operating Instructions for the
Owner’s Installation ,Manual
WARNING: SHUT POWER OFF AT FUSE OR CIRCUIT BREAKER
MAKE THE ELECTRIC CONNECTIONS
AFTER INSTRUCTION
INSTALLING THE LIGHT KIT
WARNING: To avoid possible electrical shock, be sure electricity is turned off at the main
fuse box before wiring.
1. Insert the receiver into the mounting bracket with the flat side of the receiver facing the
ceiling.
2. Motor to Receiver Electrical Connections: Connect the Black wire from the fan to Black
wire from the receiver. Connect the white wire from the fan to the white wire from the
receiver. Connect the blue wire from the fan to the Blue wire from the receiver. Secure wire
connections with the wire nuts provided.
3. Receiver to House suppliy wires Electrical Connections: Connect the black(hot) wire from
the ceiling to the black wire from the receiver. Connect the white(neutral) wire from the
ceiling to the white wire from the Receiver. Secure the wire connections with the wire nuts
provided.
4. Ligt kit to motor wires Electrical Connections: Connect the two white wires from light pan
to the black and blue wires from fan. Secure the wire connections with the wire nuts
provided.
WOBBLE
The fan blades have been adjusted in the factory to minimize any wobble
NOTE:CEILING FANS TEND TO MOVE DURING OPERATION DUE TO THE FACT THAT THEY ARE MOUNTED ON A RUBBER CROMMET. IF THE FAN WAS MOUNTED RIGIDLY TO THE CEILING, IT WOULD CAUSE EXCESS
VIBRATION. MOVEMENT OF A FEW CENTIMENTERS IS QUITE ACCEPTABLE AND DOES NOT SUGGEST ANY PROBLEM
TO REDUCE THE FAN WOBBLE: PLEASE CHECK THAT ALL SCREWS WHICH SECURED THE MOUNTING BRACKET AND DOWNROD ARE SECURE.
BALANCING A WOBBLIGNG CEILING FAN:
For your convenience, a Balancing Kit is included; please follow this procedure when balancing the fan:
1) Install fan without light dome before balancing the fan.
2) Define the base plate into four areas(point A,B,C&D). Use one weight from the balance kit to lightly stick on the edge of the base plate(Point A), if the wobble worsens, then take off the balance kit to lightly stick on the
opposite side(Point B); if the wobble is worse,then go to the adjacent point C or D, if the wobble gets better, then securely stick on the weight at this location on the base plate.
3) After balancing the fan, assemble the light dome to the light base.
NOISE
When it is quiet(especially at night) you may hear occasional small noises. Slight power fluctuations and frequency signals superimposed in the electricity for off-peak hot water control,may cause a change in fan motor
noise. This is normal. Please allow a 24-hour “breaking-in” period, most noises associated with a new fan disappear during the time. The manufacturer’s warranty covers actual faults that may develop and NOT minor
complaints such as hearing the motor run – All electric motors are audible to some extent.
CARE AND CLEANING
1. Periodic cleaning of your ceiling fan is the only maintenance required. Use a soft brush or lint free cloth to avoid scratching the paint finish. Please make sure to turn off electricity power before you maintain your fan
2. Do not use water when cleaning your ceiling fan. It could damage the motor or the blades and create the possibility of an electrical shock.
3. Motor has permanently lubricated ball bearing. No need to oil
NOTE: MAKE SURE THE POWER IS OFF AT THE ELECTRICAL PANEL BOX BEFORE YOU ATTEMPT ANY CLEANING OR REPAIRS.
1.Remove the 4 garnish nuts preassembled from the garnish screws on the base plate.
Connect two white wires from light kit to the black and blue wires from fan, using wire
nuts provided. Attach the light fixture onto the base plate. Aligning the 4 holes on the light
fixture with the 4 preassembled garnish bolts on the base plate. Reinstall the 4 garnish
nuts that were just removed. And tighten all nuts and screws securely.
2. Install 5 X Max.40 watt bulbs (bulb not included)
WARNING: Over lamping the fan will result in the fan lights shutting down until the proper
wattage of bulbs are installed. Replace bulbs with the correct wattage bulbs, turn the
power on.
WARNING: Do not replace bulb until it cools down.

F4503
Installation & Operating Instructions for the
Owner’s Installation ,Manual
WARNING: SHUT POWER OFF AT FUSE OR CIRCUIT BREAKER
BEFORE INSTALLATION
Unpack your fan and check the contents.You should have followings
1. Mounting Bracket
2. Canopy screws
3. Canopy
4. Downrod&hanger ball
5. Bolt
6. Coupling cover
7. Lock pin
8. Top housing
9. Blades
10. Fan motor assembly
11. Base plate
12. Light kit
13. Wood screws
14. Expansion screws
15. Plastic anchor
16. Balance tapes
17. Remote control set
