Parrot Uncle F8279110V Manual

www.parrotuncle.com
English ñ / Francais/ Espanol ç
F8279110V

TECHNICAL INFORMATION
SKU
120Vac 25W 18W
Nominal Voltage Nominal output(motor) light
Safety Information
WARNING: SHUT POWER OFF AT FUSE OR CIRCUIT BREAKER
F8279110V
Installation & Operating Instructions for the
Parrot Uncle Owner's Installation, Manual
F8279110V
WARNING: TO reduce the risk of personal injury,
do not bend the blade brackets (also referred to as
flanges) during assembly or after installation. Do not
insert objects in the path of the blades.
WARNING: Remove the rubber motor stops on
the bottom of the fan before installing the blades
or testing the motor.
WARNING: To reduce the risk or fire or electric
shock, do not use this fan with any solid-state
speed control device.
WARNING: To avoid possible electric shock,
turn the electricity off at the main fuse box before
wiring. lf you feel you do not have enough electrical
wiring knowledge or experience, contact a licensed
electrician.
WARNING: Electrical diagrams are for reference
only. Optional use of any light kit shall be UL-listed
and marked suitable for use with this fan.
WARNING: To reduce the risk of fire, electric
shock, or personal injury, mount to outlet box
marked”Acceptable for fan support of 35lbs.
(15.9 kg) or less "and use the screws provided
with the outlet box.
1. To reduce the risk of electric shock, the electricity has been
turned off at the circuit breaker or fuse box before begin.
2. All wiring must be in accordance with the National Electrical
Code NASI/NFPA70-1999 and local electrical codes.
Electrical installation should be performed by a qualified
licensed electrician.
3. The outlet box and support structure must be securely
mounted and capable of reliably supporting 35lb.(15.9kg).
Use only UL listed outlet boxes marked “Acceptable for Fan
Support of 35lbs (15.9kg) or less.”
4. The fan must be mounted with a minimum of 7 ft. (2.1m)
clearance from the trailing edge of the blades to the floor.
5. Do not operate the reversing switch while the fan blades are
in motion. You must turn the fan off and stop the blades
before you reverse the blade direction.
6. Do not place objects in the path of the blades.
7. To avoid personal injury or damage to the fan and other
items, please be careful when working around or cleaning
the fan.
8. Electrical diagrams are for reference only. Light kits that are
not packed with the fan must be UL-listed and marked
suitable for use with the model fan you are installing.
Switches must be UL General Use Switches.
Refer to the instructions packaged with the light kits and
switches for proper assembly.
9. After making electrical connections, spliced conductors
should be turned upward and pushed carefully up into the
outlet box. The wires should be spread apart with the
grounded conductor and the equipment-grounding conductor
on one side of the outlet box. and the ungrounded conductor
on the other side of the outlet box.
10. All setscrews must be checked and retightened where
necessary before installation.

WARNING: SHUT POWER OFF AT FUSE OR CIRCUIT BREAKER
F8279110V
Installation & Operating Instructions for the
Parrot Uncle Owner's Installation, Manual
Pls check whether above accessories are completed or not?Yes,and install.
x6
REMOTE CONTROL ( 1PC )
Blade screw (16PCS)
Washer (2PCS)
Plastic wire nut (4PCS)
Screws (2PCS)
Mounting screws (2PCS)
Light kit
Shade
Blade (5PCS)
Ceiling Bracket
Motor Assembly
Switch Housing
Mounting Bracket

WARNING: SHUT POWER OFF AT FUSE OR CIRCUIT BREAKER
F8279110V
Installation & Operating Instructions for the
Parrot Uncle Owner's Installation, Manual
1
2
Check existing outlet box (not included) to ensure it is
securely fastened to at least two points in a structural
ceiling member and can support the full weight of the
fan.Once verified, install ceiling plate to the outlet
box using the screws and washers provided.
DANGER: A loose outlet box can cause the fan to
wobble and increase the fan’s potential to fall, which
could result in serious injury or death.
Hang the motor assembly from the hook on the ceiling
bracket assembly as shown. (Figure 2) You can now
proceed with the electrical wiring of your fan.

WARNING: SHUT POWER OFF AT FUSE OR CIRCUIT BREAKER
F8279110V
Installation & Operating Instructions for the
Parrot Uncle Owner's Installation, Manual
LIGHT MUST BE KEPT AT THE ON POSITION
FAN MUST BE KEPT AT THE HIGH SPEED
After connections have been made,
put the white and green leads to one
side and the black leads towards the
other side, the connection should be
turned upward and carefully push
leads into the outlet box.
The wires should be spread apart
with the grounded conductor and
the equipment-grounding conductor
on one side of the outlet box and
the ungrounded conductor on the
other side.
Install remote control
Outlet box
Receiver
GREEN GREEN
GREEN
BLACK (AC IN L)
WHITE (AC IN N)
BLACK (L) WHITE (N)
BLUE (FOR LIGHT)
BLUE (FOR LIGHT)
WHITE (TO MOTOR N)
BLACK (TO MOTOR L)
WHITE (TO MOTOR)
BLACK (TO MOTOR)

WARNING: SHUT POWER OFF AT FUSE OR CIRCUIT BREAKER
F8279110V
Installation & Operating Instructions for the
Parrot Uncle Owner's Installation, Manual
3
4
5
Remove and retain two opposing screws from the
motor assembly, then loosen the remaining two
screws.
Mount your fan by sliding the motor assembly over
the mounting bracket with the two loosened screws
going into the “L” slots in the ceiling bracket. Be sure
all wiring is tucked into the motor housing and is not
pinched. Once the motor assembly is flush with your
ceiling, turn clockwise to seat the screws into the
keyed portion of the slot. Tighten the screws.
Assemble the motor assembly to ceiling bracket
using the previously removed screws and securely
tighten all screws.

WARNING: SHUT POWER OFF AT FUSE OR CIRCUIT BREAKER
F8279110V
Installation & Operating Instructions for the
Parrot Uncle Owner's Installation, Manual
6
7
8
Please remove the flexible bushing prior to pushing
the canopy trim ring up. Push the canopy trim ring
up to conceal the screws, such that the mounting
tabs seat into the dimpled grooves in the ceiling
bracket midway between the screws.
Slide blades through slots in motor housing and
attach to the motor hub using the screws. Make sure
the screws securing the blades to the motor hub are
tight and are properly seated.
NOTE: Periodically check blade hardware and
resecure if necessary.
Remove one of the three screws in the support bracket
at the bottom of the motor assembly. Retain the screw
for later and slightly loosen the remaining two screws.

WARNING: SHUT POWER OFF AT FUSE OR CIRCUIT BREAKER
F8279110V
Installation & Operating Instructions for the
Parrot Uncle Owner's Installation, Manual
9
10
11
Assemble the swith housing to the support bracket
using the two key slots in the switch housing. Replace
the previously removed screw and securely tighten
all three screws.
Remove the three screws in the switch housing.
Retain them for step 11.
Connect the wires from motor to the wires from
the light kit by using the 9-pin molex plug .
Replace the removed screws from Step 10 and
secure all three screws.

WARNING: SHUT POWER OFF AT FUSE OR CIRCUIT BREAKER
F8279110V
Installation & Operating Instructions for the
Parrot Uncle Owner's Installation, Manual
12
13
NOT: Wait for the fan to stop before reversing the
direction of the blade rotation
A. warm weather-(Forward) A Downward airflow creates
a cooling effect.
This allows you to set your air conditioner on a higher
setting without affecting your comfort.
B. Cool weather-(Reverse) An upward airflow moves warm
air off the ceiling area. This allows you to set heating
unit on a lower setting without affecting your comfort.
OPERATING YOUR FAN
The appropriate speed settings for warm or cool weather
depends on factors such as the room size, ceiling height,
and number of fans.
The slide switch controls the directionof the blades: forward
(switch left) or reverse (switch right).
Turn on the power and check the operation of the fan.
Fan Speed:
“ ”Turn on the fan and turn speed up.
“ ”Turn on the fan and turn speed down.
A.Warm Weather
(SUMMER TIME)
B.Cool Weather
(WINTER TIME)
Whole structure
Secure the shade to switch housing by twisting in a
clockwise direction. Twist the shade gradually until
it snaps on to the switch housing. Do not over-tighten.

WARNING: SHUT POWER OFF AT FUSE OR CIRCUIT BREAKER
F8279110V
Installation & Operating Instructions for the
Parrot Uncle Owner's Installation, Manual

WARNING: SHUT POWER OFF AT FUSE OR CIRCUIT BREAKER
F8279110V
Installation & Operating Instructions for the
Parrot Uncle Owner's Installation, Manual
a. WARNING: Chemical Burn Hazard. Keep batteries away from children.
b) This product contains a lithium button/coin cell battery. If a new or used lithium button/coin cell
battery is swallowed or enters the body, it can cause severe internal burns and can lead to death in
as little as 2 hours. Always completely secure the battery compartment. If the battery compartment
does not close securely, stop using the product, remove the batteries, and keep it away from children.
If you think batteries might have been swallowed or placed inside any part of the body, seek
immediate medical attention.
c) The cells shall be disposed of properly, including keeping them away from children; and
d) Even used cells may cause injury
25W120 V 18W
Voltage Fan (max.) Lamp (max.)
Antenna wire
Power supply live-wire
Power supply neutral-wire
White
Black
Blue
Light live-wire
To Motor wire
To Motor wire
WIRING SCHEMATIC DIAGRAM FOR RECEIVER
POWER PARAMETER LIST
FUNCTION INSTRUCTION OF EMITTER
KINDLY REMINDERS:
White wire
Black wire
7
6
7
5
4
3
1
256
LED indicated light
Turn up the speed of the fan
Short press: ON/OFF the light
Long press: Adjust the brightness
of the light
ON/OFF the fan
Turn down the speed of the fan
Timing control of the fan
3V CR2032 battery X 1pcs
Adopt RF wireless digit emission technique, biunique controlled , coincident code rate is less than one
millionth. (Emitter and receiver must be sent back to factory for maintenance if damaged.)
Receiver can be controlled by any angles of the emitter in prescriptive space, unrestricted by direction.
With the memory function, the controller can save the status( light and direction ) while the supply
power OFF and resume to the original after reload the power supply.
1. If the emitter can not control the fan, learning code matching mode is used between emitter and receiver.
Turn “ON" the supply power within 30 seconds and press the emitter's “ ” button for 5 seconds, it can load
normally after hearing a long sound “bee”, which means learning successfully and it can works normally.
(PS: Learning mode is not accepted after turn “ON” the supply power for 30 seconds)
2. When the emitter cannot control the receiver, please check the battery switch touching normally or not, correction of the positive
and negative, full or empty of the power.
3. When the emitter cannot control the receiver, please check is there any existence of similar remote controlled products nearby,
then check whether they works, because remote controlled product with the same frequency will disturb each other.
4. Low voltage of battery will affect the sensitivity of the emitter and the signal reception accordingly(the indicated light will flash
out its warning when the battery get low voltage), must replace if the battery is getting low voltage.
5. Please take out the battery from the emitter when leaving unused for long time.
6. The maximum load of lighting see the above“POWER PARAMETER LIST”
PS: please connect the ground wire correctly, otherwise it may cause the light micro-light or flash
7. When installing the fan, the fan ceiling cover don't press the antenna (or other wire), it is easy to breakdown the wire and
short-circuited.
WIRING SCHEMATIC DIAGRAM FOR RECEIVER
POWER PARAMETER LIST

WARNING: SHUT POWER OFF AT FUSE OR CIRCUIT BREAKER
F8279110V
Installation & Operating Instructions for the
Parrot Uncle Owner's Installation, Manual
SIZE OF PRODUCT
7.09"
2.87"
11.14"
Ø27.2"
Ø24"

WARNING: SHUT POWER OFF AT FUSE OR CIRCUIT BREAKER
F8279110V
Installation & Operating Instructions for the
Parrot Uncle Owner's Installation, Manual
TROUBLESHOOTING GUIDE
1.FAN / REMOTE IS NOT WORKING
2.THE FAN IS NOISY
3.THE FAN WOBBLES
Loose electrical connections.
Shut off the branch circuit electricity at the fuse box or breaker panel and check the LED light fixture assembly electrical
connectors for proper installation.
To reset the remote control: 1) Turn off power to fan using the wall switch or circuit breaker. 2) Remove batteries from
remote. 3) wait 10 seconds. 4) Replace batteries and turn power on
4.LIGHT IS NOT WORKING
Ensure the remote is within the 20 foot range of the receiver
To reset the remote control: 1) Turn off power to fan using the wall switch or circuit breaker.
2) Remove batteries from remote. 3) Wait 10 seconds. 4) Replace batteries and turn power on
Check batteries to insure they are good and oriented correctly
Check to make sure the frequency switches (DIP Switches) from the remote to the receiver are
set to the same frequency
Check the main and branch circuit fuses or breakers
If using a Variable Speed Wall Switch,ensure it is specifically designed for use with a ceiling fan.
Check the line wire connections to the fan and the switch wire connections in the switch housing per the instructions
If fan still does not work, please contact Customer Service Support@Parrot Uncle.com
Make sure all motor housing screws are tight
Make sure the screws that attach fan blade to motor are tight
Make sure the wire nut connectors are not rattling against each other or the interior wall of the switch housing
Allow 24-hour break in period. Most noises associated with the new fan may disappear during this time
if using a ceiling light kit,make sure the glassware is secured tightly
Make sure there is a short distance/gap from the ceiling to the top of the canopy. The canopy should not touch the ceiling!
Make sure your ceiling box is secure and that the rubber insulating pads are used between the mounting bracket and outlet box
Verify all blades and blade bracket screws are secure (most fan wobble problems are caused by loose parts).Once fan is properly
installed,run the ceiling fan for 10 minutes to let the fan self-adjust.
If wobble occurs after running the fan for 10 minutes, verify blade level using the following process:
a) select a point on the ceiling above the tip of one of the blades. Then select the fan blade and measure from the center
of the selected blade to point on the ceiling. Rotate the fan until the next blade is positioned and repeat the
measurement using the same point from the ceiling for every blade. Measurements should be within 1/8 inch.
b) If all deviation are less than 1/8 inch and the fan continues to wobble, please contact Customer Service Support@parrot Uncle.
com to order a complimentary Blade Balancing Kit
-If all deviation are less than 1/8 inch and the fan continues to wobble, please contact Customer service Support@Parrot Uncle.
com to order a complimentary Blade Balancing Kit.

WARNING: SHUT POWER OFF AT FUSE OR CIRCUIT BREAKER
F8279110V
Installation & Operating Instructions for the
Parrot Uncle Owner's Installation, Manual
AFTER INSTALLATION
Wobble
The fan blades have been adjusted in the factory to minimize any wobble
Note: ceiling fans tend to move during operation due to the fact that they are mounted on a rubber
grommet. If the fan was mounted rigidly to the ceiling, It would cause excess vibration. Movement of
A few centimeters is quite acceptable and does not suggest any problem to reduce the fan
Wobble: Please check that all screws which secured the mounting bracket and downrod are secure.
Balancing a wobbling ceiling fan:
1. Check that all blade and blade arm screws are secure.
2. Most fan wobbling problems are caused when blade levels are unequal. Check this level by electing a point on
the ceiling above the tip of one of the blades. Measure this distance. Rotate the fan until the next blade is
positioned for measurement. Repeat for each blade. The distance deviation should be equal within 1/8"(0.32cm).
3. If the blade wobble is still noticeable, Interchanging two adjacent (side by
side) blades can redistribute the weight and possibly result in smoother
operation.
Warning: To reduce the risk of personal injury, Do not bend the blade
arm while installing, Balancing the blades, or cleaning the fan. Do not
insert foreign objects between rotating fan blades.
Noise
When it is quiet (especially at night) you may hear occasional small noises. This is normal.
Please allow a 24-hour “breaking-in” period, Most noises associated with a new fan disappear during the time.
Care and cleaning
1.Periodic cleaning of your ceiling fan is the only maintenance required. Use a soft brush or lint free cloth to
avoid scratching the paint finish. Please make sure to turn off electricity power before you clean your fan
2.Do not use water when cleaning your ceiling fan. It could damage the motor or the blades and create the
possibility of an electrical shock.
3.Motor has permanently lubricated ball bearing. No need to oil.
Note: Make sure the power is off at the electrical panel box before you attempt any cleaning or repairs.
Touching
Ceiling

120Vac 25W 18W
