Paslode PCF 1000 User manual

1
MODEL PCF 1000
Corrugated Fastener
Tool
IMPORTANT!
DO NOT DESTROY
It is the customer’s responsibility to have all
operators and service personnel read and
understand this manual.
OPERATING MANUAL AND
SCHEMATIC
P
502422-4
11/10
PRINTED IN U.S.A.
© 2010, Illinois Tool Works, Inc.

10
1 502361 4 Screw
2 1015483 8 Washer
3 502362 1 Top Cap
4 502363 1 Piston Stop
5 502364 1 Spring
6 502365 2 O-Ring
7 501621 1 O-Ring
8 502366 1 Washer
9 502367 1 Valve
10 502368 1 Valve Assy.
11 502369 1 O-Ring
12 502370 1 Piston
13 502371 1 Driver Blade
14 502372 1 Bumper
15 501625 1 O-Ring
16
502373 1 Noseplate
17
502374 1 Lower WCE
18
502375 2 Screw
19
502376 1 WCE, Spring Cover
20
1015482 2 Screw
21
1015506 4 Screw
22
502377 1 Sleeve Seal
23
502378 1 O-Ring
24
502379 1 Sleeve
25
502380 1 O-Ring
26
502381 1 Gasket
27
502382 1 Housing
28
1015303 1 O-Ring
29
502383 1 Trigger Valve Housing
30
501860 1 O-Ring
31
1015511 1 O-Ring
32
501418 1 O-Ring
33
502384 1 Valve Piston
34
1015514 1 O-Ring
35
502718 1 Spring
36
502385 2 O-Ring
37
502386 1 Trigger Valve
502387 1 Bushing
501635 1 Trigger Valve Assy.
40
511159 1 Screw
PARTS LEGEND PCF 1000, 502360
* Denotes Normal Wear Items.
** Make sure Warning Label (502426) is properly affixed.
Replace if necessary.
Label available at no charge through the Service Parts Dept.
▲ Apply Loctite 242 (Blue) Part No. 093500.
Apply Loctite (Green) Part No. 401491
Denotes New Change Always wear hearing protection and eye protection
devices, including side shields when operating or
working in the vicinity of a tool.
Operate the tool using only the recommended air
pressure. Do not exceed the maximum air pressure
marked on the tool. Be sure the air pressure gauge is
operating properly and check it at least twice a day.
41
502389 1 Nut
42
502390 2 Screw
43
511160 1 Support
44
511161 1 Spacer
45
502393 1 Pusher
46
502394 1 Screw
47
511162 1 Spring
48
502396 1 Spacer Stop
49
502397 1 Screw
50
502398 1 Washer
51
502399 1 Magazine
52
502407 1 Nut
53
502408 1 Latch
54
502409 1 Screw
55
502410 1 Spring
56
502411 1 Slider
57
502412 1 Spring
58
502413 1 Roller
59
502414 1 Pin
60
502415 1 Inlet Cap
61
502416 1 O-Ring
62
1 Trigger Assy.
63
1015317
1 Screw
64
502417 1 Safety Guide
65
66
502419 1 Driver Blade Seal
Never use any bottled air or gases such as oxygen
to operate the tool since they could cause the tool
to explode.
➔
SAFETY INSTRUCTIONS
WEAR EYE AND HEARING PROTECTION
*
*
*
*
*
*
*
■
*
*
*
*
*
*
*
■
AIR CONSUMPTION - SCF / FASTENER
AIR PRESSURE - PSIG
DO NOT EXCEED MAXIMUM
RECOMMENDED AIR PRESSURE
*
■
■67
501696 2 Screw
68
502420 1 Plate
69 501140 1 Logo, Housing Left
70
501141 1 Logo, Housing Right
71 502426 1 Warning Label
72 502427 1 Oil Daily Label
.010
.070
.030
.040
.050
.060
.020
•
.036
SCF
38
1 Spring, WCE
39
502428
*
*501648
➔
➔
➔
➔

Torque Values
IN•LBS
11
PCF 1000
502360
Always Wear
Safety Glasses
When Using
Power Tools
401382
61
54
58
57
56
55
47
46
53
59
60
44
42
43
45
48
51
52
50
49
17
15
16
14
13
12
11
2
26
28
29
24
27
63
62
25
52
66
65
64
41
30
31
32
33
34
35
36
37
38
39
40
10
6
7
8
6
1
2
3
4
5
68
67
9
80
80
62
62
62
45
❂
❂
❂
❂
❂
❂❂
❂
❂
❂
❂
45
45
45
80
22
23
20
18
21
62
❂
19
70
69
72
71

16
Lubricants and Loctite
Loctite 620 (Green) Part No. 401491
Lubricating Oil 16 oz. Part No. 403720
Lubricaing Oil with Anitfreeze 8 oz. Part No. 219090
Chemplex 710 Lubricant 1lb. Part No. 403734
Tool Cleaner
Ideal cleaner for all Paslode tools. Part No. 219348
Safety Glasses
Clear Part No. 401382
ACCESSORIES
P
An Illinois Tool Works Company
888 Forest Edge Drive
Vernon Hills, Illinois 60061-3105
Sequential Trigger kit
(SILVER/GREY TRIGGER)
Piston Removal Tool
Piston Removal
• Piston unlocking
13
12
Part No. 502421
Part No. 502424
Loctite 242 (Blue) Part No. 093500
®
