Patiorama PA-10 User manual

OTTOMAN
W
A
R
R
A
N
T
Y
1
Y
E
A
R
1
PA-10
Thank you for choosing Patiorama!
Our goal is to provide high quality outdoor furniture with
outstanding customer service-all at an affordable price.
Please let us know how we are doing!
Problems?
(Missing pieces, wrong pieces...)
We will fix it Immediately. Send us an email at
[email protected]. If you are not satisfied with our
customer service, pls send your comments to
[email protected].
Happy?
Please leave us a review!
You can make others happy too!

IMPORTANT, RETAIN FOR
FUTURE REFERENCE:
READ CAREFULLY.
Safety
For domestic use only.
Don't tighten all the bolts before the product is fully assembled.



Periodic structural checks of this product should be
It would be useful to ask someone to help you assemble
the product.
undertaken, do not use if you have any doubts about its
Do not stand on the seat.
Do not let children play with this product.
At the beginning of the season

product are secure, do not use if you have any doubts
At the end of the season
This product should be stored under cover during
prolonged spells of adverse weather (wet or cold) and
also during the winter (ideally in a garden shed or
garage).
Always clean and dry thoroughly before storage.
- 1 -

Tips for Cushions
1
3
OK
2
In order to compress the package, we put the cushions in
the gap of some parts. So there may be crinkle on the fabric.
Don’t worry. Just flap every corner of the cushion evenly and
it will get back into its original shape soon.
- 2 -

Item
no.
Reference
Image Description Qty.
R
M
H
F
K
L
Q
Side Panel
Washer
Side Panel
Top Panel
2
2
1
12
12
1
1
Allen Key
Ottoman Cushion
M6X35
Head Cap Screws
- 3 -
COMPONENT LIST - OTTOMAN X 2
NOTE:
When tightening the Screws, tighten sequentially.
DO NOT tighten any Screws fully and then move on to the next one.
This may cause the frame to warp.
If there is still wobbles or screw holes cannot be aligned,loosen the
bolts and execute this same process.
If the Ottoman is not stable it could lead to damage to the product.

- 4 -
Attach the side panel (M) to the side panel (R) with M6*35 Head Cap Screws
(K) and Washers (F). Do this in 2 places.
x2
NOTE:DO NOT TIGHTEN THE SCREWS COMPLETELY.
1
2
M
R
FK

- 5 -
Attach the side panel (R) to another side panel (M) with M6*35 Head Cap Screws (K)
and Washers (F). Do this in 2 places.
x2
NOTE:DO NOT TIGHTEN THE SCREWS COMPLETELY.
2
R
2
M
M
F
K

- 6 -
x4
NOTE:DO NOT TIGHTEN THE SCREWS COMPLETELY.
R
4
R
MM
Attach two side panels (M) to the side panel (R) with M6*35 Head
Cap Screws (K) and Washers (F). Do this in 4 places.
3
F
K

- 7 -
x4
NOTE:DO NOT TIGHTEN THE SCREWS COMPLETELY.
Attach two side panels (R) to the top panel (H) with bolts
(M6X35) and washers.Do this in 4 places.
4
H
4
R
M
F
K

- 8 -
Tighten all 12 Screws into place with Allen Key (L).
5
x12
L
NOTE:IF ANY SCREW HOLES CANNOT BE ALIGNED,
LOOSEN ALL THE SCREWS AND GO BACK STEP
1 AND RESTART ASSEMBLY.

- 9 -
Place the Ottoman on a level surface. Place the Ottoman Cushion
(Q) on the ottoman. Your Ottoman is ready for use.
6
Q

- 10 -
SECTIONAL SOFA CONNECTOR MANUAL
Sectional outdoor wicker patio sofa is very light weight in
nature and subject to movement.
These high quality fasteners prevents movement between
modules to maintain the aesthetically good look of your
modular patio furniture set.
Two fasteners are recommended between Two adjoining
module.
1
2
