Patiowell T-PS22-0108A-BN User manual

METAL
GARDEN SHED
ASSEMBLY INSTRUCTIONS
SKU: T-PS22-0108A-BN
https://www.patiowell.com/
pages/video-t-ps22-0108a-bn
Metal Garden Shed
Installation Tutorial
[email protected]www.patiowell.com
BE
YOUR
LIFE BUILDER

Owner's Manual
Prior to installation, it is important that you contact your local government authority to
determine if building approval is required. Study and understand this owner's manual.
Important information and helpful tips will make your construction easier and more
enjoyable.
Assembly instructions
Instructions are supplied in this manual and contain all appropriate information for your
building model. Review all instructions before you begin. During assembly, follow the
step sequence carefully for correct results .Please be aware: this unit takes two people
about one full day to complete.
Parts
Check to be sure that you have all the necessary parts for the building.
Separate contents of the carton by the part number while reviewing parts list.
Familiarize yourself with the hardware and fasteners for easier use during
construction. These are packaged within the carton. Note that extra fasteners have been
supplied for your convenience.
Use heavy duty gloves when handling steel sheets and flashing
Watch the weather:
Please be sure the day you select for installation is dry and calm.
DO NOT attempt to assemble your shed in windy weather
because of risk of damage to panels, or personal injury. Be careful
of wet or muddy ground.
Teamwork:
Whenever possible, two or more people should work together to
assemble the building. One person can position parts or panels
while the other is able to handle the fasteners and the tools.
It requires two people a full
day to complete installation
BEFORE YOU START
TOOLS MAY REQUIRED
PLAN AHEA
02

Site Selection
Avoid overhanging trees as much as possible as leaves will make regular cleaning
necessary and broken branches are a potential hazard.
Small trees,bushes or fences nearby can be helpful,acting as a wind break.
Site Preparation
The site must be prepared so that the base of the shed is level all round and checking
with a spirit level is required.
The base can be constructed by treated timber or concrete,in order to stop the moisture
getting into the shed.The shed is not designed to be built onto lawn directly.Also the
ground will get muddy during rainy days.
If a concrete pad is made,it is important that this slopes towards the edges to prevent
water ingress.
Time must be allowed for any concrete or cement to dry before building the shed on top.
Bases can also be constructed from bricks,blocks,or mounted on a concrete pad.
The bricks or blocks should be cemented onto firm and level concrete footings and the
greenhouse frame drilled and screwed to the base.
Find someone to help you:it is much easier with someone to hold parts,pass tools
ect.Also some steps require two people to lift structures together.This is not very
heavy work so would suit most able-bodied people.
Allow plenty of time:rushing often causes errors and the re-doing of incorrect
assemblies.If you have never built a shed before,it can take most of a day to carefully
complete the construction.
Have the right tools to hand.
Safety clothing as recommended in the 'Tools' section.
Ideally lat out the parts and check that all are present before commencing
construction.Lay on cloths or plastic sheets if there is any risk of scratching the parts.
Tighten all nuts carefully,being sure not to miss any.Check the frame is square and
using a spirit level to check that it is upright.
03
PLAN AHEAD
IMPORTANT NOTES

04
FOUNDATION
1 X4 2 X2
3R X1
3L X1
P2 X8P1 X16
P4 X2
P6 X2
P3 X2
5 X1
PLATES
P5 X2
P9 X8P7 X2

05
21R X221L X2
D X2 D2 X1D1 X1
PLATES
STRIPS
9 X4
7L X1
6 X1
7R X1
4L X1 4R X1

06
STRIPS
15L X2 15R X2
16 X1
19 X2
D4 X6
14L X2
14R X2
12 X211 X2
13 X4
10R X210L X2
17 X4
20 X2

07
STRIPS
23 X3
37 X2
22 X6
36 X4
GB X2G2 X4
STANDARD
35 X3
D3 X4
GD X4 GC X4
GF X4GE X2 GS X4 GB1 X2

08
S2 X 310
STANDARD
S3 X430
F1 X440
SCREW
F2 X70 F3 X8

21L
21R
15R
14R
14L
15L
16
12
12
14R
15R
14L
15L
21R
21L
11
11
10L
GC
GC
17
GC
GC
GE
17
19
P4
P3
P7
P6
P4
P3
P7
P5
17
GE
17
P5
P6
19
10R
10R
10L
1
1
2
2
1
1
3R
5
3L
4R
6
7R
7L
4L
22
23
23
13
23
9
9
9
9
35
36
36
20
20
35
36
35
36
37
37
P1
P9
P9
P9
P9
P9
P9
P9
P9
P2
P2
P2
P2
P2
P2
P2
P2
22
22
22
22
22
13
13
13
P1
P1
P1
P1
P1
P1
P1
P1
P1
P1
P1
P1
P1
P1
P1
D1
D2
D
D
D3
D3
D3
D3
D4
D4
D4
D4
D4
D4
GB
GB
GB1
GB1
ASSEMBLY BREAKDOWN DRAWING
09

STEP 1
F1 X8
F1 X4
STEP 2
10
F1
1
1
F1
2
2
x2
These anchor holes are located on the inner side.
These anchor holes are located on the inner side.
