Peak PCAN-GPRS Link User manual

PCAN-GPRS Link
Platform for Telematic Applications
User Manual
V1.0.4

PCAN-GPRS Link – User Manual
2
Products taken into account
Product Name Model Item Number
PCAN-GPRS Link IPEH-004000
PCAN-GPRS Link Set evaluation version IPEH-004000-EVAL
CANopen® and CiA® are registered community trade marks of CAN in Automation
e.V.
All other product names mentioned in this document may bet he trademarks or
registered trademarks of their respective companies. They are not explicitly marked
by „™“ and „®“.
© 2011 PEAK-System Technik GmbH
PEAK-System Technik GmbH
Otto-Röhm-Straße 69
64293 Darmstadt
Germany
Phone: [phone]
Fax: [phone]
www.peak-system.com
[e-mail]
Document version 1.0.4 (2011-10-18)

PCAN-GPRS Link – User Manual
3
Contents
1Introduction 5
1.1 Properties of a Glance 5
1.2 Prerequisites for Operation 7
1.3 Scope of Supply 7
2Hardware 9
2.1 Pin Assignment Automotive Connector 10
2.2 Microcontroller LPC2368 10
2.3 GPS-Module u-blox LEA-5S 11
2.4 GPRS-Module Wavecom Wireless CPU WMP50 11
2.5 Extension 12
2.5.1 Pin Header 1 - J2 13
2.5.2 Pin Header 2 - J5 13
2.6 SD Card 14
3Operation 15
3.1 Status LEDs 15
3.2 Wake-up 16
3.3 Cabling 17
3.3.1 Termination 17
3.3.2 Example of a Connection 18
3.3.3 Maximum Bus Length 18
4Transfer CAN Data via TCP/IP 19
5Firmware 20
5.1 Installing the WinARM Package 20
5.1.1 Decompressing the ZIP Archive 21
5.1.2 Setting up Additional Search Paths 21
5.2 Compiling Projects with gcc and µVision 23

PCAN-GPRS Link – User Manual
4
5.3 Microcontroller LPC2368 25
5.3.1 JTAG Pin Assignment ARM 20-Pin Connector 26
5.3.2 FMS Data 27
5.3.3 DTCO Data 28
5.3.4 GPS Data 28
5.3.5 OBD-2 via CAN 29
5.4 Wavecom Wireless CPU WMP50 32
6Firmware-Upload 34
6.1 Uploading the Firmware via SD Card 34
6.2 Firmware Update over the Air 35
6.3 Uploading Firmware via the Serial Connections 35
7Technical Specifications PCAN-GPRS Link 37
Anhang A CE-Certificate 39
Anhang B Dimension Drawing 40
Anhang C Current Consumption PCAN-GPRS Link 41

PCAN-GPRS Link – User Manual
5
1Introduction
PCAN-GPRS Link is a hardware and firmware platform for the
recording and forwarding of vehicle data. There are two freely
programmable microcontrollers within the unit which process
internal vehicle data.
The PCAN-GPRS Link is provided as a development platform for
telematic applications.
PCAN-GPRS Link supports the evaluation of FMS and Bus FMS data
(Fleet Management Standard). This produces consumption-related
vehicle data. The DTCO info interface also allows the connection
and processing of a digital tacho with access to information such as
driver identification and driver working time. The GPS module can
be used to determine location and output the direction of travel.
There is an optional expansion to allow any volume of additional
data to be processed, output and recorded. These include
temperature and movement sensors, barcode scanners, RFID
readers, displays and WIFI or Bluetooth connections.
1.1 Properties of a Glance
Dualcore ARM7 (core) and ARM9 (GPRS) system
U-blox 5 GPS module with 50 channels and over 1 Million
correlators. Position accuracy 2.5 m CEP at -130 dBm
Data transfer via GPRS or CSD
Wavecom GPRS class 10 quad-band modem
Handling of FMS data
Handling of DTCO data

PCAN-GPRS Link – User Manual
6
Handling of OBD-2 data via CAN (complete PID support not
ensured)
CiA® 447 protocol support on request
Support for the PCAN-Link software package by PEAK-System
Two High-speed CAN channels (ISO 11898-2) with bit rates of
40 kbit/s to 1 Mbit/s
Wake-up function
•via CAN
•via clamp 15 (ignition)
Two digital inputs
•Low- or High-active (depending on the circuit Pull-up/
-down)
One digital output
•Low-side driver (BSP75)
•Maximum inverse voltage 40 V
•Output current 500 mA
One UART V.24
DTCO (digital tacho) with input level 0 - 9 V DC
Internal flash memory (maximum 2 GB)
Firmware update over the air
5 individual extension pins (on the automotive connector)
6 dual LEDs free configurable, 1 LED fixed function (GPRS
modem)
Extended operating temperature range from -40 to 85 °C
(-40 to 185 °F)

PCAN-GPRS Link – User Manual
7
1.2 Prerequisites for Operation
Operating voltage: 6 - 32 V DC
FAKRA GSM/GPS combination antenna
For programming
•Windows 7/Vista/XP/2000
•SD card reader
•ARM Evaluation Software μVision from Keil
(www.keil.com/demo/eval/arm.htm)
For the demo server
•Linux server with root rights
•MySQL Server version 5 or higher
•MySQL connector C++ version 1.0.5 or higher
•Xerces XML Parser 2.8 or higher
1.3 Scope of Supply
PCAN-GPRS Link Set:
PCAN-GPRS Link in aluminum casing
Preconfigured cable set (CAN/Power/RS-232)
Installed 1 GB SD card
JTAG programming adapter
Additional set of crimp contacts
GPRS/GPS combination antenna
CD with library, software, programming example and manual in
PDF format

PCAN-GPRS Link – User Manual
8
PCAN-GPRS Link:
PCAN-GPRS Link in aluminum casing
Tyco mating connector including crimp contacts
CD with library, software, programming example and manual in
PDF format

PCAN-GPRS Link – User Manual
9
2Hardware
Description of the hardware module.
Figure 1: Arrangement of the hardware on the board

PCAN-GPRS Link – User Manual
10
2.1 Pin Assignment Automotive Connector
Figure 2: Arrangement of the pins on the automotive connector
Pin Function Pin Function
1 Power supply (6 - 32 V) 14 Power supply (6 - 32 V)
2 GND 15 GND
3 For extension J2:10 16 For extension J2:7
4 For extension J2: 6 17 For extension J2:8
5 Clamp 15 (ignition) 18 For extension J2:4
6 Digital IN 1 19 UART CTS (Software)
7 Digital IN 0 20 UART RTS (Software)
8 Digital OUT 21 UART TxD
9 DTCO TxD 22 UART RxD
10 CAN 0 Low 23 CAN 0 Low
11 CAN 0 High 24 CAN 0 High
12 CAN 1 Low (FMS) 25 CAN 1 Low (FMS)
13 CAN 1 High (FMS) 26 CAN 1 High (FMS)
2.2 Microcontroller LPC2368
Basics
ARM 7 72 MHz
RTC 32,768 kHz
Flash 512 Kbyte
SRAM 32 Kbyte

PCAN-GPRS Link – User Manual
11
2.3 GPS-Module u-blox LEA-5S
Basics
Sensitivity -160 dBm (SuperSense)
Receiver 50 channels with over 1 Million correlators
Accuracy 2,5 m CEP at -130 dBm
DGPS SBAS (WAAS, EGNOS, MSAS, GAGAN)
2,0 m CEP at -130 dBm
Time To First Fix (TTFF)
Hot Start (Autonomous) < 1 s
Warm Start
(Autonomous)
29 s
Cold Start
(Autonomous)
29 s
Antenna
Antenna feeder 3,3 V, maximum 50 mA
Minimum gain 15 - 20 dB
Maximum noise figure 1,5 dB
Maximum gain 50 dB
Impedance 50 Ω
Connector FAKRA Code C
2.4 GPRS-Module Wavecom Wireless CPU WMP50
Basics
Data transfer GPRS Class 10
Transmission power 1 W at 1800/1900 MHz
2 W at 900/800 MHz
Modem type Quad band 800/900/1800/1900 MHz
ARM9 26 MHz (optional: WMP100 with 104 MHz)

PCAN-GPRS Link – User Manual
12
Antenna
VSWR max. 1,5:1
Impedance 50 Ω
Typical radiated gain 0 dBi
Connector FAKRA Code D
2.5 Extension
It is possible to extend the hardware using two pin headers.
Following pins on these pin header are available:
Figure 3: Pin header 1 - J2, pin header 2 - J5

PCAN-GPRS Link – User Manual
13
2.5.1 Pin Header 1 - J2
Pin Function Pin Function
1 Supply voltage, maximum
500 mA
6 Extension (Pin 4 automotive connector)
2 RESERVED 7 Extension (Pin 16
automotive connector)
3 3,3 V maximum 100 mA 8 Extension (Pin 17
automotive connector)
4 Extension (Pin 18
automotive connector)
9 GND
5 5 V, maximum 500 mA 10 Extension (Pin 3 automotive connector)
2.5.2 Pin Header 2 - J5
Pin Function Pin Function
1 Global reset (Low-active) 8 Extension microcontroller: P0.15
(P0[15], TXD1, SCK0 (SSP0), SCK
(SPI))
2 Start microcontroller with
internal boot loader
9 3,3 V, maximum 100 mA
3 Extension microcontroller:
P0.26 (P0[26], AD0[3],
AOUT, RXD3)
10 GND
4 Extension microcontroller:
P0.18 (P0[18], DCD1,
MOSI0 (SSP0), MOSI
(SPI))
11 UART 3 microcontroller Software CTS
5 Module Identification micro-
controller: P0.23 (P0[23],
AD0[0], I2SRX_CLK,
CAP3[0])
12 UART 3 microcontroller Software RTS
6 Extension microcontroller:
P0.17 (P0[17], CTS1,
MISO0 (SSP0), MISO
(SPI))
13 UART 3 microcontroller TxD
7 Extension microcontroller:
P0.16 (P0[16], RXD1,
SSEL0 (SSP0), SSEL (SPI))
14 UART 3 microcontroller RxD

PCAN-GPRS Link – User Manual
14
2.6 SD Card
The SD card is located in the card slot on the board of the PCAN-
GPRS Link. To format the SD card and/or to install the firmware, you
need an SD card reader and an SD card with maximum 2 GB
capacity (supplied with the PCAN-GPRS Link set is a 1 GB SD card)
Do the following to setup and/or install the SD card:
1. Unscrew the back panel of the PCAN-GPRS Link.
2. Press the SD card at its end to eject it from the card slot.
3. Insert the card into the card reader on the computer.
4. Format the card and/or copy the firmware onto it (see also
on page 34 Uploading the Firmware via SD Card
).
Format the SD card with the file system FAT16 or FAT32
through the appropriate application of the operating system
(maximum sector size 512 byte).
5. Log off the SD card from the Computer and take the card
from the card reader.
6. Insert the SD card back into the card slot.
7. Close the back panel of the PCAN-GPRS Link.

PCAN-GPRS Link – User Manual
15
3Operation
The power supply of the PCAN-GPRS Link is switched on by apply-
ing the supply voltage. To save power it is possible to switch off the
internal power supply. Restart is only possible via CAN or clamp 15
(ignition). The RTC from the microcontroller and the GPS are still
supplied. This allows a fast GPS Fix.
Attention! The GSM antenna must always be connected! If this
is not the case, the transmitter can be damaged.
3.1 Status LEDs
Figure 4: Layout of the LEDs on the PCAN-GPRS Link
LED Status Meaning
Supply Green blinking Supply voltage available
Green static Modem readyGPRS
Green blinking GPRS connection established
Red blinking Waiting for valid NEMA data
(during GPS receiver initialization)
Green blinking GPS receiver ready, forwarding valid
NEMA data without GPS position data.
Waiting for GPS fix
GPS
Green static Valid GPS position found. GPS receiver
forwarding valid NEMA data with
GPS position data
Red blinking FMS data not validFMS
Green blinking FMS data valid

PCAN-GPRS Link – User Manual
16
LED Status Meaning
Red blinking No valid OBD-2 data receivedOBD-2
Green blinking Valid OBD-2 data received
Off No SD card foundMemory
Green blinking SD card found, Log is running
Off No DTCO found
Red blinking No valid DTCO data found
DTCO
Green blinking DTCO data valid
Note: All LEDs, except for the GPRS LED, are freely
configurable. Blink patterns are fixed in the LIB.
3.2 Wake-up
If the PCAN-GPRS Link is in Sleep mode, the operation will be
resumed by a wake-up signal.
Following possibilities are available for activating the PCAN-GPRS
Link by a wake-up signal:
CAN: When a message is received via CAN 1 or CAN 2, the
PCAN-GPRS Link turns on. Within the wake-up time of 370 ms
further incoming CAN messages are not processed.
Clamp 15 (ignition): With a positive level on clamp 15 the PCAN-
GPRS Link is set in operation. The wake-up time is also 370 ms.

PCAN-GPRS Link – User Manual
17
Figure 5: Power supply PCAN-GPRS Link
The PCAN-GPRS Link goes to sleep mode, if no CAN data is
transmitted/received, the microcontroller is inactive, and clamp 15 is
low. Activation of the PCAN-GPRS Link is in this case only possible
via CAN or clamp 15.
3.3 Cabling
3.3.1 Termination
A High-speed CAN bus (ISO 11898-2) must be terminated on both
ends with 120 Ohms. Otherwise, there are interfering signal
reflections and the transceivers of the connected CAN nodes (CAN
interface, control device) will not work.
The PCAN-GPRS Link does not have an internal termination. Use
the adapter on a terminated CAN bus.

PCAN-GPRS Link – User Manual
18
3.3.2 Example of a Connection
Figure 6: Simple CAN connection
In this example, the PCAN-GPRS Link is connected with a control
unit by a cable that is terminated at both ends.
3.3.3 Maximum Bus Length
CAN networks may have bit rates of up to 1 Mbit/s, where all CAN
nodes must be able to process messages simultaneously. The
maximum bus length depends on the bit rate.
The following table shows some examples with the bus length in
relation to the bit rate:
Bit rate Max. bus length
125 kbit/s 530 m (580 yards)
250 kbit/s 270 m (300 yards)
500 kbit/s 130 m (140 yards)
1 Mbit/s 40 m (45 yards)
Note: The PCAN-GPRS Link is set by default to 500 kbit/s. Only
in the case of the use of FMS used standard is 250 kbit/s. All
other bit rates can be used freely.

PCAN-GPRS Link – User Manual
19
4Transfer CAN Data via
TCP/IP
The PCAN-Link software package allows the transfer of CAN data
using TCP/IP. PCAN-Link is based on the CANAPI2 interface by
PEAK-System, thus supporting various communication scenarios
(PCAN-Link is not included in the scope of supply).
Several virtual or physical CAN networks can be connected via a
network medium.
A simple PCAN-Link client can be integrated in the PCAN-GPRS
Link. Note that the data rates of GPRS are 50 kbit/s in the best case.
For more information about PCAN-Link visit our website:
www.peak-system.com

PCAN-GPRS Link – User Manual
20
5Firmware
The WinARM software provided can be used to produce your own
firmware. This chapter describes the installation of the package.
Furthermore, the properties for the programming of CPUs are
described.
Note: You need the WinARM package only if you don’t have the
full version of the μVision development environment!
The ARM Evaluation Software μVision from Keil to compile the
firmware can be found at:
https://www.keil.com/arm/demo/eval/arm.htm
Attention! From μVision version 4.20, there is currently no gcc
support. Use the version 4.13 or less.
5.1 Installing the WinARM Package
This chapter covers the installation of the program package
WinARM. Software, source code, and additional information is
included on the supplied CD in the following directory branch:
/tools
WinARM is collection of tools to develop applications for ARM
processors and microcontrollers on Windows platforms. The
package includes the GNU GCC Compiler for C and C++.
The installation of the WinARM package is done in two major steps,
the decompression of the ZIP archive and the setup of additional
search paths under Windows.
