Pellux Pellux slim 12 Installation instructions

21-01-2019

03-08-2021

30609

Pellet boiler

PELLUX SLIM 12

PELLUX SLIM 18

INSTALLATION & OPERATING MANUAL

PELLUX SLIM

2PELLUX SLIM 12

PELLUX SLIM 18

Information for the User |

Dataplate is located on the side housing.

Symbol Description

PELLUX SLIM 12 Type of boiler

IP 21 Degree of protection

Q Range of heating power

PQN Power consumption at nominal power

PQmin Power consumption at minimum power

Tmax

The maximum operating temperature

PMS

Maximum working pressure

Water storage capacity

C (EN 303-5)

Boiler class according to the EN 303-5

Basic fuel

The CE marking

Sign electro recycling - waste

Sign indicating the need to read the manufacturer’s information

NIBE-BIAWAR sp. z o.o.

15-703 Białystok, Al. Jana Pawła II 57

PQN

PQmin

Tmax

C (EN 303-5)

1/N/PE 230V, 50Hz, 10A IP21

3,5-12,1 kW

90 W

30 W

90 °C

2,0 bar

38 L

PELLUX SLIM 12 069235

Information for the User

We recommend the following steps after the consumption of 300 kg of pellets:

1. Check the ash container and the combustion chamber. If necessary, empty the ash drawer and clean it. Clean

the chamber of soot and ash using a vacuum cleaner.

2. Check the burner grate. If you  nd ash or deposits there, clean the grate (including air holes).

3. Check the bottom of the pellet tray. If dust has accumulated there clean it.

4. Use only high quality wood pellets of a diameter from 6 to 8 mm and a maximum length of 30 mm.

IMPORTANT

In summer, the boiler must remain connected to the power supply - to reduce the risk of condensation in the panel. To stop the

boiler operation, turn o󰀨 the heating circuits on the regulator.

The product is not intended for use by persons with reduced physical ﬁ tness/mental eﬃ ciency or without experience and knowledge,

if they are not supervised or instructed by a person responsible for their safety. Operation of the product by children is

strictly prohibited.

All installation diagrams in this manual do not replace the system design; they can only be used for illustrative purposes.

We reserve the right to make the product design changes and changes in the manual.

©NIBE-BIAWAR 2021

3PELLUX SLIM 12

PELLUX SLIM 18

List of contents |

List of contents

1 General __________________________ 4

Equipment ____________________________4

Accessories ___________________________4

2 Symbols__________________________ 5

3 Information regarding safety_________ 5

Installation - location of the boiler __________5

Electrical Installation ____________________5

Heating System ________________________5

4 Installation________________________ 6

Intended Use __________________________6

Product description _____________________6

System diagram _______________________6

Heating ______________________________6

Hot Utility Water Treatment _______________6

5 Control Panel _____________________ 7

Start-Up and Shutdown __________________8

Operating Modes_______________________9

Firing up _____________________________9

Incandescence ________________________9

Operation_____________________________9

Supervision ___________________________10

Burning o󰀨 ____________________________10

Stop _________________________________10

CHIMNEY SWEEP mode ________________10

Menu główne - Użytkownika ______________11

6 Heating __________________________ 13

General ______________________________13

Basic Modes of Operation of the Boiler______13

Weather-Based Control__________________14

Selecting the heat source for the mixer______15

Return protection 3-way _________________15

Return protection 4-way _________________15

7 Hot Utility Water ___________________ 16

Hot Utility Water (HUW) Settings___________16

HUW tank disinfection ___________________16

Setting of the HUW Temperature Setpoint ___16

The HUW tank hysteresis ________________16

HUW Circulation _______________________16

Activation of the summer feature___________16

8 Other Boiler Settings ________________17

Fuel Level Conguration _________________17

Information ___________________________17

Manual Control ________________________17

Cooperation with the room panel __________17

Cooperation with the internet module _______18

9 Maintenance and Troubleshooting ____ 18

General ______________________________18

Burner _______________________________18

Soot and Ash Removal __________________18

Causes of Failure and Remedy____________19

10 General Information for Installers____ 20

Location of the Boiler____________________20

Chimney – Requirements ________________20

11 Connection to the System __________ 22

12 Electrical connections _____________ 23

Direct Connection of the Units_____________23

Connection ___________________________25

Internal Overvoltage Protection____________25

Control Panel Connection ________________25

13 Boiler settings____________________ 29

14 Service__________________________ 33

Service settings ________________________37

Software update _______________________44

Loss of Voltage ________________________44

Anti-Frost Protection ____________________44

Pump Protection Against Sticking __________44

Fuse Replacement _____________________44

Replacement of the Control Panel _________44

Connecting Accessories _________________45

Boiler (STB) and Feeder ________________47

Temperature Limiters____________________47

Cleaning _____________________________48

Periodic cleaning of the boiler _____________49

Alarms _______________________________51

15 Wiring Diagrams __________________ 52

Boiler ________________________________52

16 Location of Components ___________ 53

Electrical Components __________________55

17 Dimensions ______________________ 56

19 Technical Specications ___________ 57

4PELLUX SLIM 12

PELLUX SLIM 18

Chapter 1 | General

1 General

Thank you for your condence in us and our product,

we also congratulate you on your choice of the Pellux

boiler. In order to achieve the highest e󰀩ciency and

safe working conditions, please read this Installation

& Operating Manual carefully and comply with the rec-

ommendations and observations contained in it.

The Pellux Slim boiler is designed to operate in open

or closed systems. Please note that the system has

to be protected in accordance with the applicable

regulations. For the boilers operating in an open and

closed systems, protection of the system must be in

accordance with local regulations. Pellux Slim’s can

be used in residential single and multi-family build-

ings, guest houses, department stores, etc.

The basic boiler fuel is a modern, eco-friendly fuel in

the form of wood pellets. A burner used in the unit en-

sures minimum pellet consumption in relation to the

thermal power received, resulting in fuel-e󰀩cient and

comfort operation of the boiler.

The Pellux boiler has a compact design and opera-

tional solutions adapted to streamline its operation.

With the enhanced electronic control, you can control

many parameters of the unit, adjusting it to di󰀨erent

installation conditions and individual needs.

This Manual applies to the Pellux Slim 12 boiler and

the Pellux Slim 18 boiler.

Equipment

Accessories

The Pellux Slim boiler is equipped with the following

set components:

• CT4 temperature sensor, L=3m (2 pce.)

• Wire with connector (1 pce.)

• Weather temperature sensor CT6-P (1 pce.)

• User’s Manual (1 pce.)

The Pellux Slim boiler can be equipped with addition-

al accessories that are not part of the boiler kit. Below

is a list of available accessories:

• Internet module ecoNET300

• Room temperature controller ecoSTER TOUCH

• Expansion module B/C

• Lambda probe module assembly

• Wireless room thermostat eSTER_x40

• Wireless room panel eSTER_x80

• Automatic cleaning kit

ADVICE

Certicates conrming the possession of the 5th class

according to the EN 303-5: 2012 standard and com-

pliance with the Ecodesign requirements are available

on the website www.pellux.pl.

5PELLUX SLIM 12

PELLUX SLIM 18

• The hydraulic and heating system must meet the

requirementsof applicable standards and legal re-

gulations.

Chapter 2 |

Chapter 3 |

Symbols

Information regarding safety

• The boiler should be installed in accordance with

current standards.

• The boiler room should have adequate air Ex-

change rate.

• Ventilation ducts should be made of non-amma-

ble materials.

Observation of the following safety rules is the basic

condition for safe boiler operation:

• the boiler should be used as intended and kept in

good condition (regular cleaning);

• always use the fuel recommended by the ma-

nufacturer;

• all boiler installations should have the necessary

safety systems in accordance with applicable re-

gulations;

• never insert any objects and limbs into moving

parts in the boiler (feeder, turbulators, burner, etc.);

• never insert any objects and limbs in the rear part

of the boiler with electrical devices when the boiler

is connected to the power supply;

• use safety gloves to operate the boiler;

• maintain cleanliness and adequate lighting in the

boiler room;

• rst start-up of the boiler should be carried out by

an authorized installer/ service technician.

• The electrical installation and any service of it may

only be performed by a person with appropriate

certications and qualications. Electrical installa-

tion and cable routing must be carried out in accor-

dance with applicable regulations.

• The installation should always be made with a pro-

tective conductor..

Installation - location of the boiler

Electrical Installation

Heating System

2 Symbols

3 Information regarding safety

IMPORTANT

The electrical installation, to which the boiler will be

connected, should be made in accordance with current

regulations.

IMPORTANT

Before starting the installation and use of the boiler,

read the entire contents of this manual thoroughly.

The manufacturer shall not be held liable for damages

caused by non-observance of this manual.

IMPORTANT

PELLUX Slim boiler may only be installed by compe-

tent and qualied personnel, in accordance with ap-

plicable regulations, standards and manufacturer’s

recommendations. Failure to follow these instructions

may void your warranty.

IMPORTANT

Use only original spare parts and accessories. The

manufacturer takes no responsibility for damages re-

sulting from the use of parts from other manufacturers.

CAUTION

The smoke conduit should undergo technical inspec-

tion and acceptance by a chimney sweep before in-

stallation.

IMPORTANT

Flush the system before connecting the boiler to re-

move any small impurities that may damage the boiler

or pumps.

IMPORTANT

This symbol informs about the risk to the device or a

person.

CAUTION

This symbol points to important information to be no-

ted when operating the device.

ADVICE

This symbol shall mean tips to make product operation

easier.

6PELLUX SLIM 12

PELLUX SLIM 18

The Pellux Slim heating boiler is designed for heating

single and multi-family residential buildings or public

buildings.

The heating medium is discharged to the heating sys-

tem through outlet located on the back of the boiler.

Chapter 4 | Installation

System diagram

Heating

UWAGA

This is a schematic representation only. The actual

diagram of the system should be developed by an in-

dividual quali ed to do so, in compliance with all stan-

dards and regulations

4 Installation

Intended Use

Product description

Hot Utility Water Treatment

The system can be expanded up to:

• 5 heating circuits

• hot utility water treatment circuit

• heating system control with heat accumulation

tank– a bu󰀨 er

• control of the domestic hot water circulation pump

The boiler is designed to burn wood pellets. The ver-

tical convection system and the soot removal system

from the combustion tubes facilitate its cleaning. This

ensures a high and equal level of energy e󰀩 ciency.

A ash pan facilitates the daily maintaining of cleanli-

ness. The fuel is transported from the integrated con-

tainer by an automatic fuel feeding system. The boiler

regulator is responsible for the fuel supply and the

burner operation. The fuel combustion process takes

place with the participation of air supplied by a blower

fan. Exhaust gas is removed by means of an exhaust

fan installed in the boiler.

The boiler can be equipped with an internal circula-

tion DHW pump to which you can connect an external

DHW heat exchanger.

7PELLUX SLIM 12

PELLUX SLIM 18

Control Panel

10 11

Chapter 5 |

DESCRIPTION:

1. Operating modes:

• INCANDESCENCE

• FIRING UP

• OPERATION

• SUPERVISION

• BURNING OFF

• STOP

• CHIMNEY SWEEP mode.

2. Boiler temperature setpoint, press and hold to

edit the value,

3. Boiler measured temperature,

4. Press to enter the menu list,

5. Information bar::

Both left and right window on the Home panel may dis-

play various information. By touching the screen, you

can toggle between the following information displayed:

mixer circuits, information panel, hot utility water panel

and fuel level panel.

Tip: The fuel level can also be seen in the room panel.

6. HUW tank temperature setpoint,

7. HUW tank temperature setpoint; hold it for a longer

time to enter into editing of the value,

8. Time and day of the week,

9. Outdoor temperature (weather),

10. Other symbols:

Fan operation [% or rpm]

Feeder operation

Pump operation

Igniter operation

Run of standby boiler

Opening of the room thermostat contacts –

room temp. setpoint has been achieved

Temperature setpoint drop from the active

intervals

Temperature setpoint increase during  lling

the hot utility water (HUW) tank

Boiler temperature setpoint increase by the

mixer circuit

Temperature setpoint increase when  lling

the bu󰀨 er

Active return protection

Weather control for boiler circuit switched on

or mixer circuit

11. Quick entry to the set temperature editing menu:

boiler, HUW tank, mixer circuit

5 Control Panel

OPERATION

We,12:00

HUW

Boiler

Run of standby boiler

8PELLUX SLIM 12

PELLUX SLIM 18

Before the  rst start-up of the burner (or if you run out

of fuel),  ll the auger with pellets. This is done by  l-

ling the storage bin with pellets, and then switching the

feeder function to the „On” position in the Manual Con-

trol. When  lling, extend the grate in the Manual Con-

trol and let the pellets fall through the burner into the

ash container so that they can be thrown back into the

storage bin. Leave the feeder running for 3 minutes.

Chapter 5 | Control Panel

Start-Up and Shutdown

The burner is fully automatic, i.e. it automatically  res

up and extinguishes, and does not require manual

start-up and adjustment during operation. The pro-

cess of  ring pellets in the burner is initiated by the

boiler controller.

1. In order to start the boiler, press on any point on

the control panel containing the text Burner O󰀨 .

A request ‘Activate regulator?’ appears; con rm

your selection by pressing on the mark. You can

also use another boiler start-up procedure: press

on MENU and  nd and press on the button on

the rotating menu.

2. After starting the boiler there will be PURGE. The

regulator analyzes the  ue gas temperature, if

the temperature does not change by a given dif-

ference (delta), the boiler will start CLEANING. If

the delta is exceeded, PURGE will continue until

the temperature stabilizes.

3. After CLEANING, the status of FIRING UP is

shown on the display of the operator panel.

• The pellets are supplied to the burner at a spe-

ci c dose (default for Pellux Slim 12 boiler is

100g, for Pellux Slim 18 - 140g )

• Igniter is activated

The order in which the feeder and heater are start-

ed depends on the time of feeding the starting

dose of fuel.

• After the heating-up time has elapsed, the

fans are turned on.

• After  ame detection, the igniter turns o󰀨 au-

tomatically.

4. The boiler goes into the INCANDESCENCE mode

1. In order to stop the boiler operation, press on

MENU and  nd and press on the button on

the rotating menu.

2. The control panel displays the BURNING OFF

status.

3. The pellet feeder stops.

4. The burner air blower operates until detecting the

no ame status.

Shutdown

Start-Up

01.09

2019

Burner off

12:00

nacisnąć przycisk

on MENU and  nd and press on the button on

nacisnąć przycisk

MENU and  nd and press on the button on

nacisnąć przycisk .

IMPORTANT

The standard  re up process takes approx. 9 min. If

no  ame is detected within this time, the igniter will

try again 3 times. When  ame still cannot be detected

after 3 attempts, the emergency procedure is initiated

(Ignition failed) and the  re up process is interrupted.

IMPORTANT

The burner may still operate after switching the con-

troller OFF (damping a  re), depending on the previ-

ous status. Do not interrupt this condition. If the unit is

to be disconnected from the mains, wait until the  re

extinguishing process ends up and the burner status

shifts to the BURNER OFF status.

5. After completing the INCANDESCENCE proce-

dure, the boiler switches to OPERATION mode.

9PELLUX SLIM 12

PELLUX SLIM 18

Chapter 5 | Control Panel

The FIRING UP mode is used for the re up of the

boiler furnace in auto mode. Parameters a󰀨ecting the

re up process are grouped in the menu:

Service Settings → Boiler Settings → Firing Up

If the furnace re up fails, there are further attempts to

ignite performed. These re up attempts are indicated

by numbers at the igniter symbol.

The Firing up attempt failed is reported after three un-

successful attempts. Automatic operation of the boiler

may not be continued – the boiler operator has to in-

tervene. Restart the boiler after remedying the cause

for the re up failure.

The air blower operates in continuous mode. The

fuel feeder operates in cycles. A cycle consists of the

feeder operation time and a break time.

Parameters that a󰀨ect the burner output: feeder op-

eration time, airow time and feeder operation time.

Operating Modes

Operation

Firing up

Status Description

FIRING UP Supply of an initial dose of fuel, start

of the lighter and blower. Fuel re up.

INCANDES-

CENCE

After detecting the ame in the

ring up, the feeder continues

to work, the blower power is in-

creased to heat up the furnace.

OPERATION Boiler goes into the constant duty

cycle as specied by default or by

the user.

SUPERVI-

SION

The continuous operation duty cy-

cle of the boiler in longer intervals,

not allowing the damping.

BURNING OFF Damping of the furnace. Air blower

operates until complete disappear-

ance of ame.

STOP The burner is not working, but it

is approved for operation. The re-

quired boiler temperature has been

reached.

Incandescence

After detecting a ame in the ring up phase, there oc-

curs an incandescence of the furnace before serving

the next portion of fuel in the time specied by the In-

candescence time parameter and increasing the blow-

ing power. Parameter is in the menu:

Service Settings → Boiler Settings → Firing Up

You can set the boiler temperature setpoint as well as

the mixer circuit temperature setpoint from the menu

level:

Boiler Settings → Preset Boiler Temperature

HUW settings → HUW preset temperature

Mixer 1-5 settings → Preset mixer 1-5 temperature

The controller can automatically increase the boiler

temperature setpoint in order to be able to ll the hot

utility water tank or supply the mixer heating circuits.

There are two control modes available that are re-

sponsible for the boiler temperature setpoint stabili-

zation, i.e.:

1. Standard

2. Fuzzy Logic

If the boiler temperature reaches or exceeds the set-

point value by the hysteresis value, the boiler goes into

the SUPERVISION or BURNING OFF mode.

Service Menu → Boiler Settings → Output Modu-

lation → Regulation Mode

If the boiler temperature reaches or exceeds the set-

point value by the hysteresis value, the boiler goes into

the SUPERVISION or BURNING OFF mode. The con-

troller includes a mechanism for the boiler output mod-

ulation and allowing gradual reduction of it when the

boiler temperature comes closer to the setpoint value.

There are three output levels predened:

• maximum output,100%,

• medium output, 50%

• minimum output, 30%.

Various fuel supply times and airow outputs can be

assigned to these levels. The output level parameters

are available in the menu:

Service Menu → Boiler Settings → Output Modulation

The controller determines the power of the burner

with which the boiler will work at the moment, de-

pending of the boiler temperature setpoint and prede-

ned hysteresis in the parameters 50% H2 hysteresis

and 30% H1 hysteresis.

You can congure the H1 and H2 values so that the

modulation will occur without the transient condition,

i.e. passing directly from 100 % to 30 % with the

omission of 50 %.

Setting the Temperature Setpoint

Operation in Standard Mode

Regulation modes

They can be found at:

Service Menu → Boiler Settings → Output Modu-

lation

10 PELLUX SLIM 12

PELLUX SLIM 18

Chapter 5 | Control Panel

In Fuzzy Logic mode, the controller decides automat-

ically the burner output, at which the boiler will op-

erate in order to maintain the boiler temperature at

the preset level. The controller uses the prede ned

output levels same as in the Standard mode. There

is no need to set parameters for H2 Hysteresis and

H1 Hysteresis in this mode. The controller goes into

the SUPERVISION or BURNING OFF mode when

the boiler temperature setpoint is exceeded by 5 de-

grees.

Operation in Fuzzy Logic Mode

After the lapse of the monitoring ti me, the control-

ler enters into the BURNING OFF mode, unless the

boiler temperature has dropped earlier, and the boiler

returns into the OPERATION mode automatically.

In the SUPERVISION mode, the air blower operates

in continuous mode and feeder operate in cycles in

longer intervals than in the OPERATION mode. This

is to prevent dampening the  re.

The SUPERVISION mode parameters can be ac-

cessed in the menu:

Service Settings → Boiler Settings → Supervision

Set the Supervision mode parameters so as to prevent

the furnace extinguishing during the boiler outages.

Supervision

Output level 3

Temp Setpoint

T=85ºC

Temp Setpoint

T=85ºC

Output level 2

IMPORTANT

If only the HUW tank is heated (in the summer), we

recommend to switch the controller to the Standard

mode.

IMPORTANT

Parameters in the Monitoring mode must be select-

ed so that the temperature decreases gradually or is

maintained at a constant level. Incorrect settings can

lead to overheating the boiler.

In the STOP mode, the boiler is extinguished and

waits for the signal to begin operation.

The signal to begin operation can be as follows:

• the boiler temperature setpoint drops below the

temperature setpoint minus the boiler hysteresis

(Boiler hysteresis),

• when the boiler is con gured for operation with

the bu󰀨 er, drop of the bu󰀨 er overall temperature

below the setpoint (Temperature of the bu󰀨 er  ll-

ing start)

In the burning o󰀨 process, the remaining pellet is  red

up and the boiler is prepared for stopping or switching

o󰀨 . All parameters a󰀨 ecting the burning o󰀨 process are

grouped in the menu:

Service Settings → Boiler settings → Burning o󰀨

The regulator stops feeding fuel and performs scav-

enge to burn o󰀨 remaining fuel. After SWITCHING

OFF, the controller switches to STOP mode.

Stop

Burning o󰀨

IMPORTANT

If the monitoring ti me parameter = 0, the controller

goes into the BURNING OFF mode immediately omit-

ting the SUPERVISION mode.

IMPORTANT

If the monitoring time parameter = 60, the controller

remians in the SUPERVISION mode for 60min., after

that time the controller goes into the BURNING OFF

mode.

The regulator has a special chimney sweep mode,

during which the boiler works at a constant power of

30% or 100%. The boiler works with the given power

for the set time: Worktime,

This parameter can be found in the menu:

Chimney sweep mode

The function can be used to adjust the air setpoints

using an exhaust gas analyzer.

CHIMNEY SWEEP mode

11PELLUX SLIM 12

PELLUX SLIM 18

Menu główne - Użytkownika

MENU Information

Boiler settings

HUW settings*

SUMMER mode

Mixer 1-5 settings*

General settings

Manual control

Chimney-sweep

Alarms

Turn o󰀨 the controler

Service Settings

Menu Description

Main menu

12:00

Information

Contains various information relating to the controller operation:

measured temperatures of the bu󰀨er, boiler and mixers, input and

output statuses and soft ware versions, etc.

Main menu

12:00

Boiler settings

Contains setpoints of the boiler-related parameters.

Main menu

12:00

HUW settings

Contains settings of hot utility water-related parameters. *

Main menu

12:00

SUMMER mode

The SUMMER mode means switching the central heating

system OFF and leaving only hot utility water heating ON. Auto

activation of this mode is based upon the indications of the outdoor

temperature sensor.

Main menu

12:00

Mixer settings

This menu contains setpoints of the controlled heating circuits.

These circuits are controlled by electric actuator operating the

mixing valve. Lower temperature in relation to the boiler temperature

can be achieved in these circuits. *

Chapter 5 | Control Panel

12 PELLUX SLIM 12

PELLUX SLIM 18

Menu Description

Main menu
