Penlon AV-S Reference manual

Penlon
InterMed
Partnership for Life
AV-S Ventilator
Introduction

Penlon
InterMed
Partnership for Life
AV-S Ventilator
◆Product Overview
◆Introduction
◆Characteristics
◆Configuration
◆Sub-assemblies

Penlon
InterMed
Partnership for Life
AV-S Ventilator
◆Operation
◆Ventilator control settings
◆Operation workshop
◆Pre-operative checkout procedure

Penlon
InterMed
Partnership for Life
AV-S Ventilator
◆ECHNICAL DESCRIP ION
◆AV-S Pneumatic description.
◆AV-S Electrical description.

Penlon
InterMed
Partnership for Life
AV-S Ventilator
◆Practical:
◆Disassembly.
◆Planned maintenance.
◆est and calibration procedures.
◆Fault finding.

Penlon
InterMed
Partnership for Life
AV S ventilator
Product Overview

Penlon
InterMed
Partnership for Life
Aims and Objectives
◆Aim:
◆he aim of this module is to give the student a full
understanding of the features and characteristics of the
AV-S ventilator.
◆Objective:
◆By the end of this module the student will be able to:
◆Describe the features of the AV-S.
◆Recognise user controls.
◆Recognise AV-S configuration.

Penlon
InterMed
Partnership for Life
AV-S Ventilator
◆Pneumatically driven.
◆Software controlled.
◆Multi-mode ventilator.
◆ime-cycled, volume/pressure controlled and pressure
limited.
◆Compliance & fresh gas compensated.
◆User adjustable sigh & inspiratory pause.

Penlon
InterMed
Partnership for Life
AV-S monitoring
Integrated monitoring:
◆Inspired oxygen measurement.
◆Measured from inspiratory limb.
◆Airway pressure measurement.
◆Measured in the expiratory limb.
◆idal/Minute volume measurement.
◆Dual spirometry system.

Penlon
InterMed
Partnership for Life
AV-S features
◆Large 8.4” high definition colour screen.
◆ouch screen.
◆Rotary control dial.
◆Single/ Dual waveform display.
◆Designed to integrate with:
◆PrimaSP; SP2 and SP3.
◆A100SP; A200SP.

Penlon
InterMed
Partnership for Life
AV-S features
◆Print outs & interfacing:
◆USB, Serial Port, Analogue outputs, HPPCL4
printer output.
◆30 minutes battery back up as standard:
◆Optional 60 minute battery available.

Penlon
InterMed
Partnership for Life
AV-S features
LED power indicators:
Yellow when connected /battery
charging
On/Off Switch
Alarm silence/mute key.
Menu selection key
LED on/off indicator.
Green when switched on
Rotary control dial.
Membrane keys

Penlon
InterMed
Partnership for Life
Modes of ventilation
◆Mandatory modes:
◆Volume Mode.
◆Pressure Mode.
◆Spontaneous breathing support modes:
◆SIMV.
◆SMMV.
◆Pressure Support.

Penlon
InterMed
Partnership for Life
Modes of ventilation
Volume Controlled Ventilation
◆AV-S delivers a mandatory set volume of
gas at fixed breath intervals.
◆he Patient is making no respiratory effort.
◆AV-S is volume limited and time cycled.
◆idal volume setting range, 20 to 1600ml.
◆Inspiration terminated after a preset time.

Penlon
InterMed
Partnership for Life
Modes of ventilation
◆Airway Flow and Pressure Patterns
Airway Flow
Airway
Pressure
Expiration
Inspiration

Penlon
InterMed
Partnership for Life
Modes of ventilation
Volume ventilation parameter limits:
◆idal volume adjustable from 20 – 1600 m
◆Rate adjustable from 4 – 100 bpm
◆I:E ratio adjustable from 1:0.3 – 1:8
◆Peep 'Off' or adjustable from 4 – 20 cmH
2
O
◆Inspiratory pressure limit from 10 to 80 cmH2O
◆Inspiratory pause 0-60%
◆Does not affect I:E ratio
◆Sigh 1.5 x Set Vt
◆Adjustable 1:10 to 1:100 breaths

Penlon
InterMed
Partnership for Life
1.87.xx display

Penlon
InterMed
Partnership for Life
Fresh Gas Compensation
AV-S uses spirometry information to adjust for:
◆Gas added to the system from the anaesthesia machine.
◆Losses in the system:
◆Gas compliance.
◆Maximum adjustment - 60% of set tidal volume.
◆Alarms if measured volume 50% different than set.
◆Alarm is user adjustable.
◆Ambient pressure compensation.
◆Adjusts delivered volume accordingly.

Penlon
InterMed
Partnership for Life
Compliance Compensation
◆Corrects volume delivery for pressure
losses in Circuit.
◆Used if Fresh Gas Compensation is off.
◆Switched off or Spirometry not available.
◆Requires Breathing Circuit Compliance
measurement.
◆Carried out as pre-use check.
◆Does not compensate for additional gas
from anaesthesia machine.

Penlon
InterMed
Partnership for Life
Modes of ventilation
Pressure controlled ventilation.
◆Delivers a volume of gas to achieve a set
pressure at fixed breath intervals.
◆he Patient is making no respiratory effort.
