PENNCO 41J Series Guide

USER'S
INFORMATION
MANUAL
Information and specifications outlined in this manual in effect at the
time of printing of this manual. ECR International reserves the right to
discontinue, change specifications or system design at any time without
notice and without incurring any obligation, whatsoever.
Check our website frequently for updates: www.ecrinternational.com
P/N 240006925P, Rev. A [8/2011]
SERIES 41J
GAS FIRED STEAM AND HOT WATER HEATING BOILER
WARNING: If the information in this manual is not
followed exactly, a fire or explosion may result causing
property damage, personal injury or loss of life.
Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
WHAT TO DO IF YOU SMELL GAS
Do not try to light any appliance.• Do not touch any electrical switch; do not use• any phone in your building.
Immediately call your gas supplier from a• neighbor's phone. Follow the gas supplier's
instructions.
If you cannot reach your gas supplier, call the• fire department.
Installation and service must be performed by a
qualified installer, service agency or the gas
supplier.
Do not use this boiler if any part has been under water. Immediately call a qualified service technician to
inspect the boiler and to replace any part of the control system and any gas control which has been under
water.
Should overheating occur or the gas supply fail to shut off, do not turn off or disconnect the electrical supply to
the pump. Instead, shut off the gas supply at a location external to the appliance.
PENNCO BOILERS
2201 Dwyer Avenue, Utica NY 13501
web site: www.ecrinternational.com

2
USERS INFORMATION MANUAL
INSTRUCTIONS FOR OPERATION AND MAINTENANCE
OF GAS FIRED HOT WATER HEATING BOILER
RETAIN FOR FUTURE REFERENCE
SAFETY SYMBOLS & WARNINGS
The following defined symbols are used throughout
this manual to notify the reader of potential hazards of
varying risk levels.
DANGER
!
DANGER
Indicates a hazardous situation which, if
not avoided, WILL result in death or serious
injury.
NOTICE
Indicates information which should be
followed to ensure proper installation and
operation.
!
WARNING
Indicates a hazardous situation which, if
not avoided, could result in death or serious
injury.
!
CAUTION
Indicates a hazardous situation which, if not
avoided, may result in minor or moderate
injury.
Utica Boilers recommends all boiler maintenance be
performed by a trained heating technician.

3
LIGHTING INSTRUCTIONS
!
WARNING
Before lighting make certain boiler contains water:
Steam - water visible in gauge glass•
Water - System pressure minimum 12 psi•
LIGHTING PROCEDURE
!
WARNING
If you do not follow these instructions exactly,
a fire or explosion may result causing property
damage, personal injury or loss of life.
This appliance is equipped with an ignition device whichA. automatically lights the pilot. Do not try to light the
appliance by hand.
Before operating, smell all around the appliance areaB. for gas. Be sure to smell next to the floor because
some gas is heavier than air and will settle on the floor.
Read "What To Do If You Smell Gas" on front page of
this manual.
Use only your hand to push in or turn the gas controlC. knob. Never use tools. If the knob will not push in
or turn by hand, don’t try to repair it, call a qualified
service technician. Force or attempted repair may
result in a fire or explosion.
Do not use this appliance if any part has been underD. water. Immediately call a qualified service technician
to inspect the appliance and to replace any part of the
control system and any gas control which has been
under water. E.
F.
Operating Instructions For Intermittent Pilot
System
STOP! 1. Read the safety information above.
Set the thermostat to lowest setting. 2.
Turn off all electric power to the appliance. 3.
This appliance is equipped with an ignition device 4.
which automatically lights the pilot. Do not try to
light the pilot by hand.
Turn gas control knob clockwise 5. to “OFF.” See
Figure 1 or 2.
Wait (5) minutes to clear out any gas. If you
6.
then smell gas, STOP! Follow “What To Do If You
Smell Gas” on front cover of this manual. If you
don’t smell gas, go on to the next step.
Turn gas control knob counterclockwise
7. to
“ON.”
Turn on all electric power to the appliance. 8.
Set thermostat to desired setting. 9.
If the appliance will not operate, follow the 10.
instructions “To Turn Off Gas To Appliance” on
page 5 and call a qualified service technician or
your gas supplier.
Figure 1 - Honeywell VR8300 Series Gas Valve
(300/400 Bases)
Figure 2 - Robertshaw 7000 DERHC Series Gas Valve
(500 Base)

4
LIGHTING INSTRUCTIONS
To Turn Off Gas To Appliance
Set the thermostat to lowest setting. 1.
Turn off all electric power to the appliance if service is 2.
to be performed.
Push in gas control knob slightly and turn clockwise 3.
to "OFF." DO NOT FORCE.
Note Some gas control knobs cannot be turned from
"PILOT" to "OFF" unless knob is pushed in slightly. DO
NOT FORCE.
Replace access panel. 4.
GENERAL INSTRUCTIONS
!
WARNING
Burn and scald hazard. Discharge of water,
vapor and steam may scald. Follow these
instructions to avoid possible hazard.
Before the beginning of each heating season have a
professional service agency check and clean the boiler
if necessary. Check for the following:
Flue ways for dirt and scale. 1.
Venting flue connectors for plugging, sagging, rust 2.
through and solid joints.
Burners and pilot for proper flame and operation. 3.
Gas piping for leaks. 4.
Operation of electronics and wiring condition. 5.
Functionality of low water cutoff 6. (steam).
Functionality of Pressure Control. 7.
Water pump oiling 8. (See manufacturer's manual).
S 9. afety relief valve or safety valve.
Blow down. 10.
Air vents on steam heaters. 11.
Operation of other custom system components. 12.
Purge air from water systems. 13.
Clean and Flush steam systems, if required, and fill to 14.
proper level. (See Figure #3 next page)

5
GENERAL INSTRUCTIONS
!
WARNING
Water and steam are under pressure, open all
valves slowly. !
WARNING
Burn and scald hazard. Discharge of water,
vapor and steam may scald. Follow these
instructions to avoid possible hazard.
Owner should be aware of weekly and monthly
maintenance. Since some equipment is non-factory
installed, please refer to manufactures literature.
Weekly, do the following. All boilers are equipped with
safety valve (steam) or safety relief valve (water).
The lever of the safety relief valve should be operated
periodically to ensure proper operation. If valve leaks
steam when boiler is operating at normal pressure it
must be replaced. On steam boilers with manual low
water cut-off valves, open purge valve until water
flows clear. (Figure# 3)
STEAM BOILERS: During the heating season the owner
should blow down the boiler at least once each month.
Before blowing down the boiler, fill it to the water line. Light
the burners and allow steam pressure to build up. Run
a temporary connection from one of the drain valves. If
possible, connect a hose to the drain valve on the opposite
side of the boiler from the make up water. Shut off the gas
burners, open the drain valve and blow down the entire
contents of the boiler. Allow the boiler to thoroughly cool
and slowly refill to the water line. Repeat the process as
many times as required until the blow-off water is clear.
Maintain proper water level – Flush manual Low Water Cutoff once a week.
!
Figure 3 - Steam Boiler – Optimum Water Level

6
NOTES

7
Date Service Performed Company Name & Tech Initials Company Address & Phone #

8
An ISO 9001-2008 Certified Company
ECR International, Inc.
2201 Dwyer Ave.
Utica, NY 13501
Date of Installation:
Boiler Model #:
Installed By:
