Perel CAMSET29 User manual

CAMSET29
CAMERA PEEPHOLE VIEWER
DEURSPIONCAMERA
CAMÉRA OEILLETON
CÁMARA MIRILLA
TÜRSPION-KAMERA
WIZJER DO DRZWI Z KAMERĄ
CÂMARA DE POSTIGO
USER MANUAL 3
GEBRUIKERSHANDLEIDING 10
MODE D'EMPLOI 17
MANUAL DEL USUARIO 25
BEDIENUNGSANLEITUNG 32
INSTRUKCJA OBSŁUGI 40
MANUAL DO UTILIZADOR 48

CAMSET29
V. 02 –27/11/2017 2 ©Velleman nv

CAMSET29
V. 02 –27/11/2017 3 ©Velleman nv
USER MANUAL
1. Introduction
To all residents of the European Union
Important environmental information about this product
This symbol on the device or the package indicates that
disposal of the device after its lifecycle could harm the
environment. Do not dispose of the unit (or batteries) as
unsorted municipal waste; it should be taken to a
specialized company for recycling. This device should be
returned to your distributor or to a local recycling service. Respect
the local environmental rules.
If in doubt, contact your local waste disposal authorities.
Thank you for choosing Perel! Please read the manual thoroughly
before bringing this device into service. If the device was damaged in
transit, do not install or use it and contact your dealer.
2. General Guidelines
Refer to the Velleman® Service and Quality Warranty on the last
pages of this manual.
Do not expose the device to high temperatures, dripping or
splashing water, strong vibrations or heavy mechanical stress.
Do not press hard on the LCD display area to prevent damage or
leakage.
The wire connecting the camera to the display is fragile. Please
handle with care to prevent breaking or internal damage.
3. Features
photo and video recording
energy saving mode
easy installation
discreet: camera looks like peephole
bright 2.8" TFT LCD
video/photo browsing via calendar function
recording on micro SD card (not included)

CAMSET29
V. 02 –27/11/2017 4 ©Velleman nv
4. Overview
Refer to the illustrations on page 2 of this manual.
1
LCD display
8
User Guide - System Information
2
Answer key
9
Menu/OK key indicator
3
Left key
10
Right key indicator
4
Right key
11
Left key indicator
5
Menu/OK key
12
Battery status
6
Time
13
System Settings
7
Date
14
Visitor Records
5. Installation
Step 1
Remove the existing peephole
viewer.
Make sure the hole matches the
camera (range between 13mm
and 28mm).
If necessary, drill a new hole.
Step 2
Screws are included in the
package.
oUse the short screws if the
door is less than 65 mm thick.
oUse the long screws if the door
is between 65 and 95 mm.
Insert the appropriate screws into
the camera part.
Do not tighten the screws yet.

CAMSET29
V. 02 –27/11/2017 5 ©Velleman nv
Step 3
Remove the adhesive foam.
Please note the UP sign at the
back of the camera.
Turn the camera part upward.
Gently slide the camera cable
through the hole and attach the
camera by pressing the adhesive
foam.
Make sure the connector on the
wire is turned to the outside.
Step 4
Please note the UP sign at the
back of the bracket.
Slide the cable through the
bracket.
Slide the screws from the large
part to the smaller part of the
slots.
Step 5
Tightly fix the screws and the
bracket tightly.
When finished, gently straighten
the camera cable.
Step 6
Open the battery lid.
Insert the Micro SD card as
shown.
Install the batteries as shown.
Note: The device will only recognize
the SD card if inserted before the
batteries.

CAMSET29
V. 02 –27/11/2017 6 ©Velleman nv
Step 7
Hold the display with the Answer
key down.
Flip the device by 180 degrees,
Connect the camera cable to the
connector next to the SD card.
Put the battery lid back in place.
Step 8
Flip the device back again.
Straighten the camera cable.
Align the device with the bracket
and gently push it down until the
device is fastened on the bracket.
Make sure the camera is firmly
attached to the door.
Press keys to check if the device
works correctly.
6. Operation
6.1 Start the camera
1. Press the Answer key to activate the device.
The LCD displays the camera view.
2. To record (video or picture), press the Answer key again.
The device automatically saves the picture or video to the Visitor
records (see below).
You can set whether the device records video or pictures in the
settings (see below).
6.2 Visitor records
The visitor Records lists all visits, sorted by time.
To view the visitor records:
1. Press the Answer key to activate the device.
The LCD displays the camera view.
2. Press the Menu/OK key to change the view.
3. Use the arrow keys to select Visitor records and press Menu/OK
key.

CAMSET29
V. 02 –27/11/2017 7 ©Velleman nv
4. Select a record with the arrow keys and press Menu/OK key.
5. Press the Answer key to go up one level and the Visitor records.
View a picture or video
1. Go to Visitor Records as described above.
The Visitor Records lists all recorded visits by date.
2. Use the arrow keys to select the appropriate folder and press the
Menu/OK key.
3. Press the Menu/OK key to select an item.
4. Press the Answer key to leave and go back to Visitor records.
Delete a picture or video
1. Go to Visitor Records as described above.
The Visitor Records lists all recorded visits by date.
2. Use the arrow keys to select the appropriate folder and press the
Menu/OK key.
3. Press the Menu/OK key to select an item.
4. While viewing the item, press the Menu/OK key and press the
Menu/OK key again to confirm deletion.
6.3 System Settings
To go to the system settings:
1. Press the Answer key to activate the device.
The LCD displays the camera view.
2. Press the Menu/OK key to change the view.
3. Use the arrow keys to select System Settings and press the
Menu/OK key to enter the system settings.
4. Use the arrow keys to go through the system settings and press
the Menu/OK key to select a setting.
5. Change the setting as desired and press the Menu/OK key to
confirm.
If you want to cancel your changes, press the Answer key.
6. Go back to the main menu with the Answer key.
7. Activate the camera view with the Answer key.
Available settings
The device has the following settings:
Date and time
Language
Recording Mode: photo or video
LCD Brightness

CAMSET29
V. 02 –27/11/2017 8 ©Velleman nv
Video Recording Time: changes the default length of recorded
video
Backlight Time: changes the time the device remains powered on
(5 –10 –15 –20 seconds).
Format Micro SD card: allows formatting the Micro SD card (press
the Answer key to cancel or the Menu-OK key to confirm).
Restore factory settings: restores factory settings (press the
Answer key to cancel or the Menu-OK key to confirm).
6.4 User manual
The User manual contains the user guide and system information.
7. Troubleshooting
Problem
Possible solution
The device randomly powers
on/off.
May be caused by low batteries.
Change the batteries.
When inserting the Micro SD
card, the device displays a
message “Insert Memory Card”
or “Param Error”.
Remove and put back the
batteries.
Use another Micro SD card.
The device displays the message
“Param Error”.
Reconnect the camera cable.
8. Cleaning and maintenance
Insert or replace the batteries
Install the Micro SD card before the batteries and click the Micro
SD card. The device will only recognize the SD card if inserted
before the batteries.
Only use appropriate batteries (see Technical Specifications
below).
1. Remove the battery lid.
2. Remove the used battery and install a new one.
Mind the battery polarity (+ and -).
3. Close the battery lid.

CAMSET29
V. 02 –27/11/2017 9 ©Velleman nv
9. Technical Specifications
monitor
2.8" TFT LCD
viewing angle
75°
door dimensions
drill hole range: 13 - 28 mm
door thickness range: 35 - 105 mm
monitor
dimensions
135 x 75 x 17 mm
camera
dimensions
Ø 30 x 7 mm
power supply
3 x 1.5V AA batteries (LR6C - not included)
weight
180 g
Use this device with original accessories only. Velleman nv
cannot be held responsible in the event of damage or injury
resulting from (incorrect) use of this device. For more info
concerning this product and the latest version of this manual,
please visit our website www.perel.eu. The information in this
manual is subject to change without prior notice.
© COPYRIGHT NOTICE
The copyright to this manual is owned by Velleman nv. All
worldwide rights reserved. No part of this manual may be copied,
reproduced, translated or reduced to any electronic medium or
otherwise without the prior written consent of the copyright holder.

CAMSET29
V. 02 –27/11/2017 10 ©Velleman nv
GEBRUIKERSHANDLEIDING
1. Inleiding
Aan alle ingezetenen van de Europese Unie
Belangrijke milieu-informatie betreffende dit product
Dit symbool op het toestel of de verpakking geeft aan dat,
als het na zijn levenscyclus wordt weggeworpen, dit toestel
schade kan toebrengen aan het milieu. Gooi dit toestel (en
eventuele batterijen) niet bij het gewone huishoudelijke
afval; het moet bij een gespecialiseerd bedrijf terechtkomen
voor recyclage. U moet dit toestel naar uw verdeler of naar een
lokaal recyclagepunt brengen. Respecteer de plaatselijke
milieuwetgeving.
Hebt u vragen, contacteer dan de plaatselijke autoriteiten
betreffend de verwijdering.
Dank u voor uw aankoop! Lees deze handleiding grondig voor u het
toestel in gebruik neemt. Werd het toestel beschadigd tijdens het
transport, installeer het dan niet en raadpleeg uw dealer.
2. Algemene richtlijnen
Raadpleeg de Velleman® service- en kwaliteitsgarantie
achteraan deze handleiding.
Stel het apparaat niet bloot aan hoge temperaturen, druip- of
spatwater, sterke trillingen of hoge mechanische belastingen.
Druk niet hard op het LCD-scherm om schade of lekken te
voorkomen.
Het snoer dat de camera verbindt, is fragiel. Wees voorzichtig om
elke beschadiging te vermijden.
3. Eigenschappen
foto en video-opname
energiebesparende functie
eenvoudige installatie
discreet: de camera ziet eruit als een spionnetje
helder 2.8" TFT LCD-beeldscherm
foto's/video's doorbladeren met de kalenderfunctie
opname op micro SD-kaart (niet meegelev.)
