Pfaff 1295 User manual

1295
1296
296-12-19 309/002
Instruction Manual engl. 10.15
This instruction manual applies to machines
from the following serial numbers onwards: 7 262 456
and software version 0435/002.
INSTRUCTION MANUAL

Reprinting, copying and translation - including excerpts - from PFAFF instruction
books is permitted only with our prior approval and listing of sources.
PFAFF Industriesysteme
und Maschinen GmbH
Hans-Geiger-Str. 12 - IG Nord
D-67661 Kaiserslautern
This instruction manual applies for all of the models and subclasses listed in
Chapter 3 Technical Data.
The adjustment manual for the machine can be downloaded at no charge under
www.pfaff-industrial.de/de/service-support/downloads/technical. As an al-
ternative to the Internet download, the adjustment manual can also be ordered
as a hard copy under order no. 296-12-19 310/002.

Table of Contents
Contents ..................................................................................Page
1Safety .................................................................................................................................... 5
1.01 Directives............................................................................................................................... 5
1.02 General safety instructions .................................................................................................... 5
1.03 Safety symbols ...................................................................................................................... 6
1.04 Special points of attention for the owner-operator ................................................................ 6
1.05 Operating personnel and technical staff ................................................................................ 7
1.05.01 Operating personnel .............................................................................................................. 7
1.05.02 Technical staff........................................................................................................................ 7
1.06 Danger warnings.................................................................................................................... 8
2Proper Use............................................................................................................................ 9
3Technical Data s...................................................................................................................................................................................................... 10
3.01 PFAFF 1295.......................................................................................................................... 10
3.02 PFAFF 1296.......................................................................................................................... 11
4Disposal of the Machine.................................................................................................... 12
5Transport, Packaging and Storage ................................................................................... 13
5.01 Transport to the customer's premises ................................................................................ 13
5.02 Transport within the customer's premises.......................................................................... 13
5.03 Disposal of the packaging materials .................................................................................... 13
5.04 Storage ................................................................................................................................ 13
6Work Symbols.................................................................................................................... 14
7Operating Controls ............................................................................................................ 15
7.01 Main switch ......................................................................................................................... 15
7.02 Buttons on the machine head (only in machines with backtacking system -911/..) ............ 15
7.03 Treadle ................................................................................................................................. 16
7.04 Hand lever to raise the sewing feet..................................................................................... 16
7.05 Lever for stitch length regulation and reverse sewing ........................................................ 17
(In machines without backtacking system -911/..)................................................ 17
7.06 Lever for stitch length regulation (in machines with backtacking system -911/..)................. 17
7.07 Top feed lift setting.............................................................................................................. 18
7.08 Knee lever (in machines without backtacking system -911/..)............................................. 18
7.08 Control panel (only in machines with P40 CD)..................................................................... 19
8Set-up and Initial Commissioning .................................................................................... 20
8.01 Set-up .................................................................................................................................. 20
8.01.01 Setting the table height ....................................................................................................... 20
8.01.02 Inserting the sewing machine into the stand ...................................................................... 21
8.01.04 Tensioning the V-belt ........................................................................................................... 22
8.01.06 Assembling the upper V-belt guard ..................................................................................... 23
8.01.07 Mounting the synchroniser.................................................................................................. 24

Table of Contents
Contents ..................................................................................Page
8.01.08 Assembling the anti-tipping device...................................................................................... 24
8.02 Connecting the plug-in connections and ground cable ........................................................ 25
8.03 Assembling the reel stand ................................................................................................... 26
8.04 Initial start-up ....................................................................................................................... 27
8.05 Switching the machine on / off............................................................................................ 27
8.06 Machine drive home position .............................................................................................. 27
9Set-up.................................................................................................................................. 28
9.01 Inserting the needle ............................................................................................................ 28
9.02 Winding the bobbin thread, adjusting the thread tension.................................................... 29
9.03 Removing / inserting the bobbin case ................................................................................. 30
9.04 Inserting the bobbin case / adjusting the bobbin thread tension ......................................... 30
9.05 Threading the needle thread / adjusting the needle thread tension
(with the PFAFF 1295) ....................................................................................................... 31
9.07 Threading the needle thread / adjusting the needle thread tension
(with the PFAFF 1296) ....................................................................................................... 32
9.08 Setting the bobbin stitch counter ....................................................................................... 32
10 Maintenance and Care....................................................................................................... 33
10.01 Maintenance intervals.......................................................................................................... 33
10.02 Cleaning the machine .......................................................................................................... 33
10.03 General oiling ....................................................................................................................... 34
10.04 Oiling the hook..................................................................................................................... 35
10.05 Oiling the front parts............................................................................................................ 35
10.06 Lubricating the top feed driving eccentric ........................................................................... 36
10.07 Checking / setting the air pressure ...................................................................................... 36
10.08 Cleaning the maintenance unit air filter ............................................................................... 37
10.09 Parameter settings ............................................................................................................. 37
11 Table Top............................................................................................................................ 38
11.01 Table top cutout................................................................................................................... 38
11.02 Table top assembly.............................................................................................................. 39
12 Wearing Parts..................................................................................................................... 40

Safety
5
1 Safety
1.01 Directives
The machine was built in compliance with the European regulations specified in the
declaration of conformity and declaration of incorporation.
As a supplement to this instruction manual, please also observe the generally applicable,
legal and other regulations and legislation – also in the country of use – and the valid
environmental protection regulations! Always comply with the locally applicable regulations
of the professional associations and other supervisory authorities!
1.02 General safety instructions
OThe machine may only be operated after you have become acquainted with the
associated instruction manual and only by operating personnel who have received
appropriate training!
OAlways read the safety instructions and the instruction manual of the motor manufacturer
before starting up the machine!
OAlways follow the hazard and safety instructions attached to the machine!
OThe machine may only be operated for its intended purpose and only with the associated
safety covers, while adhering to all the relevant safety requirements.
OThe machine must always be disconnected from the power supply by pressing the main
switch or pulling out the mains plug when sewing tools are replaced (such as the needle,
sewing foot, needle plate and bobbin) and when threading, leaving the workstation, or
performing maintenance!
OThe daily maintenance work may only be carried out by suitably qualified personnel!
ORepairs and special maintenance work may only be carried out by technical staff or
people with appropriate training!
OWork on electrical equipment may only be carried out by qualified technical staff!
OWork on parts and equipment under voltage is not permitted!
OExceptions are regulated by the EN 50110 standards.
OModifications and changes to the machine may only be made in compliance with all of
the relevant safety requirements!
OOnly those replacement parts approved by us for usage may be used for repairs! We
warn you expressly that spare parts and accessories that are not supplied by us are also
not tested and approved by us.
Fitting or using these products may therefore have negative effects on features which
depend on the machine design. We are not liable for any damage caused by the use of
non-Pfaff parts.

Safety
6
1.03 Safety symbols
Hazard point!
Special points of attention.
Risk of injury to operating personnel or technical staff!
Electric voltage!
Danger to operating personnel or technical staff
Danger of hands being crushed!
Danger to operating personnel or technical staff
Caution!
Do not operate without finger guard and safety
covers! Turn off the main switch before threading, chang-
ing the bobbin or needle, cleaning, etc!
1.04 Special points of attention for the owner-operator
OThis instruction manual is a part of the machine and must be made available to the
operating personnel at all times. The instruction manual must have been read before the
initial start-up.
OThe operating personnel and technical staff must be instructed about the machine’s
safety covers and about safe working methods.
OThe owner-operator may only operate the machine in a flawless condition.
OThe owner-operator must ensure that no safety covers are removed or disabled.
OThe owner-operator must ensure that only authorised persons work on the machine.
Additional information can be requested from the responsible sales centre.

Safety
7
1.05 Operating personnel and technical staff
1.05.01 Operating personnel
Operating personnel are persons responsible for equipping, operating and cleaning the ma-
chine and for fault clearance in the sewing area.
The operating personnel are obligated to comply with the following points:
OThe safety instructions provided in the instruction manual must be followed for all work!
OAny work method jeopardising machine safety must be refrained from!
OTight-fitting clothing must be worn. The wearing of jewellery such as chains and rings is
prohibited!
OCare must be taken to ensure that no unauthorised persons are located in the machine's
hazard zone!
OAny changes occurring on the machine which impair its safety must be reported to the
owner-operator immediately!
1.05.02 Technical staff
Technical staff are persons with technical training in electricity/electronics and mechanics.
They are responsible for lubricating, servicing, repairing and adjusting the machine.
The technical staff are obligated to comply with the following points:
OThe safety instructions provided in the instruction manual must be followed for all work!
OTurn off the main switch and secure it against reactivation before starting any adjustment
and repair work!
ONever work on live parts and equipment!
Exceptions are regulated by the EN 50110 standards.
OReattach the safety covers following repair and maintenance work!

Safety
8
Fig. 1 - 01
1.06 Danger warnings
A work area of 1mmust be kept free in front of and behind the machine to en-
sure unobstructed access at all times.
Do not reach into the needle range during the sewing operation!
Risk of injury from the needle!
Do not allow any objects to be placed on the table during the adjustment work!
The objects could become jammed or be slung away!
Risk of injury from parts flying around!
Do not operate the machine without the take-up lever guard 1!
Risk of injury due to the motion of the take-up lever!
Do not operate the machine without the finger guard 2!
Risk of injury from the needle!
Do not operate the machine without the anti-tipping device 3!
Risk of injury by crushing between the sewing head and the table top!
Do not operate the machine without the support 4! Risk of damage due to the
top-heavy sewing head!
Machine can tip over backwards when moving it!
Do not operate the machine without the belt guard 5and 6!
Risk of injury due to the rotating driving belt!
16
2
1
2
3
0
5
3
4

Proper Use
99
2 Proper Use
The PFAFF 1295 is a single needle lockstitch post-bed sewing machine with bottom feed,
top feed and needle feed and large vertical hook.
The PFAFF 1294 is a two-needle lockstitch post-bed sewing machine with bottom feed,
top feed and needle feed and large vertical hook.
The machines are used for sewing lockstitch seams in the clothing industry.
Any usage not approved by the manufacturer is deemed misuse! The
manufacturer shall assume no liability for damage caused by misuse!
Proper use also includes compliance with the operating, maintenance,
adjustment and repair measures specified by the manufacturer!

Technical Data
10
3 Technical Data s
3.01 PFAFF 1295
Stitch type:.........................................................................................................301 (lockstitch)
Needle system:............................................................................................................... 134-35
Model CN; CN11:...............................................for the machining of medium-heavy materials
Needle size in 1/100 mm:
Model CN; CN11:........................................................................................................ 120 - 150
Stitch length max:
Model CN.......................................................................................................................6.0 mm
Model CN11.................................................................................................................11.0 mm
Speed max.:
Clearance beneath the sewing foot:...............................................................................10 mm
Passage width: .............................................................................................................265 mm
Clearance height: ..........................................................................................................115 mm
Post height....................................................................................................................165 mm
Bed plate dimensions: ............................................................................................... 518 x 177
Sewing head dimensions:
Length:.............................................................................................................approx. 530 mm
Width: ..............................................................................................................approx. 177 mm
Height ( above table ):......................................................................................approx. 440 mm
Motor data: ..................................................................................see motor specification plate
Working air pressure.......................................................................................................... 6 bar
Air consumption.......................................................................................~0.8 l / working cycle
Noise data:
Emissions sound pressure level in the workplace at n = 1600 min-1:.............. LpA = 77 dB(A) n
(Noise measurement in accordance with DIN 45 635-48-A-1, ISO 11204, ISO 3744, ISO 4871)
Net weight of sewing head: ................................................................................ approx. 57 kg
Gross weight of sewing head:............................................................................. approx. 67 kg
sSubject to alterations.
nKpA = 2,5 dB
Top feed lift Max. rpm
with stitch length CN
Max. rpm
with stitch length CN11
up to 5.5 mm 1900 1000
over 5.5 up to 7.0 mm 1800 1000

Technical Data
11
3.02 PFAFF 1296
Stitch type:.........................................................................................................301 (lockstitch)
Needle system:............................................................................................................... 134-35
Model CN; CN11:...............................................for the machining of medium-heavy materials
Needle size in 1/100 mm:
Model CN; CN11:........................................................................................................ 120 - 150
Stitch length max:
Model CN:......................................................................................................................6.0 mm
Model CN11:................................................................................................................11.0 mm
Speed max.:
Clearance beneath the sewing foot:...............................................................................10 mm
Passage width: .............................................................................................................265 mm
Clearance height: ..........................................................................................................115 mm
Post height....................................................................................................................165 mm
Bed plate dimensions: ............................................................................................... 518 x 177
Sewing head dimensions:
Length:.............................................................................................................approx. 570 mm
Width: ..............................................................................................................approx. 177 mm
Height (above table):........................................................................................approx. 440 mm
Motor data: ..................................................................................see motor specification plate
Working air pressure.......................................................................................................... 6 bar
Air consumption.......................................................................................~0.8 l / working cycle
Noise data:
Emissions sound pressure level in the workplace at n = 1500 min-1:.............. LpA = 76 dB(A) n
(Noise measurement in accordance with DIN 45 635-48-A-1,ISO 11204, ISO 3744, ISO 4871)
Net weight of sewing head: ................................................................................ approx. 59 kg
Gross weight of sewing head:............................................................................. approx. 69 kg
sSubject to alterations.
nKpA = 2,5 dB
Top feed lift
Max. rpm
with stitch lengths
up to
6 mm and
needle gauges
up to 10 mm
Max. rpm
with stitch lengths
up to
6 mm and
needle gauges
over 10 mm
Max. rpm
with stitch length
CN11
needle gauges
up to 10 mm
Max. rpm
with stitch length
CN11
needle gauges
over 10 mm
up to 5.5 mm 1800 1600 1000 1000
over 5.5 mm 1600 1400 1000 1000

Disposal of the Machine
12
4 Disposal of the Machine
OIt is up to the customer to dispose of the machine properly.
OThe materials used for the machine include steel, aluminium, brass and various plastics.
The electrical equipment consists of plastics and copper.
OThe machine must be disposed of in accordance with the locally valid environmental pro-
tection regulations, with a specialised company being contracted if necessary.
Please ensure that parts coated with lubricants are disposed of separately in ac-
cordance with the locally valid environmental protection regulations!

Transport, Packaging and Storage
13
5 Transport, Packaging and Storage
5.01 Transport to the customer's premises
All machines are completely packed for delivery.
5.02 Transport within the customer's premises
The manufacturer assumes no liability for transport within the customer's premises or to
the individual usage sites. Please ensure that the machines are only transported in a vertical
position.
5.03 Disposal of the packaging materials
The packaging materials of these machines consists of paper, cardboard and VCI fleece. It is
up to the customer to dispose of the packaging properly.
5.04 Storage
The machine can be stored for up to 6months when not in use. It must then be protected
from dirt and moisture. For longer storage periods, the machine's single components,
especially its sliding surfaces, must be protected against corrosion, e.g. by an oil film.

Work Symbols
14
6 Work Symbols
Activities to be performed or important information in this instruction manual are
emphasised by symbols. The symbols used have the following meaning:
Note, information
Cleaning, care
Lubrication
Maintenance, repairs, adjustment, service work
(only to be carried out by technical staff)

Operating Controls
15
Fig. 7 - 02
7.02 Buttons on the machine head (only in machines with backtacking system -911/..)
OThe machine sews backwards as long as
the button 1is pressed during the sew-
ing operation.
7 Operating Controls
7.01 Main switch
Before switching on the ma-
chine, raise the take-up lever as
far as possible.
OTurning the main switch 1switches the
machine on and off.
Fig. 7 - 01
1
BA-P-114_Fig-7-01
1

Operating Controls
16
7.03 Treadle
OWith the main switch turned on
In machines without backtacking
system -911/..
0 = Neutral position
+1= Sewing
-1= Trim thread/
(in machines with thread
trimmer -900/56)
In machines with backtacking system
-911/..
0 = Neutral position
+1= Sewing
-1= Raise sewing foot
-2= Trim thread/
(in machines with thread
trimmer -900/56)
0
-2
-1
Fig. 7 - 03
+1
Fig. 7 - 04
7.04 Hand lever to raise the sewing feet
OBringing the hand lever 1to the top posi-
tion raises the sewing feet.
1

Operating Controls
17
7.05 Lever for stitch length regulation and reverse sewing
(In machines without backtacking system -911/..)
OTurning the knurled thumb screw on
lever 1sets the stitch length.
OYou can sew in reverse by pressing the
lever 1upwards until you feel it stop.
Fig. 7 - 05
1
7.06 Lever for stitch length regulation
(in machines with backtacking system -911/..)
OTurning the knurled thumb screw 1sets
the stitch length for the forward switch
OTurning the knurled thumb screw 2sets
the stitch length for the reverse stitch.
Fig. 7 - 06
1
1
2
3
0
The reverse stitch can be set to
any length irrespective of the
forward stitch.
Please refer to the separate
instruction manual for the
drive for the setting options for
the automatic front and end
backtack.
2

Operating Controls
18
7.08 Knee lever (in machines without backtacking system -911/..)
OTurning the knee lever 1in the direction
shown by the arrow raises the sewing
foot.
Fig. 7 - 08
1
7.07 Top feed lift setting
Switch off the machine!
Risk of injury due to accidental
machine start-up!
OOpen the cover 1on the back of the
machine, loosen the nut 2and move
accordingly.
Fig. 7 - 07
2
1

Operating Controls
19
7.08 Control panel (only in machines with P40 CD)
The description can be found in the instruction manual for the drive.

Set-up and Initial Commissioning
20
8 Set-up and Initial Commissioning
The machine may only be set up and started up by qualified personnel! All of
the relevant safety regulations must always be complied with in this process!
If the machine was delivered without a table, then the stand and the table top
provided must safely support the weight of the machine and its motor.
Adequate stability of the stand must be guaranteed, even during the sewing
operations.
8.01 Set-up
Suitable electrical supply connections must be provided at the erection site, see Chapter 3
Technical data. The erection site must also have a firm and level subsurface and adequate
lighting.
The table top is lowered for packaging purposes.
The adjustment of the table height is described below.
8.01.01 Setting the table height
Fig. 8 - 01
OLoosen the screws 1and 2.
OMove the table top to the desired working height by pulling it out and pushing it in and
align the table top horizontally.
Adjust the stand on both sides evenly to prevent it tilting.
OThe stand must have all four feet firmly on the ground to make sure it is positioned se-
curely.
OFirmly tighten the screws 1.
OAdjust and tighten the desired treadle position on the screws 2.
1
1
2
