PFS KP5513 User manual

11785 SE Highway 212 – Suite 305
Clackamas, OR 97015-9050
[phone]
WWW.PFSTECO.COM
United States Stove
Company
Project # 21-735
Model: KP5513
Additional Models: KP5513-P, KP5513-L,
US5513, US5513-P, US5513-L, AP5613,
AP5613-P, AP5613-L, VG5713,
VG5713-P, VG5713-L, Little E (SP500),
5501S-XH
Type: Pellet-Fired Room Heater
December 21, 2021
ASTM E2779 Standard Test Method for
Determining Particulate Matter Emissions
from Pellet Heaters
Contact: Mr. John Voorhees
227 Industrial Park Road
South Pittsburg, TN 37380
[e-mail]
[phone]
Prepared by: Sebastian Button,
Laboratory Supervisor

Project # 21-735 Model: KP5513
Page | 1
This page intentionally left blank.

Project # 21-735 Model: KP5513
Page | 2
Contents
Affidavit ......................................................................................................................................................... 3
Introduction ................................................................................................................................................... 4
Notes ......................................................................................................................................................... 4
Pellet Heater Identification and Testing ........................................................................................................ 5
Test Procedures and Equipment .................................................................................................................. 6
Results .......................................................................................................................................................... 7
Summary Table ......................................................................................................................................... 7
Test Run Narrative .................................................................................................................................... 8
Run 1 ..................................................................................................................................................... 8
Test Conditions Summary ............................................................................................................................. 8
Appliance Operation and Test Settings .................................................................................................... 8
Settings & Run Notes ................................................................................................................................ 8
Appliance Description ................................................................................................................................... 9
Appliance Dimensions ............................................................................................................................... 9
Test Fuel Properties .................................................................................................................................... 12
Pellet Fuel Analysis ................................................................................................................................. 13
Sampling Location and Descriptions ........................................................................................................... 14
Photos ..................................................................................................................................................... 14
Sampling Methods ...................................................................................................................................... 15
Analytical Methods Description ................................................................................................................... 15
Calibration, Quality Control and Assurances .............................................................................................. 15
Appliance Sealing and Storage ................................................................................................................... 15
Sealing Label .......................................................................................................................................... 15
Sealed Unit .............................................................................................................................................. 16
List of Appendices ....................................................................................................................................... 17

Project # 21-735 Model: KP5513
Page | 3
Affidavit
PFS-TECO was contracted by United States Stove Company to provide testing services
for the KP5513 Pellet-Fired Room Heater per ASTM E2779, Determining PM Emissions
from Pellet Heaters. All testing and associated procedures were conducted at PFS-
TECO’s Portland Laboratory on 12/2/2021. PFS-TECO’s Portland Laboratory is located
at 11785 SE Highway 212 – Suite 305, Clackamas, Oregon 97015. Testing procedures
followed ASTM E2779. Particulate sampling was performed per ASTM E2515, Standard
Test Method for Determination of Particulate Matter Emissions Collected by a Dilution
Tunnel.
PFS-TECO is accredited by the U.S. Environmental Protection Agency for the certification
and auditing of wood heaters pursuant to subpart AAA of 40 CFR Part 60, New Source
Performance Standards for Residential Wood Heaters and subpart QQQQ of 40 CFR
Part 60, Standards of Performance for New Hydronic Heaters and Forced Air Furnaces,
Methods 28R, 28WHH, 28 WHH-PTS, and all methods listed in Sections 60.534 and
60.5476. PFS-TECO holds EPA Accreditation Certificate Numbers 4 and 4M (mobile).
PFS-TECO is accredited by IAS to ISO 17020:2012 “Criteria for Bodies Performing
Inspections”, and ISO 17025:2005 “Requirements for Testing Laboratories.” PFS-TECO
is also accredited by Standards Council of Canada to ISO 17065:2012 “Requirements for
Bodies Operating Product Certification Systems.”
The following people were associated with the testing, analysis and report writing
associated with this project.
Sebastian Button, Laboratory Supervisor

Project # 21-735 Model: KP5513
Page | 4
Introduction
United States Stove Company of South Pittsburg, TN, contracted with PFS-TECO to
perform EPA certification testing on KP5513 Pellet-Fired Room Heater. All testing was
performed at PFS-TECO’s Portland Laboratory. Testing was performed by Mr. Sebastian
Button.
Notes
• Prior to start of testing, 50 hours of conditioning was performed at a medium burn
setting per ASTM E2779
• Prior to start of testing, the dilution tunnel was cleaned with a steel brush.
• Filters were changed on sample train A at one hour after the test began.
• A single, integrated test run, in accordance with ASTM E2779 was performed:
o 1 Hour at Maximum Burn Setting
o 2 Hours at Medium Burn Setting (Defined as <50% of Maximum Burn Rate)
o 3 Hours at Minimum Burn Setting

Project # 21-735 Model: KP5513
Page | 5
Pellet Heater Identification and Testing
• Appliance Tested: KP5513
• Serial Number: CH1026-36
• Manufacturer: United States Stove Company
• Catalyst: No
• Heat exchange blower: Integral
• Type: Pellet Stove
• Style: Free Standing
• Date Received: Thursday, November 18, 2021
• Testing Period – Start: Thursday, December 02, 2021 Finish: Thursday,
December 02, 2021
• Test Location: PFS-TECO Portland Laboratory, 11785 SE HWY 212 - Suite
305, Clackamas, OR 97015
• Elevation: ≈131 Feet above sea level
• Test Technician(s): Sebastian Button
• Observers: N/A

Project # 21-735 Model: KP5513
Page | 6
Test Procedures and Equipment
All Sampling and analytical procedures were performed by Sebastian Button. All
procedures used are directly from ASTM E2779 and ASTM E2515. See the list below for
equipment used. See Appendix C submitted with this report for calibration data.
Equipment List:
Equipment ID#
Equipment Description
190
Mettler Toledo 3'x3' floor scale w/digital weight indicator
129
APEX XC-50-DIR Digital Emissions Sampling Box A
130
APEX XC-50-DIR Digital Emissions Sampling Box B
055
APEX Ambient sampling box
187
California Analytical ZRE CO2/CO/O2 IR ANALYZER
064
Digital Barometer
109A/B
Troemner 100mg/200mg Audit Weights
107
Sartorius Analytical Balance
097
10 lb audit weight
095
Anemometer
111
Microtector
91005049
Gas Analyzer Calibration Span Gas
CC170624
Gas Analyzer Calibration Mid Gas

Project # 21-735 Model: KP5513
Page | 7
Results
The integrated test run emission rate for test Run 1 was measured to be 1.5 g/hr with a
Higher Heating Values efficiency of 76% and a CO emission rate of 0.5 g/min. The
calculated first hour particulate emission rate was 2.4 g/hr. The United States Stove
Company Model KP5513 Pellet-Fired Room Heater meets the 2020 PM emission
standard of ≤ 2.0 g/hr per CFR 40 part 60, §60.532 (b).
Detailed individual run data can be found in Appendix A submitted with this report.
Summary Table
EPA Application Table
Run
Number
Date
Segments
Run
Time
(min)
Heat
Output
(BTU/hr)
1st Hr
Emissions
(g/hr)
Integrated
Total (g/hr)
CO
Emissions
(g/min)
Overall CO
Emissions
(g/min)
Heating
Efficiency
(%HHV)
Overall
Heating
Efficiency
(%HHV)
Setting
BR
1
12/2/2021
H
1.69
60
24676
2.4
1.5
0.4
0.5
79%
76%
M
0.79
120
11193
0.1
76%
L
0.75
180
10609
0.1
76%
OA
0.92
360
42471
0.5
76%

Project # 21-735 Model: KP5513
Page | 8
Test Run Narrative
Run 1
Run 1 was performed on 12/2/2021 as an attempted integrated test run per ASTM E2779.
The overall test duration was 360 minutes. The particulate emissions rate for the
integrated test run was 1.5 g/hr. The run had an overall HHV efficiency of 76%. Sample
train A was changed at 1 hr. All test results were appropriate and valid and the burn rate
requirement for the integrated test run were achieved. There were no anomalies and all
criteria were met.
Test Conditions Summary
Testing conditions for all runs fell within allowable specifications of ASTM E2779 and
ASTM E2515. A summary of facility conditions, fuel burned, and run times is listed below.
Runs
Ambient (°F)
Relative
Humidity (%)
Average
Barometric
Pressure
(In. Hg.)
Preburn
Fuel
Weight
(lbs)
Test Fuel
Weight
(lbs)
Test Fuel
Moisture
(%DB)
Test Run
Time
(Min)
Pre
Post
Pre
Post
1
68
69
50.7
49.6
30.18
4.3
12.9
6.13
360
Appliance Operation and Test Settings
The appliance was operated according to procedures as described in the Operations
Manual, found in Appendix B submitted with this report. Detailed run information can be
found in Appendix A submitted with this report.
Settings & Run Notes
Pre-Burn
Test Run
Run 1
Heat Setting #5
High Segment: Heat Setting #5
Medium Segment: Heat Setting #1
Low Segment: Heat Setting #1

Project # 21-735 Model: KP5513
Page | 9
Appliance Description
Model(s): KP5513
Additional Models Discussion: This model is offered under a variety of different
branding designations under the following model numbers: KP5513-P, KP5513-L,
US5513, US5513-P, US5513-L, AP5613, AP5613-P, AP5613-L, VG5713, VG5713-P,
VG5713-L, Little E (SP500), and 5501S-XH. The various models are identical in all
aspects with the exception of the brand names.
Appliance Type: Pellet-Fired Room Heater
Air Introduction System: Air enters the burn chamber by being pulled though the firepot,
via the exhaust blower, see air flow diagram in Appendix D.
Combustion Control: Feed rate is electronically controlled via user-selectable controls.
Baffles: N/A
Flue Outlet: 3-inch exhaust outlet located on the bottom/rear of the appliance, with an
optional adapter piece to convert to 6-inch venting.
Appliance Dimensions
KP5513 Dimensions
Height
Width
Depth
29.5”
18.5”
21”
Appliance design drawings can be found in Appendix D submitted with the CBI copy of
this report.

Project # 21-735 Model: KP5513
Page | 10
Appliance Front
Appliance Left

Project # 21-735 Model: KP5513
Page | 11
Appliance Right
Appliance Rear

Project # 21-735 Model: KP5513
Page | 12
Test Fuel Properties
Test fuel used was Bear Mountain Wood Pellet Fuel, a PFI Certified Premium Pellet
Brand. A sample of pellets was sent to Twin Ports Testing for analysis, see report below.

Project # 21-735 Model: KP5513
Page | 13
Pellet Fuel Analysis
Sampling Locations and Descriptions

Project # 21-735 Model: KP5513
Page | 14
Sampling Location and Descriptions
Sample ports are located 16.5 feet downstream from any disturbances and 2 feet
upstream from any disturbances. Flow rate traverse data was collected 8 feet
downstream from any disturbances and 4 feet upstream from any disturbances. (See
below).
Photos
Sample Points
Traverse Points
Traverse Points
Detail
Sample Points
Detail

Project # 21-735 Model: KP5513
Page | 15
Sampling Methods
ASTM E2515 was used in collecting particulate samples. The dilution tunnel is 12 inches
in diameter. All sampling conditions per ASTM E2515 were followed. No alternate
procedures were used.
Analytical Methods Description
All sample recovery and analysis procedures followed ASTM E2515 procedures. At the
end of each test run, filters, O-Rings and probes were removed from their housings,
dessicated for a minimum of 24 hours, and then weighed at 6 hour intervals to a
constant weight per ASTM E2515-11 Section 10.
Calibration, Quality Control and Assurances
Calibration procedures and results were conducted per EPA Method 28R, ASTM E2515-
11 and ASTM E2780-10. Test method quality control procedures (leak checks, volume
meter checks, stratification checks, proportionality results) followed the procedures
outlined.
Appliance Sealing and Storage
Upon completion of testing, the appliance was secured with metal strapping and the seal
below was applied, the appliance was then returned to the manufacturer’s location at:
227 Industrial Park Road, South Pittsburg, TN 37380 for archival.
Sealing Label

Project # 21-735 Model: KP5513
Page | 16
Sealed Unit

Project # 21-735 Model: KP5513
Page | 17
List of Appendices
The following appendices have been submitted electronically in conjunction with this
report:
Appendix A – Test Run Data, Technician Notes, and Sample Analysis
Appendix B – Labels and Manuals
Appendix C –Equipment Calibration Records
Appendix D – Design Drawings (CBI Report Only)
Appendix E – Manufacturer QAP (CBI Report Only)

Conditioning Data.xlsm
Client: Job #:
Model: Tracking #:
Date(s): Technician:
0241 N/A
1252 N/A
2254 N/A
3253 N/A
4252 N/A
5254 N/A
6253 N/A
7258 N/A
8258 N/A
9254 N/A
10 256 N/A
11 254 N/A
12 259 N/A
13 257 N/A
14 261 N/A
15 255 N/A
16 257 N/A
17 259 N/A
18 259 N/A
19 254 N/A
20 241 N/A
21 250 N/A
22 251 N/A
23 255 N/A
24 260 N/A
25 241 N/A
26 235 N/A
27 241 N/A
28 243 N/A
29 247 N/A
30 249 N/A
31 246 N/A
32 246 N/A
33 246 N/A
34 248 N/A
35 245 N/A
36 247 N/A
37 247 N/A
38 246 N/A
39 240 N/A
40 242 N/A
41 250 N/A
42 248 N/A
43 245 N/A
44 250 N/A
45 248 N/A
46 245 N/A
47 248 N/A
48 254 N/A
49 256 N/A
50 255 N/A
SJB
11/22/21 - 11/23/21
Elapsed Time
(hrs)
Flue (°F)
Catalyst Exit
(°F)
117
USSC
21-735
KP5513
Notes: Indicate initial air setting and any changes in in setting during
conditioning, as well as weight and average moisture content of all fuel
additions.
Added 40lbs of Pellets, Medium Heat setting
Added 28 lbs of pellets
Added 15 lbs of pellets
Added 20 lbs of pellets
Added 10 lbs of pellets
Pre-Conditioning Data
Added 29 lbs of pellets
PFS-TECO Page 1 of 1
Signature/Date:___________________________12/1/2021

1
Sebastian Button
From: Sebastian Button
Sent: Wednesday, December 1, 2021 10:58 AM
To: Sebastian Button
Subject: FW: 5513 test


SebastianButton
LaboratorySupervisor‐PortlandLaboratory

From:JohnVoorhees<john.v[email protected]>
Sent:Tuesday,November30,202111:41AM
To:SebastianButton<sebastian.but[email protected]m>;JohnSteinert<[email protected]>
Cc:BrandonBarry<[email protected]>
Subject:5513test

HeySebandJohn,

Highburn:Setting5damperfullyopen
Medium:Setting1damperfullyclosed
Low:Setting1damperfullyclosed

Cheers,



JOHN D. VOORHEES
VP PRODUCT COMPLIANCE
C 503-887-4566 
E [e-mail]
UNITED STATES STOVE COMPANY
227 Industrial Park Road · South Pittsburg
T
ennessee · 37380 · USA · usstove.com


This message, Including any attachments, contains confidential and/or proprietary information intended only for the addressee. Any unauthorized disclosure, copying, distribution or reliance on
t
is strictly prohibited and may constitute a violation of law. If you are not the intended recipient, please notify the sender immediately by responding to this e-mail, and delete the message from yo
u
questions about this e-mail, please notify the sender immediately. 



Disclaimer
