Philips BDP2180 User manual

TABLE OF CONTENTS
Page
Service Manual
. Mechanical and Dismantling Instructions…………........................3-1
. Software Upgrades ........................................................................4-1
. Trouble Shooting Chart……………………………………………….5-1
. Wiring Diagram………………………………………..………..….….6-1
. Electrical Diagrams and Print-layouts..….…………………....….…7-1
. Set Mechanical Exploded view & Part list.…………………..….…10-1
©Copyright 2013Philips Consumer Electronics B.V. Eindhoven, The Netherlands
All rights reserved. No part of this publication may be reproduced, stored in aretrieval system or
transmitted, in any form or by any means, electronic, mechanical, photocopying, or otherwise
without the prior permission of Philips.
CLASS 1
LASER PRODUCT
PHILIPS
GB
. DFU Instruction..............................................................................2-1
. Revision List.................................................................................11-1
Blu-ray Player
. Technical Specifications…………....………………………..............1-
3
. Safety Instruction, Warning & Notes….……………………....….....1-
4
. Location of PCB Boards,Version Variation and Repair Scenario Matrix.....1-2
Published by Arya & Sophie - 1305 Printed in The Netherlands Subject to modification
3141 785 39131
Version 1.1
Service
. Votages and Waveforms for Connection Pins..….………………...8-1
. Pin Description & Block Diagrams of ICs..….………………..........9-1
. Pin Description & Block Diagrams of ICs..….………………..........9-1
. Votages and Waveforms for Connection Pins..….………………...8-1
BDP2180/12/05/X78

PCB BOARD LOCATIONS
1-2
VERSION VARIATIONS
Type / Versions
Service Policy /12 /05 /X78
MAIN BOARD M M M
MMM
LOADER M M M
POWER BOARD M M M
＊Tips：
Board in used
FRONT BOARD
BDP2180
C -- Component Lever Repair
M -- Module Lever Repair
X -- Used
Loader
Main Board
Power Board
Front Board

Specifications
Note
6SHFLÀFDWLRQVDUHVXEMHFWWRFKDQJHZLWKRXWQRWLFH
Region code
This player can play discs with the following
region codes.
DVD Blu-ray Countries
Europe, United
Kingdom
Playable media
 BD-Video, BD 3D
 DVD-Video, DVD+R/+RW, DVD-R/-RW,
DVD+R/-R DL (Dual Layer)
 VCD/SVCD
 Audio CD, CD-R/CD-RW, MP3 media,
:0$PHGLD-3(*ÀOHV
 DivX (Ultra)/DivX Plus HD media, MKV
media
 USB storage device
File format
 Video: .avi, .divx, .mp4, .mkv
 Audio: .mp3, .wma, .wav
 3LFWXUHMSJJLISQJ
Video
 Signal system: PAL / NTSC
 HDMI output: 480i/576i, 480p/576p, 720p,
1080i, 1080p, 1080p/24Hz
Audio
 Digital output: 0.5 Vp-p (75 ohm)
 Coaxial
 HDMI output
 Sampling frequency:
 MP3: 32 kHz, 44.1 kHz, 48 kHz
 WMA: 44.1 kHz, 48 kHz
 Constant bit rate:
 MP3: 112 kbps - 320 kpbs
 WMA: 48 kpbs - 192 kpbs
USB
 Compatibility: Hi-Speed USB (2.0)
B
 Class support: USB Mass Storage Class
 File system: FAT16, FAT32
 USB port: 5V , 500mA
 Support HDD (a portable hard disc drive):
an external power source may be needed.
Main unit
 Power supply rating: 220-240V~, 50Hz -
60Hz
 Power consumption: 10 W
 Power consumption in standby mode:
< 0.5 W
 Dimensions (w x h x d): 310 x 39.5 x
217.7 (mm)
 Net Weight: 1.12 kg
Accessories supplied
 Remote control and batteries
 User manual
Optional accessory
 A wireless Philips USB adapter(named
WUB1110, sold separately)
 Multimedia connections:Wi-Fi
802.11b/g/n
 Connectivity: Rear connection (USB)
 Ambient temperature: 5 deg C to 40
deg C.
 Dongle dimensions (W x H x D): 28.4
x 82 x 13.4 mm
/DVHU6SHFLÀFDWLRQ
 Laser Type (Diode): AlGaInN (BD), AlGaInP
(DVD/CD)
 Wave length: 398nm to 413nm
(BD),645nm to 664nm (DVD), 770nm to
800nm(CD)
 Output power: 1.7mW (BD),
0.19mW(DVD), 0.25mW (CD)
1-3
BDP2180/12/05:

Safety instruction
1. General safety
Safety regulations require that during a repair:
. Connect the unit to the mains via an isolation transformer.
. Replace safety components indicated by the symbol ,
only by components identical to the original ones. Any
other component substitution (other than original type)
may increase risk of fire or electrical shock hazard.
Safety regulations require that after a repair, you must
return the unit in its original condition. Pay, in particular,
attention to the following points:
. Route the wires/cables correctly, and fix them with the
mounted cable clamps.
. Check the insulation of the mains lead for external
damage.
. Check the electrical DC resistance between the mains
plug and the secondary side:
1) Unplug the mains cord, and connect a wire between
the two pins of the mains plug.
2) Set the mains switch the “on” position (keep the
mains cord unplug).
3) Measure the resistance value between the mains
plug and the front panel, controls, and chassis
bottom.
4) Repair or correct unit when the resistance
measurement is less than 1M
¡
.
5) Verify this, before you return the unit to the
customer/user (ref. UL-standard no. 1492).
6) Switch the unit “off”, and remove the wire between
the two pins of the mains plug.
2.Laser safety
This unit employs a laser. Only qualified service personnel
may remove the cover, or attempt to service this device
(due to possible eye injury).
Laser device unit
Type :SemiconductorlaserGaAlAs
Wavelength : 650nm (DVD)
: 780nm (VCD/CD)
Output power : 7mW (DVD)
:10mW(DVD/CD)
Beam divergence: 60 degree
Note: Use of controls or adjustments or performance of
procedure other than those specified herein, may result in
hazardous radiation exposure. Avoid direct exposure to
beam.
Safet
y
instruction, Warnin
g
& Notes
1-4

Warning
1.General
. All ICs and many other semiconductors are susceptible to
electrostatic discharges (ESD). Careless handing during
repair can reduce life drastically. Make sure that, during
repair, you are at the same potential as the mass of the
set by a wristband with resistance. Keep components and
tools at this same potential. Available ESD protection
equipment:
1) Complete kit ESD3 (small tablemat, wristband,
connection box, extension cable and earth cable)
4822 310 10671.
2) Wristband tester 4822 344 13999.
. Be careful during measurements in the live voltage
section. The primary side of the power supply , including
the heat sink, carries live mains voltage when you
connect the player to the mains (even when the player is
“off”!). It is possible to touch copper tracks and/or
components in this unshielded primary area, when you
service the player. Service personnel must take
precautions to prevent touching this area or components
in this area. A “lighting stroke” and a stripe-marked
printing on the printed wiring board, indicate the primary
side of the power supply.
. Never replace modules, or components, while the unit is
“on”.
2. Laser
. The use of optical instruments with this product, will
increase eye hazard.
. Only qualified service personnel may remove the cover
or attempt to service this device, due to possible eye
injury.
. Repair handing should take place as much as possible
with a disc loaded inside the player.
. Text below is placed inside the unit, on the laser cover
shield:
Notes: Manufactured under licence from Dolby
Laboratories. The double-D symbol is trademarks of Dolby
Laboratories, Inc. All rights reserved.
CAUTION: VISIBLE AND INVISIBLE LASER
RADIATION WHEN OPEN, AVOID EXPOSURE
TO BEAM.
1-5

 6HUYLFH+LQWV
 &$87,21
&+$5*('&$3$&,7256217+(6(592%2$5'0$<'$0$*(7+('5,9(
(/(&7521,&6:+(1&211(&7,1*$1(:'5,9(7+$7¶6:+<%(6,'(67+(6$)(7<
0($685(6/,.(
  6:,7&+2))32:(56833/<
  (6'3527(&7,21
$'',7,21$/$&7,2160867%(7$.(1%<7+(5(3$,57(&+1,&,$1
 7KHIROORZLQJVWHSVKDYHWREHGRQHZKHQUHSODFLQJWKHGHIHFWLYHORDGHU

  'LVPDQWOLQJRIWKHORDGHUWRDFFHVVWKH(6'SURWHFWLRQSRLQWLIQHFHVVDU\
   6ROGHUWKH(6'SURWHFWLRQSRLQW    
  'LVFRQQHFWÀH[IRLOFDEOHIURPWKHGHIHFWLYHORDGHU
  3XWDSDSHUFOLSRQWKHÀH[IRLOWRVKRUWFLUFXLWWKHFRQWDFWV¿J
  5HSODFHWKHGHIHFWLYHORDGHUZLWKDQHZORDGHU
  5HPRYHSDSHUFOLSIURPWKHÀH[IRLODQGFRQQHFWLWWRWKHQHZORDGHU
  5HPRYHVROGHUMRLQWRQWKH(6'SURWHFWLRQSRLQW

$77(17,217KHODVHUGLRGHRIWKLVORDGHULVSURWHFWHGDJDLQVW(6'E\DVROGHUMRLQWZKLFKVKRUWFLUFXLWVWKHODVHUGLRGHWRJURXQG
)RUSURSHUIXQFWLRQDOLW\RIWKHORDGHUWKLVVROGHUMRLQWPXVWEHUHPRYHDIWHUFRQQHFWLRQORDGHUWRWKHVHW



 2QO\DSSOLFDEOHIRUGHIHFWLYHORDGHUQHHGHGWREHVHQWEDFNWRVXSSOLHUIRUIDLOXUHDQDO\VLVDQGWRVXSSRUWEDFNFKDUJLQJ 
 HYLGHQFH
 7KLVLVDOVRDSSOLFDEOHIRUDOOSDUWQHUVKLSZRUNVKRSV
(6'SURWHFWLRQSRLQWLVDFFHVVLEOHIURPWRSRIORDGHU
SolderJoint
1-6

Lead-Free requirement for service
INDENTIFICATION:
Regardless of special logo (not always indicated)
One must treat all sets from 1.1.2005 onwards, according
next rules.
Important note: In fact also products a little older can also
be treated in this way as long as you avoid mixing
solder-alloys (leaded/ lead-free). So best to always use
SAC305 and the higher temperatures belong to this.
Due to lead-free technology some rules have to be
respected by the workshop during a repair:
xUse only lead-free solder alloy Philips SAC305 with
order code 0622 149 00106. If lead-free solder-paste is
required, please contact the manufacturer of your
solder-equipment. In general use of solder-paste within
workshops should be avoided because paste is not easy
to store and to handle.
xUse only adequate solder tools applicable for lead-free
solder alloy. The solder tool must be able
oTo reach at least a solder-temperature of 400°C,
oTo stabilize the adjusted temperature at the
solder-tip
oTo exchange solder-tips for different applications.
xAdjust your solder tool so that a temperature around
360°C – 380°C is reached and stabilized at the solder
joint. Heating-time of the solder-joint should not exceed
~ 4 sec. Avoid temperatures above 400°C otherwise
wear-out of tips will rise drastically and flux-fluid will be
destroyed. To avoid wear-out of tips switch off un-used
equipment, or reduce heat.
xMix of lead-free solder alloy / parts with leaded solder
alloy / parts is possible but PHILIPS recommends
strongly to avoid mixed
solder alloy types (leaded and lead-free). If one cannot
avoid, clean carefully the
solder-joint from old solder alloy and re-solder with new
solder alloy (SAC305).
xUse only original spare-parts listed in the
Service-Manuals. Not listed standard-material
(commodities) has to be purchased at external
companies.
xSpecial information for BGA-ICs:
- always use the 12nc-recognizable soldering
temperature profile of the specific BGA (for
de-soldering always use highest lead-free
temperature profile, in case of doubt)
- lead free BGA-ICs will be delivered in so-called
‘dry-packaging’ (sealed pack including a silica gel
pack) to protect the IC against moisture. After
opening, dependent of MSL-level seen on
indicator-label in the bag, the BGA-IC possibly
still has to be baked dry. This will be
communicated via AYS-website.
Do not re-use BGAs at all.
xFor sets produced before 1.1.2005, containing
leaded soldering-tin and components, all needed
spare-parts will be available till the end of the
service-period. For repair of such sets nothing
changes.
xOn our website:
www.atyourservice.ce.Philips.com
You find more information to:
BGA-de-/soldering (+ baking instructions)
Heating-profiles of BGAs and other ICs used in
Philips-sets
You will find this and more technical information
within the “magazine”, chapter “workshop news”.
For additional questions please contact your local
repair-helpdesk.
Notes
1-7

Before you connect this Blu-ray disc/ DVD player, read and understand all accompanying instructions.
2-1

Register your product and get support at
www.philips.com/welcome
COAXIAL
C
OA
X
IAL
A
A
( )
HDMI
1
2-2

2
HDMI
1 HDMI HDMI {VIDEO {COAXIAL {AUDIO LINE OUT
COAXIAL
C
OA
XIA
AL
A
A
2 COAXIAL {HDMI {VIDEO COAXIAL {AUDIO LINE OUT
2-3

4
3
5
SOURCE
1
2
TV
2-4

6
USB
DVD/VCD/CD
BD/BD 3D
DivX Plus HD/MKV
MP3 / JPEG
2
3
4
1
1
2
3
2-5

2 Use your Blu-
ray disc/ DVD
player
Congratulations on your purchase, and
ZHOFRPHWR3KLOLSV7RIXOO\EHQHÀWIURP
the support that Philips offers (e.g. product
software upgrade), register your product at
www.philips.com/welcome.
Basic play control
2-6

During play, press the following buttons to
control.
Button Action
Turn on the player, or switch
to standby.
Access the home menu.
/ Stop play.
Press and hold (more than 4
seconds) to open or close the
disc compartment.
Pause play.
Press repeatedly to slow
forward frame by frame.
Start or resume play.
/ Skip to the previous or next
WUDFNFKDSWHURUÀOH
/ Fast backward or forward.
Press repeatedly to change the
search speed.
Press once, and then press
to slow forward.
AUDIO Select an audio language or
channel.
SUBTITLE Select a subtitle language.
DISC MENU
/POP-UP
MENU
Access or exit the disc menu.
TOP MENU Access the main menu of a
video disc.
Color
buttons
Select tasks or options for
Blu-ray discs.
Navigate the menus.
Press to rotate a picture
clockwise or counter-clockwise
during slideshow.
OK &RQÀUPDVHOHFWLRQRUHQWU\
Return to a previous display
menu.
Access more options during
play.
Alphanumeric
buttons
Select an item to play.
Enter values.
Enter letters via SMS style
entry.
Video, audio and picture
options
More options are available for video or picture
play from a disc or USB storage device.
Video options
Access more options during video play.
 [Audio language]: Select an audio language.
 [Subtitle Language]: Select a subtitle
language.
 [Subtitle shift]: Change the subtitle
position on the screen. Press to
change the subtitle position.
 [Info]: Display play information.
 [Character set]: Select a character set that
supports the DivX video subtitle (only for
DivX videos).
 [Time search]6NLSWRDVSHFLÀFWLPH
via the numeric buttons on the remote
control.
 [2nd audio language]: Select the second
audio language (only for Blu-ray discs that
support BonusView).
 [2nd Subtitle Language]: Select the second
subtitle language (only for Blu-ray discs that
support BonusView).
 [Titles]: Select a title.
 [Chapters]: Select a chapter.
 [Angle list]: Select a camera angle.
 [Menus]: Display a disc menu.
 [PIP selection]: Display a picture-in-picture
window (only for Blu-ray discs that support
BonusView).
1
2
3
2-7

 [Zoom]: Zoom into a video picture. Press
to select a zoom factor.
 [Repeat]: Repeat a chapter or title.
 [Repeat A-B]: Mark two points within a
chapter for repeat play, or turn off repeat
mode.
 [Picture settings]6HOHFWDSUHGHÀQHG
color setting.
Note
Available video options depend on the video source.
Picture options
Access more options during slideshow.
 [Rotate +90]: Rotate a picture 90 degrees
clockwise.
 [Rotate -90]: Rotate a picture 90 degrees
counter-clockwise.
 [Zoom]: Zoom into a picture. Press to
select a zoom factor.
 [Info]: Display picture information.
 [Duration per slide]: Set a display interval
for a slideshow.
 [Slide Animation]: Select a transition effect
for a slideshow.
 [Picture Settings]6HOHFWDSUHGHÀQHG
color setting.
 [Repeat]: Repeat a selected folder.
1
2
3
Audio options
Press repeatedly to cycle through the
following options.
 Repeat the current track.
 Repeat all the tracks on the disc or folder.
 Play audio tracks in a random loop.
 Turn off a repeat mode.
DivX videos
You can play DivX videos from a disc or a USB
storage device.
VOD code for DivX
 Before you purchase DivX videos and play
them on this player, register this player on
www.divx.com using the DivX VOD code.
 Display the DivXVOD code: press , and
select [Setup] > [Advanced] > [DivX®
VOD Code].
DivX subtitles
 Press SUBTITLE to select a language.
 If the subtitle is not displayed correctly,
change the character set that supports the
DivX subtitle. Select a character set: press
, and select [Character Set].
2-8

Character
set
Languages
[Standard] English, Albanian, Danish,
Dutch, Finnish, French, Gaelic,
German, Italian, Kurdish (Latin),
Norwegian, Portuguese, Spanish,
Swedish, and Turkish
[Central
Europe]
Albanian, Croat, Czech, Dutch,
English, German, Hungarian, Irish,
Polish, Romanian, Slovak, Slovene,
and Serbian
[Cyrillic] Bulgarian, Belorussian, English,
Macedonian, Moldavian, Russian,
Serbian, and Ukrainian
[Greek] Greek
[Baltic] Northern Europe
Note
7RSOD\'LY;'50SURWHFWHGÀOHVIURPD86%VWRUDJH
device, connect this player to aTV through HDMI.
7RXVHWKHVXEWLWOHVPDNHVXUHWKDWWKHVXEWLWOHÀOH
KDVWKHVDPHQDPHDVWKH'LY;YLGHRÀOHQDPH)RU
H[DPSOHLIWKH'LY;YLGHRÀOHLVQDPHG´PRYLHDYL
VDYHWKHVXEWLWOHÀOHDV´PRYLHVUWµRU´PRYLHVXEµ
7KLVSOD\HUFDQSOD\VXEWLWOHÀOHVLQWKHIROORZLQJ
formats: .srt, .sub, .txt, .ssa, and .smi.
Play a musical slideshow
Play music and pictures simultaneously to create
a musical slideshow.
1From a disc or connected USB storage
GHYLFHSOD\DPXVLFÀOH
2Press , and go to the picture folder.
3Select a picture from the same disc or
USB, and press OK to start slideshow.
4Press to stop slideshow.
5Press again to stop music play.
BonusView on Blu-ray
View special content (such as commentaries) in
a small screen window.
This feature is only applicable to Blu-ray discs
compatible with BonusView (also known as
picture in picture).
1During play, press .
»The options menu is displayed.
2Select [PIP Selection] > [PIP], and press
OK.
»PIP options [1]/[2] depend on the
video contents.
»The secondary video window is
displayed.
3Select [2nd Audio Language] or [2nd
Subtitle Language], and press OK.
BD-Live on Blu-ray
Access exclusive online services, such as movie
trailers, games, ringtones and other bonus
contents.
This feature is only applicable to Blu-ray discs
that are BD-Live enabled.
1Prepare the Internet connection and set
XSDQHWZRUNVHH6HWXSDQHWZRUN
2Connect a USB storage device to this
player.
 A USB storage device is used to store
the downloaded BD-Live content.
 To delete the BD-Live previously
downloaded on the USB storage
device for memory release, press
and select [Setup] > [Advanced] >
[Clear memory].
3Play a disc that is BD-Live enabled.
4On the disc menu, select the BD-Live icon,
and press OK.
»BD-Live starts to load.The loading
time depends on the disc and the
Internet connection.
2-9

5On the BD-Live interface, select an item
to access.
Note
BD-Live services vary from discs and countries.
When you use BD-Live, data on the disc and this player
are accessed by the content provider
Use a USB storage device with at least 1GB of free
space to store the download.
Play a Blu-ray 3D video
What you need
 A 3D compliant TV
 This player is connected to the TV through
HDMI
 3D glasses compatible with theTV
 3D Blu-ray disc
1Make sure that 3D output is turned on:
press , and select [Setup] > [Video]
>[Watch 3D video] > [Auto].
2Play a Blu-ray 3D video.
3Put on the 3D glasses for 3D effects.
 To play 3D video in 2D, turn off Blu-ray
3D output (press , and select [Setup]
>[Video] > [Watch 3D video] >
[Off]).
Set up a network
Connect this player to the Internet to access
the services:
 BD-Live: access online bonus features
(applicable to Blu-ray discs that are BD-
Live enabled)
 Update software: update the software of
this player via the Internet.
 Browse PC (DLNA): play photos, music,
DQGYLGHRÀOHVVWUHDPHGIURP\RXU
computer.
Note
For wireless connection, you need to use an optional
Philips Wi-Fi USB adapter (named WUB1110).
Te Wi-Fi USB Adapter (WUB1110) is not included.To
purchase this adapter, visit shop.philips.com. If the Philips
online shop is not available in your country, please
contact Philips customer service. For contact details, go
to www.philips.com/support.
1Connect this player to the Internet through
wired (Ethernet) or wireless connection.
 For wired connection, connect a
network cable (not supplied) to the
LAN port on the back panel of this
player.
 For Wi-Fi, connect a Philips Wi-Fi USB
adapter (named WUB1110) to the
(USB) connector on the front
panel of this player.
PC (DLNA)
2-10

2Perform the network installation.
1) Press .
2) Select [Setup], and press OK.
3) Select [Network] > [Network
installation], and press OK.
4) Follow the instructions on the TV screen to
complete the installation. If necessary, use the
alphanumeric buttons on the remote control
to enter a password.
Caution
Before you connect to a network, familiarize yourself
with the network router, and networking principles. If
necessary, read documentation accompanying network
components. Philips is not responsible for lost, damaged
or corrupt data.
Smartphone control
Use a smartphone to browse, control and play
PHGLDÀOHVIURPWKLVSOD\HU
What you need
 An iPhone (iOS 3.1.3 and above) or
Android based device (Android 2.1 and
above)
 On your smartphone, download Philips
MyRemote application
PC (DLNA)
 For iPhone, search for the application
in App Store
 For Android based device, search for
the application in Android Market
Before you start
 Connect this player to a home network
VHH6HWXSDQHWZRUN
 Connect your smartphone to the same
home network (see the user manual of the
smartphone for details).
 Turn on this player
Control your player
Use a smartphone to browse, control and play
PHGLDÀOHVIURPWKLVSOD\HU
1Insert a data disc or USB storage device
into this player.
2On your smartphone, tap the MyRemote
icon from the home screen.
»The name of this player is displayed on
the smartphone.
3Select this player from the smartphone
screen.
»The smartphone used as a virtual
remote control is enabled.
4On the smartphone, tap the Media
(Media) tab, and then select the disc or
USB source.
»The folders in the data disc or USB
storage device are displayed.
52SHQDIROGHUDQGVHOHFWDÀOHWRSOD\
 To access the remote control, return
to the previous smartphone screen,
and then tap the Remote (Remote)
tab. Only the relevant control buttons
are enabled.
6Tap the control buttons on the
smartphone to control play.
 To access more control buttons, swipe
the screen to the left or right.
 To exit the application, press the home
button on the smartphone.
2-11

Browse PC through DLNA
Through this player, you can stream and play
video, music and photo from a computer on
your TV.
Before you start
 On your PC, install a DLNA-compliant
media server application (such as Windows
Media Player 11 or higher)
 2Q\RXU3&HQDEOHPHGLDVKDULQJDQGÀOH
VKDULQJVHHWKH+HOSGRFXPHQWLQWKH
media server application)
1Connect this player and your PC in the
VDPHKRPHQHWZRUNVHH6HWXSD
QHWZRUN
 For better video quality, use wired
network connection whenever
possible.
2Press .
»The home menu is displayed on the
TV screen.
3Select [browse PC], and press OK.
»A content browser is displayed.
46HOHFWDÀOHDQGSUHVVOK to play.
 Use the remote control to control play.
Use Philips EasyLink
This player supports Philips EasyLink which
uses the HDMI CEC (Consumer Electronics
Control) protocol.You can use a single remote
control to control EasyLink compliant devices
that are connected through HDMI. Philips does
not guarantee 100% interoperability with all
HDMI CEC devices.
1Connect the HDMI CEC compliant devices
through HDMI, and turn on the HDMI
CEC operations on the TV and other
connected devices (see the user manual of
the TV or other devices for details).
2Press .
3Select [Setup]>[EasyLink].
4Select [On] under the options: [EasyLink],
[One Touch Play] and [One Touch
Standby].
»EasyLink function is turned on.
One Touch Play
When a video disc is in the disc compartment,
press to wake up the TV from standby, and
then play a disc.
One Touch Standby
When a connected device (for example TV)
is put to standby with its own remote control,
this player is put to standby automatically.
2-12

3 Change settings
This section helps you to change the settings of
this player.
Note
You cannot change a menu option that is grayed out.
To return to the previous menu, press . To exit the
menu, press .
1Press .
2Select [Setup] > [Video] to access the
video setup options.
 [TV display]: Select a picture display
IRUPDWWRÀWWKH79VFUHHQ
 [HDMI video]: Select an HDMI video
resolution.
 [HDMI Deep Color]: Display colors
with more shades and hues when the
video content is recorded in Deep
Color and the TV supports this feature.
 [Picture settings]6HOHFWDSUHGHÀQHG
color setting.
1
2
3
Watch 3D video
 [Watch 3D video]: Set to 3D or 2D
output when playing a Blu-ray 3D disc.
The player must be connected to a 3D
TV through HDMI.
Note
If you change a setting, make sure that the TV supports
the new setting.
For settings related to HDMI, the TV must be
connected through HDMI.
For the composite connection (via the VIDEO
connector), select a video resolution of 480i/576i
or 480p/576p under [HDMI video] to enable video
output.
Sound
1Press .
2Select [Setup] > [Audio] to access the
audio setup options.
 [Night Mode]: Select quiet or full
dynamic sound. Night mode decreases
the volume of loud sound and
increases the volume of soft sound
(such as speech).
 [HDMI Audio]: Set an HDMI audio
format when this player is connected
through HDMI.
 [Digital Audio]: Select an audio format
for the sound output when this
player is connected through a digital
connector (coaxial).
 [PCM Downsampling]: Set the
sampling rate for PCM audio output
when this player is connected through
a digital connector (coaxial).
Note
For settings related to HDMI, the TV must be
connected through HDMI.
Night mode is only available for Dolby encoded DVD
and Blu-ray discs.
2-13
