Philips BDP3210B User manual

www.philips.com/support
User manual
Register your product and get support at
Blu-raydisc/
DVD player
BDP3210B
BDP3215B
Blu-raydisc/
DVD player

1
Safety and
important notice
Read and understand all instructions
before you use this Blu-ray disc/ DVD
player. If damage is caused by failure
to follow the instructions, the warranty
does not apply.
Safety
Risk of electric shock or re!
• Before you make or change any
connections, make sure that all
devices are disconnected from the
power outlet.
• Never expose the product and
accessories to rain or water. Never
place liquid containers, such as
vases, near the product. If liquids
are spilt on or into the product,
disconnect it from the power
outlet immediately. Contact Philips
Consumer Care to have the product
checked before use.
• Never place the product and
accessories near naked ames or
other heat sources, including direct
sunlight.
• Never insert objects into the
ventilation slots or other openings
on the product.
• Where the mains plug or an
appliance coupler is used as the
disconnect device, the disconnect
device shall remain readily
operable.
• Batteries (battery pack or batteries
installed) shall not be exposed to
excessive heat such as sunshine,
re or the like.
• Disconnect the product from the
power outlet before lightning
storms.
• When you disconnect the power cord,
always pull the plug, never the cable.
Risk of short circuit or re!
• For identication and supply ratings,
see the type plate at the back or
bottom of the product.
• Before you connect the product to
the power outlet, ensure that the
power voltage matches the value
printed on the back or bottom of
the product. Never connect the
product to the power outlet if the
voltage is dierent.
Risk of injury or damage to the product!
• For wall mounting, this product
must be securely attached to
the wall in accordance with the
installation instructions. Use only
the supplied wall mount bracket (if
available). Improper wall mounting
may result in accident, injury or
damage. If you have any query,
contact Consumer Care in your
country.
• Visible and invisible laser radiation
when open. Avoid exposure to beam.
• Do not touch the disc optical lens
inside the disc compartment.
• Never place the product or any
objects on power cords or on other
electrical equipment.
• If the product is transported in
temperatures below 5°C, unpack
the product and wait until its
temperature matches room
temperature before connecting it to
the power outlet.
Risk of overheating!
• Never install this product in a
conned space. Always leave a
space of at least four inches around
the product for ventilation. Make
sure that curtains or other objects
never cover the ventilation slots on
the product.

2
Risk of contamination!
• Do not mix batteries (old and new
or carbon and alkaline, etc.).
• Danger of explosion if batteries are
incorrectly replaced. Replace only
with the same or equivalent type.
• Remove batteries if they are
exhausted or if the remote control is
not to be used for a long time.
• Batteries contain chemical
substances, they should be
disposed of properly.
Risk of swallowing batteries!
• The product/remote control may
contain a coin/button type battery,
which can be swallowed. Keep the
battery out of reach of children at
all times! If swallowed, the battery
can cause serious injury or death.
Severe internal burns can occur
within two hours of ingestion.
• If you suspect that a battery
has been swallowed or placed
inside any part of the body, seek
immediate medical attention.
• When you change the batteries,
always keep all new and
used batteries out of reach of
children. Ensure that the battery
compartment is completely secure
after you replace the battery.
• If the battery compartment cannot
be completely secured, discontinue
use of the product. Keep out of
reach of children and contact the
manufacturer.
This is CLASS II apparatus with double
insulation, and no protective earth
provided.
Use only the power supplies listed in
the user manual.
CLASS 1
LASER PRODUCT
Care for your product
• Do not insert any objects other than
discs into the disc compartment.
• Do not insert warped or cracked
discs into the disc compartment.
• Remove discs from the disc
compartment if you are not using
the product for an extended period
of time.
• Only use microber cloth to clean
the product.
Care of the environment
Disposal of your old product and
battery
Your product is designed and
manufactured with high quality
materials and components, which can
be recycled and reused.
This symbol on a product means that
the product is covered by European
Directive 2012/19/EU.

3
This symbol means that the product
contains batteries covered by European
Directive 2013/56/EU which cannot be
disposed of with normal household
waste.
Inform yourself about the local separate
collection system for electrical and
electronic products and batteries.
Follow local rules and never dispose of
the product and batteries with normal
household waste. Correct disposal
of old products and batteries helps
prevent negative consequences for the
environment and human health.
Removing the disposable batteries
To remove the disposable batteries, see
battery installation section.
Compliance
This product complies with the radio
interference requirements of the
European Community.
Copyright
This item incorporates copy protection
technology that is protected by U.S.
patents and other intellectual property
rights of Rovi Corporation. Reverse
engineering and disassembly are
prohibited.
This product incorporates proprietary
technology under license from Verance
Corporation and is protected by U.S.
Patent 7,369,677 and other U.S. and
worldwide patents issued and pending
as well as copyright and trade secret
protection for certain aspects of such
technology. Cinavia is a trademark
of Verance Corporation. Copyright
2004-2013 Verance Corporation. All
rights reserved by Verance. Reverse
engineering or disassembly is
prohibited.
Cinavia notice
This product uses Cinavia technology
to limit the use of unauthorized copies
of some commercially-produced lm
and videos and their soundtracks. When
a prohibited use of an unauthorized
copy is detected, a message will be
displayed and playback or copying will
be interrupted.
More information about Cinavia
technology is provided at the Cinavia
Online Consumer Information Center
at http://www.cinavia.com. To request
additional information about Cinavia
by mail, send a postcard with your
mailing address to: Cinavia Consumer
Information Center, P.O. Box 86851, San
Diego, CA, 92138, USA.
Open source software
Philips Electronics Hong Kong hereby
oers to deliver, upon request, a copy
of the complete corresponding source
code for the copyrighted open source
software packages used in this product
for which such delivery is requested by
the respective licenses. This oer is valid
up to three years after product purchase
to anyone in receipt of this information.
To obtain source code, please send
your request in English with product
type to open.sour[email protected]. If
you prefer not to use email or if you

4
do not receive conrmation receipt
within 2 weeks after mailing to this
email address, please write in English to
“Open Source Team, Philips Intellectual
Property & Standards, P.O. Box 220,
5600 AE Eindhoven, The Netherlands”.
If you do not receive timely conrmation
of your letter, please email to the email
address above. The texts of the licenses
and acknowledgements for open
source software used in this product are
included on a separate leaet.

5
User Manual
Quick start guide
x 2
1
HDMI OUT

6
3
2
4
1
2
3
SOURCE
12
TV

7
5
USB
1
2
3
DVD/VCD/CD
DivX Plus HD/MK
V
BD
MP3 / JPEG
1
2
3

8
31 mm
2
2
2x
2x
X
4~4.5 mm
8-9 mm 3.5-4 mm
>25 mm
1

1EN
Contents
1 Use your Blu-ray disc/ DVD
player 2
Basic play control 2
“Smile” light indication 3
Video, audio and picture options 3
DivX videos 4
Play a musical slideshow 5
Auto play 5
BonusView on Blu-ray 6
Use Philips EasyLink 6
2 Change settings 7
Picture 7
Sound 7
Preference (languages, parental
control...) 7
Advanced options (clear memory...) 8
3 Update software 9
Update software via USB 9
4 Optional placement 10
Vertical placement 10
Wall mount 10
5 Product specications 11
6 Troubleshooting 14

2EN
1Use your Blu-
ray disc/ DVD
player
Congratulations on your purchase, and
welcome to Philips! To fully benet
from the support that Philips oers (e.g.
product software upgrade), register your
product at www.philips.com/welcome.
Basic play control
During play, press the following buttons
to control.
Button Action
Turn on the player, or
switch to standby.
Access the home menu.

3EN
Button Action
DISC MENU Access or exit the disc
menu or Pop-up menu.
TOP MENU Access the main menu
of a video disc.
Navigate the menus.
Press to rotate a
picture clockwise or
counter-clockwise
during slideshow.
OK Conrm a selection or
entry.
Return to a previous
display menu.
Access more options
during play.
Color buttons Select tasks or options
for Blu-ray discs.
Eject a disc from the
disc compartment.
Start or resume play.
Pause play.
Press repeatedly to slow
forward frame by frame.
Stop play.
/ Skip to the previous or
next track, chapter or
le.
/ Fast backward or
forward.
Press repeatedly to
change the search
speed.
Press once, and
then press to slow
forward.
AUDIO Select an audio
language or channel.
SUBTITLE Select a subtitle
language.
Alphanumeric
buttons
Select an item to play.
Enter values.
Enter letters via SMS
style entry.
“Smile” light indication
This product is designed with an
animated light strip to form an
expression of this product’s current
status.
• Light o: standby.
• Light on: power on and ready.
• Light dim: playback in progress.
• 2 lights ashing: Error or unable to
read disc.
• Other light animation: Like starting
up, loading disc, pause, stop, skip
to next/previous, forward/backward
play, and ejecting disc.
Video, audio and picture
options
More options are available for video or
picture play from a disc or USB storage
device.
Video options
Access more options during video play.
• [Audio language]: Select an audio
language.
• [Subtitle language]: Select a subtitle
language.
• [Subtitle shift]: Change the subtitle
position on the screen. Press to
change the subtitle position.
• [Info]: Display play information.
2
3
1

4EN
• [Character set]: Select a character
set that supports the DivX video
subtitle (only for DivX videos).
• [Time search]: Skip to a specic
time via the numeric buttons on the
remote control.
• [2nd audio language]: Select the
second audio language (only
for Blu-ray discs that support
BonusView).
• [2nd subtitle language]: Select the
second subtitle language (only
for Blu-ray discs that support
BonusView).
• [Titles]: Select a title.
• [Chapters]: Select a chapter.
• [Angle list]: Select a camera angle.
• [Menus]: Display a disc menu.
• [PIP selection]: Display a picture-
in-picture window (only for Blu-ray
discs that support BonusView).
• [Zoom]: Zoom into a video picture.
Press to select a zoom factor.
• [Repeat]: Repeat a chapter or title.
• [Repeat A-B]: Mark two points
within a chapter for repeat play, or
turn o repeat mode.
• [Picture settings]: Select a
predened color setting.
Note
• Available video options depend on the
video source.
Picture options
2
3
1
Access more options during slideshow.
• [Rotate +90]: Rotate a picture
90 degrees clockwise.
• [Rotate -90]: Rotate a picture
90 degrees counter-clockwise.
• [Zoom]: Zoom into a picture.
Press to select a zoom factor.
• [Info]: Display picture information.
• [Duration per slide]: Set a display
interval for a slideshow.
• [Slide animation]: Select a transition
eect for a slideshow.
• [Picture settings]: Select a
predened color setting.
• [Repeat]: Repeat a selected folder.
Audio options
Press repeatedly to cycle through the
following options.
• Repeat the current track.
• Repeat all the tracks on the disc or
folder.
• Play audio tracks in a random loop.
• Turn o a repeat mode.
DivX videos
You can play DivX videos from a disc or
a USB storage device.
VOD code for DivX
• Before you purchase DivX videos
and play them on this player,
register this player on www.divx.com
using the DivX VOD code.

5EN
• Display the DivX VOD code: press ,
and select [Setup] > [Advanced] >
[DivX® VOD Code].
DivX subtitles
• Press SUBTITLE to select a
language.
• If the subtitle is not displayed
correctly, change the character set
that supports the DivX subtitle.
Select a character set: press , and
select [Character set].
Character
set
Languages
[Standard] English, Albanian,
Danish, Dutch, Finnish,
French, Gaelic, German,
Italian, Kurdish (Latin),
Norwegian, Portuguese,
Spanish, Swedish, and
Turkish
[Central
Europe]
Albanian, Croat, Czech,
Dutch, English, German,
Hungarian, Irish, Polish,
Romanian, Slovak,
Slovene, and Serbian
[Cyrillic] Bulgarian, Belorussian,
English, Macedonian,
Moldavian, Russian,
Serbian, and Ukrainian
[Greek] Greek
[Baltic] Estonian, Latvian and
Lithuanian
[Chinese] Simplied Chinese
[Chinese-
Traditional]
Traditional Chinese
[Korean] English and Korean
Note
• To use the subtitles, make sure that the
subtitle le has the same name as the DivX
video le name. For example, if the DivX
video le is named “movie.avi", save the
subtitle le as “movie.srt”, or “movie.sub”.
• This player can play subtitle les in the
following formats: .srt, .sub, .txt, .ssa, and
.smi.
Play a musical slideshow
Play music and pictures simultaneously
to create a musical slideshow.
1 From a disc or connected USB
storage device, play a music le.
2 Press , and go to the picture
folder.
3 Select a picture from the same
disc or USB, and press OK to start
slideshow.
4 Press to stop slideshow.
5 Press again to stop music play.
Auto play
This player can automatically play a disc
or a video le.
Auto play disc
When this player is switched on, the
disc automatically plays.
1 Press (Home).
2 Select [Setup], and then press OK.
3 Select [Preference] > [Auto play
disc]> [On].
• The feature is turned on.
• To turn o the feature,
select [O]. The disc will not
automatically play.

6EN
Auto play video sequentially
If two or more video les are available
in the same folder from a USB storage
device, the next video le automatically
plays after the end of a video.
1 Press (Home).
2 Select [Setup], and then press OK.
3 Select [Preference] > [Auto play
after video]> [On].
• The feature is turned on.
• To turn o the feature, select
[O]. The next video le will not
automatically play after the end
of a video in the same folder.
BonusView on Blu-ray
View special content (such as
commentaries) in a small screen
window.
This feature is only applicable to Blu-ray
discs compatible with BonusView (also
known as picture in picture).
1 During play, press .
» The options menu is displayed.
2 Select [PIP selection] > [PIP], and
press OK.
» PIP options [1]/[2] depend on
the video contents.
» The secondary video window is
displayed.
3 Select [2nd audio language] or [2nd
subtitle language], and press OK.
Use Philips EasyLink
This player supports Philips EasyLink
which uses the HDMI CEC (Consumer
Electronics Control) protocol. You can
use a single remote control to control
EasyLink compliant devices that are
connected through HDMI. Philips does
not guarantee 100% interoperability
with all HDMI CEC devices.
1 Connect the HDMI CEC compliant
devices through HDMI, and turn on
the HDMI CEC operations on the TV
and other connected devices (see
the user manual of the TV or other
devices for details).
2 Press .
3 Select [Setup]> [EasyLink].
4 Select [On] under the options:
[EasyLink], [One Touch Play] and
[One Touch Standby].
» EasyLink function is turned on.
One Touch Play
When a video disc is in the disc
compartment, press to wake up the
TV from standby, and then play a disc.
One Touch Standby
When a connected device (for
example TV) is put to standby with its
own remote control, this player is put
to standby automatically.

7EN
2 Change
settings
This section helps you change the
settings of this player.
Note
• You cannot change a menu option that is
grayed out.
• To return to the previous menu, press .
To exit the menu, press .
1 Press .
2 Select [Setup] > [Video] to access
the video setup options.
• [TV display]: Select a picture display
format to t the TV screen.
• [HDMI video]: Select an HDMI video
resolution.
• [HDMI Deep Color]: Display colors
with more shades and hues when
the video content is recorded in
Deep Color and the TV supports this
feature.
• [Picture settings]: Select a
predened color setting.
1
3
2
3
TV display
HDMI video
16:9 Widescreen
Picture settings
Note
• If you change a setting, make sure that the
TV supports the new setting.
Sound
1 Press .
2 Select [Setup] > [Audio] to access
the audio setup options.
• [Night mode]: Select quiet or
full dynamic sound. Night mode
decreases the volume of loud
sound and increases the volume of
soft sound (such as speech).
• [HDMI audio]: Set an HDMI
audio format when this player is
connected through HDMI.
Note
• Night mode is only available for Dolby®
TrueHD / Dolby® Digital Plus encoded DVD
and Blu-ray discs.
Preference (languages,
parental control...)
1 Press .
2 Select [Setup] > [Preference]
to access the preference setup
options.
• [Menu language]: Select an
onscreen display menu language.
• [Audio]: Select an audio language
for video.
• [Subtitle]: Select a subtitle language
for video.
• [Disc menu]: Select a menu
language for a video disc.

8EN
• [Parental control]: Restrict access
to discs that are encoded with
ratings. Input "0000" to access the
restriction options. To play all discs
irrespective of the rating, select
level "8".
• [Screen saver]: Enable or disable
screen saver mode. If enabled,
the screen enters idle mode
after 10 minutes of inactivity (for
example, in pause or stop mode).
• [Auto subtitle shift]: Enable or
disable subtitle shift. If enabled,
the subtitle position is changed
automatically to t the TV screen
(this feature works with some
Philips TVs only).
• [Change password]: Set or change
a password to play a restricted disc.
Input "0000" if you do not have a
password or if you have forgotten
your password.
• [Auto standby]: Enable or disable
auto standby. If enabled, the player
switches to standby after 18 minutes
of inactivity (for example, in pause
or stop mode).
• [Fast wake up]: Enable or disable
the player to wake up faster from
standby. If fast wakeup is turned
o, less power is consumed during
standby.
• [VCD PBC]: Display or skip the
content menu for VCD and SVCD.
• [Auto play disc]: Enable or disable
the automatic disc playback after
power on.
• [Auto play after video]: Enable
or disable sequential playback of
videos from USB.
Note
• If your preferred language is not available
for disc language, audio or subtitle, you can
select [Other] from the menu options and
input 4-digit language code which can be
found at the back of this user manual.
• If you select a language which is not
available on a disc, this player uses the
default language of the disc.
Advanced options (clear
memory...)
1 Press .
2 Select [Setup] > [Advanced] to
access the advanced setup options.
• [Downmix mode]: Control
2-channel stereo audio output.
• [Software update]: Update software
through a USB storage device.
• [Clear memory]: Remove some Blu-
ray disc data (such as BonusView)
that are automatically copied on
the connected USB device. A folder
named “BUDA” is automatically
created to store some necessary
data from Blu-ray disc.
• [DivX® VOD Code]: Display the
DivX® registration code or the
deregistration code for this player.
• [Version information]: Display the
software version of this player.
• [Restore default settings]: Reset
this player to the default settings
made at the factory, except for
password and parental control level.
Note
• You cannot restrict Internet access on
commercial Blu-ray discs.
• Before you purchase DivX videos and play
them on this player, register this player on
www.divx.com with the DivX VOD code.

9EN
3 Update
software
Before you update the software of
this player, check the current software
version:
• Press , and then select [Setup] >
[Advanced] > [Version information],
and press OK.
Update software via USB
1 Check the latest software version on
www.philips.com/support.
• Search for your model and click
on "Software and drivers".
2 Download the software into a USB
storage device.
a Unzip the download, and make
sure that the unzipped folder is
named "UPG".
b Put the "UPG" folder in the root
directory.
3 Connect the USB storage device
to the (USB) connector on this
player.
4 Press , and select [Setup].
5 Select [Advanced] > [Software
update]> [USB].
» If an upgrade media is detected,
you are prompted to start the
update.
6 Follow the instructions on the TV
screen to update the software.
» When the update is complete,
this player automatically turns
o and on again.
Caution
• Do not turn o the power or remove the
USB storage device when the software
update is in progress because you might
damage this player.

10 EN
4 Optional
placement
The design of this product allows you to
place this product in the following ways:
• Horizontal placement on the
tabletop.
• Vertical placement on the tabletop.
• Wall mount
You may simply place this product
horizontally on the tabletop.
Vertical placement
You may place this product vertically
on the tabletop. See the section of the
quick start guide in this user manual for
placement illustration.
1) Assemble the supplied brackets.
2) Fix the assembled bracket to this
product.
Wall mount
Note
• Before wall mounting, make sure the wall
can support the weight of this product.
• For wall mounting, this product must be
securely attached to the wall in accordance
with the installation instructions. Improper
wall mounting may result in accident, injury
or damage. If you have any query, contact
Consumer Care in your country.
You may mount this product on the
wall. See the section of the quick start
guide in this user manual for placement
illustration.
1) Fix the supplied bracket to this
prodcut.
2) Drill two holes on the wall, then
secure the dowels and screws in the
holes.
3) Hang this product on the wall.
