Philips 24PW6302 User manual

WideScreenTelevision
24PW6302
24PW6322
NICAM
Product highlights
• Ultra Flat BLS picture tube
• Wide Screen Modes
• Smart Picture
• Smart Sound
• Contrast Plus and ColourTransient Improvement
• Acoustic Horns
• Incredible Surround
• EasyTune (ATS/ACI)
• Daily on/off clock

WideScreenTelevision
24PW6302
24PW6322
NICAM
Technical specifications
Chassis
• Type : Mid 1.2
• Screen diameter : 61 cm FSQ
• Visible diagonal : 57 cm
• Picture tube : 16x9 U-BLS
•S-Video display
• ColourTransient Improvement (CTI)
• Tint,adjustable white colour
• Blackstretch
• Smart control key on remote control for four
independent picture settings
• Settings via menu of :
- Brightness,Colour,Contrast,Sharpness,Tint,
Noise reduction
• Game and Digital optimal settings
Sound
•Sound system : 2 speakers stereo
• Loudspeakers : 2x5" acoustic horn
• Output (RMS) : 16W
• Frequency respons : 60Hz-20Hz
+1/-3dB (amplifier)
• Incredible sourround:switchable by menu
• Bi-langual switch on remote control
• Smart control key on remote control for four
independent sound settings
• Headphone with independent volume control
• Settings via menu of :
-Treble,Bass,Balance, Incredible surround,
Headphone volume
Operation
•Easy menu-driven installation and operation
• Multi-language selection for menu
• Automatic Channel Installation (ACI)
•100 preselections
• Programme name for all programmes
•Easy Logic remote control withVCR functions
• Personal Preference setting per programme
• ATS (AutomaticTuning System)
• Learning knob for direct access to menu
functions
•Direct access for picture,sound and feature menu
•Sleeptimer up to 180 minutes
• Daily on/off clock,to program automatic switch
on and off
• Smart Clock for automatic downloding of the
internal clock
• Electronic lock
• Program title display (transmitted by teletext)
• Message mode
Teletext
•Reception standards:WST/TOP/FLOF
•8 pages ofTeletext memory
• Teletext time with one button on the remote
control
• Favourite page
Reception
• Tuning system : 100 fold PLL
•Colour transmissionsystem off air:
/00,/11 PAL B/G
/01 PAL B/G/L/I
SECAM B/G/L/L'
D/K/K'
/58 PAL B/G/D/K
SECAM B/G/D/K/K'
•NTSC playback : 4,43 MHz
•Channel selections : VHF,UHF,
S-Channels,
Hyperband
• Frequency range : 47.25-855.25 MHz
• Aerial input : 75 Ohm (Coax)
Connections
• Side
• Stereo headphone out (3.5 mm jack)
•S-VHS in
•Audio L/R in (cinch)
• Video CVBS-in (cinch)
• Rear
• EXT1: RGB-in + CVBS-in/out
• EXT2: CVBS-in/out +Y/C in
• Audio out L/R constant level (cinch)
Remote control
•RC type: RC 7535
Miscellaneous
•Ambient temperature: +5/+55°C
• Mains : AC220-240V ±10%
• Power consumption : 90W
• Stand-by power cons.: 3W at 220V
• Weight incl.pack : 30.5kg
• Weight excl.pack : 26.5kg
• Dimensions:
- incl.pack (wxhxd) : 80.5x57.0x55.5cm
- excl.pack (wxhxd) : 66.3x41.3x44.1cm
•Cabinet Painting : Mid Grey 10763
Product highlights
• Ultra Flat BLS picture tube
The flat screen offers an improved viewing angle
and less disturbing reflections.
The BLS offers high contrast and reduced reflections,
for natural colours and improved daytime viewing
• Contrast Plus and ColourTransient
Improvement
For a picture with more contrast and nicer colours.
•Acoustic Horns
Which allows the sound to be projected to the front
of the cabinet.
• Incredible Surround
Which increases the stereo effect by better filling
the room.
• EasyTune
Easy way of channel installation thanks to ACI
(Automatic Channel Installation) by means of special
teletext transmission of local cable operator.
• Viewing modes
- Conventional 4:3
- Zoom 14:9
- Zoom 16:9
- Subtitle Zoom
- Super Zoom
-Wide screen
•Additional Easy of use 16:9 features
- Subtitle shift
- Continuous zoom
-WideScreen Signalling Bit
Supporting Features
•Ease of use
Easy logic Remote Control with cursor control forTV
andVCR functions.Smart control keys and
programmable keys available.
•Daily on/off clock
Easy to set wake up clock as well as programmable
switch off.
• Power consumption
- Low standby power: 3W at 220V.
• Easy Access
Side connectors mounted on a toblerone.
•Information Line
Which indicates the currently watched program title.
Release date : April ‘97
Predecessor(s) : 24PW6301
Date of issue : February‘97
Subject to modification without notice
12 3
4 5 6
7 8 9
0
MENU
P
h ei
u
c Ufg
qs
yÚ
B
o
pœ
π
®
Ò
†
‡
π
F
V
- +
- +
◊
0
¬
a
M
+
-
b
X
SMART CONTROLS
RC 7535
